Transporto priemonė: O 302 S OTOMARSAN/TUERKEI; VIN numerio dalis: 373158
Grupė: 47 FUELSYSTEM - 001 FUEL SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 010 | A 3734700701 | FUEL TANK |
| LESS SENDER UNIT | ||
| 010 | A 3734708001 | FUEL TANK |
| LESS SENDER UNIT | ||
| 012 | A 3734708601 | FUEL TANK |
| LESS SENDER UNIT | ||
| 012 | A 3734709401 | FUEL TANK |
| LESS SENDER UNIT | ||
| 012 | A 3734709201 | FUEL TANK |
| LESS SENDER UNIT | ||
| 014 | A 0004710980 | GASKET |
| 017 | A 0004700993 | VALVE |
| 020 | N 007603014405 | SEAL RING |
| 030 | N 915026008000 | FITTING |
| 030 | N 915023010001 | FITTING |
| 040 | A 0029977245 | SEAL RING |
| FUEL STRAINER SCREEN TO FUEL TANK | ||
| 050 | A 3734700006 | FUEL STRAINER |
| 060 | A 3735420017 | SENDER UNIT |
| FUEL GAUGE | ||
| 060 | A 0065427417 | SENDER UNIT |
| FUEL GAUGE | ||
| 065 | A 0055426917 | SENDER UNIT |
| FUEL GAUGE | ||
| 070 | A 4044710080 | GASKET |
| FUEL GAUGE SENDER UNIT TO FUEL TANK | ||
| 080 | A 0669970640 | SEAL RING |
| FUEL GAUGE SENDER UNIT TO FUEL TANK | ||
| 090 | N 007985005168 | SCREW |
| Repalced by: N 007985005175 | ||
| 090 | N 007985005175 | SCREW |
| FUEL GAUGE SENDER UNIT TO FUEL TANK | ||
| 100 | A 3734700420 | FILLER NECK |
| 110 | A 3734730026 | HOSE |
| 120 | N 916017080000 | CLAMP |
| Repalced by: N 000000000675 | ||
| 120 | N 000000000675 | CLAMP |
| 120 | A 3739971201 | PLUG |
| 180 | A 3734700005 | FILLER CAP |
| 190 | A 3049970340 | SEAL RING |
| 200 | N 915005006001 | LOCKING CONE |
| 210 | N 915017008200 | UNION NUT |
| 220 | A 0010921801 | FILTER |
| KNECHT | ||
| 220 | A 0010921901 | FILTER |
| HENGST | ||
| 225 | A 0014779801 | FUEL FILTER |
| KNECHT | ||
| 225 | A 4220900252 | FILTER |
| KNECHT | ||
| 225 | A 4220900252 | FILTER |
| KNECHT | ||
| 230 | A 3524700092 | FILTER ELEMENT |
| 230 | A 4220900051 | FILTER ELEMENT |
| Repalced by: A 0000901451 | ||
| 230 | A 0000901451 | FILTER ELEMENT |
| 230 | A 0000901451 | FILTER ELEMENT |
| 230 | A 0000901451 | FILTER ELEMENT |
| 235 | A 0004773180 | SEAL RING |
| 235 | A 0004773180 | SEAL RING |
| 235 | A 0004773180 | SEAL RING |
| 240 | N 000931008251 | SCREW |
| COVER TO HOUSING | ||
| 240 | N 000931008251 | SCREW |
| COVER TO HOUSING | ||
| 240 | N 000931008251 | SCREW |
| COVER TO HOUSING | ||
| 240 | N 000931008207 | SCREW |
| COVER TO HOUSING | ||
| TO HENGST | ||
| 250 | N 007603008109 | SEAL RING |
| 250 | N 007603008109 | SEAL RING |
| COVER TO HOUSING | ||
| KNECHT | ||
| 260 | N 007604014109 | SCREW PLUG |
| LATERAL TOP | ||
| TO KNECHT | ||
| 260 | N 000906014000 | SCREW PLUG |
| LATERAL TOP | ||
| TO HENGST | ||
| 270 | N 007603014405 | SEAL RING |
| LATERAL TOP | ||
| TO KNECHT | ||
| 280 | N 007603008109 | SEAL RING |
| BREATHER | ||
| 280 | N 007603006101 | SEAL RING |
| BREATHER | ||
| TO HENGST | ||
| 290 | A 0000745171 | SCREW |
| Repalced by: A 4420740071 | ||
| 290 | A 4420740071 | SCREW |
| BREATHER | ||
| 290 | A 0004773072 | SCREW |
| BREATHER | ||
| TO HENGST | ||
| 300 | A 0004773580 | SEAL RING |
| COVER TO HOUSING | ||
| 310 | A 0000922808 | FILTER HEAD |
| MULTI-STAGE FUEL FILTER | ||
| TO KNECHT | ||
| 310 | A 0004773708 | COVER |
| MULTI-STAGE FUEL FILTER | ||
| TO HENGST | ||
| 310 | A 4220900112 | COVER |
| MULTI-STAGE FUEL FILTER | ||
| KNECHT | ||
| 310 | A 4220900112 | COVER |
| MULTI-STAGE FUEL FILTER | ||
| KNECHT | ||
| 320 | A 0004770605 | HOUSING |
| TO KNECHT | ||
| 325 | A 4220900007 | HOUSING |
| 325 | A 4220900007 | HOUSING |
| KNECHT | ||
| 325 | A 4220900007 | HOUSING |
| 330 | N 000933012071 | SCREW |
| FUEL FILTER TO SUBSTRUCTURE | ||
