Transporto priemonė: C 250 CDI 4MATIC; VIN numerio dalis: 204082
Grupė: 24 ENGINE SUSPENSION
| # | Kodas | Pavadinimas |
|---|---|---|
| 010 | A 2042400317 | ENGINE MOUNT |
| FRONT LEFT | ||
| Repalced by: A 2042404717 | ||
| 010 | A 2042404717 | ENGINE SUPPORT |
| FRONT LEFT | ||
| 010 | A 2122404117 | ENGINE SUPPORT |
| FRONT LEFT | ||
| 010 | A 2042400317 | ENGINE MOUNT |
| FRONT RIGHT | ||
| Repalced by: A 2042404717 | ||
| 010 | A 2042404717 | ENGINE SUPPORT |
| FRONT RIGHT | ||
| 010 | A 2122404217 | ENGINE SUPPORT |
| FRONT RIGHT | ||
| 010 | A 2042400117 | ENGINE MOUNT |
| FRONT LEFT | ||
| Repalced by: A 2042404217 | ||
| 010 | A 2042404217 | ENGINE SUPPORT |
| FRONT LEFT | ||
| 010 | A 2042400117 | ENGINE MOUNT |
| FRONT RIGHT | ||
| Repalced by: A 2042404217 | ||
| 010 | A 2042404217 | ENGINE SUPPORT |
| FRONT RIGHT | ||
| 010 | A 2042401817 | ENGINE MOUNT |
| FRONT LEFT | ||
| 010 | A 2042403617 | ENGINE SUPPORT |
| FRONT LEFT | ||
| 010 | A 2042401917 | ENGINE MOUNT |
| FRONT RIGHT | ||
| 010 | A 2042404117 | ENGINE SUPPORT |
| FRONT RIGHT | ||
| 020 | A 2042410334 | SCREENING PLATE |
| RIGHT | ||
| 020 | A 2042411034 | SCREENING PLATE |
| RIGHT | ||
| 020 | A 2042400145 | SCREENING PLATE |
| RIGHT | ||
| 020 | A 2042410434 | SCREENING PLATE |
| RIGHT | ||
| 025 | A 0005462075 | CLIP |
| TO SHIELD | ||
| 18.0X18.5 MM | ||
| 030 | N 910105010003 | HEXAGON HEAD BOLT |
| ENGINE MOUNTING TO ENGINE SUPPORT | ||
| M10X60 | ||
| 050 | N 910105008014 | HEXAGON HEAD BOLT |
| FRONT ENGINE MOUNT ON FRAME-TYPE INTEGRAL SUPPORT | ||
| M8X35 | ||
| 100 | A 2042421001 | ENGINE SUPPORT |
| REAR | ||
| 100 | A 2042421101 | ENGINE SUPPORT |
| REAR | ||
| 100 | A 2042422101 | ENGINE MOUNT |
| REAR | ||
| 100 | A 2042420901 | ENGINE SUPPORT |
| REAR | ||
| Repalced by: A 2042422501 | ||
| 100 | A 2042422501 | ENGINE MOUNT |
| REAR | ||
| 100 | A 2042420201 | ENGINE SUPPORT |
| REAR | ||
| 100 | A 2042421601 | ENGINE SUPPORT |
| REAR | ||
| Repalced by: A 2042422601 | ||
| 100 | A 2042422601 | ENGINE MOUNT |
| REAR | ||
| 110 | A 0019903703 | BOLT |
| ENGINE REAR SUPPORT TO FRAME | ||
| M10X22 | ||
| 120 | A 2122400418 | ENGINE SUPPORT |
| REAR | ||
| 120 | A 2122400818 | RUBBER BUSHING |
| REAR | ||
| 120 | A 2202401818 | ENGINE MOUNT |
| REAR | ||
| Repalced by: A 2122400418 | ||
| 120 | A 2122400418 | ENGINE SUPPORT |
| REAR | ||
| 130 | N 000000000428 | HEXAGON HEAD BOLT |
| BRACKET TO TRANSMISSION MOUNTING | ||
| M10X35 | ||
| 140 | N 000000000276 | HEXALOBULAR BOLT |
| ENGINE MOUNT REAR TO TRANSM. CARRIER | ||
| M8X20 | ||
| 150 | A 1402421340 | BRACKET |
| AT TRANSMISSION | ||
| 150 | A 2112420340 | BRACKET |
| AT TRANSMISSION | ||
| 160 | N 910143008003 | HEXALOBULAR BOLT |
| BRACKET TO TRANSMISSION | ||
| M8X30 | ||
| 160 | A 0049903412 | BOLT |
| BRACKET TO TRANSMISSION | ||
| M6X30 | ||
| 200 | A 2042400302 | ENGINE MOUNT |
| REAR | ||
| 210 | A 0019903703 | BOLT |
| ENGINE REAR SUPPORT TO FRAME | ||
| M10X22 | ||
| 220 | A 2042400618 | TRANSMISSION MOUNT |
| REAR | ||
| 230 | N 000000003175 | NUT |
| ENGINE MOUNT REAR TO TRANSM. CARRIER | ||
| M8 | ||
| 240 | N 910143008003 | HEXALOBULAR BOLT |
| BEARING TO TRANSMISSION | ||
| M8X30 | ||
| 900 | A 0225451926 | CLUTCH HOUSING |
| ENGINE FRONT LEFT MOUNTING | ||
| 2-PIN MLK1.2;Y123 | ||
| 900 | A 0225451926 | CLUTCH HOUSING |
| ENGINE FRONT RIGHT MOUNTING | ||
| 2-PIN MLK1.2;Y123/1 | ||
