Transporto priemonė: FORTWO CABRIO BRABUS; VIN numerio dalis: 451433

Grupė: 77 FOLDING TOP - 100 ELECTRIC, HYDRAULIC FOLDING TOP

#	Kodas	Pavadinimas
010	A 4517780001	COVER
		FOLDING TOP,FRONT
	Repalced by: A 4517780201
010	A 4517780201	SOFT TOP COVERING
		FOLDING TOP,FRONT
010	A 4517780401	SOFT TOP COVERING
015	A 4517780114	BRACKET
		LEFT
015	A 4517780214	BRACKET
		RIGHT
020	A 4517780175	COVER
		REPAIR KIT
020	A 4517780601	RS SOFT TOP COVERING
		REPAIR KIT
040	A 4517780182	HEADLINER
		HEADLINER
050	A 4517740013	PIVOT
		PARTS KIT FOR LEFT SOFT TOP LOCK
	Repalced by: A 4517740613
050	A 4517740613	PIVOT
		PARTS KIT FOR LEFT SOFT TOP LOCK
060	A 4517740313	PIVOT
		PARTS KIT FOR RIGHT SOFT TOP LOCK
	Repalced by: A 4517740713
060	A 4517740713	PIVOT
		PARTS KIT FOR RIGHT SOFT TOP LOCK
070	A 4517710105	FOLDING TOP FRAME
		LEFT & RIGHT COVERING
080	A 4517710037	LEVER
		LEFT AND RIGHT SOFT TOP LOCK CENTERING UNIT
090	A 4517710005	FOLDING TOP FRAME
		LEFT AND RIGHT
100	A 4517740133	CLAMP
		FOLDING TOP LOCK,FRONT
105	A 4516400053	BOX
		SOFT TOP ROOF CASSETTE
110	A 4517710205	FOLDING TOP FRAME
		FOLDING TOP LOCK,FRONT
120	A 4517760017	LOCKING HANDLE
		FOLDING TOP LOCK,FRONT
130	A 4517760064	CATCH
		FOLDING TOP
135	A 0039902497	BLIND RIVET
		ATTACHMENT COVER
		4.8X8
140	A 4517730222	BEARING
		A-PILLAR,LEFT
150	A 4517730322	BEARING
		A-PILLAR,RIGHT
155	A 4527740165	DEFLECTOR
		DRAFT DEFLECTOR
160	A 4517710398	SEAL
		ROOF RAIL,FRONT
162	A 4507710098	SEALING CORD
		ROOF RAIL,FRONT
165	A 4516910198	SEAL
		SIDE PANEL,LEFT
165	A 4516910098	SEAL
		SIDE PANEL,RIGHT
170	A 4517730001	BOW
		ROOF BOW
180	A 4517820028	SLIDE
		ROOF BOW
185	A 4517800089	PULL
		SOFT TOP DRIVE, LEFT AND RIGHT
190	A 4517760016	REINFORCEMENT
		FASTENER
200	A 4517770007	MOUNTING KIT
		REAR WINDOW AND ROOF CASSETTE AT SOFT TOP SUPPORT
210	A 4517770098	SEAL
		REAR WINDOW FRAME
215	A 0009915170	SPRING CLAMP
		REAR WINDOW PANE
220	A 4517700073	GLASS PANE
		REAR WINDOW PANE
240	A 4517930188	SPOILER
		SOFT TOP, REAR
250	A 4517760141	CATCH
		B-PILLAR ON THE LEFT
260	A 4517760041	CATCH
		B-PILLAR ON THE RIGHT
270	A 4517760241	EYE
		LATCH, LEFT AND RIGHT
280	A 4517730225	MOLDED PIECE
		REAR SOFT TOP MOTOR MOUNT, LEFT AND RIGHT
300	A 4517700318	BOW
		LEFT SIDE SUPPORT
310	A 4517700418	BOW
		RIGHT SIDE SUPPORT
350	A 4517730198	SEAL
		LEFT SIDE SUPPORT
360	A 4517730098	SEAL
		RIGHT SIDE SUPPORT
380	A 4517730422	BEARING
		SIDE MEMBER
390	A 4517700022	FOLDING TOP SUPPORT
		LEFT
395	A 0019983501	GROMMET
		RANGE OF DELIVERY;1 SET = 2 PIECES
400	A 4517700122	FOLDING TOP SUPPORT
		RIGHT
405	A 4517700114	MOUNTING KIT
		AT BEARING BRACKET
410	A 0089903804	BOLT
		FOLDING TOP SUPPORT
440	A 4518200242	ELECTRIC MOTOR
		RANGE OF DELIVERY
450	A 4518200142	ELECTRIC MOTOR
		SOFT TOP DRIVE
460	A 4519880180	PINION
		SOFT TOP DRIVE, LEFT AND RIGHT
470	A 0089903704	BOLT
		FASTENER, SOFT TOP TO VEHICLE
480	A 4517800068	HOSE
		CONDENSED WATER DRAIN
490	A 0025427419	RELAY
		FOLDING TOP
500	A 4518200104	ELECT. LINE
		LEFT
520	A 4518200204	ELECT. LINE
		RIGHT
	A 4518220014	BRACKET
		MICRO-SWITCH
550	A 4517700195	COVER
		FOLDING TOP SUPPORT,LEFT
560	A 4517700095	COVER
		RIGHT SOFT TOP SUPPORT
600	A 0009838910	FELT STRIP
		FOLDING TOP
		3X70 MM
620	A 0009837110	FELT STRIP
		FOLDING TOP CASE
700	A 4517700014	MOUNTING KIT
		FOLDING TOP
750	A 4517700214	MOUNTING KIT
		MOTOR TO ROOF
760	Q 0010144V001 00	CLEANING FELT
		SET = 2 PIECES
