Transporto priemonė: CBC-FAHRGESTELL 2-ACHSER; VIN numerio dalis: 634420
Grupė: 49 EXHAUST SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 6294910700 | MUFFLER |
| 008 | A 6344900510 | EXHAUST PIPE |
| 011 | A 6294910041 | BRACKET |
| 014 | A 0004910285 | RUBBER MOUNTING |
| 017 | A 0009958602 | CLAMP |
| 148MM | ||
| 020 | N 910112010001 | NUT |
| M10 | ||
| 050 | A 0009980246 | INSULATION |
| 050 | A 0009980846 | DASHPOT |
| 086 | N 913023010002 | NUT |
| M10 | ||
| 101 | A 0004907714 | CATALYST |
| 101 | A 0014904814 | CATALYST |
| NOX SENSOR | ||
| 102 | A 0061530328 | SENDER UNIT |
| TEMPERATURE SENSOR,EXHAUST | ||
| 103 | A 0005460522 | CLAMPING RING |
| 107 | A 6344900810 | EXHAUST PIPE |
| 107 | A 6344901210 | EXHAUST PIPE |
| 108 | A 6344920404 | REAR EXHAUST PIPE |
| 110 | A 6344900440 | BRACKET |
| 110 | A 6344900440 | BRACKET |
| 113 | A 6344900540 | BRACKET |
| 116 | A 6344921741 | BRACKET |
| 120 | A 6344921841 | BRACKET |
| 120 | A 6344921841 | BRACKET |
| Repalced by: A 6344923241 | ||
| 120 | A 6344923241 | BRACKET |
| 128 | A 6344921941 | BRACKET |
| 128 | A 6344922841 | BRACKET |
| 130 | A 0004920087 | BUFFER |
| 131 | A 0032371012 | BUFFER |
| 132 | A 0004910053 | SPACER TUBE |
| 133 | A 0069905640 | WASHER |
| 50X11X3MM | ||
| 134 | A 6219970090 | CLAMP |
| 137 | A 6554920140 | CLAMP |
| 138 | A 6294920040 | CLAMP |
| D=120/445LG | ||
| 140 | A 0059970690 | CLAMP |
| 143 | N 910105008026 | HEXAGON HEAD BOLT |
| M8X20MM | ||
| 146 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25MM | ||
| 147 | N 910105008010 | HEXAGON HEAD BOLT |
| M8X40MM | ||
| 149 | N 910105010040 | HEXAGON HEAD BOLT |
| M10X16MM | ||
| 150 | N 910105010016 | HEXAGON HEAD BOLT |
| M10X80MM | ||
| 152 | N 910105010009 | HEXAGON HEAD BOLT |
| M10X25MM | ||
| 155 | N 910105010001 | HEXAGON HEAD BOLT |
| M10X30 | ||
| 158 | N 910105010007 | HEXAGON HEAD BOLT |
| M10X35MM | ||
| 161 | N 910105010012 | HEXAGON HEAD BOLT |
| M10X65MM | ||
| 164 | N 913023008003 | NUT |
| M8 | ||
| 164 | N 913023008003 | NUT |
| M8 | ||
| 168 | A 0001420050 | BUSHING |
| 170 | A 0001400368 | WATER NOZZLE |
| REDUCING AGENT | ||
| 173 | A 6344900039 | PRESSURE LINE |
| 182 | A 6344911441 | BRACKET |
| 185 | A 6344911130 | PROTECTIVE PLATE |
| 188 | A 6344922641 | BRACKET |
| 188 | A 6344922641 | BRACKET |
| 188 | A 6344923641 | BRACKET |
| 191 | A 6344911541 | BRACKET |
| 194 | A 6344911230 | PROTECTIVE PLATE |
| FOR NOX SENSOR | ||
| 197 | N 916016006201 | CLAMP |
| 6/15 | ||
| Repalced by: N 000000003085 | ||
| 197 | N 000000003085 | CLAMP |
| 6/15 | ||
| Repalced by: N 000000007509 | ||
| 197 | N 000000007509 | CLAMP |
| 6/15 | ||
| 200 | N 916016012200 | CLAMP |
| 12/15 | ||
| Repalced by: N 000000000321 | ||
| 200 | N 000000000321 | CLAMP |
| 12/15 | ||
| Repalced by: N 000000007512 | ||
| 200 | N 000000007512 | CLAMP |
| 12/15 | ||
| 203 | N 910105008006 | HEXAGON HEAD BOLT |
| M8X60MM | ||
| 203 | N 910105006002 | HEXAGON HEAD BOLT |
| M6X12MM | ||
| 206 | N 910105010006 | HEXAGON HEAD BOLT |
| M10X20MM | ||
| 206 | N 910105006006 | HEXAGON HEAD BOLT |
| M6X20MM | ||
| 209 | A 6343107458 | CONSOLE |
| 216 | N 913023006002 | NUT |
| M6 | ||
| 218 | A 0029976890 | CABLE TIE |
| 221 | A 6344901240 | BRACKET |
| 224 | A 6344901340 | BRACKET |
| 227 | A 6344901034 | SUPPORT |
| 230 | A 6344900121 | EXHAUST PIPE |
| 233 | A 6344910083 | INSULATING MAT |
| FOR FLEXIBLE TUBE | ||
| 236 | A 0009881073 | WIRE |
| FASTENING, INSULATING MAT | ||
| 239 | A 6284920180 | FLANGE GASKET |
| 242 | A 0129900601 | SCREW |
| 245 | A 6344900541 | CLAMP |
| 248 | A 6344900114 | CATALYST |
| 251 | A 6294910215 | CONSOLE |
| 254 | A 0004920087 | BUFFER |
| 257 | A 0004910053 | SPACER TUBE |
| 260 | A 0069905640 | WASHER |
| 50X11X3MM | ||
| 263 | N 910105010016 | HEXAGON HEAD BOLT |
| M10X80MM | ||
| 266 | N 913023010002 | NUT |
| M10 | ||
| 269 | N 910105010006 | HEXAGON HEAD BOLT |
| M10X20MM | ||
| 272 | A 6344910741 | BRACKET |
| 275 | N 910105012020 | HEXAGON HEAD BOLT |
| M12X1,5X35MM | ||
| 278 | N 913023012002 | NUT |
| M12X1,5 | ||
| 281 | A 6294910115 | CONSOLE |
| 284 | A 6344910541 | BRACKET |
| 287 | N 910105010044 | HEXAGON HEAD BOLT |
| M10X90MM | ||
| 290 | N 910105010009 | HEXAGON HEAD BOLT |
| M10X25MM | ||
| 293 | A 6344900221 | EXHAUST PIPE |
| 296 | A 6344900641 | CLAMP |
| 300 | A 6344900030 | PROTECTIVE PLATE |
| 303 | A 6344900130 | PROTECTIVE PLATE |
| 306 | A 6344900230 | PROTECTIVE PLATE |
| 309 | A 6344910641 | BRACKET |
| 312 | N 910105006004 | HEXAGON HEAD BOLT |
| M6X16MM | ||
| 312 | N 910105008041 | HEXAGON HEAD BOLT |
| M8X16MM | ||