| 340 | N 912004012100 | LOCK WASHER |
| FUEL FILTER TO SUBSTRUCTURE | ||
| 350 | N 000934012021 | NUT |
| FUEL FILTER TO SUBSTRUCTURE | ||
| 360 | A 0000911190 | PUMP |
| (MANUAL AUXILIARY PUMP) | ||
| 363 | A 3734702664 | LINE |
| FROM FUEL TANK TO CONNECTOR I | ||
| 363 | A 3734704264 | LINE |
| Repalced by: A 3734708665 | ||
| 363 | A 3734708665 | LINE |
| FROM FUEL TANK TO CONNECTOR I | ||
| 363 | A 3734709064 | LINE |
| FROM FUEL TANK TO CONNECTOR I | ||
| 366 | A 3734702764 | LINE |
| FROM CONNECTOR I TO CONNECTOR II | ||
| 366 | A 3734708165 | LINE |
| FROM CONNECTOR I TO CONNECTOR II | ||
| 366 | A 3734708265 | LINE |
| FROM CONNECTOR I TO CONNECTOR II | ||
| 366 | A 3734703864 | LINE |
| FROM CONNECTOR I TO CONNECTOR II | ||
| 369 | A 3734702864 | LINE |
| FROM CONNECTOR II TO RUBBER HOSE | ||
| 372 | A 3734702964 | LINE |
| FUEL LINE TO ENGINE | ||
| 372 | A 3734708365 | LINE |
| FUEL LINE TO ENGINE | ||
| 375 | A 3734708664 | LINE |
| FROM FUEL HOSE TO MANUAL AUXILIARY PUMP | ||
| 378 | A 3734708764 | LINE |
| FROM FUEL FILTER TO CONNECTING HOSE, FEED | ||
| 381 | A 3734708864 | LINE |
| FROM FUEL FILTER TO RUBBER HOSE;RETURN | ||
| 384 | A 3734703364 | LINE |
| FUEL LINE TO RETURN LINE CONNECTION AT ENGINE | ||
| 384 | A 3734708465 | LINE |
| FUEL LINE TO RETURN LINE CONNECTION AT ENGINE | ||
| 387 | A 3734703464 | LINE |
| FROM FUEL LINE TO T-FITTING | ||
| 387 | A 3734708565 | LINE |
| FROM FUEL LINE TO T-FITTING | ||
| 390 | A 3734703564 | LINE |
| FROM CONNECTOR TO T-FITTING | ||
| 395 | A 3734703664 | LINE |
| FROM CONNECTOR II TO FUEL TANK | ||
| 395 | A 3734708765 | LINE |
| FROM CONNECTOR II TO FUEL TANK | ||
| 395 | A 3734709164 | LINE |
| FROM CONNECTOR II TO FUEL TANK | ||
| 410 | A 0004290901 | LINE |
| LESS CONNECTIONS | ||
| 410 | A 0004293301 | LINE |
| LESS CONNECTIONS | ||
| 435 | N 915017010100 | UNION NUT |
| 435 | N 915017010200 | UNION NUT |
| 450 | N 003861010009 | GLAND |
| 453 | N 003902010002 | CONNECTION FITTING |
| Repalced by: A 0049971672 | ||
| 453 | A 0049971672 | FITTING |
| 456 | A 3054760126 | HOSE |
| LINE CONNECTIONS | ||
| 458 | N 900288016011 | CLAMP |
| LINE CONNECTIONS | ||
| 460 | A 0039974582 | HOSE |
| FUEL LINE TO FUEL LINE | ||
| 465 | N 915005008000 | LOCKING CONE |
| 470 | A 0089976482 | HOSE |
| FUEL RETURN LINE | ||
| 480 | A 3129950232 | CLAMP |
| FUEL LINES TO BRACKET | ||
| 490 | A 3179950832 | CLAMP |
| FUEL PUMP AND RETURN HOSES | ||
| 490 | A 3179950832 | CLAMP |
| FUEL LINES TO BRACKET | ||
| 500 | A 3125251089 | BASE |
| FUEL PUMP AND RETURN HOSES | ||
| 510 | N 000933006127 | SCREW |
| FUEL PUMP AND RETURN HOSES | ||
| 520 | N 913004006003 | NUT |
| FUEL PUMP AND RETURN HOSES | ||
| A 3734760236 | BRACKET | |
| Repalced by: A 3734767136 | ||
| 530 | A 3734767136 | BRACKET |
| FUEL LINES TO TRANSMISSION | ||
| 540 | A 3734767236 | BRACKET |
| FUEL LINES TO BRACKET | ||
| 550 | N 916016010201 | CLAMP |
| LINE MOUNTING | ||
| 560 | N 000933006127 | SCREW |
| LINE MOUNTING | ||
| 570 | N 009021006205 | WASHER |
| LINE MOUNTING | ||
| 580 | N 913004006003 | NUT |
| LINE MOUNTING | ||
| 590 | N 915021010000 | FITTING |
| FUEL HOSE TO BODY | ||
| 610 | A 3529970772 | HOLLOW SCREW |
| FUEL LINE TO FUEL FILTER | ||
| 610 | A 6159900263 | HOLLOW SCREW |
| FUEL LINE TO FUEL FILTER | ||
| 620 | N 915036010204 | HOLLOW SCREW |
| FUEL LINE TO FUEL FILTER | ||
| 620 | N 915036010204 | HOLLOW SCREW |
| FROM FUEL HOSE TO MANUAL AUXILIARY PUMP | ||
| 630 | A 0009906863 | HOLLOW SCREW |
| FROM FUEL PUMP TO FILTER | ||
| 630 | A 4219900063 | HOLLOW SCREW |
| FROM FUEL PUMP TO FILTER | ||
| 640 | N 007603014403 | SEAL RING |
