Transporto priemonė: O 364,365; VIN numerio dalis: 364111
Grupė: 25 CLUTCH
| # | Kodas | Pavadinimas |
|---|---|---|
| 007 | A 0022509504 | CLUTCH PRESSURE PLATE |
| 007 | A 3442500104 | CLUTCH PRESSURE PLATE |
| Repalced by: A 3442507104 | ||
| 007 | A 3442507104 | CLUTCH PRESSURE PLATE |
| 012 | A 0032502004 | CLUTCH PRESSURE PLATE |
| 012 | A 3452507004 | CLUTCH PRESSURE PLATE |
| A 3642507004 | CLUTCH PRESSURE PLATE | |
| 022 | A 0002524312 | PRESSURE PLATE |
| 027 | A 0002525012 | PRESSURE PLATE |
| Repalced by: A 0002520412 | ||
| 027 | A 0002520412 | PRESSURE PLATE |
| TO 003 250 20 04,364 250 70 04 | ||
| 032 | A 0002522045 | FLANGE |
| Repalced by: A 0002520345 | ||
| A 0002520345 | FLANGE | |
| 037 | A 0002520827 | SPRING |
| 042 | A 0002520616 | SPINDLE |
| TO 003 250 20 04 | ||
| 047 | A 0002521616 | SPINDLE |
| A 0002520535 | SLEEVE | |
| TO 003 250 20 04,364 250 70 04 | ||
| 057 | A 0002522971 | SCREW |
| TO 003 250 20 04 | ||
| 057 | A 0002522971 | SCREW |
| TO 003 250 20 04 | ||
| A 0002522971 | SCREW | |
| 062 | A 0002521372 | NUT |
| Repalced by: A 0002523072 | ||
| 062 | A 0002523072 | NUT |
| TO 003 250 20 04 | ||
| 067 | A 0002522472 | NUT |
| Repalced by: A 0002523372 | ||
| 067 | A 0002523372 | NUT |
| 072 | N 000127005001 | LOCK WASHER |
| TO 003 250 20 04 | ||
| 077 | A 0002521073 | LOCK |
| TO 003 250 20 04,364 250 70 04 | ||
| 077 | A 0002521073 | LOCK |
| TO 003 250 20 04,364 250 70 04 | ||
| 082 | A 0002520473 | LOCK |
| 087 | A 0002520519 | LEAF SPRING |
| TO 003 250 20 04,364 250 70 04 | ||
| 092 | A 0002520619 | LEAF SPRING |
| 097 | A 0002524320 | PRESSURE SPRING |
| TO 003 250 20 04,364 250 70 04 | ||
| 102 | A 0002525120 | PRESSURE SPRING |
| 107 | A 0002520929 | CLAMP |
| TO 003 250 20 04 | ||
| 112 | A 0002520727 | SPRING |
| TO 003 250 20 04 | ||
| 117 | A 0002521927 | SPRING |
| TO 003 250 20 04 | ||
| 122 | A 0002520253 | SPACER TUBE |
| 127 | A 0002520932 | HOUSING |
| Repalced by: A 0002525432 | ||
| 127 | A 0002525432 | HOUSING |
| TO 003 250 20 04,364 250 70 04 | ||
| 132 | A 0002524332 | HOUSING |
| A 0002524432 | HOUSING | |
| 137 | A 0002524613 | RELEASE LEVER |
| TO 003 250 20 04 | ||
| 142 | A 0002523713 | RELEASE LEVER |
| 147 | A 0002522816 | SPINDLE |
| TO 003 250 20 04 | ||
| 152 | A 0002521716 | SPINDLE |
| 157 | A 0002520614 | BRACKET |
| TO 003 250 20 04 | ||
| 162 | A 0002522314 | BRACKET |
| 167 | A 0002520118 | ROLLER |
| TO 003 250 20 04 | ||
| 172 | A 0002520318 | ROLLER |
| 177 | N 006799007003 | LOCK PLATE |
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| TO 344 250 01 04 | ||
