Transporto priemonė: O 371 UL; VIN numerio dalis: 364304
Grupė: 52 CHASSIS SHEET METAL - 120 AIR INTAKE
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3640909801 | AIR CLEANER |
| 005 | A 3450909401 | AIR CLEANER |
| 006 | A 3740907001 | AIR CLEANER |
| 008 | A 3640909301 | AIR CLEANER |
| 008 | A 3640907104 | AIR CLEANER |
| 008 | A 3640907004 | AIR CLEANER |
| 011 | A 3450909201 | AIR CLEANER |
| 014 | A 0010940303 | FILTER BOWL |
| TO 345 090 94 01,364 090 71 04 | ||
| 014 | A 3440947003 | FILTER BOWL |
| TO 364 090 70 04 | ||
| 014 | A 3500947103 | FILTER BOWL |
| 017 | A 0010945204 | FILTER ELEMENT |
| 017 | A 3500947004 | FILTER ELEMENT |
| TO 364 090 98 01,93 01 | ||
| 017 | A 3500947004 | FILTER ELEMENT |
| TO 374 090 70 01 | ||
| 020 | A 3450947004 | FILTER ELEMENT |
| TO 364 090 70 04 | ||
| 023 | N 000936016003 | NUT |
| TO 364 090 70 04 | ||
| 026 | N 913002008001 | NUT |
| 026 | A 3500947072 | NUT |
| 029 | A 0000948703 | FILTER BOWL |
| 029 | A 3500947003 | FILTER BOWL |
| 032 | A 3760947165 | VALVE |
| 035 | A 3640947041 | BRACKET |
| 035 | A 0000947941 | BRACKET |
| 038 | N 000084008172 | SCREW |
| TO 364 090 98 01,93 01 | ||
| 038 | N 007985008160 | SCREW |
| TO 345 090 94 01,364 090 71 04 | ||
| 041 | A 1109900052 | NUT |
| TO 364 090 98 01,93 01 | ||
| 044 | A 0010940055 | FASTENER |
| TO 364 090 70 04 | ||
| 047 | A 3500907072 | NUT |
| PARTS KIT | ||
| 050 | A 3645407145 | SWITCH |
| 051 | A 3865207067 | STRAP |
| AIR CLEANER | ||
| 052 | A 3865287021 | STRAP |
| AIR CLEANER | ||
| 053 | A 3645289240 | BRACKET |
| AIR CLEANER | ||
| 054 | N 000933008288 | SCREW |
| STRAP TO SUPPORT | ||
| M 8X25 | ||
| 055 | N 000933010294 | SCREW |
| AIR CLEANER TO SUBSTRUCTURE | ||
| M 10X20 | ||
| 056 | N 000934010007 | NUT |
| AIR CLEANER TO SUBSTRUCTURE | ||
| 057 | A 3445280185 | RUBBER MOUNTING |
| AIR CLEANER TO BRACKET | ||
| 058 | N 009021010102 | WASHER |
| AIR CLEANER TO BRACKET | ||
| 059 | N 000127010202 | LOCK WASHER |
| AIR CLEANER TO BRACKET | ||
| 062 | N 000934010000 | NUT |
| AIR CLEANER TO BRACKET | ||
| 065 | A 3440107570 | BREATHER PIPE |
| AIR CLEANER | ||
| 068 | N 080705026000 | NUT |
| AIR CLEANER | ||
| 071 | N 900271025021 | HOSE |
| AIR CLEANER | ||
| 074 | A 3449978590 | LOOM TIE |
| AIR CLEANER | ||
| 074 | N 916018025000 | CLAMP |
| AIR CLEANER | ||
| 077 | A 3645287682 | HOSE |
| ENGINE BREATHING | ||
| 080 | A 3645280082 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 080 | A 3645280082 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 080 | A 3645280182 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 080 | A 3645280182 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 083 | A 3648320188 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 083 | A 3648320188 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 083 | A 3645287482 | HOSE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 086 | A 3649979582 | HOSE |
| 089 | A 3645209201 | AIR INTAKE PIPE |
