Transporto priemonė: 200 GE; VIN numerio dalis: 460237

Grupė: 30 CONTROL

#	Kodas	Pavadinimas
007	A 1233000204	ACCELERATOR PEDAL
014	A 1233010082	PAD
021	A 1233010022	JOINT
028	A 1249888678	CLIP
		ACCELERATOR PEDAL
035	A 1153010241	STOP
		ACCELERATOR PEDAL
042	A 1159970640	SEAL RING
049	A 4603000725	LEVER
050	A 4603001320	SHAFT
		(CONTROL SHAFT)
050	A 4603003120	SHAFT
	Repalced by: A 4603003220
050	A 4603003220	SHAFT
		(CONTROL SHAFT)
051	A 4603000220	SHAFT
		(CONTROL SHAFT)
051	A 4603003220	SHAFT
		(CONTROL SHAFT)
053	N 071803008207	BALL PIVOT
056	A 1233010118	BEARING
		CONTROL SHAFT
063	A 4603010084	SHIM
		BEARING TO FIRE WALL
067	N 912001012001	LOCK
		CONTROL SHAFT
071	N 000988012009	FITTED WASHER
		CONTROL SHAFT
077	N 000933006102	SCREW
		BEARING TO FIRE WALL
		M 6X16
082	N 000933006102	SCREW
		BEARING TO FIRE WALL
		M 6X16
082	N 000933006127	SCREW
		BEARING TO FIRE WALL
		M6X25
086	N 000933006229	SCREW
		BEARING TO FIRE WALL
		M6X8
091	N 000137006204	SPRING WASHER
		BEARING TO FIRE WALL
096	N 000934006007	NUT
		BEARING TO FIRE WALL
103	A 4609930010	SPRING
		RELEASE SPRING
109	A 1233010297	BOOT
	Repalced by: A 1233010497
109	A 1233010497	BOOT
		PULL ROD THRU CAB FLOOR
114	A 4603010915	ROD
		FROM ACCELERATOR PEDAL TO SHAFT
115	A 4603011915	ROD
		FROM ACCELERATOR PEDAL TO SHAFT
115	N 900331005161	PULL ROD
		FROM ACCELERATOR PEDAL TO SHAFT
116	A 4603012015	ROD
		FROM ACCELERATOR PEDAL TO SHAFT
118	A 4603011115	ROD
		FROM ACCELERATOR PEDAL TO SHAFT
123	A 4603011215	ROD
		FROM ACCELERATOR PEDAL TO SHAFT
123	N 900331005161	PULL ROD
		FROM ACCELERATOR PEDAL TO SHAFT
125	A 4603011615	ROD
125	N 900331005162	PULL ROD
126	A 1263010585	RUBBER BUFFER
		TO 460 301 20 15
127	A 0009918922	BALL SOCKET
	Repalced by: A 0009930461
127	A 0009930461	CONICAL CUP
127	A 0009918922	BALL SOCKET
	Repalced by: A 0009930461
127	A 0009930461	CONICAL CUP
129	A 0009910822	BALL SOCKET
	Repalced by: A 6089910022
129	A 6089910022	BALL SOCKET
131	N 000934005008	NUT
136	A 4603000136	BEARING BRACKET
138	A 4603000236	BEARING BRACKET
138	A 4603000336	BEARING BRACKET
141	N 000933006103	SCREW
	Repalced by: N 304017006018
141	N 304017006018	SCREW
		BEARING BRACKET TO FIRE WALL
145	N 000137006204	SPRING WASHER
		BEARING BRACKET TO FIRE WALL
150	A 4603001428	LEVER
151	A 4603000028	LEVER
152	A 4603001728	LEVER
153	A 4603001828	LEVER
155	N 071803008202	BALL PIVOT
155	A 0009911620	BALL PIVOT
159	A 1102910750	BUSHING
166	N 912001008000	LOCK
		LEVER TO BEARING BRACKET
167	A 1263000540	BRACKET
		VENTILATION CASE
168	N 000933006103	SCREW
	Repalced by: N 304017006018
168	N 304017006018	SCREW
		BRACKET TO VENTILATION CASE
168	N 000933006102	SCREW
170	N 913004006002	NUT
	Repalced by: N 913004006001
170	N 913004006001	NUT
		BRACKET TO VENTILATION CASE
171	A 0003001415	ROD