| 180 | H 983455860025 | REPAIR KIT |
| A 0315860025 | REPAIR KIT | |
| Repalced by: A 3505867025 | ||
| 181 | A 3505867025 | REPAIR KIT |
| TO 345 250 70 04,364 250 70 04 | ||
| 182 | A 3452507403 | CLUTCH DISC |
| IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: | ||
| 003 250 82 03 | ||
| 187 | A 3442507203 | CLUTCH DISC |
| IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: | ||
| 004 250 89 03 | ||
| A 3642507003 | CLUTCH DISC | |
| A 3455867025 | REPAIR KIT | |
| 193 | A 3455867125 | REPAIR KIT |
| 197 | N 000933008275 | SCREW |
| CLUTCH TO FLYWHEEL | ||
| 197 | A 3452520071 | SCREW |
| 202 | N 000931010409 | SCREW |
| CLUTCH TO FLYWHEEL | ||
| 207 | N 912004008100 | LOCK WASHER |
| CLUTCH TO FLYWHEEL | ||
| 212 | N 000127010202 | LOCK WASHER |
| CLUTCH TO FLYWHEEL | ||
| 217 | A 3452500005 | HOUSING |
| Repalced by: A 3642507005 | ||
| 217 | A 3642507005 | HOUSING |
| A 3642510901 | BELL HOUSING | |
| 222 | A 3452500205 | HOUSING |
| Repalced by: A 3512500005 | ||
| 222 | A 3512500005 | HOUSING |
| 227 | A 3442500205 | HOUSING |
| Repalced by: A 3642500705 | ||
| 227 | A 3642500705 | HOUSING |
| A 3442510201 | BELL HOUSING | |
| 232 | A 3142540074 | PIN |
| STARTING MOTOR TO BELL HOUSING | ||
| 237 | N 000939010116 | STUD BOLT |
| STARTING MOTOR TO BELL HOUSING | ||
| A 0009904805 | STUD | |
| STARTING MOTOR TO BELL HOUSING | ||
| A 0009902805 | STUD | |
| Repalced by: A 0009902605 | ||
| A 0009902605 | STUD | |
| Repalced by: A 0009904805 | ||
| A 0009904805 | STUD | |
| STARTING MOTOR TO BELL HOUSING | ||
| 247 | A 3432510050 | BUSHING |
| TOP | ||
| 252 | A 3439920003 | BUSHING |
| 257 | N 005419025101 | FELT RING |
| 262 | A 3432930027 | COVER PLATE |
| 267 | A 3432510150 | BUSHING |
| BOTTOM | ||
| 272 | A 3439920103 | BUSHING |
| A 3172930177 | WASHER | |
| 0.8 MM | ||
| A 3172930277 | WASHER | |
| 0.9 MM | ||
| A 3172930377 | WASHER | |
| 1.0 MM | ||
| A 3172930477 | WASHER | |
| 1.1 MM | ||
| A 3172930577 | WASHER | |
| 1.2 MM | ||
| A 3172930677 | WASHER | |
| 1.3 MM | ||
| A 3452937011 | RELEASE YOKE | |
| Repalced by: A 3452930111 | ||
| A 3452930111 | RELEASE YOKE | |
| A 3432930001 | RELEASE SHAFT | |
| A 0009973683 | SLEEVE | |
| N 000137014203 | SPRING WASHER | |
| N 000936014010 | NUT | |
| N 071412008300 | GREASE NIPPLE | |
| A 3459977288 | GREASE NIPPLE | |
| A 3432930052 | SPACER WASHER | |
| RELEASE YOKE TO SHAFT | ||
| N 000931012283 | SCREW | |
| RELEASE YOKE TO SHAFT | ||
| N 000127012201 | LOCK WASHER | |
| RELEASE YOKE TO SHAFT | ||
| N 000471024000 | LOCK RING | |
| RELEASE YOKE TO SHAFT | ||
