Transporto priemonė: S 415 HD; VIN numerio dalis: 629411
Grupė: 52 SHEET METAL,AIR INTAKE - 120 AIR INTAKE
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 0135422917 | CONTACT SENSOR |
| 005 | A 0135422917 | CONTACT SENSOR |
| 005 | A 0135422917 | CONTACT SENSOR |
| 008 | N 000000002136 | CLAMP |
| 180-200X13MM | ||
| 008 | N 000000002136 | CLAMP |
| 180-200X13MM | ||
| 011 | N 910105006002 | HEXAGON HEAD BOLT |
| M6X12 | ||
| 011 | N 910105006002 | HEXAGON HEAD BOLT |
| M6X12 | ||
| 014 | N 912004006100 | SPRING LOCK WASHER |
| 014 | N 000125006449 | WASHER |
| 014 | N 912004006100 | SPRING LOCK WASHER |
| 014 | N 000125006449 | WASHER |
| 017 | N 000000000678 | CLAMP |
| 130-150X12MM | ||
| Repalced by: N 000000005892 | ||
| 017 | N 000000005892 | CLAMP |
| 130-150X12MM | ||
| 017 | N 000000000678 | CLAMP |
| 130-150X12MM | ||
| Repalced by: N 000000005892 | ||
| 017 | N 000000005892 | CLAMP |
| 130-150X12MM | ||
| 020 | A 6295200902 | RESONATOR |
| 026 | A 6295201002 | AIR INTAKE CASE |
| 026 | A 6295201402 | AIR INTAKE CASE |
| 026 | A 6295201402 | AIR INTAKE CASE |
| 029 | A 0029977552 | HOSE |
| 030 | A 6325280282 | HOSE |
| 032 | A 6345280139 | CONSOLE |
| Repalced by: A 6345280839 | ||
| 032 | A 6345280839 | CONSOLE |
| 033 | A 6325280039 | CONSOLE |
| 035 | A 6295201301 | AIR INTAKE PIPE |
| Repalced by: A 6295280608 | ||
| 035 | A 6295280608 | AIR INTAKE PIPE |
| CASTING | ||
| D 150 | ||
| 035 | A 6325200001 | AIR INTAKE PIPE |
| D 150 | ||
| 038 | A 6295200901 | AIR INTAKE PIPE |
| 041 | A 0249970582 | HOSE |
| D 130/132; 215 MM | ||
| 044 | A 0129977745 | O-RING |
| 047 | A 6295201001 | AIR INTAKE PIPE |
| 050 | A 0249970882 | HOSE |
| 130/130/175 | ||
| 053 | A 0029953201 | CLAMP |
| BRSGU 158/25 | ||
| 056 | A 0009980450 | PLUG |
| 059 | A 0029977052 | HOSE |
| 920 MM | ||
| 062 | A 6298321213 | BRACKET |
| 065 | N 000000002772 | CLAMP |
| 25-40X13MM | ||
| 065 | N 000000002772 | CLAMP |
| 25-40X13MM | ||
| 065 | N 000000002772 | CLAMP |
| 25-40X13MM | ||
| 068 | N 000000000671 | CLAMP |
| 40-60X12MM | ||
| 068 | N 000000000671 | CLAMP |
| 40-60X12MM | ||
| 071 | N 916016035201 | CLAMP |
| 35/20MM | ||
| Repalced by: N 000000005975 | ||
| 071 | N 000000005975 | CLAMP |
| 35/20MM | ||
| 074 | N 910105006006 | HEXAGON HEAD BOLT |
| M6X20 | ||
| 074 | N 910105006006 | HEXAGON HEAD BOLT |
| M6X20 | ||
| 077 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 077 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 080 | A 0029977152 | HOSE |
| 25X100MM | ||
| 083 | N 910105008026 | HEXAGON HEAD BOLT |
| M8X20 | ||
| 083 | N 910105008026 | HEXAGON HEAD BOLT |
| M8X20 | ||
| 086 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 089 | N 910112008000 | NUT |
| M8 | ||
| 089 | N 910112008000 | NUT |
| M8 | ||
| 092 | A 0004313640 | BRACKET |
| 095 | N 916016028200 | CLAMP |
