Transporto priemonė: S 416 HDH; VIN numerio dalis: 629425
Grupė: 95 MULTIBLE OCCUPANCY SEAT - 045 PASSENGER SEATS, DOUBLE SEAT: CXR SEATING
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 6299700738 | SUPPORT |
| LEFT | ||
| 005 | A 6299700838 | SUPPORT |
| RIGHT | ||
| 006 | A 6299700938 | SUPPORT |
| LEFT | ||
| 006 | A 6299701038 | SUPPORT |
| RIGHT | ||
| 007 | A 6299701338 | SUPPORT |
| HIGH SEAT,LEFT | ||
| 007 | A 6299701438 | SUPPORT |
| HIGH SEAT,RIGHT | ||
| 008 | A 6299700041 | GUIDE |
| 010 | A 6299701138 | SUPPORT |
| HIGH SEAT,LEFT | ||
| 010 | A 6299701238 | SUPPORT |
| HIGH SEAT,RIGHT | ||
| 011 | A 6299700220 | SUPPORT |
| 014 | A 6299700048 | LEVER |
| LEFT | ||
| 014 | A 6299700148 | LEVER |
| RIGHT | ||
| 015 | A 6299760333 | BRACKET |
| HIGH SEAT | ||
| 017 | A 6299800064 | GAS SPRING |
| HUB 65 MM 300 N | ||
| 020 | A 6299970037 | LEVER |
| 021 | A 6299760312 | ANGLE |
| HIGH SEAT,LEFT | ||
| 021 | A 6299760412 | ANGLE |
| HIGH SEAT,RIGHT | ||
| 023 | Q 0101481017 | CLAMPING PIN |
| A 5 X 20 | ||
| 026 | A 6299880080 | FASTENER BUTTON |
| 027 | A 6299760433 | BRACKET |
| HIGH SEAT | ||
| 029 | N 000000000446 | TAPPING SCREW |
| 3.5X9.5 | ||
| 030 | N 910105008026 | SCREW |
| HIGH SEAT | ||
| M 8X20 | ||
| 032 | Q 0200936004 | HEX. HEAD NUT |
| M 10 | ||
| 035 | A 6299920305 | BUSHING |
| 038 | N 913023008003 | NUT |
| M 8 | ||
| 041 | N 913018013202 | PROTECTION CAP |
| 13 X 14.1 | ||
| 044 | A 0069901840 | WASHER |
| 8.1 X 16 X 2 | ||
| 047 | A 6299700462 | PLATE |
| 050 | A 6299700015 | RAIL |
| LEFT | ||
| 050 | A 6299700115 | RAIL |
| RIGHT | ||
| 056 | A 6299760511 | PLATE |
| 059 | N 913023008003 | NUT |
| M 8 | ||
| 062 | A 6299760013 | WASHER |
| 065 | N 913018013202 | PROTECTION CAP |
| 13 X 14.1 | ||
| 068 | A 0009882963 | SNAP LOCK |
| 071 | A 0029901120 | SCREW |
| M 5X16 TX25 - 4.8 | ||
| 074 | A 6299700416 | PAD |
| 077 | A 6299910012 | PIN |
| 080 | A 6299760157 | SLEEVE |
| 083 | A 6299760257 | SLEEVE |
| 086 | A 6299900005 | STUD |
| 089 | A 6299700054 | FASTENER |
| 092 | N 000000002027 | TAPPING SCREW |
| ST 2.9 X 9.5 C | ||
| 095 | A 0039907612 | SCREW |
| M 4X8 - 4.8 -TX20 | ||
| 098 | Q 0206798003 | SERRATED WASHER |
| A 4.3 | ||
| 101 | A 6299410117 | BUSHING |
| 104 | N 913023008003 | NUT |
| M 8 | ||
| 107 | N 913018013202 | PROTECTION CAP |
| 13 X 14.1 | ||
| 110 | A 6299760132 | STOP |
| 113 | A 0039907512 | SCREW |
| M 3X16 - 4.8 - TX10 | ||
| 116 | N 000000002486 | WASHER |
| 3.2 | ||
| 119 | A 6299760033 | BRACKET |
| 122 | N 913023006002 | NUT |
| M 6 | ||
| 125 | A 6124750318 | ELASTIC BAND |
| 40 X 2 MM | ||
| 128 | N 910143008000 | SCREW |
| M 8X16 | ||
| 131 | N 913023008003 | NUT |
| M 8 | ||
| 150 | A 6299580016 | PAD |
