Transporto priemonė: O 170; VIN numerio dalis: 341252
Grupė: 29 PEDAL ASSEMBLY
| # | Kodas | Pavadinimas |
|---|---|---|
| 003 | A 3212900219 | BEARING BRACKET |
| A 3412907219 | BEARING BRACKET | |
| A 3412907219 | BEARING BRACKET | |
| 006 | N 000933010016 | SCREW |
| PEDAL BEARING BRACKET TO FRAME | ||
| 006 | N 000933010026 | SCREW |
| PEDAL BEARING BRACKET TO FRAME | ||
| 009 | N 000933010034 | SCREW |
| PEDAL BEARING BRACKET TO FRAME | ||
| 012 | N 000127010202 | LOCK WASHER |
| PEDAL BEARING BRACKET TO FRAME | ||
| 015 | N 000934010000 | NUT |
| PEDAL BEARING BRACKET TO FRAME | ||
| A 3212900220 | BEARING | |
| Repalced by: A 3212900620 | ||
| 018 | A 3212900620 | BEARING |
| 021 | A 3122940150 | BUSHING |
| 024 | N 071412010200 | GREASE NIPPLE |
| 027 | N 000988040001 | FITTED WASHER |
| 030 | N 000933008036 | SCREW |
| BEARING TO PEDAL BEARING BRACKET | ||
| 033 | N 912004008102 | LOCK WASHER |
| BEARING TO PEDAL BEARING BRACKET | ||
| 036 | N 000934008000 | NUT |
| BEARING TO PEDAL BEARING BRACKET | ||
| A 3212900216 | PEDAL | |
| Repalced by: A 3442900416 | ||
| 039 | A 3442900416 | PEDAL |
| 042 | N 000933010034 | SCREW |
| PEDAL PLATE TO PEDAL | ||
| A 3212900224 | PEDAL PLATE | |
| Repalced by: A 3442900024 | ||
| 045 | A 3442900024 | PEDAL PLATE |
| Repalced by: A 3442907024 | ||
| 045 | A 3442907024 | PEDAL PLATE |
| 048 | A 3122911097 | SEAL WASHER |
| 051 | A 3202925082 | PAD |
| PEDAL PLATE | ||
| 054 | A 3212900718 | PEDAL |
| 057 | A 3122911550 | BUSHING |
| 060 | N 071412010100 | GREASE NIPPLE |
| 063 | N 000933010034 | SCREW |
| PEDAL PLATE TO PEDAL | ||
| 066 | N 000471040000 | LOCK RING |
| CLUTCH SHAFT | ||
| A 3212900124 | PEDAL PLATE | |
| Repalced by: A 3442900124 | ||
| 069 | A 3442900124 | PEDAL PLATE |
| 072 | A 3122911097 | SEAL WASHER |
| 075 | A 3202925082 | PAD |
| PEDAL PLATE | ||
| 078 | A 3129931510 | SPRING |
| PEDAL TO BRACKET | ||
| 081 | A 3212920740 | BRACKET |
| 081 | A 3212920740 | BRACKET |
| A 3529931110 | SPRING | |
| A 3529931110 | SPRING | |
| 084 | A 3212930010 | LEVER |
| 087 | N 000931008057 | SCREW |
| LEVER TO SHAFT | ||
| 090 | N 000934008000 | NUT |
| LEVER TO SHAFT | ||
| 093 | N 900331008028 | PULL ROD |
| BETWEEN CLUTCH PEDAL AND LEVER | ||
| N 071752008001 | YOKE | |
| Repalced by: A 0419960101 | ||
| 096 | A 0419960101 | YOKE |
| PULL ROD | ||
| 099 | N 000934008000 | NUT |
| PULL ROD | ||
| 102 | A 3212900031 | PIVOT PIN |
| A 3412907131 | BEARING | |
| A 3412907131 | BEARING | |
| 105 | N 071412010300 | GREASE NIPPLE |
| PIVOT PIN TO SUBSTRUCTURE | ||
| 108 | N 000933008036 | SCREW |
| PIVOT PIN TO SUBSTRUCTURE | ||
| 111 | N 912004008102 | LOCK WASHER |
| PIVOT PIN TO SUBSTRUCTURE | ||
| N 000934008000 | NUT | |
| PIVOT PIN TO SUBSTRUCTURE | ||
| 114 | A 3212900127 | LEVER |
| A 3412907127 | LEVER | |
| A 3412907127 | LEVER | |
| 117 | A 3213010050 | BUSHING |
| 120 | A 3219900040 | WASHER |
| 123 | N 000471020000 | LOCK RING |
| PIVOT PIN | ||
| N 071412010300 | GREASE NIPPLE | |
| 126 | N 001434008002 | PIN |
| PULL ROD TO INTERMEDIATE LEVER | ||
| N 000094002052 | COTTER PIN | |
| PULL ROD TO INTERMEDIATE LEVER | ||
| N 000094004049 | COTTER PIN | |
| PULL ROD TO INTERMEDIATE LEVER | ||
| 135 | N 071752008001 | YOKE |
| Repalced by: A 0419960101 | ||
| 135 | A 0419960101 | YOKE |
| 138 | N 900331008253 | PULL ROD |
| A 3412937029 | ROD | |
| 141 | N 000934008000 | NUT |
| 144 | A 1362930033 | NUT |
| 147 | N 900331008101 | PULL ROD |
| 147 | N 900331008100 | PULL ROD |
| 153 | N 000934008004 | NUT |
| 156 | A 3219962225 | ROD |
| 159 | N 071805016101 | BALL SOCKET |
| 162 | N 071805016300 | SNAP RING |
| 163 | A 3212902337 | BEARING |
| SHIFT TUBE GUIDE,CLUTCH & ACCELERATOR CONTROL LINKAGE,EXHAUST BRAKE | ||
| 166 | A 3212680850 | BUSHING |
| 169 | A 3173010085 | RUBBER BUFFER |
| 172 | A 3172910085 | BUSHING |
| 175 | A 3212902437 | BEARING |
| Repalced by: A 3412907057 | ||
| 175 | A 3412907057 | GUIDE |
| GUIDE FOR CLUTCH AND ACCELERATOR CONTROL LINKAGE,EXHAUST BRAKE | ||
| 178 | A 3173010085 | RUBBER BUFFER |
| 181 | A 3172910085 | BUSHING |
| 184 | N 000933008036 | SCREW |
| BEARING | ||
| 187 | N 000125008413 | WASHER |
| BEARING | ||
| 190 | N 912004008102 | LOCK WASHER |
| BEARING | ||
| 193 | N 000934008000 | NUT |
| BEARING | ||
