Transporto priemonė: IBC FAHRGESTELL 2-ACHSER; VIN numerio dalis: 634200
Grupė: 69 ENGINE COMPARTMENT COVERING
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 6346940133 | COVERING |
| 006 | A 6346840026 | COVERING |
| 007 | A 6346840118 | COVERING |
| 008 | A 6346940033 | COVERING |
| 009 | A 6346840018 | COVERING |
| 011 | A 6346940020 | RAIL |
| REAR RIGHT | ||
| 014 | A 6346940120 | RAIL |
| REAR LEFT | ||
| 015 | A 6346840321 | RAIL |
| 016 | A 6343172841 | BRACKET |
| 017 | A 6346900012 | ANGLE |
| 018 | A 6346840421 | RAIL |
| 019 | A 6346840521 | RAIL |
| 020 | A 0009908891 | NUT RETAINER |
| 022 | A 6346800035 | RAIL |
| REAR RIGHT | ||
| 024 | A 6346800135 | RAIL |
| REAR LEFT | ||
| 026 | A 0009840764 | MOUNTING PLATE |
| 026 | A 0009840764 | MOUNTING PLATE |
| 029 | A 0009846436 | LOCKING PIN |
| 029 | A 0009846436 | LOCKING PIN |
| N 910105008039 | SCREW | |
| M8X25 | ||
| N 910105008039 | SCREW | |
| M8X25 | ||
| N 910112008000 | NUT | |
| M8 | ||
| N 910112008000 | NUT | |
| M8 |
