Transporto priemonė: OH 1835L/30; VIN numerio dalis: 397058
Grupė: 43 EXHAUST BRAKE
| # | Kodas | Pavadinimas |
|---|---|---|
| X XXXXXXXXXXXX | PART NAME MISSING | |
| EXHAUST BRAKE VALVE LINE CONNECTION | ||
| 005 | N 003952006102 | FITTING |
| BRANCH-OFF TO EXHAUST BRAKE CYLINDER | ||
| 008 | A 3889978836 | VALVE |
| Repalced by: A 3889978336 | ||
| 008 | A 3649977236 | VALVE |
| Repalced by: A 3889978136 | ||
| 008 | A 3889978136 | VALVE |
| Repalced by: A 3889978336 | ||
| 008 | A 3889978336 | VALVE |
| (THREE-WAY SOLENOID VALVE) | ||
| "PARKER" | ||
| 011 | A 0004311868 | VALVE PART |
| TO 364 997 72 36 | ||
| 014 | A 0014311687 | PROTECTIVE CAP |
| TO 364 997 72 36 | ||
| 017 | A 0139971648 | SEAL RING |
| TO 364 997 72 36 | ||
| 020 | A 0004310472 | NUT |
| TO 364 997 72 36 | ||
| 023 | A 0007630956 | MAGNET |
| TO 364 997 72 36 | ||
| 023 | A 0005460488 | SOLENOID |
| TO 388 997 88 36 | ||
| 024 | A 0004206855 | REPAIR KIT |
| TO 388 997 88 36 | ||
| 024 | A 0059972336 | REPAIR KIT |
| TO 388 997 81 36 | ||
| 026 | A 6884347040 | BRACKET |
| TO 364 997 72 36 | ||
| 027 | A 3454297736 | CONNECTOR |
| EXHAUST BRAKE | ||
| 029 | A 3509977472 | FITTING |
| (SOLENOID VALVE) | ||
| 032 | N 007603012405 | SEAL RING |
| (SOLENOID VALVE) | ||
| 032 | N 007603012405 | SEALING RING |
| (SOLENOID VALVE) | ||
| 035 | N 915036008202 | HOLLOW SCREW |
| (SOLENOID VALVE) | ||
| 035 | N 915036008202 | BANJO BOLT |
| (SOLENOID VALVE) | ||
| 038 | N 915047008200 | HOLLOW SCREW |
| (SOLENOID VALVE) | ||
| 041 | N 000933005095 | SCREW |
| SOLENOID VALVE TO BRACKET | ||
| 044 | N 912004005100 | LOCK WASHER |
| SOLENOID VALVE TO BRACKET | ||
| 047 | N 000933010200 | SCREW |
| BRACKET TO FRAME SIDE MEMBER | ||
| 050 | N 913004010011 | NUT |
| BRACKET TO FRAME SIDE MEMBER | ||
| 053 | A 0024297444 | VALVE |
| 056 | A 3839900051 | NUT |
| SOLENOID VALVE TO PEDESTAL | ||
| 059 | N 915036006202 | HOLLOW SCREW |
| 3/2-WAY VALVE;CONNECTION: | ||
| "10" | ||
| 065 | N 007603010404 | SEAL RING |
| 3/2-WAY VALVE;CONNECTIONS: | ||
| "10,42" | ||
| 068 | N 915039006203 | HOLLOW SCREW FITTING |
| 3/2-WAY VALVE;CONNECTION: | ||
| "42" | ||
| 071 | A 0005456209 | SWITCH |
| 3/2-WAY VALVE;CONNECTION: | ||
| "42" | ||
| 072 | A 3864297040 | BRACKET |
| AT CROSS MEMBER NO.1 | ||
| 072 | A 3864297040 | BRACKET |
| AT AIR RESERVOIR SUPPORT | ||
| 073 | N 000933008288 | SCREW |
| BRACKET TO NO.1 CROSS MEMBER | ||
| 073 | N 000933008288 | SCREW |
| AT AIR RESERVOIR SUPPORT | ||
| 073 | N 000933008288 | SCREW |
| COMPRESSED AIR LINE TO BRACKET | ||
