Transporto priemonė: TRAVEGO RHD; VIN numerio dalis: 632245
Grupė: 52 CHASSIS SHEET METAL - 120 AIR INTAKE
| # | Kodas | Pavadinimas |
|---|---|---|
| 020 | N 000000007512 | CLAMP |
| 12/15 | ||
| 023 | N 000000002136 | CLAMP |
| 180-200X12MM | ||
| 032 | N 000000000678 | CLAMP |
| 130-150X12MM | ||
| 032 | N 000000000678 | CLAMP |
| 130-150X12MM | ||
| Repalced by: N 000000005892 | ||
| 032 | N 000000005892 | CLAMP |
| 130-150X12MM | ||
| 062 | N 000000007537 | CLAMP |
| 28/20 | ||
| 065 | N 000000002772 | CLAMP |
| 25-40X13MM | ||
| 065 | N 000000002772 | CLAMP |
| 25-40X13MM | ||
| 068 | N 000000000671 | CLAMP |
| 40-60X12MM | ||
| 068 | N 000000000671 | CLAMP |
| 40-60X12MM | ||
| Repalced by: N 000000003528 | ||
| 068 | N 000000003528 | CLAMP |
| 45-65X13MM | ||
| 068 | N 000000002774 | CLAMP |
| 35-50X13MM | ||
| 068 | N 000000002774 | CLAMP |
| 35-50X13MM | ||
| 068 | N 000000000669 | CLAMP |
| 080 | A 0135422917 | CONTACT SENSOR |
| 104 | A 0005280406 | AIR CLEANER |
| 107 | A 0009891311 | FILTER ELEMENT |
| 110 | A 0020940006 | COVER |
| 113 | A 0029975252 | HOSE |
| 925MM | ||
| 116 | N 000000000680 | CLAMP |
| 150-170X12MM | ||
| 116 | A 0009951236 | CLAMP |
| 150-170MM | ||
| 119 | A 6295240192 | SEAL |
| 122 | A 0009872143 | RUBBER BUSHING |
| D=50X45MM | ||
| 125 | A 0009888011 | BUFFER |
| D=25X10 | ||
| 128 | A 6299910040 | SPACER SLEEVE |
| 131 | A 0000500095 | SEAL RING |
| 134 | A 0004291127 | THRUST RING |
| 14X10X2.6MM | ||
| 137 | A 0269970248 | O-RING |
| 140 | N 910105006002 | HEXAGON HEAD BOLT |
| M6X12 | ||
| 140 | N 910105006002 | HEXAGON HEAD BOLT |
| M6X12 | ||
| 146 | A 6295200902 | RESONATOR |
| 150 | A 6325280282 | HOSE |
| 150 | A 0029977552 | HOSE |
| 153 | A 6325280039 | CONSOLE |
| 155 | A 6325200001 | AIR INTAKE PIPE |
| 155 | A 6295280608 | AIR INTAKE PIPE |
| D150 | ||
| 158 | A 0029953201 | CLAMP |
| 156/25MM | ||
| 161 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 164 | N 910105006006 | HEXAGON HEAD BOLT |
| M6X20 | ||
| 167 | N 910105008026 | HEXAGON HEAD BOLT |
| M8X20 | ||
| 167 | N 910105008026 | HEXAGON HEAD BOLT |
| M8X20 | ||
| 170 | N 910112008000 | NUT |
| M8 | ||
| 170 | N 910112008000 | NUT |
| M8 | ||
| 180 | A 0005200002 | RESONATOR |
| 180 | A 6325200702 | RESONATOR |
| 181 | A 6325200502 | RESONATOR |
| 182 | A 6325281409 | CONNECTION FITTING |
| STRAIGHT | ||
| 183 | A 6325281509 | CONNECTION FITTING |
| 90 DEGREES POSITION | ||
| 184 | N 910105005002 | HEXAGON HEAD BOLT |
| M5X16 | ||
| 185 | A 0199974948 | O-RING |
| 187 | A 0029971752 | HOSE |
| 28X265MM | ||
| 198 | A 6325240028 | COVERING |
| 212 | A 0009888111 | BUFFER |
| 215 | A 6295200702 | RESONATOR |
| 218 | A 0029976352 | HOSE |
| 150X100MM | ||
| 221 | A 6295280082 | HOSE |
| 150X130MM | ||
| 224 | A 0029979052 | HOSE |
| D38/28 | ||
| 227 | A 6325280182 | HOSE |
| 430MM | ||
| 230 | A 6295280582 | HOSE |
| 1080MM | ||
| 230 | A 6325280082 | HOSE |
| 1600MM | ||
| 239 | A 6295500354 | FASTENING PLATE |
| 242 | N 910105008041 | HEXAGON HEAD BOLT |
| M8X16 | ||
| 242 | N 910105008041 | HEXAGON HEAD BOLT |
| M8X16 | ||
| 245 | A 6295500254 | MOUNTING PLATE |
| 246 | A 6325200141 | BRACKET |
| 248 | A 0000906901 | AIR CLEANER |
| 248 | A 0000907301 | AIR FILTER |