| 28/20MM | ||
| Repalced by: N 000000006228 | ||
| 095 | N 000000006228 | CLAMP |
| 28/20MM | ||
| 098 | A 0005010053 | SPACER SLEEVE |
| 101 | A 0005280340 | BRACKET |
| 104 | A 0000940276 | WASHER |
| 107 | A 6295500137 | RESONATOR |
| 108 | A 0005200002 | RESONATOR |
| 108 | A 0005200002 | RESONATOR |
| 108 | A 0005200002 | RESONATOR |
| 109 | A 6325200502 | RESONATOR |
| 110 | A 6325281409 | CONNECTION FITTING |
| STRAIGHT | ||
| 111 | A 6325281509 | CONNECTION FITTING |
| 90 DEGREES POSITION | ||
| 112 | N 910105005010 | HEXAGON HEAD BOLT |
| M5X10 | ||
| 113 | A 0199974948 | O-RING |
| 115 | A 0029971752 | HOSE |
| 28X265MM | ||
| 116 | N 916016012200 | CLAMP |
| 12/15MM | ||
| Repalced by: N 000000000321 | ||
| 116 | N 000000000321 | CLAMP |
| 12/15MM | ||
| 119 | N 910105010010 | HEXAGON HEAD BOLT |
| M10X70 | ||
| 122 | A 6295280324 | PIPE LINE |
| 125 | A 6295280226 | CONNECTOR |
| 90 DEGREES | ||
| 128 | A 6295200122 | COVERING |
| 129 | A 6325240028 | COVERING |
| 131 | A 0049901071 | ELBOW FITTING |
| 134 | A 0029901278 | CONNECTOR |
| 137 | A 0029975252 | HOSE |
| 925 MM | ||
| 137 | A 0029977852 | HOSE |
| 600 MM | ||
| 143 | A 0005280009 | PLASTIC PIPE |
| 146 | A 6295200633 | CONSOLE |
| 149 | A 0115425017 | SENDER UNIT |
| 152 | N 910105005005 | HEXAGON HEAD BOLT |
| M5X35 | ||
| 155 | N 913023005002 | NUT |
| M5 | ||
| N 916016040200 | CLAMP | |
| 40/20MM | ||
| 161 | A 6295200802 | AIR INTAKE CASE |
| 162 | A 6295200702 | AIR INTAKE CASE |
| PLASTIC | ||
| 164 | A 6295201202 | AIR INTAKE CASE |
| 164 | A 6295201102 | AIR INTAKE CASE |
| PLASTIC | ||
| 164 | A 6325200402 | AIR INTAKE CASE |
| 167 | A 0029976352 | HOSE |
| D 150; 100 MM | ||
| 170 | A 6295280082 | HOSE |
| D 150; 130 MM | ||
| 173 | A 0029975952 | HOSE |
| D 130; 116 MM | ||
| 176 | A 6295280640 | BRACKET |
| 176 | A 6295280640 | BRACKET |
| 179 | A 6295280740 | BRACKET |
| 182 | A 0005280406 | AIR CLEANER |
| 182 | A 0005280406 | AIR CLEANER |
| 185 | A 0009891311 | FILTER ELEMENT |
| 185 | A 0009891311 | FILTER ELEMENT |
| 188 | A 0020940006 | COVER |
| 188 | A 0020940006 | COVER |
| 189 | N 000000002774 | CLAMP |
| 35-50X13MM | ||
| 189 | N 000000003528 | CLAMP |
| 45-65X13MM | ||
| 191 | A 0009951236 | CLAMP |
| 150-170MM | ||
| 191 | N 000000000680 | CLAMP |
| 150-170X12MM | ||
| 194 | A 0009872266 | SEALING STRIP |
| 20X15X630MM | ||
| 197 | A 0009888111 | RUBBER MOUNTING |
| 197 | A 0009888111 | RUBBER MOUNTING |
| 200 | A 0029979052 | HOSE |
| D 38 / D 28 / 545 MM | ||
| 200 | A 0029979052 | HOSE |
| D 38 / D 28 / 545 MM | ||
| 200 | A 6325280182 | HOSE |
| D 38 / D 28 / 430 MM | ||
| 203 | A 6295240192 | SEAL |
| 203 | A 6295240192 | SEAL |
| 204 | A 6295280080 | GASKET |
| 204 | A 6295280080 | GASKET |
| 206 | A 0009872143 | RUBBER BUSHING |
| D=50X45MM | ||
