Transporto priemonė: O 405 GT; VIN numerio dalis: 612633
Grupė: 24 ENGINE SUSPENSION
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3572420307 | BEARING BRACKET |
| REAR RUBBER MOUNTING | ||
| 008 | N 308676014002 | SCREW |
| BEARING BRACKET TO SUBSTRUCTURE | ||
| 011 | N 910113014000 | NUT |
| BEARING BRACKET TO SUBSTRUCTURE | ||
| Repalced by: N 000000005585 | ||
| 011 | N 000000005585 | HEXAGON NUT |
| BEARING BRACKET TO SUBSTRUCTURE | ||
| 014 | A 3072400017 | RUBBER MOUNTING |
| FRONT | ||
| 014 | A 3072400117 | RUBBER MOUNTING |
| FRONT | ||
| 017 | N 000961012097 | SCREW |
| RUBBER MOUNTING TO BEARING BRACKET | ||
| 020 | N 912004012100 | LOCK WASHER |
| RUBBER MOUNTING TO BEARING BRACKET | ||
| 023 | N 000961014064 | SCREW |
| RUBBER MOUNTING TO ENGINE FRONT SUPPORTING ARM | ||
| 026 | N 912004014100 | LOCK WASHER |
| RUBBER MOUNTING TO ENGINE FRONT SUPPORTING ARM | ||
| 029 | A 0002402348 | ENGINE VIBRATION ABSORBER |
| 029 | A 0002402248 | ENGINE VIBRATION ABSORBER |
| 032 | A 0002410150 | BUSHING |
| 035 | A 0003234385 | RUBBER MOUNTING |
| 038 | N 000939012117 | STUD BOLT |
| ENGINE SHOCK ABSORBER TO BEARING BRACKET | ||
| 041 | N 000125013022 | WASHER |
| ENGINE SHOCK ABSORBER TO BEARING BRACKET | ||
| 044 | N 910113012002 | NUT |
| ENGINE SHOCK ABSORBER TO BEARING BRACKET | ||
| 047 | A 3572420440 | BRACKET |
| ENGINE SHOCK ABSORBER | ||
| 050 | N 000912012165 | SCREW |
| BRACKET TO ENGINE SUPPORTING ARM | ||
| 053 | N 912004012100 | LOCK WASHER |
| BRACKET TO ENGINE SUPPORTING ARM | ||
| 056 | N 000960012246 | SCREW |
| Repalced by: N 000960012353 | ||
| 056 | N 000960012353 | SCREW |
| ENGINE SHOCK ABSORBER TO BRACKET | ||
| 059 | N 910113012002 | NUT |
| ENGINE SHOCK ABSORBER TO BRACKET | ||
| 062 | A 6122400201 | ENGINE SUPPORT |
| FRONT | ||
| 065 | A 6452400018 | RUBBER MOUNTING |
| CENTRAL | ||
| 065 | A 6452400118 | RUBBER MOUNTING |
| CENTRAL | ||
| 065 | A 6452400218 | RUBBER MOUNTING |
| CENTRAL | ||
| 068 | A 6122400101 | ENGINE SUPPORT |
| REAR | ||
| 071 | A 6282400417 | RUBBER MOUNTING |
| REAR | ||
| 074 | A 3572400418 | RUBBER MOUNTING |
| FRONT RIGHT | ||
| 074 | A 3572400618 | RUBBER MOUNTING |
| FRONT LEFT | ||
| 077 | N 000961012097 | SCREW |
| RUBBER MOUNTING TO BEARING BRACKET | ||
| 080 | A 3572410176 | WASHER |
| RUBBER MOUNTING TO BEARING BRACKET | ||
| 083 | A 3572420605 | SUPPORTING ARM |
| 083 | A 3572420705 | SUPPORTING ARM |
| 086 | N 000961016077 | SCREW |
| SUPPORTING ARM TO TRANSMISSION CASE | ||
| 089 | A 3579900240 | WASHER |
| SUPPORTING ARM TO TRANSMISSION CASE | ||
| 092 | N 308676016015 | SCREW |
| RUBBER MOUNT & ENGINE SHOCK ABSORBER BRACKET TO BELL HOUSING SUPPORTING ARM | ||
| 095 | A 3529902440 | WASHER |
| RUBBER MOUNT & ENGINE SHOCK ABSORBER BRACKET TO BELL HOUSING SUPPORTING ARM | ||
| 098 | A 3572420640 | BRACKET |
| ENGINE SHOCK ABSORBER | ||
| 101 | A 0002402348 | ENGINE VIBRATION ABSORBER |
| ENGINE SUSPENSION,CLUTCH END | ||
| 101 | A 0002402248 | ENGINE VIBRATION ABSORBER |
| ENGINE SUSPENSION,CLUTCH END | ||
| 104 | A 0002410150 | BUSHING |
| 107 | A 0003234385 | RUBBER MOUNTING |
| 110 | N 000939012117 | STUD BOLT |
| ENGINE SHOCK ABSORBER TO BRACKET | ||
| 113 | N 000125013022 | WASHER |
| ENGINE SHOCK ABSORBER TO BRACKET | ||
| 116 | N 910113012002 | NUT |
| ENGINE SHOCK ABSORBER TO BRACKET | ||
| 119 | N 000961012208 | SCREW |
| ENGINE SHOCK ABSORBER TO SUBSTRUCTURE | ||
| 122 | N 000125013022 | WASHER |
| ENGINE SHOCK ABSORBER TO SUBSTRUCTURE | ||
| 125 | N 910113012002 | NUT |
| ENGINE SHOCK ABSORBER TO SUBSTRUCTURE | ||
| 128 | A 3575401371 | CONSOLE |
| LEFT FRONT | ||
| 128 | A 3575401271 | CONSOLE |
| RIGHT REAR | ||
| 131 | A 3575401471 | CONSOLE |
| LEFT REAR AND RIGHT FRONT | ||
| 134 | N 910105012020 | SCREW |
| 137 | N 910112012001 | NUT |
| Repalced by: N 913023012002 | ||
| 137 | N 913023012002 | NUT |
