Transporto priemonė: 230 S; VIN numerio dalis: 111010
Grupė: 78 SLIDING ROOF
| # | Kodas | Pavadinimas |
|---|---|---|
| 006 | A 1106500270 | ROOF PANELLING |
| Repalced by: A 1106500570 | ||
| 006 | A 1106500570 | ROOF PANELLING |
| 011 | A 1107800529 | FRAME |
| BOTTOM | ||
| 016 | A 0009871840 | RUBBER BUFFER |
| FRAME,BOTTOM | ||
| 022 | A 0009833087 | CARPET |
| BETWEEN REINFORCEMENT FRAME AND BOTTOM FRAME | ||
| 2 MM | ||
| N 000933006102 | SCREW | |
| Repalced by: N 304017006016 | ||
| N 304017006016 | SCREW | |
| FRAME,BOTTOM | ||
| N 000933006130 | SCREW | |
| FRAME,BOTTOM | ||
| N 912004006102 | LOCK WASHER | |
| FRAME,BOTTOM | ||
| N 009021006103 | WASHER | |
| Repalced by: N 009021006208 | ||
| N 009021006208 | WASHER | |
| FRAME,BOTTOM | ||
| N 000433006405 | WASHER | |
| FRAME,BOTTOM | ||
| 031 | A 1107820407 | SEAL |
| Repalced by: A 1157820098 | ||
| 031 | A 1157820098 | SEAL |
| FRAME,BOTTOM | ||
| A 1107820607 | SEAL | |
| Repalced by: A 0039895485 | ||
| A 0039895485 | ADHESIVE TAPE | |
| 036 | A 0009978482 | HOSE |
| 036 | A 0009978482 | HOSE |
| 041 | A 1107820019 | GROMMET |
| WATER DRAIN, FRONT | ||
| N 900285008100 | CLAMP | |
| WATER DRAIN, FRONT | ||
| A 0009894685 | ADHESIVE TAPE | |
| WATER DRAIN, FRONT,6 MM X 50 MM | ||
| 047 | A 0009871260 | RUBBER PAD |
| Repalced by: A 1087840297 | ||
| A 1087840297 | PAD | |
| Repalced by: A 1107841597 | ||
| A 1107841597 | PAD | |
| 800 MM | ||
| 053 | A 1107800021 | SLIDING ROOF PLATE |
| 060 | A 0009830098 | FOAM PLASTICS |
| Repalced by: A 0009833598 | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| 5 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| 5 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| 5 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| 5 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| 5 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| REINFORCEMENT FRAME | ||
| 150X950 MM | ||
| 060 | A 0009833598 | FOAM PLASTICS |
| BETWEEN FRAME AND HEADLINER | ||
| 50X590 MM | ||
| 066 | A 1107800322 | SLIDING ROOF MECHANISM |
| N 007985004123 | SCREW | |
| SLIDING ROOF MECHANISM | ||
| N 006797004132 | TOOTHED WASHER | |
| SLIDING ROOF MECHANISM | ||
| N 007987004122 | SCREW | |
| SLIDING ROOF MECHANISM | ||
| 071 | A 1107800576 | ROD |
| LEFT | ||
| A 1107800676 | ROD | |
| RIGHT | ||
| 076 | A 1107800126 | ROLLER |
| 081 | A 1107830096 | SEAL |
| 086 | A 1107830415 | PIN |
| N 001481002001 | CLAMPING SLEEVE | |
| N 000933005036 | SCREW | |
| N 006797005132 | TOOTHED WASHER | |
| 091 | A 1107870040 | SHACKLE |
| 096 | A 1107830134 | SPRING |
| N 007985004123 | SCREW | |
| N 006797004132 | TOOTHED WASHER | |
| 102 | A 1107800312 | ANGLE |
| Repalced by: A 1107800612 | ||
| 102 | A 1107800612 | ANGLE |
| FRONT LEFT AND RIGHT | ||
| 107 | A 1107820030 | SLIDING JAW |
| N 007985004123 | SCREW | |
| SLIDING ANGLE TO SLIDING ROOF PLATE | ||
| N 006797004132 | TOOTHED WASHER | |
| SLIDING ANGLE TO SLIDING ROOF PLATE | ||
| 112 | A 1107800512 | ANGLE |
| REAR LEFT AND RIGHT | ||
| A 1107820030 | SLIDING JAW | |
| N 000933006234 | SCREW | |
| SLIDING ANGLE TO SLIDING ROOF PLATE | ||
