Transporto priemonė: O 170; VIN numerio dalis: 341252
Grupė: 32 SPRINGS AND SUSPENSION
| # | Kodas | Pavadinimas |
|---|---|---|
| 003 | A 3213210804 | FRONT SPRING |
| 003 | A 3443210004 | FRONT SPRING |
| 006 | A 3213200666 | SPRING CLAMP |
| BOTTOM | ||
| 006 | A 3443200166 | SPRING CLAMP |
| BOTTOM | ||
| 009 | N 001472010005 | GROOVED PIN |
| A 3213200543 | BRACKET | |
| Repalced by: A 3443200243 | ||
| 012 | A 3443200243 | BRACKET |
| SPRING SEAT | ||
| 015 | N 000127020202 | LOCK WASHER |
| BRACKET AND SPRING CLAMP TO FRONT AXLE BEAM,BOTTOM | ||
| 018 | N 000960020078 | SCREW |
| BRACKET AND SPRING CLAMP TO FRONT AXLE BEAM,BOTTOM | ||
| 021 | A 3213220144 | RUBBER BUFFER |
| BRACKET AND SPRING CLAMP TO FRONT AXLE BEAM,BOTTOM | ||
| 024 | A 3213250525 | SPRING CLAMP |
| FRONT SPRING | ||
| 024 | A 3443210233 | SPRING CLAMP |
| FRONT SPRING | ||
| 027 | A 3213210506 | HELPER SPRING |
| FRONT SPRING | ||
| 030 | A 3213250225 | SPRING CLAMP |
| 033 | A 3213310143 | BRACKET |
| 036 | A 3219900102 | SCREW |
| 036 | A 3449900102 | SCREW |
| 039 | A 3129901540 | WASHER |
| 042 | N 000935020000 | NUT |
| N 000094004065 | COTTER PIN | |
| 045 | A 3213310144 | RUBBER BUFFER |
| 048 | A 0003237600 | SHOCK ABSORBER |
| H 990003230000 | SHOCK ABSORBER | |
| 051 | A 0003231260 | SEAL RING |
| 054 | A 0003230262 | THRUST WASHER |
| 057 | A 0003230960 | SEAL RING |
| 060 | A 0003230405 | PISTON |
| 063 | A 0003230277 | LOCK WASHER |
| 066 | A 0003230272 | NUT |
| 069 | A 0003231293 | SPRING |
| 072 | A 0003230051 | SPACER RING |
| 075 | A 0003230008 | PISTON INSERT |
| 078 | A 0003230078 | CONICAL SPRING WASHER |
| 081 | A 0003230178 | CONICAL SPRING WASHER |
| 084 | A 0003230278 | CONICAL SPRING WASHER |
| 087 | A 0003230009 | PISTON BOTTOM |
| 090 | A 0003230294 | LOCK RING |
| 093 | A 0003230123 | CYLINDER BOTTOM |
| 096 | A 0003230277 | LOCK WASHER |
| 099 | A 0003231062 | THRUST WASHER |
| 102 | A 0003231393 | SPRING |
| 105 | A 0003230041 | VALVE PLATE |
| 108 | A 0003230108 | PISTON INSERT |
| 111 | A 0003230109 | PISTON BOTTOM |
| 114 | A 0003230022 | TUBE |
| 117 | A 0003230122 | TUBE |
| 120 | A 0003231160 | SEAL RING |
| 123 | A 0003230502 | COVER |
| 126 | N 007603010103 | SEAL RING |
| 129 | A 0003230656 | SCREW PLUG |
| 132 | A 0003230785 | RUBBER MOUNTING |
| 135 | A 0003230553 | SPACER TUBE |
| 138 | A 3213230571 | SCREW |
| SHOCK ABSORBER TO FRONT AXLE | ||
| 141 | N 000937020001 | NUT |
| SHOCK ABSORBER TO FRONT AXLE | ||
| N 000094004065 | COTTER PIN | |
| SHOCK ABSORBER TO FRONT AXLE | ||
| 141D | A 3443200030 | SHOCK ABSORBER |
| 141H | H 983445860032 | REPAIR KIT |
| 141M | H 983445860132 | REPAIR KIT |
