Transporto priemonė: 280 SL USA; VIN numerio dalis: 113044
Grupė: 49 EXHAUST SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 001 | A 1134900920 | EXHAUST PIPE |
| FRONT | ||
| A 1814920011 | FLANGE | |
| 002 | A 1134900022 | EXHAUST PIPE |
| CENTRAL | ||
| 003 | A 1134920304 | REAR EXHAUST PIPE |
| REAR | ||
| 004 | A 1134911301 | MUFFLER |
| 005 | A 1134910092 | BAFFLE PLATE |
| 006 | N 915035000023 | SEAL RING |
| 007 | N 000931008217 | SCREW |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| 008 | N 999901008002 | NUT |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| 009 | A 1134920143 | CLAMP |
| BOTTOM | ||
| 010 | A 0004920183 | INSULATION |
| Repalced by: A 0004920983 | ||
| 010 | A 0004920983 | INSULATION |
| 011 | A 1134920053 | SPACER TUBE |
| 012 | A 1134900043 | BRACKET |
| TOP | ||
| 013 | N 000931008327 | SCREW |
| Repalced by: N 304017008043 | ||
| 013 | N 304017008043 | SCREW |
| 014 | N 912004008102 | LOCK WASHER |
| 015 | A 1134920082 | DAMPING PAD |
| 016 | A 0004920343 | CLAMP |
| BOTTOM | ||
| 017 | A 0004920183 | INSULATION |
| Repalced by: A 0004920983 | ||
| 017 | A 0004920983 | INSULATION |
| A 0004920053 | SPACER TUBE | |
| 020 | A 0004920243 | CLAMP |
| TOP | ||
| 021 | N 912004008102 | LOCK WASHER |
| 022 | N 000934008010 | NUT |
| Repalced by: N 304032008006 | ||
| 022 | N 304032008006 | NUT |
| 023 | A 1074920082 | DAMPING PAD |
| 025 | A 1129870140 | RUBBER BUFFER |
| 026 | A 1134920214 | END PIECE |
| 027 | A 1134900030 | PROTECTIVE PLATE |
| TOEBOARD | ||
| N 000063006145 | SCREW | |
| 030 | A 1134920330 | PROTECTIVE PLATE |
| N 007981004233 | SHEET METAL SCREW | |
| Repalced by: N 000000000460 | ||
| N 000000000460 | SHEET METAL SCREW | |
| N 009021005202 | WASHER | |
| Repalced by: N 009021005205 | ||
| N 009021005205 | WASHER | |
