Transporto priemonė: O 303; VIN numerio dalis: 301245
Grupė: 26 TRANSMISSION
| # | Kodas | Pavadinimas |
|---|---|---|
| T YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 714.0 | ||
| T YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 719.1 | ||
| T YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 719.0 | ||
| 005 | N 000933014024 | SCREW |
| TRANSMISSION TO BELL HOUSING | ||
| M14X45 | ||
| 006 | N 912004014100 | LOCK WASHER |
| TRANSMISSION TO BELL HOUSING | ||
| 009 | A 3012600139 | SHIFT LEVER |
| 009 | A 3012600139 | SHIFT LEVER |
| 009 | A 3012600139 | SHIFT LEVER |
| 009 | A 3012600639 | SHIFT LEVER |
| 009 | A 3012600939 | SHIFT LEVER |
| 010 | A 3002600039 | SHIFT LEVER |
| 011 | A 3222600040 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 011 | A 3602600040 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 011 | A 3602600140 | HANDLE |
| Repalced by: A 3432600040 | ||
| 011 | A 3432600040 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 012 | A 6202680042 | KNOB |
| (SHIFT LEVER HANDLE) | ||
| 013 | A 6202680457 | COVER |
| WITH GEAR INDICATOR | ||
| 014 | N 000936010010 | NUT |
| GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER | ||
| 015 | A 3029930401 | SPRING |
| SHIFT LEVER LOWER PART | ||
| 015 | A 3029930401 | SPRING |
| SHIFT LEVER LOWER PART | ||
| 015 | A 3179930501 | SPRING |
| SHIFT LEVER LOWER PART | ||
| 016 | A 3022670008 | SPHERICAL PIECE |
| SHIFT LEVER LOWER PART | ||
| 016 | A 3022670008 | SPHERICAL PIECE |
| SHIFT LEVER LOWER PART | ||
| 016 | A 3022670008 | SPHERICAL PIECE |
| SHIFT LEVER LOWER PART | ||
| 017 | A 3022670006 | COVER |
| SHIFT LEVER TO BEARING BRACKET | ||
| 017 | A 3022670006 | COVER |
| SHIFT LEVER TO BEARING BRACKET | ||
| 017 | A 3022670006 | COVER |
| SHIFT LEVER TO BEARING BRACKET | ||
| 018 | A 3212670025 | SLIDING BLOCK |
| SHIFT LEVER LOWER PART | ||
| 018 | A 3212670025 | SLIDING BLOCK |
| SHIFT LEVER LOWER PART | ||
| 018 | A 3212670025 | SLIDING BLOCK |
| SHIFT LEVER LOWER PART | ||
| 019 | N 009045008002 | SNAP RING |
| SHIFT LEVER LOWER PART | ||
| 019 | N 009045008002 | SNAP RING |
| SHIFT LEVER LOWER PART | ||
| 019 | N 009045008002 | SNAP RING |
| SHIFT LEVER LOWER PART | ||
| 020 | A 3012680037 | BEARING BRACKET |
| SHIFT CASE | ||
| 020 | A 3012680037 | BEARING BRACKET |
| SHIFT CASE | ||
| 020 | A 3012680137 | BEARING BRACKET |
| SHIFT CASE | ||
| 021 | A 3002600062 | BRACKET |
| SHIFT LEVER UPPER PART | ||
| 021 | A 3002600062 | BRACKET |
| SHIFT LEVER UPPER PART | ||
| 021 | A 3002600362 | BRACKET |
| SHIFT LEVER UPPER PART | ||
| 021 | A 3002600662 | BRACKET |
| SHIFT LEVER UPPER PART | ||
| 022 | A 3002680080 | GASKET |
| SHIFT LEVER | ||
| 023 | A 0019811931 | JOINT BEARING |
| SHIFT LEVER | ||
| 024 | A 3052680150 | BUSHING |
| Repalced by: A 3572680050 | ||
| 024 | A 3572680050 | BUSHING |
| BEARING BRACKET | ||
| 024 | A 3572680050 | BUSHING |
| BEARING BRACKET | ||
| 024 | A 3572680050 | BUSHING |
| BEARING BRACKET | ||
| 025 | A 3002680051 | SPACER RING |
| SHIFT LEVER | ||
| 026 | N 000472047000 | LOCK RING |
| SHIFT LEVER BEARING | ||
| 027 | N 001473005012 | GROOVED PIN |
| BEARING BRACKET | ||
| 027 | N 001473005012 | GROOVED PIN |
| BEARING BRACKET | ||
| 027 | N 001473005012 | GROOVED PIN |
| BEARING BRACKET | ||
| 028 | A 0002680396 | BOOT |
| BEARING BRACKET | ||
| 028 | A 0002680396 | BOOT |
| BEARING BRACKET | ||