| TO A6299500031/...0131/...1031/...0931 | ||
| 164 | A 6329500585 | PADDING |
| SEAT CUSHION(INTEGRATED LEG PADDING,STANDARD) | ||
| 164 | A 6329500385 | PADDING |
| SEAT CUSHION(INTEGRATED LEG PADDING),HIGH CHAIR,LOW | ||
| 164 | A 6329500685 | PADDING |
| SEAT CUSHION(INTEGRATED LEG PADDING)VIP 2+1 | ||
| 164 | A 6329500485 | PADDING |
| SEAT CUSHION(INTEGRATED LEG PADDING),HIGH CHAIR,STANDARD | ||
| 167 | A 6299590214 | BRACKET |
| 170 | N 000000006408 | SCREW |
| 4,2X16MM | ||
| 171 | A 6299500073 | SCREW |
| 172 | A 6299590464 | SPRING |
| 173 | A 6299515721 | COVERING |
| LEFT,WITH REINFORCEMENT | ||
| 173 | A 6299515821 | COVERING |
| RIGHT,WITH REINFORCEMENT | ||
| 173 | A 6299515921 | COVERING |
| GREY, LEFT | ||
| 173 | A 6299516021 | COVERING |
| GREY, RIGHT | ||
| 174 | A 6299513421 | COVERING |
| GREY, LEFT | ||
| 174 | A 6299513521 | COVERING |
| GREY, RIGHT | ||
| 175 | A 6299502255 | COVER |
| GREY, LEFT | ||
| 175 | A 6299502355 | COVER |
| GREY, RIGHT | ||
| 176 | A 6299730034 | SPRING |
| 177 | A 0009944310 | LOCK |
| 179 | A 6299590215 | PIN |
| 179 | A 6299900065 | NUT |
| 182 | A 0029906522 | SCREW |
| 183 | N 000000000533 | SHEET METAL SCREW |
| 4,8 X 38 | ||
| 185 | A 6299590060 | HANDLE |
| LEFT | ||
| 185 | A 6299590160 | HANDLE |
| RIGHT | ||
| 188 | A 0009590071 | SCREW |
| 191 | A 6139510121 | COVERING |
| GREY, LEFT | ||
| 191 | A 6139510321 | COVERING |
| GREY, RIGHT | ||
| 191 | A 6299513021 | COVERING |
| LEFT,CARBON,SETRA | ||
| 191 | A 6299513121 | COVERING |
| RIGHT,CARBON,SETRA | ||
| 191 | A 6299513221 | COVERING |
| LEFT,BURL WOOD,SETRA | ||
| 191 | A 6299513321 | COVERING |
| RIGHT,BURL WOOD,SETRA | ||
| 191 | A 6299513821 | COVERING |
| LEFT,LIGHT WOOD,SETRA | ||
| 191 | A 6299513921 | COVERING |
| RIGHT,LIGHT WOOD,SETRA | ||
| 191 | A 6299515121 | COVERING |
| LEFT MULTIPOINT | ||
| 191 | A 6299515221 | COVERING |
| RIGHT MULTIPOINT | ||
| 191 | A 6299515321 | COVERING |
| LEFT,FLAIR | ||
| 191 | A 6299515421 | COVERING |
| RIGHT,FLAIR | ||
| 194 | A 6299510421 | COVERING |
| SEAT BELT BUCKLE COVER, LEFT | ||
| 195 | A 6299515521 | COVERING |
| SEAT BELT BUCKLE COVER, LEFT | ||
| 195 | A 6299515621 | COVERING |
| SEAT BELT BUCKLE COVER, RIGHT | ||
| 197 | N 000000002349 | HEXALOBULAR BOLT |
| M6X16MM | ||
| 200 | A 6329700064 | STAY |
| DIA., | ||
| 21MM | ||
| 200 | A 6329700064 | STAY |
| DIA., | ||
| 21MM | ||
| 203 | A 0009590120 | SUPPORT |
| M8X1MM | ||
| 206 | A 6299590197 | UNDERLAYER |
| 209 | A 0009840732 | SCREW |
| M8X16 | ||
| 212 | A 6299590117 | BUSHING |
| REAR | ||
| 212 | A 6299590117 | BUSHING |
| REAR | ||
| 215 | A 0009911725 | WASHER |
| 215 | A 0009911725 | WASHER |
| 218 | A 6299590017 | BUSHING |
| FRONT | ||