| N 000470052001 | EXPANSION PLUG | |
| TO PLUG THE BORES | ||
| 332 | N 900170012005 | SCREW |
| BELL HOUSING TO ENGINE | ||
| 337 | N 000931012277 | SCREW |
| BELL HOUSING TO ENGINE | ||
| 342 | N 000127012201 | LOCK WASHER |
| BELL HOUSING TO ENGINE | ||
| N 912004016101 | LOCK WASHER | |
| BELL HOUSING TO ENGINE | ||
| N 000934016026 | NUT | |
| BELL HOUSING TO ENGINE | ||
| 357 | A 3452500115 | RELEASE BEARING |
| Repalced by: A 3402500215 | ||
| 357 | A 3402500215 | RELEASE BEARING |
| 362 | A 3052540033 | COVER |
| TO 345 250 01 15 | ||
| 362 | A 3452547033 | COVER |
| TO 345 250 01 15 | ||
| 367 | A 0002540020 | RELEASE BEARING |
| 367 | A 0002540120 | RELEASE BEARING |
| 367 | A 3452547020 | RELEASE BEARING |
| 372 | A 3129870110 | STRIP |
| A 3409830010 | STRIP | |
| 377 | A 3022930011 | RELEASE YOKE |
| Repalced by: A 3452540508 | ||
| 377 | A 3452540508 | RELEASE LEVER |
| 382 | A 3402540013 | SPRING LOCK |
| 387 | A 3442500115 | RELEASE BEARING |
| 392 | A 3042500315 | RELEASE BEARING |
| 397 | A 3059971982 | HOSE |
| RELEASE BEARING LUBRICATION | ||
| 397 | A 3089977182 | HOSE |
| RELEASE BEARING LUBRICATION | ||
| A 3079970082 | HOSE | |
| RELEASE BEARING LUBRICATION | ||
| 402 | N 003871004100 | UNION SCREW |
| RELEASE BEARING LUBRICATION | ||
| 407 | N 003862004001 | DOUBLE TAPER RING |
| RELEASE BEARING LUBRICATION | ||
| 412 | A 0009973683 | SLEEVE |
| RELEASE BEARING LUBRICATION | ||
| 417 | N 000127014201 | LOCK WASHER |
| RELEASE BEARING LUBRICATION | ||
| 422 | N 000934014020 | NUT |
| RELEASE BEARING LUBRICATION | ||
| 427 | N 071412008300 | GREASE NIPPLE |
| RELEASE BEARING LUBRICATION | ||
| 427 | A 3459977288 | GREASE NIPPLE |
| 432 | A 3122541013 | SPRING LOCK |
| RELEASE COLLAR TO RELEASE YOKE | ||
| A 3402540013 | SPRING LOCK | |
| RELEASE COLLAR TO RELEASE YOKE | ||
| 442 | A 3439900040 | WASHER |
| RELEASE COLLAR TO RELEASE YOKE | ||
| 447 | A 3602510004 | END COVER |
| TOP | ||
| 447 | A 3602510004 | END COVER |
| TOP | ||
| 452 | N 000933006223 | SCREW |
| END COVER TO BELL HOUSING | ||
| 452 | N 000933006223 | SCREW |
| END COVER TO BELL HOUSING | ||
| 457 | N 000137006002 | SPRING WASHER |
| END COVER TO BELL HOUSING | ||
| 457 | N 000137006002 | SPRING WASHER |
| END COVER TO BELL HOUSING | ||
| 462 | A 3122511006 | PROTECTIVE PLATE |
| Repalced by: A 3522510106 | ||
| 462 | A 3522510106 | PROTECTIVE PLATE |
| BELL HOUSING | ||
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: | ||
| 352 250 00 55 | ||
| 467 | A 3522510002 | BELL HOUSING |
| Repalced by: A 3812510102 | ||
| 467 | A 3812510102 | BELL HOUSING |
| LOWER PART | ||