| 141R | H 983445860232 | REPAIR KIT |
| 141U | H 983445860332 | REPAIR KIT |
| 142 | A 3443230053 | SPACER TUBE |
| SHOCK ABSORBER | ||
| 142D | A 3203230044 | RUBBER BUFFER |
| SHOCK ABSORBER | ||
| 142H | A 3443230067 | RETAINER |
| SHOCK ABSORBER | ||
| 142M | A 3443230072 | NUT |
| SHOCK ABSORBER | ||
| N 000094004065 | COTTER PIN | |
| SHOCK ABSORBER | ||
| 142R | A 3443200145 | CLAMP |
| FRONT SHOCK ABSORBERS | ||
| 142R | A 3443207043 | BRACKET |
| FRONT SHOCK ABSORBERS | ||
| 143 | A 3449940030 | LOCK |
| SHOCK ABSORBER TO FRONT AXLE | ||
| 143D | N 000961012076 | SCREW |
| SHOCK ABSORBER TO FRONT AXLE | ||
| 143H | A 3443200056 | SHIM |
| LEFT | ||
| 143H | A 3443200156 | SHIM |
| RIGHT | ||
| 144 | A 3213200245 | CLAMP |
| FRONT SHOCK ABSORBERS | ||
| A 3443207043 | BRACKET | |
| 147 | N 000961012013 | SCREW |
| CLAMP TO FRONT AXLE | ||
| 150 | N 000127012203 | LOCK WASHER |
| CLAMP TO FRONT AXLE | ||
| A 3213201808 | REAR SPRING | |
| Repalced by: A 3413200606 | ||
| 153 | A 3413200606 | REAR SPRING |
| 12-LEAF | ||
| A 3443200306 | REAR SPRING | |
| 11-LEAF | ||
| 156 | A 3213200293 | SPRING LEAF |
| NO.1 | ||
| A 3443207094 | SPRING LEAF | |
| NO.1 | ||
| 159 | A 3203210250 | BUSHING |
| 159 | A 3443220150 | BUSHING |
| 162 | A 3209900151 | NUT |
| 165 | A 3213240712 | SPRING LEAF |
| LEAF NO.2 | ||
| A 3443240312 | SPRING LEAF | |
| LEAF NO.2 | ||
| 168 | A 3213240713 | SPRING LEAF |
| LEAF NO. 3 | ||
| A 3443240313 | SPRING LEAF | |
| LEAF NO. 3 | ||
| 171 | A 3213240714 | SPRING LEAF |
| LEAF NO.4 | ||
| A 3443207093 | SPRING LEAF | |
| LEAF NO.4 | ||
| A 3443207193 | SPRING LEAF | |
| LEAF NO.8 | ||
| A 0013216533 | SPRING CLAMP | |
| Repalced by: A 3213240233 | ||
| 174 | A 3213240233 | SPRING CLAMP |
| LEAF NO.5 | ||
| 177 | N 000124010066 | RIVET |
| A 0003219433 | SPRING CLAMP | |
| Repalced by: A 3213340033 | ||
| 180 | A 3213240033 | SPRING CLAMP |
| LEAF NO.9 | ||
| 183 | N 000124010066 | RIVET |
| 186 | A 3213240138 | SLIDING BLOCK |
| 189 | N 004626012120 | SPRING BOLT |
| CENTRAL | ||
| 189 | N 004626012112 | SPRING BOLT |
| 192 | N 000934012010 | NUT |
| CENTRAL | ||
| A 0003212553 | SPACER TUBE | |
| Repalced by: A 3443240053 | ||
| 195 | A 3443240053 | SPACER TUBE |
| U-BOLT | ||
| 198 | N 000601012003 | SCREW |
| U-BOLT | ||
| 198 | N 000601012008 | SCREW |
| 201 | N 000934012000 | NUT |
| U-BOLT | ||
| 204 | A 3213200063 | SHACKLE |
| REAR SPRING | ||
| 204 | A 3443200063 | SHACKLE |
| REAR SPRING | ||
| 207 | A 3203210250 | BUSHING |
| 207 | A 3443220150 | BUSHING |
| 210 | A 3209900151 | NUT |
| 213 | A 3213250601 | REAR SPRING BRACKET |
| FRONT | ||
