Transporto priemonė: OF 1313/1314; VIN numerio dalis: 345050
Grupė: 52 CHASSIS SHEET METAL - 001 SHEET METAL,AIR INTAKE
66452
66453
66454
66455
66456
66457
# Kodas Pavadinimas
003 A 0010900201 AIR CLEANER
006 H 983450940104 FILTER ELEMENT
Repalced by: A 0020941304
006 A 0020941304 FILTER ELEMENT
009 A 0000940380 GASKET
012 A 0010940380 GASKET
015 H 983450940003 FILTER BOWL
018 A 0000940155 FASTENER
Repalced by: A 0010940055
018 A 0010940055 FASTENER
021 A 0000940017 DUST COLLECTOR BOWL
024 A 0020940980 GASKET
027 A 0080940023 STRAINER
030 A 0010940055 FASTENER
035 A 3440900101 AIR CLEANER
Repalced by: A 3440900001
035 A 3440900001 AIR CLEANER
Repalced by: A 3450907001
035 A 3450907001 AIR CLEANER
"MANN"
040 A 3450907401 AIR CLEANER
041 A 3450907501 AIR CLEANER
042 A 3440947003 FILTER BOWL
TO 345 090 75 01
043 N 913002008001 NUT
TO 345 090 70 01,75 01
044 A 0000948703 FILTER BOWL
TO 345 090 75 01
A 0000948603 FILTER BOTTOM
TO 345 090 74 01
046 A 3440947003 FILTER BOWL
TO 344 090 00 01,345 090 74 01
047 A 0000949003 FILTER BOWL
TO 345 090 70 01
047 A 3440947203 FILTER BOWL
TO 345 090 74 01
048 A 3760947165 VALVE
TO 345 090 75 01
049 H 983440940010 BOTTOM PARTITION
TO 344 090 00 01
A 3440940010 PIPE SOCKET
TO 345 090 74 01
051 A 0010940055 FASTENER
TO 345 090 74 01,75 01
052 A 3760947165 VALVE
TO 345 090 70 01
053 N 000084008172 SCREW
TO 345 090 70 01
054 A 0000940427 BRACKET
TO 345 090 70 01,75 01
055 N 000084008172 SCREW
TO 345 090 70 01
056 A 1109900052 NUT
TO 345 090 70 01
057 A 0010945204 FILTER ELEMENT
058 A 3450947068 VACUUM BOX
A 3645407045 SWITCH
Repalced by: A 6885407645
A 6885407645 SWITCH
060 A 3445207701 AIR INTAKE PIPE
060 A 3455207701 AIR INTAKE PIPE
061 A 3215240040 BRACKET
062 A 3445280185 RUBBER MOUNTING
Repalced by: A 0019873140
062 A 0019873140 RUBBER BUFFER
AIR CLEANER TO BRACKET
065 N 009021010102 WASHER
AIR CLEANER TO BRACKET
069 N 000127010202 LOCK WASHER
AIR CLEANER TO BRACKET
073 N 000934010000 NUT
AIR CLEANER TO BRACKET
077 N 000933008288 SCREW
BRACKET TO ENGINE COMPARTMENT COVERING
081 N 912004008100 LOCK WASHER
BRACKET TO ENGINE COMPARTMENT COVERING
085 N 000934008000 NUT
BRACKET TO ENGINE COMPARTMENT COVERING
089 N 009021008100 WASHER
BRACKET TO ENGINE COMPARTMENT COVERING
096 A 3215200002 AIR INTAKE CASE
Repalced by: A 3445207002
096 A 3445207002 AIR INTAKE CASE
100 A 3219870033 RUBBER SECTION
105 A 3445200089 COVER
109 N 000084004106 SCREW
113 N 912004004102 LOCK WASHER
117 N 000934004014 NUT
