Transporto priemonė: TOURISMO 16 RHD; VIN numerio dalis: 632038
Grupė: 24 ENGINE SUSPENSION
16618
16662
16687
# Kodas Pavadinimas
011 A 6292400206 CONSOLE
014 A 0002400118 RUBBER MOUNTING
REAR
017 A 6292400217 RUBBER MOUNTING
FRONT
A 6272400901 ENGINE SUPPORT
FRONT RIGHT
020 A 6292400701 ENGINE SUPPORT
RIGHT FRONT
021 A 6292401801 ENGINE SUPPORT
RIGHT FRONT
023 A 6292400601 ENGINE SUPPORT
FRONT LEFT
024 A 6292401701 ENGINE SUPPORT
FRONT LEFT
A 6272400801 ENGINE SUPPORT
FRONT LEFT
026 A 6292411831 PLATE
029 A 0002420053 SPACER TUBE
032 A 0002400165 STOP
035 A 0002420075 WASHER
038 N 910105012020 HEXAGON HEAD BOLT
041 N 000000005578 HEXAGON HEAD BOLT
M12X1,5X180MM
044 N 000000005535 HEXAGON HEAD BOLT
047 N 000000005718 HEXAGON HEAD BOLT
M14X1,5X45MM
050 N 910105018026 HEXAGON HEAD BOLT
M18X1.5X70
Repalced by: N 000000005565
050 A 0179901501 SCREW
M18X1,5X70MM
053 N 000000005563 HEXAGON HEAD BOLT
N 000000005544 HEXAGON HEAD BOLT
N 000000005723 HEXAGON HEAD BOLT
CONSOLES TO SIDE MEMBER
M18X1.5X55
062 N 000000005706 HEXAGON NUT
M20X1,5
065 N 000000005734 HEXAGON NUT
M16X1,5
068 N 910112006001 NUT
M6
071 N 000000005733 HEXAGON NUT
074 N 913023012002 NUT
077 A 6272401301 ENGINE SUPPORT
LEFT FRONT
080 A 6332410001 ENGINE SUPPORT
RIGHT FRONT
083 N 000000005723 HEXAGON HEAD BOLT
M18X1.5X55
086 A 6332410101 ENGINE SUPPORT
FRONT LEFT
089 A 0179901801 BOLT W FLANGE
M18X1,5X100MM
092 A 0179901701 BOLT AND WASHER ASSY.
M18X1,5X90MM
095 A 0179900901 SCREW
M18X1,5X110MM
098 A 6272401201 ENGINE SUPPORT
RIGHT FRONT
101 N 000000005534 HEXAGON HEAD BOLT
M16X1,5X35MM
104 N 000000005561 SCREW
M18X1,5X35MM
107 A 6332410003 TRANSMISSION CARRIER
110 A 6332410103 TRANSMISSION CARRIER
