Transporto priemonė: O 405 NUE; VIN numerio dalis: 612426

Grupė: 52 CHASSIS SHEET METAL - 160 AIR INTAKE AND AIR CLEANER

#	Kodas	Pavadinimas
005	A 0170942002	AIR CLEANER
008	A 0180943702	AIR CLEANER
011	A 0010947904	FILTER ELEMENT
	A 0010940980	GASKET
014	A 0010949880	GASKET
017	A 0009901550	NUT
020	A 0000941255	FASTENER
023	A 0000940276	WASHER
		FELT
026	A 0010941203	FILTER BOWL
029	A 0010940903	FILTER BOWL
032	A 0000940968	MAINTENANCE INDICATOR
035	A 0000945368	VACUUM BOX
038	A 0010948506	COVER
041	A 0000940089	CAP
		AIR CLEANER
044	A 0009885511	BUFFER
		AIR CLEANER TO SUBSTRUCTURE
047	A 3225040212	RUBBER MOUNTING
		AIR CLEANER
050	A 0019875240	RUBBER BUFFER
		AIR INTAKE PIPE
053	N 304017008016	SCREW
		BUFFER TO AIR CLEANER
		M 8X16
053	N 000933008145	SCREW
		BUFFER TO SUBSTRUCTURE
056	N 009021008213	WASHER
		BUFFER TO SUBSTRUCTURE
	Repalced by: N 000000003250
056	N 000000003250	WASHER
		BUFFER TO SUBSTRUCTURE
056	N 009021008213	WASHER
		BUFFER TO AIR CLEANER
	Repalced by: N 000000003250
056	N 000000003250	WASHER
		BUFFER TO AIR CLEANER
059	N 000125008418	WASHER
	Repalced by: N 000125008443
059	N 000125008443	WASHER
		RUBBER MOUNTING TO AIR CLEANER
062	N 910113008003	NUT
		RUBBER MOUNTING TO AIR CLEANER
062	N 910113008003	NUT
		BUFFER TO SUBSTRUCTURE
065	A 3075280291	BOOT
		FROM AIR INTAKE PIPE TO AIR CLEANER
068	A 0010943406	COVER
		FROM AIR INTAKE PIPE TO AIR CLEANER
071	A 3575202201	AIR INTAKE PIPE
		FROM AIR INTAKE PIPE TO AIR CLEANER
071	A 6125200001	AIR INTAKE PIPE
		FROM AIR INTAKE PIPE TO AIR CLEANER
071	A 6125200001	AIR INTAKE PIPE
		FROM AIR INTAKE PIPE TO AIR CLEANER
074	A 3575201401	AIR INTAKE PIPE
		AIR CLEANER
077	A 3575201201	AIR INTAKE PIPE
		FROM AIR CLEANER TO TURBOCHARGER
077	A 3575201601	AIR INTAKE PIPE
		FROM AIR CLEANER TO TURBOCHARGER
080	A 6525280082	HOSE
		CONNECTION OF AIR INTAKE PIPES
083	A 3575280082	HOSE
		AIR INTAKE PIPE TO TURBOCHARGER
086	A 0010948482	HOSE
		FROM AIR CLEANER TO ENGINE INTAKE PIPE
089	N 900271132005	HOSE
		CONNECTION OF AIR INTAKE PIPES
		132X144X100 MM
092	N 916017130000	CLAMP
	Repalced by: N 000000000678
092	N 000000000678	CLAMP
		CONNECTION OF AIR INTAKE PIPES
		130-150 MM
	Repalced by: N 000000005892
092	N 000000005892	CLAMP
		CONNECTION OF AIR INTAKE PIPES
		130-150 MM
092	N 000000000676	CLAMP
		CONNECTION OF AIR INTAKE PIPES
		100-120 MM
	Repalced by: N 000000005890
092	N 000000005890	CLAMP
		CONNECTION OF AIR INTAKE PIPES
		100-120 MM
092	N 916017080000	CLAMP
	Repalced by: N 000000000675
092	N 000000000675	CLAMP
	Repalced by: A 0059972990
092	A 0059972990	CLAMP
		HOSE TO AIR INTAKE PIPE
		82 - 105 X 15.8 MM
092	N 916017070000	CLAMP
	Repalced by: N 000000000674
092	N 000000000674	CLAMP
		HOSE TO TURBOCHARGER
		70-90 MM
095	N 000125008418	WASHER
	Repalced by: N 000125008443
095	N 000125008443	WASHER
		AIR INTAKE PIPE
098	N 910113008003	NUT
		AIR INTAKE PIPE
101	A 3909970682	HOSE
		FROM AIR CLEANER TO AIR COMPRESSOR
	T YYYYYYYYYYYY	PART NAME MISSING
		BREATHER LINE
104	N 900271035008	HOSE
		FROM AIR CLEANER TO INTAKE PIPE
	A 6125280008	AIR INTAKE PIPE
		FROM AIR CLEANER TO INTAKE PIPE
110	A 5411341082	HOSE
		FROM AIR CLEANER TO INTAKE PIPE
113	A 0005200086	HOSE
		FROM AIR INTAKE PIPE TO AIR COMPRESSOR
119	N 900271035010	HOSE
		FROM AIR INTAKE PIPE TO AIR COMPRESSOR
	A 6125280108	AIR INTAKE PIPE
		FROM AIR INTAKE PIPE TO AIR COMPRESSOR
125	A 5411341082	HOSE
		FROM AIR INTAKE PIPE TO AIR COMPRESSOR
	A 6125200002	AIR INTAKE CASE
		FROM AIR INTAKE PIPE TO AIR COMPRESSOR
140	N 916016035205	CLAMP
		FROM AIR CLEANER TO AIR COMPRESSOR
143	N 916017025000	CLAMP
	Repalced by: N 000000000668
143	N 000000000668	CLAMP
		INTAKE PIPE TO AIR COMPRESSOR AND TO AIR CLEANER
		25X40 MM
143	N 916017025000	CLAMP
143	N 916017025000	CLAMP
		BREATHER LINE
146	N 916017032001	CLAMP
		INTAKE PIPE TO AIR COMPRESSOR AND TO AIR CLEANER
		32X50 MM