| 074 | N 913004008005 | NUT |
| BRACKET TO NO.1 CROSS MEMBER | ||
| 074 | N 913004008005 | NUT |
| AT AIR RESERVOIR SUPPORT | ||
| 074 | N 913004008005 | NUT |
| COMPRESSED AIR LINE TO BRACKET | ||
| 075 | N 916016038201 | CLAMP |
| COMPRESSED AIR LINE TO BRACKET | ||
| 076 | A 6644307195 | HYDRAULIC BRAKE |
| RETARDER | ||
| VOITH | ||
| 076 | A 6644307395 | HYDRAULIC BRAKE |
| RETARDER | ||
| VOITH | ||
| 077 | A 0004380371 | SCREW |
| OIL DRAIN | ||
| M 30X1.5 | ||
| 080 | N 007603030100 | SEAL RING |
| OIL DRAIN | ||
| 083 | A 0089978447 | SEAL RING |
| HOUSING | ||
| 086 | A 0019901712 | SCREW |
| M 10X35 | ||
| 089 | N 000433010504 | WASHER |
| 092 | A 0019902412 | SCREW |
| M 10X25 | ||
| 095 | A 0004380680 | GASKET |
| M 120X120X0.5 | ||
| 098 | A 0034304181 | VALVE |
| Repalced by: A 0034305881 | ||
| 098 | A 0034305881 | VALVE |
| (FLOAT HOLLOW BALL) | ||
| 101 | N 000933008115 | SCREW |
| 104 | N 000125008418 | WASHER |
| 107 | A 0034306181 | VALVE |
| Repalced by: A 0034304181 | ||
| 107 | A 0034304181 | VALVE |
| (FLOAT HOLLOW BALL) | ||
| 110 | N 007603012104 | SEAL RING |
| 113 | A 0004380671 | SCREW |
| M 12X1.5 | ||
| 116 | A 0149975448 | SEAL RING |
| 119 | N 000910012000 | SCREW PLUG |
| M 12X1.5 | ||
| 122 | N 000910030004 | SCREW PLUG |
| M 30X1.5 | ||
| 125 | A 0004380367 | MUFFLER |
| 128 | A 0034306281 | VALVE |
| (BLEEDER VALVE) | ||
| 131 | A 0004301609 | REPAIR KIT |
| PARTS KIT | ||
| 134 | A 0009974044 | SEAL RING |
| 137 | A 0004380280 | GASKET |
| 140 | N 007603022104 | SEAL RING |
| 144 | A 0004380040 | BRACKET |
| 147 | N 000908022001 | SCREW PLUG |
| M 22X1.5 | ||
| 150 | A 0004380514 | COVER |
| 153 | A 0089973348 | SEAL RING |
| 156 | A 0089973648 | SEAL RING |
| 159 | A 0004381271 | SCREW |
| M 30X1.5 | ||
| 162 | A 0004381371 | SCREW |
| M 10X18 | ||
| 165 | A 0009911045 | RING |
| 168 | A 0149971548 | SEAL RING |
| 171 | N 914141008310 | SCREW |
| M 118X20 | ||
| 174 | A 0015403497 | VALVE |
| 177 | A 0034307081 | GASKET KIT |
| Repalced by: A 0015409797 | ||
| 177 | A 0015409797 | REPAIR KIT |
| SOLENOID VALVE | ||
| 180 | A 0034307181 | REPAIR KIT |
| LARGE SCOPE | ||
| 183 | N 000931008257 | SCREW |
| M 8X115 | ||
| 186 | A 0005460288 | SOLENOID |
| 189 | A 0069975248 | SEAL RING |
| 192 | A 0099970948 | SEAL RING |
| 195 | A 0004380571 | SCREW |
| 198 | A 0015014501 | RADIATOR |
| 201 | A 0004380076 | WASHER |
| 204 | A 0069975348 | SEAL RING |
| 207 | N 913004010008 | NUT |
| 210 | N 007991010014 | SCREW |
| M 10X25 | ||