| 029 | A 3012680040 | BRACKET |
| BEARING BRACKET | ||
| 029 | A 3012680040 | BRACKET |
| BEARING BRACKET | ||
| 029 | A 3012680040 | BRACKET |
| BEARING BRACKET | ||
| 030 | A 3002680040 | BRACKET |
| BEARING TO SHIFT LEVER | ||
| 030 | A 3002680040 | BRACKET |
| BEARING TO SHIFT LEVER | ||
| 030 | A 3002680540 | BRACKET |
| BEARING TO SHIFT LEVER | ||
| 031 | N 000471025002 | LOCK RING |
| BEARING TO SHIFT LEVER | ||
| 032 | N 000933008153 | SCREW |
| Repalced by: N 304017008034 | ||
| 032 | N 304017008034 | SCREW |
| BEARING BRACKET TO FRAME | ||
| 032 | N 304017008034 | SCREW |
| BEARING BRACKET TO FRAME | ||
| 032 | N 304017008034 | SCREW |
| BEARING BRACKET TO FRAME | ||
| 032 | N 304017008034 | SCREW |
| BRACKET TO FRAME | ||
| 033 | N 912004008102 | LOCK WASHER |
| BEARING BRACKET TO FRAME | ||
| 033 | N 912004008102 | LOCK WASHER |
| BEARING BRACKET TO FRAME | ||
| 033 | N 912004008102 | LOCK WASHER |
| BEARING BRACKET TO FRAME | ||
| 033 | N 912004008102 | LOCK WASHER |
| BRACKET TO FRAME | ||
| 034 | N 000934008010 | NUT |
| BRACKET TO FRAME | ||
| 035 | A 3002680049 | SLIDE |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| 035 | A 3002680049 | SLIDE |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| 035 | A 3962680049 | SLIDE |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| 036 | N 000933010128 | SCREW |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| M10X20 | ||
| 036 | N 000933010128 | SCREW |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| M10X20 | ||
| N 000417010015 | HEADLESS SETSCREW | |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| 037 | N 000439010202 | NUT |
| FRONT SHIFTING ROD ADJUSTMENT | ||
| A 3962680096 | BOOT | |
| FRONT SHIFTING ROD SLIDE COVERING | ||
| 038 | A 3012680105 | COVER |
| BEARING BRACKET | ||
| 038 | A 3012680105 | COVER |
| BEARING BRACKET | ||
| 038 | A 3012680105 | COVER |
| BEARING BRACKET | ||
| 039 | A 3012680180 | GASKET |
| BEARING BRACKET | ||
| 039 | A 3012680180 | GASKET |
| BEARING BRACKET | ||
| 039 | A 3012680180 | GASKET |
| BEARING BRACKET | ||
| 040 | A 3012670096 | BOOT |
| Repalced by: A 3562680197 | ||
| 040 | A 3562680197 | BOOT |
| SHIFT LEVER | ||
| 041 | A 3012600085 | PIPE |
| TRANSVERSE SHAFT | ||
| 042 | A 0059813610 | NEEDLE BEARING |
| Repalced by: A 0049813810 | ||
| 042 | A 0049813810 | NEEDLE BEARING |
| TRANSVERSE SHAFT | ||
| 043 | A 0019973047 | SEAL RING |
| TRANSVERSE SHAFT | ||
| 044 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 044 | N 304017008016 | SCREW |
| INTERMEDIATE LEVER | ||
| 045 | N 912004008102 | LOCK WASHER |
| INTERMEDIATE LEVER | ||
| 046 | A 3012600138 | SHAFT |
| Repalced by: A 3002600038 | ||
| 046 | A 3002600038 | SHAFT |
| TRANSVERSE | ||
| 049 | A 3012680013 | LEVER |
| (INTERMEDIATE LEVER) | ||
| 052 | N 006888005006 | WOODRUFF KEY |
| LEVER TO SHAFT | ||
| 055 | N 912004012100 | LOCK WASHER |
| LEVER TO SHAFT | ||
| 058 | N 000934012022 | NUT |
| LEVER TO SHAFT | ||
| 061 | A 3012600372 | SHIFT CASE |
| Repalced by: A 3002600072 | ||
| 061 | A 3002600072 | SHIFT CASE |
| 064 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 064 | N 304017008016 | SCREW |
| SHIFT CASE TO FRAME | ||
| M 8X12 | ||
| 067 | N 912004008102 | LOCK WASHER |
| SHIFT CASE TO FRAME | ||
| 070 | A 3012680144 | FLANGE |
| SHIFT CASE | ||
| 073 | N 003411002000 | GREASE CUP |
| 076 | N 000933008147 | SCREW |
