Transporto priemonė: O 530 N3 LANG EURO 3; VIN numerio dalis: 628143

Grupė: 41 PROPELLER SHAFT

#	Kodas	Pavadinimas
005	A 6284100103	PROPELLER SHAFT
	Repalced by: A 6284104602
005	A 6284104602	PROPELLER SHAFT
		PROPELLER SHAFT TO REAR AXLE
		OM 457HLA
010	A 6284100603	PROPELLER SHAFT
	Repalced by: A 6284104302
010	A 6284104302	PROPELLER SHAFT
		PROPELLER SHAFT TO DRIVE
		1731 MM, OM 906HLA,ZF
010	A 6284100703	PROPELLER SHAFT
	Repalced by: A 6284104402
010	A 6284104402	PROPELLER SHAFT
		PROPELLER SHAFT TO DRIVE
		1616 MM, OM 906HLA, VOITH
010	A 6284100803	PROPELLER SHAFT
	Repalced by: A 6284104502
010	A 6284104502	PROPELLER SHAFT
		PROPELLER SHAFT TO DRIVE
		1525MM, OM 475 HLA. ZF
012	A 6284102902	PROPELLER SHAFT
	Repalced by: A 6284100406
012	A 6284100406	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
012	A 6284104802	PROPELLER SHAFT
	Repalced by: A 6284100306
012	A 6284100306	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		OM 457HLA
012	A 6284103002	PROPELLER SHAFT
	Repalced by: A 6284100006
012	A 6284100006	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		OM 457HLA
012	A 6284103102	PROPELLER SHAFT
	Repalced by: A 6284100106
012	A 6284100106	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		OM 457HLA
012	A 6284103402	PROPELLER SHAFT
	Repalced by: A 6284100206
012	A 6284100206	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		OM 457HLA. ZF
	Repalced by: A 6284104706
012	A 6284104706	PROPELLER SHAFT
		FROM TRANSMISSION TO REAR AXLE
		OM 457HLA. ZF
015	A 0004101930	CENTERING FLANGE
		DURCHM.155 MM
018	A 0004103631	UNIVERSAL JOINT CROSS
	Repalced by: A 0004103731
018	A 0004103731	UNIVERSAL JOINT CROSS
		TO A 628 410 01 03, 07 03, 08 03
018	A 0004104231	UNIVERSAL JOINT CROSS
		TO A 628 410 43 02, 4402, 4502, 4602
018	A 0004101828	UNIVERSAL JOINT
		TO A 628 410 29 02-3102,4802,0006-0406
020	A 0004110405	UNIVERSAL JOINT YOKE
		DURCHM. 180 MM
023	A 0004100710	INTERMEDIATE BEARING
023	A 0004100052	PILLOW BLOCK
025	A 0004111810	PROPELLER SHAFT
026	N 000000000803	HEXAGON HEAD BOLT
		M20X150MM
027	A 0009940501	LOCK
028	A 0009905255	NUT
029	A 0009906082	WASHER
	A 0004110083	PROTECTIVE PLATE
030	N 910113014000	HEXAGON NUT
		INTERMEDIATE FLANGE TO DRIVE SHAFT
		M14X1,5
	Repalced by: N 000000005585
030	N 000000005585	HEXAGON NUT
		INTERMEDIATE FLANGE TO DRIVE SHAFT
		M14X1,5
033	N 308673012003	HEXAGON NUT
		PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE
		M12X1,25MM
036	N 913023012002	NUT
		M12X1,5MM
038	N 913023014003	NUT
		M14X1.5
	Repalced by: N 000000005662
038	N 000000005662	NUT
		M14X1,5
	Repalced by: N 913023014003
038	N 913023014003	NUT
		M14X1.5
040	N 308676014011	HEXAGON HEAD BOLT
		INTERMEDIATE FLANGE TO DRIVE SHAFT
		M 14X1,5X55MM
042	N 910105014012	HEXAGON HEAD BOLT
		M14X1,5X30MM
	Repalced by: N 000000005518
042	N 000000005518	HEXAGON HEAD BOLT
		M14X1.5X30
044	N 910105012010	HEXAGON HEAD BOLT
		M12X1,5X40MM
044	N 910105012007	HEXAGON HEAD BOLT
		M12X1,5X30MM
046	N 910105012005	HEXAGON HEAD BOLT
		M12X1,5X110MM
048	N 000000001051	CLAMPING PIN
		5X20MM
050	A 6284100240	BRACKET
050	A 6284100240	BRACKET
060	A 6284100340	BRACKET
	Repalced by: A 6284100440
060	A 6284100440	BRACKET
060	A 6284100340	BRACKET
	Repalced by: A 6284100440
060	A 6284100440	BRACKET
070	A 6284130717	SPACER PLATE
070	A 6284130717	SPACER PLATE
