Transporto priemonė: O 345,CONECTO H; VIN numerio dalis: 671042
Grupė: 92 SEATS - 040 REAR SEAT BENCH
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 6719205601 | REAR SEAT |
| WITH UPHOLSTERY | ||
| 005 | A 6719205701 | REAR SEAT |
| NO UPHOLSTERY | ||
| 005 | A 6719206601 | REAR SEAT |
| WITH UPHOLSTERY | ||
| 008 | A 6719205901 | REAR SEAT |
| WITH UPHOLSTERY | ||
| 008 | A 6719206001 | REAR SEAT |
| NO UPHOLSTERY | ||
| 011 | A 6719201820 | SEAT FRAMEWORK |
| 011 | A 6719201820 | SEAT FRAMEWORK |
| 014 | A 6719201920 | SEAT FRAMEWORK |
| 017 | A 6289420355 | SEAT SHELL |
| 017 | A 6289420355 | SEAT SHELL |
| 017 | A 6289420355 | SEAT SHELL |
| 017 | A 6289420155 | SEAT SHELL |
| 017 | A 6289420155 | SEAT SHELL |
| 020 | A 6289400921 | SEAT CUSHION |
| 020 | A 6289400921 | SEAT CUSHION |
| 020 | A 6289400221 | SEAT CUSHION |
| 023 | A 6289440980 | COVER |
| SEAT CUSHION | ||
| 023 | A 6289440980 | COVER |
| SEAT CUSHION | ||
| 023 | A 6289440980 | COVER |
| SEAT CUSHION | ||
| 026 | A 6289401331 | BACKREST |
| 026 | A 6289401331 | BACKREST |
| 026 | A 6289401331 | BACKREST |
| 029 | A 6289441080 | COVER |
| BACKREST | ||
| 029 | A 6289441080 | COVER |
| BACKREST | ||
| 029 | A 6289441080 | COVER |
| BACKREST | ||
| 032 | A 3579900112 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X12MM | ||
| 032 | A 3579900112 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X12MM | ||
| 032 | N 000000002241 | HEXALOBULAR BOLT |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X16 | ||
| 032 | N 000000002241 | HEXALOBULAR BOLT |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X16 | ||
| 032 | N 000000002925 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X12MM | ||
| 035 | N 007985004159 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X22MM | ||
| 035 | N 007985004159 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X22MM | ||
| 035 | N 000000002591 | SCREW |
| UPHOLSTERY TO SEAT SHELL | ||
| M4X25MM | ||
| 038 | A 6289420035 | COVERING |
| LEFT | ||
| 038 | A 6289420035 | COVERING |
| LEFT | ||
| 038 | A 6289420135 | COVERING |
| RIGHT | ||
| 038 | A 6289420135 | COVERING |
| RIGHT | ||
| 041 | N 914127003202 | SHEET METAL SCREW |
| MOUNTING, COVER | ||
| 041 | N 914127003202 | SHEET METAL SCREW |
| MOUNTING, COVER | ||
| 044 | N 304017008007 | SCREW |
| SEAT SHELL ON SEAT FRAME | ||
| M8X20MM | ||
| 044 | N 304017008007 | SCREW |
| SEAT SHELL ON SEAT FRAME | ||
| M8X20MM | ||
| 044 | N 910105008026 | SCREW |
| SEAT SHELL ON SEAT FRAME | ||
| M8X20MM | ||
| 047 | N 009021008213 | WASHER |
| SEAT SHELL ON SEAT FRAME | ||
| 047 | N 009021008213 | WASHER |
| SEAT SHELL ON SEAT FRAME | ||
| 050 | A 6719900052 | NUT |
| SEAT SHELL ON SEAT FRAME | ||
| 050 | A 6719900052 | NUT |
| SEAT SHELL ON SEAT FRAME | ||