| 206 | A 0009872143 | RUBBER BUSHING |
| D=50X45MM | ||
| 209 | A 0009888011 | BUFFER |
| D 25X10 ; M6 | ||
| 209 | A 0009888011 | BUFFER |
| D 25X10 ; M6 | ||
| 212 | A 6299910040 | SPACER SLEEVE |
| 212 | A 6299910040 | SPACER SLEEVE |
| 215 | A 6295280382 | HOSE |
| 590 MM | ||
| 215 | A 6295280382 | HOSE |
| 590 MM | ||
| 215 | A 6295280582 | HOSE |
| 1080 MM | ||
| 215 | A 6325280082 | HOSE |
| 1600 MM | ||
| 215 | A 6325280082 | HOSE |
| 1600 MM | ||
| A 0029975890 | CABLE TIE | |
| 7.4-8.4X355-375 | ||
| A 0029975890 | CABLE TIE | |
| 7.4-8.4X355-375 | ||
| 218 | A 0049941445 | SPRING-THREAD NUT |
| M 6 | ||
| 218 | A 0039941545 | NUT |
| PLUG-IN CLIP | ||
| M 8 | ||
| 218 | A 0039941545 | NUT |
| PLUG-IN CLIP | ||
| M 8 | ||
| 218 | A 0049941945 | NUT |
| M 8 | ||
| 221 | A 0005200141 | BRACKET |
| 221 | A 0005200141 | BRACKET |
| 222 | A 6275200241 | BRACKET |
| 223 | A 6325200041 | BRACKET |
| FILTER | ||
| 223 | A 6325200041 | BRACKET |
| FILTER | ||
| 224 | N 000000002774 | CLAMP |
| 35-50X13MM | ||
| 224 | N 000000002774 | CLAMP |
| 35-50X13MM | ||
| 226 | A 0009912740 | SPACER BUSH |
| 227 | N 910105008013 | HEXAGON HEAD BOLT |
| M8X12 | ||
| Repalced by: N 910143008020 | ||
| 227 | N 910143008020 | HEXALOBULAR BOLT |
| M8X12 | ||
| 227 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 227 | N 910105010006 | HEXAGON HEAD BOLT |
| M10X20 | ||
| 227 | N 910105010006 | HEXAGON HEAD BOLT |
| M10X20 | ||
| 230 | N 910112010001 | NUT |
| M10 | ||
| 230 | N 910112010001 | NUT |
| M10 | ||
| 233 | N 910105008041 | HEXAGON HEAD BOLT |
| M8X16 | ||
| 236 | A 0009902769 | WASHER |
| 8.4X30X1.6 | ||
| 239 | A 6295500254 | MOUNTING PLATE |
| 239 | A 6295500254 | MOUNTING PLATE |
| 240 | A 6325200141 | BRACKET |
| 242 | A 6295280740 | BRACKET |
| 245 | N 910105008041 | HEXAGON HEAD BOLT |
| M8X16 | ||
| 248 | A 0009902769 | WASHER |
| 8.4X30X1.6 | ||
| 251 | A 0049902568 | FITTING |
| M 36X1.5X75 | ||
| 254 | A 6295280282 | HOSE |
| D 38; 2000 MM | ||
| 260 | A 0009951236 | CLAMP |
| HKV 150-170 | ||
| 260 | N 000000000669 | CLAMP |
| 30-45X12MM | ||
| 263 | N 916016045200 | CLAMP |
| 45/20MM | ||
| Repalced by: N 000000004044 | ||
| 263 | N 000000004044 | CLAMP |
| 45/20MM | ||
| 263 | N 000000001485 | CLAMP |
| 34/20MM | ||
| Repalced by: N 000000000349 | ||
| 263 | N 000000000349 | CLAMP |
| 34/20MM | ||
| Repalced by: N 000000007539 | ||
| 263 | N 000000007539 | CLAMP |
| 34/20MM | ||
| 266 | A 6298321613 | BRACKET |
| 269 | N 910105008064 | HEXAGON HEAD BOLT |
| M8X65 | ||
| 272 | N 913023008003 | NUT |
| M8 | ||
| 275 | A 0029881035 | CAP |
| 276 | A 6295200222 | COVERING |
| 277 | A 0099874251 | RUBBER SEAL |
| Repalced by: A 0029891698 | ||
| 277 | A 0029891698 | SEALING STRIP |
| 278 | A 0000904601 | AIR CLEANER |
| 278 | A 0000904601 | AIR CLEANER |
| 279 | A 0000906901 | AIR CLEANER |
