Transporto priemonė: 240 GD; VIN numerio dalis: 460320
Grupė: 30 CONTROL
| # | Kodas | Pavadinimas |
|---|---|---|
| 007 | A 1233000204 | ACCELERATOR PEDAL |
| 014 | A 1233010082 | PAD |
| 021 | A 1233010022 | JOINT |
| 028 | A 1249888678 | CLIP |
| ACCELERATOR PEDAL | ||
| 035 | A 1153010241 | STOP |
| ACCELERATOR PEDAL | ||
| 042 | A 1159970640 | SEAL RING |
| ACCELERATOR PEDAL | ||
| 049 | A 4603000725 | LEVER |
| (PEDAL LEVER) | ||
| 050 | A 4633000025 | LEVER |
| ACCELERATOR PEDAL | ||
| 051 | A 4613000125 | LEVER |
| ACCELERATOR PEDAL | ||
| 052 | A 4603001320 | SHAFT |
| (CONTROL SHAFT) | ||
| 052 | A 4603003120 | SHAFT |
| Repalced by: A 4603003220 | ||
| 052 | A 4603003220 | SHAFT |
| (CONTROL SHAFT) | ||
| 053 | N 071803008207 | BALL PIVOT |
| 056 | A 1233010118 | BEARING |
| CONTROL SHAFT | ||
| 059 | A 2013010218 | BEARING |
| CONTROL | ||
| 064 | A 4603010084 | SHIM |
| BEARING TO FIRE WALL | ||
| 067 | N 912001012001 | LOCK |
| CONTROL SHAFT | ||
| 069 | N 000471012001 | LOCK RING |
| CONTROL | ||
| 071 | N 000988012009 | FITTED WASHER |
| CONTROL SHAFT | ||
| 072 | N 000988013100 | FITTED WASHER |
| CONTROL | ||
| 073 | N 000933006121 | SCREW |
| Repalced by: N 304017006020 | ||
| 073 | N 304017006020 | SCREW |
| BEARING TO BRACKET | ||
| 074 | N 000137006204 | SPRING WASHER |
| 082 | N 000933006102 | SCREW |
| BEARING TO FIRE WALL | ||
| M 6X16 | ||
| 082 | N 000933006102 | SCREW |
| 082 | N 000933006127 | SCREW |
| BEARING TO FIRE WALL | ||
| M 6X25 | ||
| 087 | N 000933006229 | SCREW |
| BEARING TO FIRE WALL | ||
| M 6X8 | ||
| 094 | N 000137006204 | SPRING WASHER |
| BEARING TO FIRE WALL | ||
| 101 | N 000934006007 | NUT |
| BEARING TO FIRE WALL | ||
| 108 | A 4609930010 | SPRING |
| RELEASE SPRING | ||
| 115 | A 1233010297 | BOOT |
| Repalced by: A 1233010497 | ||
| 115 | A 1233010497 | BOOT |
| PULL ROD THRU CAB FLOOR | ||
| 122 | A 4603011415 | ROD |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 124 | A 4603011115 | ROD |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 126 | A 4603011215 | ROD |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 127 | A 4603011615 | ROD |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 129 | A 0009918922 | BALL SOCKET |
| Repalced by: A 0009930461 | ||
| 129 | A 0009930461 | CONICAL CUP |
| 129 | A 0009918922 | BALL SOCKET |
| Repalced by: A 0009930461 | ||
| 129 | A 0009930461 | CONICAL CUP |
| 131 | A 0009910822 | BALL SOCKET |
| Repalced by: A 6089910022 | ||
| 131 | A 6089910022 | BALL SOCKET |
| 136 | N 000934005008 | NUT |
| 143 | A 4603000136 | BEARING BRACKET |
| 150 | N 000933006207 | SCREW |
| BEARING BRACKET TO FIRE WALL | ||