| Repalced by: N 304017008021 | ||
| 076 | N 304017008021 | SCREW |
| FLANGE TO SHIFT CASE | ||
| 079 | N 912004008102 | LOCK WASHER |
| FLANGE TO SHIFT CASE | ||
| 082 | A 3052680150 | BUSHING |
| Repalced by: A 3572680050 | ||
| 082 | A 3572680050 | BUSHING |
| SHIFT CASE | ||
| 085 | A 0002680396 | BOOT |
| SHIFT CASE | ||
| 085 | A 0002680396 | BOOT |
| FOR BOOT,FLANGE,AND BUSHING,SEE ALSO GROUP 29 | ||
| 088 | A 3012680405 | COVER |
| SHIFT CASE | ||
| 088 | A 3002680005 | COVER |
| SHIFT CASE | ||
| 091 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 091 | N 304017008016 | SCREW |
| COVER TO SHIFT CASE | ||
| 094 | N 912004008102 | LOCK WASHER |
| COVER TO SHIFT CASE | ||
| 097 | A 3002600133 | SHIFTING ROD |
| FRONT | ||
| 097 | A 3012601233 | SHIFTING ROD |
| Repalced by: A 3012604733 | ||
| 097 | A 3012604733 | SHIFTING ROD |
| FRONT | ||
| 097 | A 3012604733 | SHIFTING ROD |
| FRONT | ||
| 100 | A 3012608033 | SHIFTING ROD |
| FRONT | ||
| 100 | A 3012602933 | SHIFTING ROD |
| Repalced by: A 3012604833 | ||
| 100 | A 3012604833 | SHIFTING ROD |
| FRONT | ||
| 103 | A 3219900601 | SCREW |
| SHIFT LEVER TO FRONT SHIFTING TUBE | ||
| 106 | N 912004008102 | LOCK WASHER |
| SHIFT LEVER TO FRONT SHIFTING TUBE | ||
| 109 | N 000934008010 | NUT |
| SHIFT LEVER TO FRONT SHIFTING TUBE | ||
| 112 | A 3012602133 | SHIFTING ROD |
| Repalced by: A 3012604933 | ||
| 112 | A 3012604933 | SHIFTING ROD |
| ABOVE FRONT AXLE | ||
| 115 | A 3012602333 | SHIFTING ROD |
| Repalced by: A 3012605133 | ||
| 115 | A 3012605133 | SHIFTING ROD |
| ABOVE REAR AXLE | ||
| 118 | A 3012603533 | SHIFTING ROD |
| Repalced by: A 3012605433 | ||
| 118 | A 3012605433 | SHIFTING ROD |
| REAR | ||
| 118 | A 3012601933 | SHIFTING ROD |
| Repalced by: A 3012605233 | ||
| 118 | A 3012605233 | SHIFTING ROD |
| Repalced by: A 3012608233 | ||
| 118 | A 3012608233 | SHIFTING ROD |
| REAR | ||
| 118 | A 3012602033 | SHIFTING ROD |
| Repalced by: A 3012605333 | ||
| 118 | A 3012605333 | SHIFTING ROD |
| REAR | ||
| 121 | A 3212680228 | CONNECTOR |
| SHIFTING ROD | ||
| 124 | N 006888005006 | WOODRUFF KEY |
| SHIFTING ROD | ||
| 127 | N 912004012100 | LOCK WASHER |
| SHIFTING ROD | ||
| 130 | N 000934012022 | NUT |
| SHIFTING ROD | ||
| 133 | A 0002682289 | JOINT |
| Repalced by: A 3572680089 | ||
| 133 | A 3572680089 | JOINT |
| 133 | A 0002683189 | JOINT |
| Repalced by: A 3572680289 | ||
| 133 | A 3572680289 | JOINT |
| 136 | A 3179900301 | SCREW |
| CONNECTOR TO SHIFTING ROD AND TO SHAFT | ||
| 139 | A 3219900601 | SCREW |
| CONNECTOR TO SHIFTING ROD AND TO SHAFT | ||
| 142 | N 912004008102 | LOCK WASHER |
| CONNECTOR TO SHIFTING ROD AND TO SHAFT | ||
| 145 | N 000934008010 | NUT |
| CONNECTOR TO SHIFTING ROD AND TO SHAFT | ||
| 148 | A 3212680552 | SPACER WASHER |
| AS REQUIRED | ||
| 2.00 M | ||
| 148 | A 3212680452 | SPACER WASHER |
| AS REQUIRED | ||
| 3.00 MM | ||
| 148 | A 3212680352 | SPACER WASHER |
| AS REQUIRED | ||
| 5.00 MM | ||
| 151 | N 000931008266 | SCREW |
| SHIFTING TUBE TO TRANSMISSION | ||
| M 8X40 | ||
| 154 | N 912004008102 | LOCK WASHER |
| SHIFTING TUBE TO TRANSMISSION | ||
| 157 | N 000934008010 | NUT |
| SHIFTING TUBE TO TRANSMISSION | ||
| 160 | A 3222600075 | CONNECTOR |
| SHIFTING ROD | ||
| 163 | A 3222680150 | BUSHING |
| SHIFTING ROD | ||
| 166 | A 3222680073 | LOCK |
| SHIFTING ROD | ||
| 166 | A 3222680073 | LOCK |
| SHIFTING ROD | ||