| AIR INTAKE PIPE | ||
| 092 | A 3645209501 | AIR INTAKE PIPE |
| 095 | A 3645289609 | PIPE |
| AIR INTAKE PIPE | ||
| 098 | A 3645288940 | BRACKET |
| AIR INTAKE PIPE | ||
| 101 | N 000933010294 | SCREW |
| BRACKET TO STRUT | ||
| 104 | N 000127010202 | LOCK WASHER |
| BRACKET TO STRUT | ||
| 107 | N 000933008145 | SCREW |
| BRACKET TO AIR INTAKE PIPE | ||
| 110 | N 000125008417 | WASHER |
| BRACKET TO AIR INTAKE PIPE | ||
| 113 | N 912004008100 | LOCK WASHER |
| BRACKET TO AIR INTAKE PIPE | ||
| 116 | N 000934008010 | NUT |
| BRACKET TO AIR INTAKE PIPE | ||
| 119 | N 900271025021 | HOSE |
| ENGINE BREATHING | ||
| 119 | A 3645287682 | HOSE |
| ENGINE BREATHING | ||
| 122 | A 3449978590 | LOOM TIE |
| ENGINE BREATHING | ||
| 122 | N 916018025000 | CLAMP |
| ENGINE BREATHING | ||
| 125 | A 3449979890 | CLAMP |
| 125 | A 3449979790 | CLAMP |
| 125 | A 3649970090 | LOOM TIE |
| CONNECTING PIPE TO AIR CLEANER | ||
| 125 | A 3649970090 | LOOM TIE |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 125 | A 3649970090 | LOOM TIE |
| HOSE TO AIR CLEANER | ||
| 125 | A 3649970090 | LOOM TIE |
| HOSE TO PIPE ELBOW | ||
| 125 | N 916018130000 | CLAMP |
| CONNECTING PIPE TO AIR CLEANER | ||
| 125 | N 916018130000 | CLAMP |
| AIR CLEANER AND AIR INTAKE PIPE | ||
| 125 | N 916018130000 | CLAMP |
| HOSE TO AIR CLEANER | ||
| 125 | N 916018130000 | CLAMP |
| HOSE TO PIPE ELBOW | ||
| 128 | A 3649970190 | LOOM TIE |
| CONNECTING PIPE TO INTAKE PIPE | ||
| 128 | A 3649970190 | LOOM TIE |
| CONNECTING PIPE TO INTAKE PIPE | ||
| 128 | N 916018160000 | CLAMP |
| CONNECTING PIPE TO INTAKE PIPE | ||
| 128 | N 916018160000 | CLAMP |
| CONNECTING PIPE TO INTAKE PIPE | ||
| 129 | A 3645209601 | AIR INTAKE PIPE |
| Repalced by: A 3645209801 | ||
| 129 | A 3645209801 | AIR INTAKE PIPE |
| 131 | A 3451410707 | PIPE ELBOW |
| AT ENGINE | ||
| 134 | A 3645208006 | PIPE ELBOW |
| AT ENGINE | ||
| 137 | N 000933010294 | SCREW |
| M 10X20 | ||
| 140 | N 000127010202 | LOCK WASHER |
| 143 | A 3909970282 | HOSE |
| 146 | A 4221340056 | FITTING |
| 149 | N 007603026101 | SEAL RING |
| 152 | A 3449979390 | CLAMP |
| 152 | A 0019975090 | LOOM TIE |
| 153 | N 000933008290 | SCREW |
| AIR INTAKE PIPE TO BRACKET | ||
| M 8X16 | ||
| 154 | N 000125008417 | WASHER |
| AIR INTAKE PIPE TO BRACKET | ||
| 155 | N 913004008001 | NUT |
| AIR INTAKE PIPE TO BRACKET | ||
| 156 | A 3640947782 | HOSE |
| FROM AIR CLEANER TO PIPE ELBOW | ||
| 156 | A 3640947782 | HOSE |
| FROM AIR CLEANER TO PIPE ELBOW | ||
| 158 | A 3645287482 | HOSE |
| FROM AIR CLEANER TO PIPE ELBOW | ||
| 161 | A 3649979382 | HOSE |
| FROM PIPE ELBOW TO ENGINE CONNECTION | ||
| 164 | A 3449979890 | CLAMP |
| HOSE TO PIPE ELBOW AND TO ENGINE CONNECTION | ||
| 167 | A 3640947282 | HOSE |
| FROM AIR CLEANER TO PIPE ELBOW | ||
| 170 | A 3449979990 | LOOM TIE |
| HOSE TO AIR CLEANER AND TO INTAKE PIPE | ||
| 170 | A 3449979990 | LOOM TIE |
| HOSE TO AIR CLEANER AND TO INTAKE PIPE | ||