| 279 | A 0000906901 | AIR CLEANER |
| 280 | A 6295280208 | AIR INTAKE PIPE |
| 280 | A 6295280208 | AIR INTAKE PIPE |
| 281 | A 6295201401 | AIR INTAKE PIPE |
| 281 | A 6295201401 | AIR INTAKE PIPE |
| 282 | A 6295200302 | AIR INTAKE CASE |
| Repalced by: A 6325200002 | ||
| 282 | A 6325200002 | AIR INTAKE CASE |
| 282 | A 6295200302 | AIR INTAKE CASE |
| Repalced by: A 6325200002 | ||
| 282 | A 6325200002 | AIR INTAKE CASE |
| 282 | A 6325200002 | AIR INTAKE CASE |
| 282 | A 6325200002 | AIR INTAKE CASE |
| 283 | A 6295280310 | COVER |
| 283 | A 6295280310 | COVER |
| 284 | A 6295240028 | COVERING |
| 284 | A 6295240028 | COVERING |
| 287 | A 0040941804 | FILTER ELEMENT |
| 287 | A 0040941804 | FILTER ELEMENT |
| 290 | A 0009846136 | PIVOT |
| 290 | A 0009846136 | PIVOT |
| 293 | A 0029949835 | SNAP RING |
| Repalced by: A 0039908740 | ||
| 293 | A 0039908740 | WASHER |
| 293 | A 0029949835 | SNAP RING |
| Repalced by: A 0039908740 | ||
| 293 | A 0039908740 | WASHER |
| 294 | A 0039908740 | WASHER |
| D 6 | ||
| 294 | A 0039908740 | WASHER |
| D 6 | ||
| 296 | A 0005250041 | ANGLE |
| RETAINING CLAMP | ||
| Repalced by: A 0019884442 | ||
| 296 | A 0019884442 | FASTENER |
| RETAINING CLAMP | ||
| 296 | A 0005250041 | ANGLE |
| RETAINING CLAMP | ||
| Repalced by: A 0019884442 | ||
| 296 | A 0019884442 | FASTENER |
| RETAINING CLAMP | ||
| 299 | A 0089873425 | MOSS TYPE RUBBER |
| 3X22 | ||
| 299 | A 0089873425 | MOSS TYPE RUBBER |
| 3X22 | ||
| 302 | N 913023008003 | NUT |
| M8 | ||
| 302 | N 913023008003 | NUT |
| M8 | ||
| 305 | A 6295200015 | ROD |
| 305 | A 6295200015 | ROD |
| 308 | A 6295240012 | STIFFENING |
| 308 | A 6295240012 | STIFFENING |
| 311 | A 6295240112 | STIFFENING |
| 311 | A 6295240112 | STIFFENING |
| 314 | A 0000943865 | PLUG |
| (DUST DISCHARGE VALVE) | ||
| 314 | A 0000943865 | PLUG |
| (DUST DISCHARGE VALVE) | ||
| 317 | A 0019846329 | HEXALOBULAR BOLT |
| 5X12 | ||
| 317 | A 0019846329 | HEXALOBULAR BOLT |
| 5X12 | ||
| 320 | A 0009956914 | LINE FASTENER |
| 320 | A 0009956914 | LINE FASTENER |
| 320 | A 0009956914 | LINE FASTENER |
| 321 | A 0051536528 | SENDER UNIT |
| MOISTURE TEMPERATURE SENSOR | ||
| Repalced by: A 0071530128 | ||
| 321 | A 0071530128 | TEMPERATURE SENSOR |
| MOISTURE TEMPERATURE SENSOR | ||
| Repalced by: A 0071531128 | ||
| 321 | A 0071531128 | TEMPERATURE SENSOR |
| MOISTURE TEMPERATURE SENSOR | ||
| 321 | A 0051536528 | SENDER UNIT |
| MOISTURE TEMPERATURE SENSOR | ||
| Repalced by: A 0071530128 | ||
| 321 | A 0071530128 | TEMPERATURE SENSOR |
| MOISTURE TEMPERATURE SENSOR | ||
| Repalced by: A 0071531128 | ||
| 321 | A 0071531128 | TEMPERATURE SENSOR |
| MOISTURE TEMPERATURE SENSOR | ||
| 322 | N 000000001145 | HEXALOBULAR BOLT |
| M6X12 TX30 | ||
| 322 | N 000000001145 | HEXALOBULAR BOLT |
| M6X12 TX30 | ||
