| 005 |
A 0443000016 |
ACCELERATOR PEDAL |
|
Repalced by: A 3443000104
|
| 005 |
A 3443000104 |
ACCELERATOR PEDAL |
| 010 |
A 3213010050 |
BUSHING |
| 015 |
N 071412010300 |
GREASE NIPPLE |
| 020 |
A 3219900040 |
WASHER |
|
|
ACCELERATOR PEDAL TO BEARING BRACKET |
| 025 |
N 000471020000 |
LOCK RING |
|
|
ACCELERATOR PEDAL TO BEARING BRACKET |
| 030 |
A 3443000123 |
CLAMP |
| 035 |
N 000933008282 |
SCREW |
| 040 |
A 3443000006 |
ROLLER |
| 045 |
N 001443006200 |
PIN |
| 050 |
N 000125006420 |
WASHER |
|
N 000094001520 |
COTTER PIN |
| 060 |
A 3443000002 |
PLATE |
| 065 |
N 007985006515 |
SCREW |
| 070 |
N 000127006203 |
LOCK WASHER |
| 075 |
N 000934006006 |
NUT |
| 080 |
A 3443010082 |
PAD |
| 085 |
A 3213020815 |
SHAFT |
|
Repalced by: A 3213020004
|
| 085 |
A 3213020004 |
ROD |
| 090 |
N 000125006420 |
WASHER |
|
N 000094001203 |
COTTER PIN |
| 100 |
A 3213001025 |
LEVER |
|
Repalced by: A 3443000125
|
| 100 |
A 3443000125 |
LEVER |
| 105 |
A 3213010050 |
BUSHING |
| 110 |
N 900331006110 |
PULL ROD |
| 115 |
N 000934006006 |
NUT |
| 120 |
N 071752006001 |
YOKE |
| 125 |
A 3219910005 |
PIN |
|
N 000137006203 |
PART NAME MISSING |
|
N 000094001203 |
COTTER PIN |
| 130 |
N 000934006004 |
NUT |
|
|
L.H. THREAD |
| 135 |
A 3219960034 |
NUT |
| 140 |
N 000934006006 |
NUT |
| 145 |
N 900331006419 |
PULL ROD |
| 150 |
N 000934006006 |
NUT |
| 155 |
N 071805010202 |
BALL SOCKET |
| 160 |
N 071805010400 |
CIRCLIP |
| 165 |
A 3443000074 |
PIN |
| 170 |
N 000933008282 |
SCREW |
| 175 |
N 912004008100 |
LOCK WASHER |
| 180 |
H 983443000328 |
LEVER |
|
Repalced by: A 3443000528
|
| 180 |
A 3443000528 |
LEVER |
| 185 |
A 3213010150 |
BUSHING |
| 190 |
N 071803010209 |
BALL PIVOT |
| 195 |
A 3129901340 |
WASHER |
| 200 |
N 000471014000 |
LOCK RING |
| 205 |
N 071412008300 |
GREASE NIPPLE |
| 205 |
A 3459977288 |
GREASE NIPPLE |
| 210 |
H 983443000615 |
ROD |
|
Repalced by: A 3443001215
|
| 210 |
A 3443001215 |
ROD |
| 215 |
N 000934006006 |
NUT |
| 220 |
N 071805010202 |
BALL SOCKET |
| 225 |
N 071805010402 |
CIRCLIP |
|
A 3224300071 |
SCREW |
|
A 3454307071 |
SCREW |
|
A 1829930601 |
SPRING |
|
A 3209930301 |
SPRING |
| 240 |
H 983213000125 |
LEVER |
|
Repalced by: A 3213002625
|
| 240 |
A 3213002625 |
LEVER |
|
H 983213010150 |
BUSHING |
|
Repalced by: A 3213010450
|
|
A 3213010450 |
BUSHING |
|
H 983213010050 |
BUSHING |
|
Repalced by: A 3213010550
|
|
A 3213010550 |
BUSHING |
|
N 000933008358 |
SCREW |
|
N 912004008100 |
LOCK WASHER |
|
|
LEVER TO COWL |
|
N 000934008010 |
NUT |
| 245 |
H 983213000136 |
BEARING BRACKET |
|
Repalced by: A 3213000536
|
| 245 |
A 3213000536 |
BEARING BRACKET |
|
N 000936010007 |
NUT |
|
A 3129910120 |
BALL PIVOT |
|
Repalced by: N 071803010209
|
|
N 071803010209 |
BALL PIVOT |
|
N 071412010300 |
GREASE NIPPLE |
|
N 000933008282 |
SCREW |
|
N 913002008000 |
NUT |
|
|
BEARING BRACKET TO SUBSTRUCTURE |
|
N 900331006149 |
PULL ROD |
|
N 000934006006 |
NUT |
|
N 071752006001 |
YOKE |
|
N 071805010202 |
BALL SOCKET |
|
N 071805010402 |
CIRCLIP |
|
N 001434006017 |
PIN |
|
N 000094001203 |
COTTER PIN |