		BETWEEN CONTROL SHAFT AND SLOTTED GATE LEVER
172	A 4603000140	BRACKET
178	N 000934006007	NUT
		BRACKET TO FIRE WALL
184	N 000137006204	SPRING WASHER
		BRACKET TO FIRE WALL
188	A 4603011440	BRACKET
189	N 000933006103	SCREW
	Repalced by: N 304017006018
189	N 304017006018	SCREW
190	N 000137006204	SPRING WASHER
192	A 1233000040	BRACKET
192	A 4603000240	BRACKET
194	N 007985005504	SCREW
		BRACKET TO BRACKET
198	N 912004005103	LOCK WASHER
		BRACKET TO BRACKET
202	N 000934005008	NUT
		BRACKET TO BRACKET
210	A 4603010240	BRACKET
		CONTROL SHAFT
223	A 4603010640	BRACKET
	Repalced by: A 4603010240
223	A 4603010218	BEARING
		OUTSIDE PART
230	A 6083010018	BEARING
		INSIDE PART
238	N 000137006204	SPRING WASHER
		BEARING TO BRACKET
242	N 000934006007	NUT
		BEARING TO BRACKET
242	N 000934006007	NUT
		BEARING TO BRACKET
247	N 000933006207	SCREW
		BRACKET TO FIRE WALL
249	N 000933006122	SCREW
	Repalced by: N 304017006034
249	N 304017006034	SCREW
249	N 000933008212	SCREW
	Repalced by: N 304017008016
249	N 304017008016	SCREW
		BRACKET TO ENGINE
		TO 460 301 06 40
251	N 000137006204	SPRING WASHER
		BRACKET TO FIRE WALL
251	N 000137008204	SPRING WASHER
	Repalced by: N 000137008212
251	N 000137008212	SPRING WASHER
		BRACKET TO ENGINE
		TO 460 301 06 40
267	A 4603001220	SHAFT
	Repalced by: A 4603002220
267	A 4603002220	SHAFT
		CONTROL
274	A 4603000920	SHAFT
		CONTROL
274	A 4603002120	SHAFT
		CONTROL
277	A 4603002720	SHAFT
		CONTROL
277	A 4603002920	SHAFT
		CONTROL
281	A 4603001020	SHAFT
		CONTROL
285	N 071803008204	BALL PIVOT
295	N 000933006127	SCREW
301	A 4603000325	LEVER
309	A 4603001025	LEVER
	Repalced by: A 4603010420
309	A 4603010420	LEVER
		(CONTROL LEVER)
312	A 4603001425	LEVER
		(CONTROL LEVER)
314	N 071803008204	BALL PIVOT
315	N 000933006102	SCREW
316	N 913004006002	NUT
	Repalced by: N 913004006001
316	N 913004006001	NUT
317	N 000125006421	WASHER
	Repalced by: N 000125006449
317	N 000125006449	WASHER
318	N 000933005035	SCREW
		LEVER TO SHAFT
322	N 000125005317	WASHER
	Repalced by: N 000433005304
322	N 000433005304	WASHER
		LEVER TO SHAFT
327	N 000934005008	NUT
		LEVER TO SHAFT
331	N 912001008000	LOCK
		CONTROL SHAFT
336	A 1233010273	LOCK
		CONTROL SHAFT
342	A 1233010140	BRACKET
		CONTROL SHAFT
345	A 1093010051	SPACER RING
		CONTROL SHAFT
348	N 912001008000	LOCK
		CONTROL SHAFT
353	N 000125008418	WASHER
	Repalced by: N 000125008443
353	N 000125008443	WASHER
		CONTROL SHAFT
357	N 912002008001	LOCK
	Repalced by: N 912002008003
357	N 912002008003	LOCK
		CONTROL SHAFT
365	A 4603010815	ROD
		FROM CONTROL SHAFT TO INTERMEDIATE LEVER AT ENGINE
369	A 0009911622	BALL SOCKET
	Repalced by: A 0009918922
369	A 0009918922	BALL SOCKET
	Repalced by: A 0009930461
369	A 0009930461	CONICAL CUP
373	N 000934005008	NUT
379	A 1263010585	RUBBER BUFFER
384	N 915042006000	PLUG
		AT FIRE WALL