| N 006797006145 | TOOTHED WASHER | |
| SLIDING ANGLE TO SLIDING ROOF PLATE | ||
| 117 | A 1107870098 | SEAL |
| SLIDING ROOF PLATE,REAR | ||
| A 0009894671 | CLEANER | |
| Repalced by: A 0009899271 | ||
| A 0009899271 | CLEANER | |
| 122 | A 1109870539 | RUBBER BUFFER |
| 128 | A 1107820124 | RAIL |
| Repalced by: A 1107820524 | ||
| A 1107820524 | RAIL | |
| LEFT | ||
| A 1107820124 | RAIL | |
| Repalced by: A 1107820624 | ||
| A 1107820624 | RAIL | |
| RIGHT | ||
| A 0019883378 | CLIP | |
| Repalced by: A 0019881778 | ||
| A 0019881778 | CLIP | |
| N 007981003214 | SHEET METAL SCREW | |
| 133 | A 0009850229 | METAL SECTION |
| 520 MM | ||
| 137 | A 1107821498 | SEAL |
| FRONT | ||
| 142 | A 1107830060 | RECESS |
| 147 | A 1107830284 | LOCKING HANDLE |
| 156 | A 1107800016 | PIN |
| Repalced by: A 1235860078 | ||
| 156 | A 1235860078 | REPAIR KIT |
| 163 | A 1897830034 | SPRING |
| Repalced by: A 1235860078 | ||
| 163 | A 1235860078 | REPAIR KIT |
| 167 | A 1897830015 | PIN |
| Repalced by: A 1235860078 | ||
| 167 | A 1235860078 | REPAIR KIT |
| 173 | A 0009879840 | RUBBER BUFFER |
| Repalced by: A 1159870140 | ||
| 173 | A 1159870140 | RUBBER BUFFER |
| N 000084004137 | SCREW | |
| Repalced by: N 007985004149 | ||
| N 007985004149 | SCREW | |
| Repalced by: N 000000001933 | ||
| N 000000001933 | SCREW | |
| N 000433004306 | WASHER | |
| 178 | A 1107800056 | COVERING |
| 183 | A 1107840114 | BRACKET |
| A 0009830098 | FOAM PLASTICS | |
| Repalced by: A 0009833598 | ||
| A 0009833598 | FOAM PLASTICS | |
| 20X430 MM | ||
| A 0009833598 | FOAM PLASTICS | |
| 20X770 MM | ||
| 186 | A 1107820113 | COVER RAIL |
| N 007983002203 | SHEET METAL SCREW | |
| 193 | A 1107820726 | SLIDING RAIL |
| FRONT LEFT | ||
| A 1107820826 | SLIDING RAIL | |
| FRONT RIGHT | ||
| A 1107821326 | SLIDING RAIL | |
| LEFT,HEADLINER FRAME | ||
| 197 | A 1107821426 | SLIDING RAIL |
| RIGHT,HEADLINER FRAME | ||
| A 1089900036 | SCREW | |
| Repalced by: A 1409900436 | ||
| A 1409900436 | SCREW | |
| SLIDING RAIL TO BOTTOM FRAME | ||
| N 007987004124 | SCREW | |
| SLIDING RAIL TO BOTTOM FRAME | ||
| A 0009830998 | FOAM PLASTICS | |
| AT CONSOLE,7 X 80 X 100 MM | ||
| A 0009830698 | FOAM PLASTICS | |
| Repalced by: A 0009831298 | ||
| A 0009831298 | FOAM PLASTICS | |
| BETWEEN REINFORCEMENT FRAME AND ROOF SIDE PANELLING,15 X 20 X 100MM | ||
| 203 | A 1107820039 | FILLER |
| REINFORCEMENT FRAME | ||
| 208 | A 1107820028 | SLIDE |
| SLIDING ROOF PLATE | ||
| 211 | A 1107820011 | PLATE |
| 217 | A 1107820111 | PLATE |
| RIGHT | ||
| A 1107820211 | PLATE | |
| LEFT | ||
| 222 | A 1109970441 | SEAL RING |
| Repalced by: A 1159971040 | ||
| A 1159971040 | SEAL RING | |
| Repalced by: A 2019870241 | ||
| A 2019870241 | RUBBER RING | |
| N 007988004128 | SCREW | |
| 228 | A 1106909950 | HEADLINER |
| IMITATION LEATHER, PERFORATED | ||
| 231 | A 1116900352 | PANELLING |
| LESS BOWS | ||
| 236 | A 1107800209 | FRAME |
| IMITATION LEATHER, PERFORATED | ||
| 241 | A 0009877952 | RUBBER SEAL |
| Repalced by: A 0019876052 | ||
| 241 | A 0019876052 | RUBBER SEAL |
| 795 MM | ||
| 246 | A 1106960301 | BOW |
| 252 | A 1106960401 | BOW |