| 050 | A 6719900352 | NUT |
| SEAT SHELL ON SEAT FRAME | ||
| 053 | A 6719871625 | PLASTIC SECTION |
| 053 | A 6719871625 | PLASTIC SECTION |
| 053 | A 6719871625 | PLASTIC SECTION |
| 060 | A 6719205101 | REAR SEAT |
| 060 | A 6719205401 | REAR SEAT |
| 063 | A 6719210206 | FRAME PART |
| 063 | A 6719210206 | FRAME PART |
| 066 | A 6719501721 | SEAT CUSHION |
| 066 | A 6719501521 | SEAT CUSHION |
| 069 | A 6719401531 | BACKREST |
| 069 | A 6719401531 | BACKREST |
| 072 | A 6719441390 | COVER |
| SEAT CUSHION | ||
| 072 | A 6719441390 | COVER |
| SEAT CUSHION | ||
| 075 | A 6719441691 | COVER |
| BACKREST | ||
| 075 | A 6719441691 | COVER |
| BACKREST | ||
| 075 | A 6719441791 | COVER |
| FOR BRACKREST,REAR | ||
| 075 | A 6719441791 | COVER |
| FOR BRACKREST,REAR | ||
| 078 | A 0009887078 | CLIP |
| 078 | A 0009887078 | CLIP |
| 081 | A 6279880069 | CLIP |
| 081 | A 6279880069 | CLIP |
| 084 | A 6299590464 | SPRING |
| 084 | A 6299590464 | SPRING |
| 087 | A 6299500073 | SCREW |
| 087 | A 6299500073 | SCREW |
| 090 | A 0029900520 | SCREW |
| M8X16MM | ||
| 090 | A 0029900520 | SCREW |
| M8X16MM | ||
| 093 | N 913023008003 | NUT |
| M8 | ||
| 093 | N 913023008003 | NUT |
| M8 | ||
| 096 | N 006797008244 | TOOTHED WASHER |
| 096 | N 006797008244 | TOOTHED WASHER |
| 099 | N 000125008443 | WASHER |
| 099 | N 000125008443 | WASHER |
| 110 | A 6719206401 | REAR SEAT |
| 113 | A 6719202020 | SEAT FRAMEWORK |
| 116 | N 910105008017 | SCREW |
| 119 | A 6719900352 | NUT |
| 122 | A 6719871625 | PLASTIC SECTION |
| 125 | A 6289400201 | SINGLE OCCUPANCY SEAT |
| 128 | A 6289410006 | FRAME PART |
| 131 | A 6289420057 | SEAT SHELL |
| 134 | A 6289430059 | BACKREST SHELL |
| 137 | A 6289430027 | CONNECTION |
| 140 | A 6289400021 | SEAT CUSHION |
| 143 | A 6289400546 | COVER |
| SEAT CUSHION | ||
| 146 | A 6289410014 | BRACKET |
| SEAT CUSHION | ||
| 149 | A 6289400031 | BACKREST |
| 152 | A 6289400147 | COVER |
| BACKREST | ||
| 155 | A 6289410014 | BRACKET |
| BACKREST | ||
| 158 | A 6289410071 | SCREW |
| 161 | A 6289410171 | SCREW |
| 164 | A 6289410016 | REINFORCEMENT |
| 167 | A 6719922401 | BUSHING |
| 38MM | ||
| 170 | N 000000001436 | SCREW |
| M10X60MM | ||
| 200 | A 6719206101 | REAR SEAT |
| WITH SAFETY BELT | ||
| 203 | A 6719204301 | REAR SEAT |
| WITHOUT SEAT BELT,LEFT | ||
| 203 | A 6719204401 | REAR SEAT |
| WITHOUT SEAT BELT,RIGHT | ||
| 203 | A 6719204601 | REAR SEAT |
| WITH SAFETY BELT,LEFT | ||
| 203 | A 6719204701 | REAR SEAT |
| WITH SAFETY BELT,RIGHT | ||
| 206 | A 6719505527 | SEAT FRAME |
| 209 | A 6719200266 | REINFORCEMENT |
| RIGHT | ||
| 212 | A 6719200166 | REINFORCEMENT |
| LEFT | ||
| 215 | A 6299500774 | TAKE-UP DEVICE |
| RIGHT,WITHOUT ADJUSTMENT | ||
| 215 | A 6299500574 | TAKE-UP DEVICE |