122 N 007981004252 SHEET METAL SCREW
126 N 000125005315 WASHER
135 A 0010941882 HOSE
135 A 0010940182 HOSE
135 A 3640947182 HOSE
FROM AIR CLEANER TO ENGINE INTAKE PIPE
135 A 3450947282 HOSE
FROM AIR CLEANER TO ENGINE INTAKE PIPE
139 N 900271008011 HOSE
143 A 0000947482 HOSE
Repalced by: A 0000947682
143 A 0000947682 HOSE
FROM AIR CLEANER TO ENGINE INTAKE PIPE
143 N 900271100013 HOSE
FROM AIR CLEANER TO ENGINE INTAKE PIPE
148 A 3449979890 CLAMP
AS REQUIRED
152 A 3449979790 CLAMP
AS REQUIRED
160 A 3449979890 CLAMP
160 A 3459979890 CLAMP
160 A 3449979990 CLAMP
AS REQUIRED
165 A 3455207201 AIR INTAKE PIPE
165 A 3455207301 AIR INTAKE PIPE
169 N 900271100013 HOSE
174 A 3449979990 CLAMP
184 A 3455207241 BRACKET
RIGHT
188 A 3455247040 BRACKET
LEFT
192 A 3455287540 BRACKET
AIR INTAKE CASE
192 A 3455287540 BRACKET
AIR INTAKE CASE
196 A 3455287049 ANGLE
200 A 3455207541 BRACKET
AIR CLEANER
200 A 3455207541 BRACKET
AIR CLEANER
208 N 000933008282 SCREW
AIR CLEANER TO BRACKET
M 8X20
208 N 000933008282 SCREW
AIR CLEANER TO BRACKET
M 8X20
208 N 000933008317 SCREW
AIR CLEANER TO BRACKET
210 N 000933008288 SCREW
AIR CLEANER TO BRACKET
M 8X25
210 N 000933008288 SCREW
AIR CLEANER TO BRACKET
M 8X25
216 N 000127008104 LOCK WASHER
AIR CLEANER TO BRACKET
216 N 000127008104 LOCK WASHER
AIR CLEANER TO BRACKET
222 N 000934008000 NUT
AIR CLEANER TO BRACKET
222 N 000934008000 NUT
AIR CLEANER TO BRACKET
230 N 000933006220 SCREW
BRACKET TO AIR INTAKE CASE
230 N 000933006220 SCREW
BRACKET TO SUPPORT
234 N 000125006420 WASHER
BRACKET TO AIR INTAKE CASE
234 N 000125006420 WASHER
BRACKET TO SUPPORT
238 N 000127006203 LOCK WASHER
BRACKET TO AIR INTAKE CASE
242 N 913001006001 NUT
BRACKET TO AIR INTAKE CASE
242 N 913001006001 NUT
BRACKET TO AIR INTAKE CASE
250 A 3455207001 AIR INTAKE PIPE
250 A 3455207701 AIR INTAKE PIPE
251 N 900271018048 HOSE
252 A 3441347240 BRACKET
HOSE TO AIR INTAKE PIPE
253 A 3449950101 CLAMP
HOSE TO AIR INTAKE PIPE
254 N 000933008228 SCREW
HOSE TO AIR INTAKE PIPE
255 N 000933008282 SCREW
HOSE TO AIR INTAKE PIPE
256 N 912004008100 LOCK WASHER
HOSE TO AIR INTAKE PIPE
257 N 000934008000 NUT
HOSE TO AIR INTAKE PIPE
258 A 3445207066 BRACKET
260 N 000933006220 SCREW
264 N 000125006420 WASHER
268 N 000127006203 LOCK WASHER
272 N 000934006006 NUT
276 A 3445287082 HOSE
280 A 3449979790 CLAMP
AS REQUIRED
280 A 3459979790 CLAMP
AS REQUIRED
285 A 3449979790 CLAMP
AS REQUIRED
285 A 3459979790 CLAMP
AS REQUIRED
286 A 3509970390 LOOM TIE
HOSE TO TURBOCHARGER
