Transporto priemonė: O 305 G; VIN numerio dalis: 307101
Grupė: 48 OIL TANK
| # | Kodas | Pavadinimas |
|---|---|---|
| 003 | A 3054800601 | OIL TANK |
| ENGINE OIL AUTOMATIC REPLENISHMENT | ||
| 20 L. | ||
| 006 | A 0004810403 | COVER |
| 009 | A 1104710280 | GASKET |
| 011 | A 0015429817 | SENDER UNIT |
| 013 | A 0005420880 | GASKET |
| 015 | A 0005420459 | SEAL WASHER |
| Repalced by: A 0169975848 | ||
| 015 | A 0169975848 | SEAL RING |
| 017 | N 000125008418 | WASHER |
| Repalced by: N 000125008443 | ||
| 017 | N 000125008443 | WASHER |
| OIL TANK TO SUBSTRUCTURE | ||
| 019 | N 912004008102 | LOCK WASHER |
| OIL TANK TO SUBSTRUCTURE | ||
| 021 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 021 | N 304017008016 | SCREW |
| OIL TANK TO SUBSTRUCTURE | ||
| 023 | N 007603012405 | SEAL RING |
| OIL TANK AND LINE | ||
| 025 | N 915036008202 | HOLLOW SCREW |
| OIL TANK AND LINE | ||
| 027 | A 3054800915 | OIL LINE |
| OIL TANK | ||
| 029 | N 916016012200 | CLAMP |
| OIL LINE TO BRACKET | ||
| 031 | N 000933006127 | SCREW |
| OIL LINE TO BRACKET | ||
| 033 | N 009021006205 | WASHER |
| Repalced by: N 009021006208 | ||
| 033 | N 009021006208 | WASHER |
| OIL LINE TO BRACKET | ||
| 035 | N 913004006003 | NUT |
| Repalced by: N 910113006001 | ||
| 035 | N 910113006001 | NUT |
| OIL LINE TO BRACKET | ||
| 037 | A 0004810260 | FILTER |
| Repalced by: A 0004810360 | ||
| 037 | A 0004810360 | FILTER |
| OIL | ||
| 039 | A 0004810062 | SEAL RING |
| 041 | A 0004810459 | FILTER ELEMENT |
| 043 | A 0004810058 | FILTER BOWL |
| TO 000 481 02 60 | ||
| 043 | A 0004810158 | FILTER BOWL |
| TO 000 481 03 60 | ||
| 045 | N 007603017102 | SEAL RING |
| OIL LINE TO FILTER | ||
| 047 | N 003901012007 | SCREW-IN FITTING |
| OIL LINE TO FILTER | ||
| 049 | A 3054810209 | BULKHEAD FITTING |
| Repalced by: A 3574810309 | ||
| 049 | A 3574810309 | FILLER NECK |
| OIL LINE TO FILTER | ||
| 051 | A 0004810191 | VALVE |
| SOLENOID | ||
| 053 | N 007603014405 | SEAL RING |
| VALVE TO BRACKET | ||
| 055 | A 3079970272 | FITTING |
| Repalced by: A 0029977472 | ||
| 055 | A 0029977472 | FITTING |
| VALVE TO BRACKET | ||
| 059 | A 3074810240 | BRACKET |
| SOLENOID VALVE | ||
| 063 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 063 | N 304017008016 | SCREW |
| BRACKET TO SUBSTRUCTURE | ||
| 065 | N 912004008102 | LOCK WASHER |
| BRACKET TO SUBSTRUCTURE | ||
| 067 | N 000934008010 | NUT |
| BRACKET TO SUBSTRUCTURE | ||
| 069 | A 3199970240 | SEAL RING |
| VALVE TO SUBSTRUCTURE | ||
| 071 | N 080705014002 | NUT |
| VALVE TO SUBSTRUCTURE | ||
| 073 | A 0004290627 | THRUST RING |
| VALVE | ||
| 075 | A 0079974245 | SEAL RING |
| VALVE | ||
| 083 | A 0119979382 | HOSE |
| FROM SOLENOID VALVE TO ENGINE OIL FILLER NECK | ||
| 085 | N 003902012001 | CONNECTION FITTING |
| Repalced by: A 0049971772 | ||
| 085 | A 0049971772 | FITTING |
| Repalced by: A 0029906171 | ||
| 085 | A 0029906171 | FITTING |
| 087 | N 915017012100 | UNION NUT |
| HOSE TO FILLER NECK | ||
| 089 | N 003861012007 | GLAND |
| Repalced by: A 0019901967 | ||
| 089 | A 0019901967 | SEAL CONE |
| HOSE TO FILLER NECK | ||
| 091 | A 0005423714 | INDICATOR |
| OIL SUPPLY | ||
| 093 | A 0009961772 | PULL |
| 095 | A 3054810440 | BRACKET |
| OIL LEVEL INDICATOR | ||
| 097 | N 007981004233 | SHEET METAL SCREW |
| Repalced by: N 000000000460 | ||
| 097 | N 000000000460 | SHEET METAL SCREW |
| BRACKET TO SUBSTRUCTURE | ||
| 101 | N 072571001000 | CLAMP |
| WIRE CABLE TO CAB FLOOR | ||
| 103 | N 007981004245 | SHEET METAL SCREW |
| Repalced by: N 007981004339 | ||
| 103 | N 007981004339 | SHEET METAL SCREW |
| Repalced by: N 000000000459 | ||
| 103 | N 000000000459 | SCREW |
| WIRE CABLE TO CAB FLOOR | ||
| 105 | A 3074290140 | BRACKET |
| WIRE CABLE | ||
| 107 | A 0019978490 | LOOM TIE |
| WIRE CABLE | ||
