Transporto priemonė: O 371 UL; VIN numerio dalis: 364304
Grupė: 49 EXHAUST SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3644908719 | EXHAUST PIPE |
| 008 | A 3644908119 | EXHAUST PIPE |
| FRONT TOP | ||
| 011 | A 3644908619 | EXHAUST PIPE |
| FRONT TOP | ||
| 014 | N 000960012041 | SCREW |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| M 12X45 | ||
| 017 | A 3644907420 | EXHAUST PIPE |
| FRONT | ||
| 017 | A 3644907520 | EXHAUST PIPE |
| FRONT | ||
| 017 | A 3644907620 | EXHAUST PIPE |
| FRONT | ||
| 020 | A 3644907320 | EXHAUST PIPE |
| FRONT | ||
| 023 | A 3644929201 | FRONT EXHAUST PIPE |
| FRONT | ||
| 026 | N 071555094500 | CLAMP |
| Repalced by: A 3644927040 | ||
| 026 | A 3644927040 | CLAMP |
| EXHAUST PIPE TO MUFFLER | ||
| 029 | N 000931010205 | SCREW |
| EXHAUST PIPE TO MUFFLER | ||
| 030 | N 000125010513 | WASHER |
| EXHAUST PIPE TO MUFFLER | ||
| 032 | N 000934010000 | NUT |
| EXHAUST PIPE TO MUFFLER | ||
| 033 | N 000931012046 | SCREW |
| (FLANGE) | ||
| "M12 X 60" | ||
| 034 | N 999901012000 | NUT |
| (FLANGE) | ||
| "M12" | ||
| 035 | A 3644907801 | EXHAUST MUFFLER |
| Repalced by: A 3644908001 | ||
| 035 | A 3644908001 | EXHAUST MUFFLER |
| 035 | A 3644908301 | EXHAUST MUFFLER |
| 041 | A 3054920082 | DAMPING PAD |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| 044 | A 3179910840 | SPACER TUBE |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| 044 | A 3179910840 | SPACER TUBE |
| EXHAUST MUFFLER TO SUBSTRUCTURE | ||
| 047 | A 3174920018 | BASE PLATE |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| 047 | A 3174920018 | BASE PLATE |
| EXHAUST MUFFLER TO SUBSTRUCTURE | ||
| 050 | A 3174920083 | INSULATION |
| Repalced by: A 6644927383 | ||
| 050 | A 6644927383 | INSULATION |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| 053 | N 000931008086 | SCREW |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| M 8X50 | ||
| 056 | N 000931008061 | SCREW |
| EXHAUST MUFFLER TO SUBSTRUCTURE | ||
| M 8X40 | ||
| 059 | N 913004008002 | NUT |
| EXHAUST MUFFLER TO DAMPING PAD | ||
| 059 | N 913004008002 | NUT |
| EXHAUST MUFFLER TO SUBSTRUCTURE | ||
| 062 | A 3644927114 | END PIECE |
| REAR | ||
| 065 | A 3644917112 | CHROMIUM JACKET |
| 068 | N 007513003206 | TAPPING SCREW |
| CHROMIUM JACKET TO REAR EXHAUST PIPE | ||
| 071 | N 071555104500 | CLAMP |
| Repalced by: A 3644927140 | ||
| 071 | A 3644927140 | CLAMP |
| REAR EXHAUST PIPE TO MUFFLER | ||
| 074 | N 000931010171 | SCREW |
| REAR EXHAUST PIPE TO MUFFLER | ||
| 075 | N 000125010513 | WASHER |
| REAR EXHAUST PIPE TO MUFFLER | ||
| 077 | N 000934010000 | NUT |
| REAR EXHAUST PIPE TO MUFFLER | ||
| 080 | A 3445280185 | RUBBER MOUNTING |
| Repalced by: A 0019873140 | ||
| 080 | A 0019873140 | RUBBER BUFFER |
| REAR EXHAUST PIPE TO SUBSTRUCTURE | ||
| 083 | N 000125010517 | WASHER |
| REAR EXHAUST PIPE TO SUBSTRUCTURE | ||
| 086 | N 913004010002 | NUT |
| REAR EXHAUST PIPE TO SUBSTRUCTURE | ||
| 089 | A 3644907430 | PROTECTIVE PLATE |
| (HEAT SHIELD) | ||
| 092 | A 3644907530 | PROTECTIVE PLATE |
| (HEAT SHIELD) | ||
| 095 | A 3644907540 | BRACKET |
| (HEAT SHIELD) | ||
| 098 | N 000933006220 | SCREW |
| HEAT SHIELD TO BRACKET | ||
| 101 | N 000933006221 | SCREW |
| HEAT SHIELD TO BRACKET | ||
| 104 | N 000127006203 | LOCK WASHER |
| HEAT SHIELD TO BRACKET | ||
| 107 | N 000125006420 | WASHER |
| HEAT SHIELD TO BRACKET | ||