| 323 | A 6295401306 | CABLE HARNESS |
| 323 | A 6295401306 | CABLE HARNESS |
| 325 | A 0009894584 | INSULATING TAPE |
| 40MM | ||
| 325 | A 0009894584 | INSULATING TAPE |
| 40MM | ||
| 326 | A 0004291127 | THRUST RING |
| 14X10X2.6MM | ||
| 326 | A 0004291127 | THRUST RING |
| 14X10X2.6MM | ||
| 327 | A 0269970248 | O-RING |
| 327 | A 0269970248 | O-RING |
| 329 | A 4571540304 | COVER |
| (AIR INTAKE COVER) | ||
| 329 | A 4571540304 | COVER |
| (AIR INTAKE COVER) | ||
| 332 | A 4071540165 | COVER |
| (AIR INTAKE COVER) | ||
| 332 | A 4071540165 | COVER |
| (AIR INTAKE COVER) | ||
| 332 | A 4421540104 | COVER WITH AIR INTAKE |
| AIR INTAKE | ||
| Repalced by: A 4071540165 | ||
| 332 | A 4071540165 | COVER |
| AIR INTAKE | ||
| 335 | N 000934006006 | NUT |
| M6 | ||
| 335 | N 000934006006 | NUT |
| M6 | ||
| 335 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 338 | N 000933006058 | SCREW |
| M6X25 | ||
| Repalced by: N 910105006008 | ||
| 338 | N 910105006008 | HEXAGON HEAD BOLT |
| M6X25 | ||
| 341 | A 0029973152 | HOSE |
| 1485MM | ||
| 341 | A 0069977452 | SUCTION HOSE |
| 1485MM | ||
| 344 | A 0029974752 | HOSE |
| 1200MM | ||
| 344 | A 0029974752 | HOSE |
| 1200MM | ||
| 344 | A 0069977552 | SUCTION HOSE |
| 1200MM | ||
| 347 | A 0029973752 | HOSE |
| 1200MM | ||
| 347 | A 0029976752 | SUCTION HOSE |
| 1200MM | ||
| 350 | A 0029976652 | HOSE |
| 3040MM | ||
| 350 | A 0029976652 | HOSE |
| 3040MM | ||
| 350 | A 0069977052 | SUCTION HOSE |
| 3040MM | ||
| 350 | A 0029973252 | HOSE |
| 2385MM | ||
| 350 | A 0069977152 | SUCTION HOSE |
| 2385MM | ||
| 353 | N 000000003529 | CLAMP |
| 55-75X13MM | ||
| 353 | N 000000003529 | CLAMP |
| 55-75X13MM | ||
| 356 | N 000000003186 | CLAMP |
| 76/25MM | ||
| Repalced by: N 000000006128 | ||
| 356 | N 000000006128 | CLAMP |
| 76/25MM | ||
| 356 | N 000000003186 | CLAMP |
| 76/25MM | ||
| Repalced by: N 000000006128 | ||
| 356 | N 000000006128 | CLAMP |
| 76/25MM | ||
| 356 | N 000000003268 | CLAMP |
| 60/25MM | ||
| Repalced by: N 000000006126 | ||
| 356 | N 000000006126 | CLAMP |
| 60/25MM | ||
| 359 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 359 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 362 | A 0039941545 | NUT |
| PLUG-IN CLIP | ||
| M 8 | ||
| 362 | A 0039941545 | NUT |
| PLUG-IN CLIP | ||
| M 8 | ||
| 365 | A 0079973190 | CABLE STRAP |
| 7.8X465 | ||
| 365 | A 0079973190 | CABLE STRAP |
| 7.8X465 | ||
| 368 | A 0005280001 | PROTECTIVE GRILLE |
| 368 | A 0005280001 | PROTECTIVE GRILLE |
| 371 | A 0001541280 | CABLE GROMMET |
| 380 | A 6295281640 | BRACKET |
| 383 | A 3892650652 | SPACER WASHER |
| 9X22X8 | ||
| 386 | A 0015018382 | HOSE |
| 389 | A 0015018482 | HOSE |
| 392 | A 6295510556 | TUBE |
© 2010-2013 UAB "RPV" Paslaugų teikimo sąlygos - Privatumo politika - Kopijuoti ir naudoti komerciniais tikslais draudžiama
