Transporto priemonė: OH 1318; VIN numerio dalis: 398420

Grupė: 41 PROPELLER SHAFT

#	Kodas	Pavadinimas
502	A 3824108402	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		812 MM
502	A 3824107502	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		1372MM
502	A 3824108802	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		608 MM
518	A 0004101731	UNIVERSAL JOINT CROSS
		WITH BUSHINGS
		TO 382 410 84 02,75 02
518	A 0004102031	UNIVERSAL JOINT CROSS
		WITH BUSHINGS
		TO 382 410 88 02
519	A 0069903601	SCREW
		TO 382 410 84 02,75 02
521	A 0009974788	GREASE NIPPLE
		UNIVERSAL JOINT CROSS
		TO 382 410 84 02,88 02,75 02
556	A 0009974888	GREASE NIPPLE
		PROPELLER SHAFT
		TO 382 410 88 02,84 02,75 02
557	A 0004130380	SEAL RING
		NOTE THREAD DIAMETER
		TO 382 410 84 02,75 02;2 1/2"
557	A 0004130780	SEAL RING
		NOTE THREAD DIAMETER
		TO 382 410 84 02,75 02;2 1/4"
557	A 0004130680	SEAL RING
		TO 382 410 88 02
565	A 6654130061	PROTECTIVE CAP
		TO 382 410 88 02
597	A 3849957010	CLAMP
		PROPELLER SHAFT TO TRANSMISSION
597	A 3849957010	CLAMP
		PROPELLER SHAFT TO REAR AXLE
598	A 3849907801	SCREW
		PROPELLER SHAFT TO TRANSMISSION
598	A 3849907801	SCREW
		PROPELLER SHAFT TO REAR AXLE
600	A 3454137244	REBOUND STRAP
		PROPELLER SHAFT
600	A 3824117082	REBOUND STRAP
		PROPELLER SHAFT
603	N 000933010254	SCREW
		REBOUND STRAP TO FRAME
603	N 000961014105	SCREW
		REBOUND STRAP TO FRAME
		M 14X1.5X30
603	N 000961014106	SCREW
		REBOUND STRAP TO FRAME
		M 14X1.5X35
606	N 913004010004	NUT
		REBOUND STRAP TO FRAME
606	N 913004014005	NUT
		REBOUND STRAP TO FRAME
		M 14X1.5X35
609	A 6654117006	COVER
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
612	A 6654117071	SCREW
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