| RIGHT,FOR ADJUSTMENT | ||
| 218 | A 6299500674 | TAKE-UP DEVICE |
| LEFT,WITHOUT ADJUSTMENT | ||
| 218 | A 6299500474 | TAKE-UP DEVICE |
| LEFT,FOR ADJUSTMENT | ||
| 221 | A 0029900520 | SCREW |
| M8X16MM T45 | ||
| 224 | A 6299501631 | BACKREST |
| NARROW, LEFT | ||
| 224 | A 6299501631 | BACKREST |
| NARROW, LEFT | ||
| 224 | A 6299501731 | BACKREST |
| NARROW, RIGHT | ||
| 227 | A 6719400347 | COVER |
| BACKREST | ||
| 227 | A 6719400347 | COVER |
| BACKREST | ||
| 230 | A 6299590817 | BUSHING |
| INSIDE | ||
| 230 | A 6299590817 | BUSHING |
| INSIDE | ||
| 233 | A 6299503521 | SEAT CUSHION |
| 233 | A 6299503521 | SEAT CUSHION |
| 236 | A 6719400246 | COVER |
| SEAT CUSHION | ||
| 236 | A 6719400246 | COVER |
| SEAT CUSHION | ||
| 239 | A 0009887078 | CLIP |
| 239 | A 0009887078 | CLIP |
| 242 | A 6139140154 | HOOK |
| 242 | A 6139140154 | HOOK |
| 245 | A 6298600232 | CLAMP |
| LEFT | ||
| 245 | A 6298600232 | CLAMP |
| LEFT | ||
| 245 | A 6298600332 | CLAMP |
| RIGHT | ||
| 248 | A 6299590315 | PIN |
| LONG | ||
| 248 | A 6299590315 | PIN |
| LONG | ||
| 251 | A 6299590185 | GAS SPRING |
| 251 | A 6299590185 | GAS SPRING |
| 254 | A 0009590020 | SUPPORT |
| 254 | A 0009590020 | SUPPORT |
| 257 | A 6299500015 | PIN |
| AT REAR ON GAS-OPERATED SPRING MOUNTING | ||
| 257 | A 6299500015 | PIN |
| AT REAR ON GAS-OPERATED SPRING MOUNTING | ||
| 260 | A 6299590117 | BUSHING |
| AT REAR ON GAS-OPERATED SPRING MOUNTING | ||
| 260 | A 6299590117 | BUSHING |
| AT REAR ON GAS-OPERATED SPRING MOUNTING | ||
| 263 | A 0009911725 | WASHER |
| 263 | A 0009911725 | WASHER |
| 266 | A 6299590017 | BUSHING |
| 266 | A 6299590017 | BUSHING |
| 269 | A 3029590117 | WASHER |
| 269 | A 3029590117 | WASHER |
| 272 | A 0009590021 | STOP |
| 8,6MM | ||
| 272 | A 0009590021 | STOP |
| 8,6MM | ||
| 275 | A 6299501254 | LEVER |
| RIGHT,IN THE REAR | ||
| 278 | A 6299590028 | CAP |
| 281 | A 6299590364 | SPRING |
| 284 | A 6139500639 | PANELLING |
| 287 | A 6298600185 | SAFETY BELT |
| LEFT | ||
| 287 | A 6298600185 | SAFETY BELT |
| LEFT | ||
| 287 | A 6298600285 | SAFETY BELT |
| RIGHT | ||
| 290 | A 6298600069 | FASTENER |
| RIGID | ||
| 290 | A 6298600069 | FASTENER |
| RIGID | ||
| 293 | A 6298600169 | FASTENER |
| MOVABLE | ||
| 296 | A 6299590417 | BUSHING |
| 296 | A 6299591017 | BUSHING |
| 299 | A 6299510071 | SCREW |
| 302 | A 6299590115 | PIN |
| 305 | A 6299700103 | ARMREST LESS COVER |
| 308 | A 6299701838 | SUPPORT |
| 311 | A 0009930202 | SPRING |
| 314 | A 6299730117 | BUSHING |
| 317 | N 006799015003 | LOCK PLATE |
| 320 | N 000000000921 | ROLL PIN |
| 3,5X22MM | ||
| 323 | N 000000000922 | ROLL PIN |
| 6X22MM | ||
| 326 | A 6299590315 | PIN |
| 329 | N 001440014002 | WASHER |
| 332 | A 6299510071 | SCREW |