| A 3443250001 | REAR SPRING BRACKET | |
| FRONT | ||
| 216 | A 3213250403 | REAR SPRING BRACKET |
| REAR | ||
| A 3443250003 | REAR SPRING BRACKET | |
| REAR | ||
| 219 | N 000961012120 | SCREW |
| REAR SPRING FRONT AND REAR BRACKETS TO SUBSTRUCTURE | ||
| 219 | N 000961012117 | SCREW |
| REAR SPRING FRONT AND REAR BRACKETS TO SUBSTRUCTURE | ||
| A 3219900951 | NUT | |
| Repalced by: N 000936012013 | ||
| 222 | N 000936012013 | NUT |
| 222 | N 000936012002 | NUT |
| N 000934012016 | NUT | |
| 228 | A 3213220030 | SHACKLE PIN |
| REAR SPRING | ||
| 228 | A 3443220130 | SHACKLE PIN |
| REAR SPRING | ||
| 231 | N 071412010300 | GREASE NIPPLE |
| PIN | ||
| 234 | A 3123220173 | LOCK |
| 237 | A 3203220184 | SHIM |
| 240 | N 912004008102 | LOCK WASHER |
| LOCK PLATE | ||
| 243 | N 000933008025 | SCREW |
| LOCK PLATE | ||
| 246 | A 3443250031 | PLATE |
| Repalced by: A 3213250731 | ||
| 246 | A 3213250731 | PLATE |
| REAR AXLE TO TO REAR SPRINGS | ||
| 249 | A 3213510225 | U-BOLT |
| REAR AXLE TO TO REAR SPRINGS | ||
| 249 | A 3443510125 | U-BOLT |
| Repalced by: A 3213511925 | ||
| 249 | A 3213511925 | U-BOLT |
| REAR AXLE TO TO REAR SPRINGS | ||
| 252 | A 3279970026 | WASHER |
| REAR AXLE TO TO REAR SPRINGS | ||
| 255 | N 000934018006 | NUT |
| REAR AXLE TO TO REAR SPRINGS | ||
| 255 | N 000934018002 | NUT |
| REAR AXLE TO TO REAR SPRINGS | ||
| 258 | A 3213260065 | TORSION BAR |
| REAR STABILIZER | ||
| A 3443260165 | TORSION BAR | |
| REAR STABILIZER | ||
| 261 | A 3213260081 | RUBBER MOUNTING |
| TORSION BAR | ||
| 264 | A 3213260082 | HOUSING |
| OUTSIDE | ||
| 267 | A 3213260182 | HOUSING |
| INSIDE | ||
| 270 | A 3213260269 | LEVER |
| LEFT | ||
| 273 | A 3213260369 | LEVER |
| RIGHT | ||
| 276 | N 000961012027 | SCREW |
| TORSION BAR TO FRAME | ||
| 279 | N 000127012201 | LOCK WASHER |
| TORSION BAR TO FRAME | ||
| A 3219900255 | NUT | |
| Repalced by: A 3449900055 | ||
| 282 | A 3449900055 | NUT |
| LEVER TO TORSION BAR | ||
| 285 | N 000127018202 | LOCK WASHER |
| N 000094006311 | COTTER PIN | |
| LEVER TO TORSION BAR | ||
| 288 | A 3203230044 | RUBBER BUFFER |
| STABILIZER TO REAR AXLE | ||
| 291 | A 3219910340 | SPACER TUBE |
| STABILIZER TO REAR AXLE | ||
| 294 | A 3213230167 | RETAINER |
| STABILIZER TO REAR AXLE | ||
| 297 | A 3213230467 | RETAINER |
| STABILIZER TO REAR AXLE | ||
| 300 | A 3213230267 | RETAINER |
| STABILIZER TO REAR AXLE | ||
| 303 | A 3213200443 | BRACKET |
| STABILIZER TO REAR AXLE | ||
| 306 | N 000960018038 | SCREW |
| STABILIZER TO REAR AXLE | ||
| 309 | A 3219900155 | NUT |
| STABILIZER TO REAR AXLE | ||
| N 000094004065 | COTTER PIN | |
| STABILIZER TO REAR AXLE | ||