| 218 | A 6299590017 | BUSHING |
| FRONT | ||
| 221 | A 3029590117 | WASHER |
| 224 | A 0009590221 | STOP |
| 5MM | ||
| 224 | A 0009590321 | STOP |
| FOR GAS-OPERATED SPRING | ||
| 13.6 LG | ||
| 224 | A 0009590421 | STOP |
| 22,5MM | ||
| 224 | A 0009590521 | STOP |
| 32,5MM | ||
| 225 | A 0009985540 | STOP BUFFER |
| BACKREST | ||
| 225 | A 0009985540 | STOP BUFFER |
| BACKREST | ||
| 226 | A 0029906522 | SCREW |
| 226 | A 0029906522 | SCREW |
| 227 | A 6299730320 | SUPPORT |
| AT REAR ON GAS-OPERATED SPRING | ||
| 227 | A 6299730320 | SUPPORT |
| AT REAR ON GAS-OPERATED SPRING | ||
| 230 | A 6299500654 | LEVER |
| ON SIDE OF WALL,LEFT | ||
| 230 | A 6299500754 | LEVER |
| ON SIDE OF WALL,RIGHT | ||
| 233 | A 6299590028 | CAP |
| INSIDE | ||
| 236 | A 6299590264 | SPRING |
| LEFT | ||
| 236 | A 6299590364 | SPRING |
| RIGHT | ||
| 300 | A 6298104066 | FOLDING TABLE |
| WIDE(440 MM),WITH HOLE | ||
| 300 | A 6298103866 | FOLDING TABLE |
| WIDE(400 MM),WITH HOLE | ||
| 301 | A 6298103966 | FOLDING TABLE |
| WIDE(400 MM),WITH CUP HOLDER | ||
| 309 | A 0009909210 | SCREW |
| 2,9X17,5MM | ||
| 312 | A 6298100463 | LATCH |
| 315 | A 6298140863 | LATCH |
| 318 | A 6299970001 | PLUG |
| 324 | A 6298160759 | SUPPORTING ARM |
| LEFT | ||
| 327 | A 6298160859 | SUPPORTING ARM |
| RIGHT | ||
| 330 | N 000912006173 | SCREW |
| M 6X35 | ||
| 331 | A 6299930201 | SPRING |
| 332 | A 0009590171 | SCREW |
| 5 X 32 T20 | ||
| 333 | N 000000001159 | HEXALOBULAR BOLT |
| M6 X 19 | ||
| 345 | A 6299970071 | ADAPTER |
| STAR | ||
| 3 | ||
| 345 | A 6299970171 | ADAPTER |
| STAR | ||
| 4 | ||
| 345 | A 6299970271 | ADAPTER |
| STAR | ||
| 5 | ||
| 346 | A 6299920205 | BUSHING |
| 347 | A 0039902312 | SCREW |
| M 8X35 | ||
| 348 | A 6299920001 | BUSHING |
| 355 | A 6298161031 | CONSOLE |
| 355 | A 6298161931 | CONSOLE |
| 356 | A 0009984840 | STOP BUFFER |
| 357 | A 0019905136 | SCREW, SPECIAL SHAPE |
| 3,5X13MM | ||
| 360 | A 0009877145 | LOCKING CAP |
| 363 | N 000000003718 | WASHER |
| 380 | A 6299500146 | COVER |
| SETRA CUSHION WITHOUT SIDE BASE | ||
| 380 | A 6299500246 | COVER |
| CUSHION WITH SEAT BASE-SETRA ONLY | ||
| 380 | A 6299500346 | COVER |
| NIMBUS CUSHION VERSION-SETRA ONLY | ||
| 380 | A 6299500446 | COVER |
| AMBIENTE CUSHION VERSION-SETRA ONLY | ||
| 380 | A 6299500946 | COVER |
| SOFTLINE CUSHION VERSION | ||
| 380 | A 6299501146 | COVER |
| LUXLINE CUSHION VERSION | ||
| 380 | A 6299502146 | COVER |
| SETRA LEATHER AMBIENTE CUSHION | ||
| 380 | A 6299502246 | COVER |
| LEATHER LUXLINE CUSHION | ||
| 383 | A 6299950068 | CLIP |
| 386 | A 6299510118 | EDGE GUARD SECTION |
| LEFT | ||
| 388 | A 6299510218 | EDGE GUARD SECTION |
| RIGHT | ||
| 390 | A 6299500147 | COVER |
| . |