| 210 | N 000931010264 | SCREW |
| M 10X45 | ||
| 210 | N 000933010129 | SCREW |
| M 10X30 | ||
| 213 | N 000125010518 | WASHER |
| 216 | A 0005010023 | CONNECTOR |
| 219 | A 0005010680 | GASKET |
| 222 | N 304017010030 | SCREW |
| M 10X50 | ||
| 225 | A 0004302895 | GASKET KIT |
| LARGE SCOPE | ||
| A 3825427047 | COUPLER | |
| 234 | A 6649907101 | SCREW |
| 237 | A 6649907077 | SCREW |
| A 3825427007 | FLEXIBLE SHAFT | |
| 243 | A 6644387076 | WASHER |
| 246 | A 6644387060 | SEAL RING |
| 249 | A 6644387245 | FLANGE |
| 252 | A 6644387014 | COVER |
| 255 | A 6644307181 | VALVE |
| 258 | A 0005402745 | CONTROL UNIT |
| 261 | A 6645007003 | RADIATOR |
| 264 | A 6644387276 | WASHER |
| 2.50 MM | ||
| 264 | A 6644387376 | WASHER |
| 2.70 MM | ||
| 264 | A 6644387476 | WASHER |
| 2.90 MM | ||
| 264 | A 6644387576 | WASHER |
| 3.10 MM | ||
| 264 | A 6644387676 | WASHER |
| 3.30 MM | ||
| 264 | A 6644387776 | WASHER |
| 3.50 MM | ||
| 267 | A 6644387976 | WASHER |
| 0.50 MM | ||
| 267 | A 6644388076 | WASHER |
| 0.55 MM | ||
| 267 | A 6644388176 | WASHER |
| 0.60 MM | ||
| 267 | A 6644388276 | WASHER |
| 0.65 MM | ||
| 267 | A 6644388376 | WASHER |
| 0.70 MM | ||
| 267 | A 6644388476 | WASHER |
| 0.75 MM | ||
| 267 | A 6644388576 | WASHER |
| 0.80 MM | ||
| 267 | A 6644388676 | WASHER |
| 0.85 MM | ||
| 267 | A 6644388776 | WASHER |
| 0.90 MM | ||
| 267 | A 6644388876 | WASHER |
| 0.95 MM | ||
| 267 | A 6644388976 | WASHER |
| 1.00 MM | ||
| 267 | A 6644389076 | WASHER |
| 1.05 MM | ||
| 270 | N 000939010145 | STUD BOLT |
| COVER TO RETARDER HOUSING | ||
| M 10X22 | ||
| 270 | N 000939010148 | STUD BOLT |
| COVER TO RETARDER HOUSING | ||
| M 10X30 | ||
| 270 | N 000939010150 | STUD BOLT |
| COVER TO RETARDER HOUSING | ||
| M 10X45 | ||
| 273 | N 000934010005 | NUT |
| COVER TO RETARDER HOUSING | ||
| 273 | N 000934010005 | NUT |
| COVER TO RETARDER HOUSING | ||
| 273 | N 074361018205 | NUT |
| COVER TO RETARDER HOUSING | ||
| 276 | N 007603018104 | SEAL RING |
| PLUG | ||
| 279 | N 915036010200 | HOLLOW SCREW |
| CONTROL VALVE | ||
| 282 | N 007603014405 | SEAL RING |
| CONTROL VALVE | ||
| 285 | A 3829957101 | CLAMP |
| CONTROL VALVE TO CROSS MEMBER | ||
| 288 | A 3823127940 | BRACKET |
| CONTROL VALVE TO CROSS MEMBER | ||
| 291 | N 000933008030 | SCREW |
| CONTROL VALVE TO CROSS MEMBER | ||
| M 8X18 | ||
| 291 | N 000931008369 | SCREW |
| CONTROL VALVE TO CROSS MEMBER | ||
| M 8X80 | ||
| 297 | N 913004008001 | NUT |
| Repalced by: A 0009906350 | ||
| 297 | A 0009906350 | NUT |
| CONTROL VALVE TO CROSS MEMBER | ||
