Transporto priemonė: OC 1214; VIN numerio dalis: 341058

Grupė: 41 PROPELLER SHAFT

#	Kodas	Pavadinimas
	A 3184100101	PROPELLER SHAFT
	Repalced by: A 3414103901
008	A 3414103901	PROPELLER SHAFT
		FROM TRANSMISSION TO INTERMEDIATE BEARING I
		873 MM
016	A 3414100204	PROPELLER SHAFT
		FROM TRANSMISSION TO INTERMEDIATE BEARING
		1848 MM
	A 3274101027	PROPELLER SHAFT TUBE
	Repalced by: A 3414100829
024	A 3414100829	PROPELLER SHAFT TUBE
	A 3414100304	PROPELLER SHAFT
	Repalced by: A 3414104601
036	A 3414104601	PROPELLER SHAFT
		FROM INTERMEDIATE BEARING I TO INTERMEDIATE BEARING II
		1316 MM
	A 3414100229	PROPELLER SHAFT TUBE
	Repalced by: A 3414101229
046	A 3414101229	PROPELLER SHAFT TUBE
		1159 MM
054	N 071412008100	GREASE NIPPLE
062	A 3124131361	PROTECTIVE CAP
062	A 3524130061	PROTECTIVE CAP
		TO 341 410 03 04
070	A 3524110011	DRIVE FLANGE
	A 3854100231	UNIVERSAL JOINT CROSS
078	A 3024100031	UNIVERSAL JOINT CROSS
086	A 3224100542	BEARING BUSHING
094	A 0009815087	NEEDLE
094	A 0009815087	NEEDLE
102	A 3124111233	EXPANSION PLUG
110	A 3129941135	SNAP RING
		AS REQUIRED
		2.50 MM
110	A 3129941635	SNAP RING
		AS REQUIRED
		2.55 MM
110	A 3129941335	SNAP RING
		AS REQUIRED
		2.60 MM
110	A 3129941435	SNAP RING
		AS REQUIRED
		2.65 MM
110	A 3129941535	SNAP RING
		AS REQUIRED
		2.70 MM
110	A 3129941735	SNAP RING
		AS REQUIRED
		2.75 MM
118	N 071412008300	GREASE NIPPLE
118	A 3459977288	GREASE NIPPLE
126	A 3224100540	BRACKET
		INTERMEDIATE BEARING
134	A 3524100540	BRACKET
		INTERMEDIATE BEARING
142	A 3124131112	RUBBER MOUNTING
150	A 3524130012	RUBBER MOUNTING
158	A 3524100051	BALL BEARING
158	A 3454100051	BALL BEARING
166	A 3124131231	BEARING RING
173	A 3524100030	CENTERING FLANGE
180	A 3524100130	CENTERING FLANGE
188	A 3124131361	PROTECTIVE CAP
196	A 3524130061	PROTECTIVE CAP
204	A 3224110072	NUT
212	A 3524100302	PROPELLER SHAFT
	Repalced by: A 3444101602
212	A 3444101602	PROPELLER SHAFT
	Repalced by: A 3414106702
212	A 3414106702	PROPELLER SHAFT
		FROM INTERMEDIATE BEARING TO REAR AXLE
		1775 MM
212	A 3414106702	PROPELLER SHAFT
		IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.:
		318 410 07 02; 1753 MM
	A 3224104727	PROPELLER SHAFT TUBE
	Repalced by: A 3444102227
220	A 3444102227	PROPELLER SHAFT TUBE
228	A 3524100008	UNIVERSAL JOINT YOKE
	Repalced by: A 3444100008
228	A 3444100008	UNIVERSAL JOINT YOKE
	Repalced by: A 3414100908
228	A 3414100908	UNIVERSAL JOINT YOKE
	A 3444110005	UNIVERSAL JOINT YOKE
	Repalced by: A 3024110405
236	A 3024110405	UNIVERSAL JOINT YOKE
242	N 071412008100	GREASE NIPPLE
250	A 3524110011	DRIVE FLANGE
	A 3854100231	UNIVERSAL JOINT CROSS
258	A 3024100031	UNIVERSAL JOINT CROSS
266	A 3224100542	BEARING BUSHING
274	A 0009815087	NEEDLE
280	A 3124111233	EXPANSION PLUG
288	A 3129941135	SNAP RING
		AS REQUIRED
		2.50 MM
288	A 3129941635	SNAP RING
		AS REQUIRED
		2.55 MM
288	A 3129941335	SNAP RING
		AS REQUIRED
		2.60 MM
288	A 3129941435	SNAP RING
		AS REQUIRED
		2.65 MM
288	A 3129941535	SNAP RING
		AS REQUIRED
		2.70 MM
288	A 3129941735	SNAP RING
		AS REQUIRED
		2.75 MM
296	N 071412008300	GREASE NIPPLE
296	A 3459977288	GREASE NIPPLE
304	A 3374130080	SEAL RING
312	A 3214110158	SEAL HOLDER
320	A 3524100080	BOOT
	Repalced by: A 3414100080
320	A 3414100080	BOOT
320	A 3454107280	BOOT
328	A 3214110053	WIRE RING
336	N 916002078100	CLAMP
336	A 3419977790	CLAMP
342	N 000961010039	SCREW
		INTERMEDIATE BEARING
350	N 000127010202	LOCK WASHER
		INTERMEDIATE BEARING
358	N 007349010001	WASHER
		INTERMEDIATE BEARING
366	N 913002010010	NUT
		INTERMEDIATE BEARING
372	A 3524130011	REINFORCEMENT
		INTERMEDIATE BEARING
380	N 000127010205	LOCK WASHER
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
		TO 352 990 04 01
388	N 000934010042	NUT
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
396	A 3529900401	SCREW
	Repalced by: A 3529904701
396	A 3529904701	SCREW
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
