Transporto priemonė: O 170; VIN numerio dalis: 341252
Grupė: 30 CONTROL
| # | Kodas | Pavadinimas |
|---|---|---|
| A 3213000516 | ACCELERATOR PEDAL | |
| Repalced by: A 3443000104 | ||
| 003 | A 3443000104 | ACCELERATOR PEDAL |
| 006 | A 3213010050 | BUSHING |
| ACCELERATOR PEDAL | ||
| 009 | N 071412010300 | GREASE NIPPLE |
| ACCELERATOR PEDAL | ||
| 012 | N 304017008007 | SCREW |
| PEDAL PLATE TO PEDAL | ||
| 015 | A 3213000202 | PLATE |
| 018 | A 3203015082 | PAD |
| PEDAL PLATE | ||
| 021 | A 3219900040 | WASHER |
| ACCELERATOR PEDAL TO BEARING BRACKET | ||
| 024 | N 000471020001 | LOCK RING |
| ACCELERATOR PEDAL TO BEARING BRACKET | ||
| 027 | A 3213020004 | ROD |
| A 3413017115 | ROD | |
| N 000934006007 | NUT | |
| N 071805010101 | BALL SOCKET | |
| 030 | A 3413007325 | LEVER |
| 033 | A 3213010050 | BUSHING |
| 036 | N 000433006402 | WASHER |
| PULL ROD | ||
| N 000094001617 | COTTER PIN | |
| PULL ROD | ||
| A 0419960001 | YOKE | |
| Repalced by: N 071752006001 | ||
| 042 | N 071752006001 | YOKE |
| PULL ROD | ||
| 045 | A 3413037008 | ROD |
| A 3413017215 | ROD | |
| N 900331006288 | PULL ROD | |
| 051 | N 000934006007 | NUT |
| 054 | A 3219960034 | NUT |
| 057 | N 000934006012 | NUT |
| L.H. THREAD | ||
| 060 | A 3413037108 | ROD |
| A 3219910005 | PIN | |
| Repalced by: A 3419917007 | ||
| 063 | A 3419917007 | PIN |
| PULL ROD TO INTERMEDIATE LEVER AND TO REAR CONTROL LEVER | ||
| 066 | N 000137006204 | PART NAME MISSING |
| PULL ROD TO INTERMEDIATE LEVER AND TO REAR CONTROL LEVER | ||
| N 000094001617 | COTTER PIN | |
| PULL ROD TO INTERMEDIATE LEVER AND TO REAR CONTROL LEVER | ||
| 072 | A 3213000925 | LEVER |
| Repalced by: A 3413007425 | ||
| 072 | A 3413007425 | LEVER |
| CONTROL LEVER | ||
| A 3413007225 | LEVER | |
| CONTROL LEVER | ||
| 075 | A 3213010150 | BUSHING |
| 075 | A 3213010150 | BUSHING |
| 078 | N 071803010204 | BALL PIVOT |
| CONTROL LEVER | ||
| A 3129901340 | WASHER | |
| LEVER TO BRACKET | ||
| N 000471014001 | LOCK RING | |
| LEVER TO BRACKET | ||
| N 071412010200 | GREASE NIPPLE | |
| LEVER TO BRACKET | ||
| 081 | A 3213010373 | PIVOT PIN |
| Repalced by: A 3413017074 | ||
| 081 | A 3413017074 | PIN |
| 084 | A 3129901340 | WASHER |
| Repalced by: A 3413017076 | ||
| 084 | A 3413017076 | WASHER |
| CONTROL LEVER TO PIVOT PIN | ||
| 087 | N 000471014001 | LOCK RING |
| CONTROL LEVER TO PIVOT PIN | ||
| 090 | N 000463013002 | LOCK PLATE |
| PIVOT PIN TO TRANSMISSION CASE COVER | ||
| 093 | N 000463010502 | LOCK PLATE |
| PIVOT PIN TO TRANSMISSION CASE COVER | ||
| 096 | A 3213020171 | SCREW |
| PIVOT PIN TO TRANSMISSION CASE COVER | ||
| 097 | A 3415867030 | REPAIR KIT |
| 099 | N 071412010300 | GREASE NIPPLE |
| N 071412010100 | GREASE NIPPLE | |
| 102 | A 3213002215 | ROD |
| A 3523000915 | ROD | |
| 105 | A 3219970182 | HOSE |
| 108 | N 000934006007 | NUT |
| PULL ROD | ||
| 111 | N 071805010203 | BALL SOCKET |
| PULL ROD | ||
| 114 | N 071805010302 | SNAP RING |
| PULL ROD | ||
| 117 | N 071805010403 | SECURING CLIP |
| PULL ROD | ||
| 120 | N 071803010101 | BALL PIVOT |
| Repalced by: N 071803010102 | ||
| 120 | N 071803010102 | BALL PIVOT |
| 123 | N 000934006007 | NUT |
| A 3123011040 | BRACKET | |
| Repalced by: A 3413010140 | ||
| 126 | A 3413010140 | BRACKET |
| 129 | A 0669930210 | SPRING |
| BETWEEN CONTROL LEVER AND BRACKET | ||
| A 3413007507 | KNOB | |
| A 3413027071 | SCREW | |
| N 000125006430 | WASHER | |
| Repalced by: A 3449907440 | ||
| A 3449907440 | WASHER | |
| A 3413027050 | BUSHING | |
| A 3413027091 | GROMMET | |
| N 000084006134 | SCREW | |
| N 000125006421 | WASHER | |
| N 000934006007 | NUT | |
| A 3413027020 | CLAMP | |
| N 007981004233 | SHEET METAL SCREW | |