288 A 3459977390 LOOM TIE
288 A 0019978290 LOOM TIE
292 H 983455200141 BRACKET
Repalced by: A 3455207441
292 A 3455207441 BRACKET
292 A 3455207341 BRACKET
300 N 000933010174 SCREW
BRACKET TO FRAME SIDE MEMBER
304 N 000127010202 LOCK WASHER
BRACKET TO FRAME SIDE MEMBER
308 N 913004010004 NUT
BRACKET TO FRAME SIDE MEMBER
315 A 3455207033 SUPPORT
315 A 3455207033 SUPPORT
315 A 3455207133 SUPPORT
324 N 000933008282 SCREW
BRACKET TO SUPPORT
324 N 000933008282 SCREW
BRACKET TO SUPPORT
329 N 912004008100 LOCK WASHER
BRACKET TO SUPPORT
334 N 000934008000 NUT
BRACKET TO SUPPORT
340 A 3455287076 BINDING RAIL
343 A 3455287640 BRACKET
345 A 3455287740 BRACKET
350 N 000933006220 SCREW
AIR INTAKE CASE AND SUPPORT TO MOUNTING RAIL
350 N 000933006220 SCREW
BRACKET TO AIR INTAKE CASE
353 N 913004006001 NUT
BRACKET TO AIR INTAKE CASE
356 N 009021006101 WASHER
AIR INTAKE CASE AND SUPPORT TO MOUNTING RAIL
356 N 009021006101 WASHER
AIR INTAKE CASE AND SUPPORT TO MOUNTING RAIL
359 N 000125006420 WASHER
BRACKET TO AIR INTAKE CASE
362 N 000127006203 LOCK WASHER
AIR INTAKE CASE AND SUPPORT TO MOUNTING RAIL
362 N 000127006203 LOCK WASHER
BRACKET TO AIR INTAKE CASE
368 N 000934006006 NUT
AIR INTAKE CASE AND SUPPORT TO MOUNTING RAIL
368 N 000934006006 NUT
BRACKET TO AIR INTAKE CASE
375 A 3455207041 BRACKET
380 N 000933008282 SCREW
BRACKET TO BRACKET
384 N 912004008100 LOCK WASHER
BRACKET TO BRACKET
388 N 000934008000 NUT
BRACKET TO BRACKET
400 A 3440940002 AIR CLEANER
Repalced by: A 3440948602
400 A 3440948602 AIR CLEANER
MANN, 545 325 96 524
400 A 3440948202 AIR CLEANER
Repalced by: A 3440948402
400 A 3440948402 AIR CLEANER
"FRAM DO BRASIL" B 21 920
401 A 0000948503 FILTER BOWL
TO 344 094 82 02
401 A 0000948403 FILTER BOWL
TO 344 094 00 02
401 A 0000948203 FILTER BOWL
TO 344 094 84 02
401 A 0000949003 FILTER BOWL
TO 344 094 86 02
402 A 3089907051 NUT
Repalced by: N 913002008001
402 N 913002008001 NUT
TO 344 094 00 02,344 094 86 02
402 A 0000940375 NUT
TO 344 094 84 02
402 A 0000940472 NUT
TO 344 094 82 02,344 094 84 02
403 A 0000940572 NUT
TO 344 094 82 02,344 094 84 02
404 H 983440940010 BOTTOM PARTITION
TO 344 094 00 02
405 A 0000945511 SCOOP
TO 344 094 82 02,344 094 84 02
406 A 0000941360 SEAL RING
TO 344 094 84 02
407 A 0000942171 SCREW
TO 344 094 82 02,344 094 84 02
407 A 0000942271 SCREW
TO 344 094 82 02,344 094 84 02
408 A 0000946011 SCOOP
TO 344 094 82 02
409 A 0000945611 SCOOP
Repalced by: A 3440947011
409 A 3440947011 SCOOP
TO 344 094 00 02,344 094 86 02