| 150 | N 304017006018 | SCREW |
| BEARING BRACKET TO FIRE WALL | ||
| 157 | N 000137006204 | SPRING WASHER |
| BEARING BRACKET TO FIRE WALL | ||
| 158 | A 4613000040 | BRACKET |
| CONTROL | ||
| 159 | N 304017006018 | SCREW |
| BRACKET TO PEDESTAL | ||
| 160 | N 006798006103 | SERRATED WASHER |
| 161 | N 000934006007 | NUT |
| 162 | A 4613010084 | SHIM |
| 163 | N 000933006122 | SCREW |
| Repalced by: N 304017006034 | ||
| 163 | N 304017006034 | SCREW |
| 164 | N 006798006103 | SERRATED WASHER |
| 165 | N 000933006121 | SCREW |
| Repalced by: N 304017006020 | ||
| 165 | N 304017006020 | SCREW |
| 166 | N 000137006204 | SPRING WASHER |
| 168 | A 4603000028 | LEVER |
| 168 | A 4603001028 | LEVER |
| BEARING BRACKET TO FIRE WALL | ||
| 171 | N 071803008202 | BALL PIVOT |
| 178 | A 1102910750 | BUSHING |
| 185 | N 912001008000 | LOCK |
| LEVER TO BEARING BRACKET | ||
| 192 | A 4603000140 | BRACKET |
| 199 | N 000934006007 | NUT |
| BRACKET TO FIRE WALL | ||
| 206 | N 000137006204 | SPRING WASHER |
| BRACKET TO FIRE WALL | ||
| 214 | A 1233000040 | BRACKET |
| 214 | A 4603000240 | BRACKET |
| 220 | N 007985005504 | SCREW |
| 227 | N 912004005103 | LOCK WASHER |
| 234 | N 000934005008 | NUT |
| 236 | A 4603010740 | BRACKET |
| CONTROL SHAFT | ||
| 342 | A 4603000620 | SHAFT |
| CONTROL | ||
| 342 | A 4603001420 | SHAFT |
| CONTROL | ||
| 374 | A 1233001925 | LEVER |
| WITH DAMPER | ||
| 381 | N 071803008204 | BALL PIVOT |
| 388 | N 000561006115 | SCREW |
| 395 | N 000125006421 | WASHER |
| Repalced by: N 000125006449 | ||
| 395 | N 000125006449 | WASHER |
| 402 | A 1233010273 | LOCK |
| CONTROL SHAFT | ||
| 409 | A 1233010140 | BRACKET |
| CONTROL SHAFT | ||
| 416 | A 1093010051 | SPACER RING |
| CONTROL SHAFT | ||
| 420 | A 4603000230 | WIRE CABLE |
| IDLING ADJUSTMENT | ||
| 420 | A 4603000030 | WIRE CABLE |
| IDLING ADJUSTMENT | ||
| 424 | A 2013010285 | RUBBER BUFFER |
| BOWDEN CABLE TO FIRE WALL | ||
| 428 | N 912007006001 | CLIP |
| BOWDEN CABLE TO ACCELERATOR PEDAL LEVER | ||
| 431 | A 4603000340 | BRACKET |
| WIRE CABLE TO ENGINE | ||
| 434 | N 304017006018 | SCREW |
| BRACKET TO ENGINE | ||
| 437 | N 000137006204 | SPRING WASHER |
| BRACKET TO ENGINE | ||
| 440 | N 916016006200 | CLAMP |
| BOWDEN CABLE TO BRACKET | ||
| 443 | N 007985005125 | SCREW |
| Repalced by: N 007985005157 | ||
| 443 | N 007985005157 | SCREW |
| BOWDEN CABLE TO BRACKET | ||
| 446 | N 000137005203 | SPRING WASHER |
| BOWDEN CABLE TO BRACKET | ||
| 472 | A 4603000032 | WIRE CABLE |
| IDLING ADJUSTMENT | ||
| 479 | A 1105450272 | NUT |
| 486 | A 1105451137 | BUTTON |
| 493 | A 1233020209 | SLEEVE |
| 500 | A 1163020150 | BUSHING |