| 251 | A 6295201401 | AIR INTAKE PIPE |
| 254 | A 6295200002 | AIR INTAKE CASE |
| 257 | A 6295280310 | COVER |
| 260 | A 6295200015 | ROD |
| 263 | A 6295240028 | COVERING |
| 266 | A 0040941804 | FILTER ELEMENT |
| 269 | A 6295240012 | STIFFENING |
| 272 | A 6295240112 | STIFFENING |
| 275 | N 913023008003 | NUT |
| M8 | ||
| 290 | A 6345280839 | CONSOLE |
| AIR INTAKE PIPE | ||
| 293 | N 910105010006 | HEXAGON HEAD BOLT |
| M10X20 | ||
| 317 | A 0000940276 | FELT WASHER |
| 320 | A 0029891698 | SEALING STRIP |
| 326 | A 0049941445 | SPRING-THREAD NUT |
| 332 | A 0009846136 | PIVOT |
| 335 | A 0039908740 | WASHER |
| 338 | A 0019884442 | FASTENER |
| RETAINING CLAMP | ||
| 341 | A 0089873425 | MOSS TYPE RUBBER |
| 347 | A 0019846329 | HEXALOBULAR BOLT |
| 5X12 | ||
| 350 | A 0009956914 | LINE FASTENER |
| 9,5MM | ||
| 353 | A 6295280640 | BRACKET |
| 356 | A 6295280740 | BRACKET |
| 357 | A 0029975890 | CABLE TIE |
| 359 | A 6325200041 | BRACKET |
| 368 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 371 | N 910105008013 | HEXAGON HEAD BOLT |
| M8X12 | ||
| 374 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 377 | A 0009902769 | WASHER |
| 8.4X30X1.6 | ||
| 377 | A 0009902769 | WASHER |
| 8.4X30X1.6 | ||
| 380 | A 6295280080 | GASKET |
| 383 | A 0009912740 | SPACER BUSH |
| 386 | A 0049941945 | NUT |
| 389 | A 0051536528 | TEMPERATURE SENSOR |
| Repalced by: A 0071530128 | ||
| 389 | A 0071530128 | TEMPERATURE SENSOR |
| Repalced by: A 0071531128 | ||
| 389 | A 0071531128 | TEMPERATURE SENSOR |
| 392 | A 6295401306 | CABLE HARNESS |
| 395 | N 000125006449 | WASHER |
| 398 | A 6295280422 | COVERING |
| 401 | A 4571540304 | COVER |
| CAST VERSION | ||
| 404 | A 4071540165 | COVER |
| 407 | N 910112006001 | HEXAGON NUT |
| M6 | ||
| 410 | A 0029974752 | HOSE |
| 1200MM | ||
| 410 | A 0029973152 | HOSE |
| 1485MM | ||
| 410 | A 0069977552 | SUCTION HOSE |
| 1200MM | ||
| 410 | A 0069977452 | SUCTION HOSE |
| 1485MM | ||
| 413 | A 0029973252 | HOSE |
| 2385MM | ||
| 413 | A 0069977152 | SUCTION HOSE |
| 2385MM | ||
| 416 | N 000000003529 | CLAMP |
| 55-75X13MM | ||
| 419 | N 000000007524 | CLAMP |
| 76/25MM | ||
| 419 | N 000000007524 | CLAMP |
| RSGU 76/25MM | ||
| 422 | N 910105008039 | HEXAGON HEAD BOLT |
| M8X25 | ||
| 422 | N 910105010006 | HEXAGON HEAD BOLT |
| 425 | A 0039941545 | NUT |
| 425 | A 0049941945 | NUT |
| 428 | N 910112008000 | NUT |
| M8 | ||
| 431 | N 000000007522 | CLAMP |
| 60/25MM | ||
| 434 | A 0079973190 | CABLE STRAP |
| 7.8X465 | ||
| 434 | A 0029975890 | CABLE TIE |
| 437 | A 0005280001 | PROTECTIVE GRILLE |
| 440 | A 0001541280 | CABLE GROMMET |
| 443 | A 0005010053 | SPACER SLEEVE |
| 446 | A 0005280340 | BRACKET |
| 449 | A 4571300190 | RESONANCE BOX |
| 452 | A 6345282282 | INTAKE HOSE |
| 455 | N 910105010010 | HEXAGON HEAD BOLT |
| M10X70 | ||
| 458 | A 6295280324 | PIPE LINE |
| 461 | A 6295200122 | SCREENING PLATE |
| 464 | A 0049901071 | ELBOW FITTING |
| 467 | A 6275200241 | BRACKET |
| 470 | A 0009980450 | PLUG |
| 473 | A 0019904917 | SCREW PLUG |
| 476 | A 4571340356 | FITTING |
| 479 | A 0029977152 | HOSE |
| D25/100MM | ||
| 481 | A 6295281241 | BRACKET |
| 484 | A 0008210088 | EDGE GUARD SECTION |