410 A 0000940173 LOCK
TO 344 094 84 02
411 A 0000941405 SEPARATOR
TO 344 094 84 02
412 A 3440947003 FILTER BOWL
CYCLONE
TO 344 094 00 02,344 094 86 02
412 A 0000941905 CYCLONE PRE-FILTER BOWL
TO 344 094 82 02
413 A 3760947165 VALVE
TO 344 094 86 02,345 094 82 02
414 A 0010940055 FASTENER
TO 344 094 00 02,344 094 86 02
414 A 0000942355 FASTENER
TO 344 094 82 02
415 A 0010948080 GASKET
TO 344 094 84 02
416 A 0010945204 FILTER ELEMENT
TO 344 094 00 02,344 094 86 02
416 A 3440947104 FILTER ELEMENT
TO 344 094 82 02,344 094 84 02
417 A 0000940427 BRACKET
TO 344 094 86 02
417 A 0000944842 CLAMP
TO 344 094 82 02
418 A 0000940768 VACUUM BOX
Repalced by: A 3450947268
418 A 3450947268 VACUUM BOX
Repalced by: A 0000940368
418 A 0000940368 VACUUM BOX
Repalced by: A 3645407045
418 A 3645407045 SWITCH
Repalced by: A 6885407645
418 A 6885407645 SWITCH
425 A 3445200341 BRACKET
430 A 3445207141 BRACKET
435 N 000127010202 LOCK WASHER
BRACKET TO FRAME SIDE MEMBER
435 N 000127012201 LOCK WASHER
BRACKET TO FRAME SIDE MEMBER
439 N 000934010000 NUT
BRACKET TO FRAME SIDE MEMBER
439 N 000934012010 NUT
BRACKET TO FRAME SIDE MEMBER
443 N 000933010129 SCREW
BRACKET TO FRAME SIDE MEMBER
443 N 000933010269 SCREW
BRACKET TO FRAME SIDE MEMBER
443 N 000933012122 SCREW
BRACKET TO FRAME SIDE MEMBER
447 N 000125010517 WASHER
BRACKET TO FRAME SIDE MEMBER
455 N 000933010174 SCREW
BRACKET TO FRAME SIDE MEMBER
459 N 000127010202 LOCK WASHER
BRACKET TO FRAME SIDE MEMBER
463 N 000934010000 NUT
BRACKET TO FRAME SIDE MEMBER
470 A 3445207101 AIR INTAKE PIPE
475 N 000933008282 SCREW
AIR INTAKE PIPE TO BRACKET
479 N 000125008417 WASHER
AIR INTAKE PIPE TO BRACKET
483 N 912004008100 LOCK WASHER
AIR INTAKE PIPE TO BRACKET
488 N 000933010294 SCREW
FILTER TO BRACKET
492 N 000125010517 WASHER
FILTER TO BRACKET
496 N 000127010202 LOCK WASHER
FILTER TO BRACKET
500 N 000934010005 NUT
FILTER TO BRACKET
510 N 900271100013 HOSE
FROM AIR CLEANER TO AIR INTAKE PIPE
516 A 3449979990 CLAMP
AS REQUIRED
516 A 3459979990 CLAMP
AS REQUIRED
517 A 3445207101 AIR INTAKE PIPE
519 N 000933008282 SCREW
AIR INTAKE PIPE TO BRACKET
521 N 000125008417 WASHER
AIR INTAKE PIPE TO BRACKET
523 N 912004008100 LOCK WASHER
AIR INTAKE PIPE TO BRACKET
525 A 0010940182 HOSE
Repalced by: A 3450947082
525 A 3450947082 HOSE
FROM AIR INTAKE PIPE TO ENGINE
525 A 3450947182 HOSE
525 A 3529971382 HOSE
528 A 3455288208 AIR INTAKE PIPE
541 A 3449979890 CLAMP
541 A 3459979890 CLAMP
541 A 3449979790 CLAMP
541 A 3459979790 CLAMP
