Transporto priemonė: CITARO 12M 2-TUERER; VIN numerio dalis: 628031
Grupė: 24 ENGINE SUSPENSION
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 6282402317 | RUBBER MOUNTING |
| ENGINE FRONT LEFT MOUNTING | ||
| OM 906 | ||
| 005 | A 6282402417 | RUBBER MOUNTING |
| ENGINE FRONT LEFT MOUNTING | ||
| 008 | A 6282402017 | RUBBER MOUNTING |
| RIGHT | ||
| OM 906 | ||
| 008 | A 9412417713 | RUBBER MOUNTING |
| RIGHT | ||
| OM 457 | ||
| 011 | N 000000005478 | HEXAGON HEAD BOLT |
| LEFT RUBBER MOUNTING TO CONSOLES | ||
| M 14X1,5X45 | ||
| 014 | N 000000005718 | HEXAGON HEAD BOLT |
| ENGINE MOUNTING TO ENGINE SUPPORT, FRONT RIGHT | ||
| M 14X1,5X45 | ||
| 017 | N 910105014013 | HEXAGON HEAD BOLT |
| ENGINE MOUNTING TO ENGINE SUPPORT, FRONT RIGHT | ||
| M 14X1,5X35 | ||
| 020 | N 000000005713 | HEXAGON HEAD BOLT |
| LEFT RUBBER MOUNTING TO CONSOLES | ||
| M 14X1,5X70 | ||
| 023 | N 000000005564 | HEXAGON HEAD BOLT |
| RIGHT | ||
| M 18X1.5X60 | ||
| 026 | N 000000005739 | NUT |
| RIGHT | ||
| 029 | A 6282410035 | BEARING BRACKET |
| 030 | A 6282410135 | BEARING BRACKET |
| 032 | A 6282410002 | SUPPORT |
| RIGHT | ||
| 035 | A 6282400015 | BEARING TUBE |
| OM 906 | ||
| 036 | A 6282400115 | BEARING TUBE |
| OM 457 | ||
| 038 | A 6282410076 | WASHER |
| LEFT | ||
| D=56 | ||
| 039 | A 6282410176 | WASHER |
| RIGHT | ||
| D=44 | ||
| 041 | A 0059902851 | NUT |
| LEFT AND RIGHT | ||
| M 22X1,5 | ||
| 044 | N 000000002315 | ROLL PIN |
| 047 | N 000000005542 | HEXAGON HEAD BOLT |
| M 16X1,5X50 | ||
| 050 | N 000000005738 | NUT |
| M16 | ||
| 053 | A 6282400406 | CONSOLE |
| HORIZONTAL | ||
| 056 | A 6282400132 | REINFORCEMENT |
| OM 906 | ||
| 058 | A 6282400332 | REINFORCEMENT |
| OM 457 | ||
| 059 | N 000000005474 | HEXAGON HEAD BOLT |
| CONSOLE TO FRAME END PLATE | ||
| M 14X1,5X40 | ||
| 062 | N 913023014003 | NUT |
| M14 | ||
| 065 | N 000000005723 | HEXAGON HEAD BOLT |
| ENGINE TO REAR RUBBER MOUNTING | ||
| M18X1.5X55 | ||
| 068 | A 9412417813 | RUBBER MOUNTING |
| 068 | A 6282401817 | RUBBER MOUNTING |
| 071 | N 000000005559 | HEXAGON HEAD BOLT |
| M 18X1,5X45 | ||
| 074 | N 000000005721 | HEXAGON HEAD BOLT |
| M14X1.5X60 | ||
| 077 | A 6282420135 | FASTENING PLATE |
| 080 | A 6282412101 | TRANSMISSION CARRIER |
| 083 | N 000000005535 | HEXAGON HEAD BOLT |
| M 16X1,5X40 | ||
| 086 | A 6282400102 | ENGINE SUPPORT |
| 089 | N 000000005562 | HEXAGON HEAD BOLT |
| 092 | A 6282420523 | PLATE |
| 095 | N 910105008017 | HEXAGON HEAD BOLT |
| 098 | A 6282400005 | SUPPORTING ARM |
| LEFT | ||
| 101 | A 6282400101 | ENGINE SUPPORT |