| A 3129971681 | GROMMET | |
| 477 | N 000933006223 | SCREW |
| PROTECTIVE PLATE TO BELL HOUSING | ||
| 482 | N 000137006002 | SPRING WASHER |
| PROTECTIVE PLATE TO BELL HOUSING | ||
| 487 | A 3522510004 | END COVER |
| 492 | N 912004008100 | LOCK WASHER |
| COVER | ||
| 497 | N 000933008282 | SCREW |
| COVER | ||
| 502 | A 3452500043 | BRACKET |
| OUTSIDE | ||
| 507 | A 3522540040 | BRACKET |
| INSIDE | ||
| 512 | A 3522540135 | BEARING |
| 517 | N 000933008282 | SCREW |
| BRACKET TO BELL HOUSING | ||
| 522 | N 912004008100 | LOCK WASHER |
| BRACKET TO BELL HOUSING | ||
| 527 | A 3452937011 | RELEASE YOKE |
| Repalced by: A 3452930111 | ||
| 527 | A 3452930111 | RELEASE YOKE |
| 532 | A 3172930377 | WASHER |
| 537 | A 3432930001 | RELEASE SHAFT |
| 542 | N 000931012283 | SCREW |
| RELEASE LEVER TO SHAFT | ||
| 547 | N 000127012201 | LOCK WASHER |
| RELEASE LEVER TO SHAFT | ||
| 552 | A 3432930052 | SPACER WASHER |
| RELEASE LEVER TO SHAFT | ||
| 557 | N 000471024000 | LOCK RING |
| RELEASE LEVER TO SHAFT | ||
| 562 | A 3642907234 | LEVER |
| CLUTCH ACTUATION | ||
| 567 | A 3339910015 | BALL PIVOT |
| CLUTCH ACTUATION | ||
| 570 | N 000934014024 | NUT |
| 572 | N 000931010409 | SCREW |
| LEVER TO RELEASE SHAFT | ||
| 577 | N 000127010202 | LOCK WASHER |
| LEVER TO RELEASE SHAFT | ||
| 582 | N 000934010005 | NUT |
| LEVER TO RELEASE SHAFT | ||
| 587 | A 3352500055 | COVER |
| 592 | N 912004016101 | LOCK WASHER |
| BELL HOUSING TO ENGINE | ||
| 597 | N 000934016026 | NUT |
| BELL HOUSING TO ENGINE | ||
| 602 | N 000931012114 | SCREW |
| BELL HOUSING TO OIL PAN | ||
| 607 | N 000127012201 | LOCK WASHER |
| BELL HOUSING TO OIL PAN | ||
| 612 | A 3645207043 | PROTECTIVE PLATE |
| Repalced by: A 3642507040 | ||
| 612 | A 3642507040 | HOUSING |
| REAR | ||
| 617 | A 3045240085 | DAMPING STRIP |
| AT ENGINE POROTECTIVE PLATE | ||
| 622 | A 3445240085 | DAMPING STRIP |
| AT ENGINE POROTECTIVE PLATE | ||
| TO 364 520 70 43 | ||
| A 3642517080 | GASKET | |
| AT ENGINE POROTECTIVE PLATE | ||
| TO 364 250 70 40 | ||
| 627 | A 3155200064 | COVER |
| TO 364 520 70 43 | ||
| 632 | A 3155200165 | LATCH |
| 637 | N 007338004104 | RIVET |
| AT ENGINE POROTECTIVE PLATE | ||
| 642 | N 000125004313 | WASHER |
| AT ENGINE POROTECTIVE PLATE | ||
| 647 | A 3129971681 | GROMMET |
| AT ENGINE POROTECTIVE PLATE | ||
| 652 | A 3642507043 | BRACKET |
| 657 | N 000933008145 | SCREW |
| ENGINE PROTECTIVE PLATE TO BRACKET | ||
| 662 | N 912004008100 | LOCK WASHER |
| ENGINE PROTECTIVE PLATE TO BRACKET | ||
| 667 | N 000934008013 | NUT |
| ENGINE PROTECTIVE PLATE TO BRACKET | ||
