Transporto priemonė: 1017 LS; VIN numerio dalis: 380251
Grupė: 40 WHEELS
| # | Kodas | Pavadinimas |
|---|---|---|
| 010 | A 3814000902 | DISC WHEEL |
| Repalced by: A 0004017005 | ||
| 010 | A 0004017005 | RIM |
| 6.00X22.5 | ||
| 010 | A 0004018405 | RIM |
| 6.00X22.5 | ||
| 010 | A 0004019405 | RIM |
| 6.00X22.5 | ||
| 020 | A 0004012913 | VALVE |
| Repalced by: A 0004017113 | ||
| 020 | A 0004017113 | VALVE |
| 27 DEGREES | ||
| A 0004010272 | NUT | |
| VALVE TO DISC WHEEL | ||
| 025 | A 3854010013 | VALVE |
| EXTENSION | ||
| 025 | A 3854010113 | VALVE |
| EXTENSION | ||
| N 007757008600 | VALVE CAP | |
| 035 | A 3854000124 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 035 | A 6174000024 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 035 | A 0004010672 | NUT |
| DISC WHEELS TO FRONT AND REAR AXLES | ||
| A 3529900702 | SCREW | |
| SPARE WHEEL TO CROSS MEMBER | ||
| N 000440014100 | WASHER | |
| SPARE WHEEL TO CROSS MEMBER | ||
| N 910113012002 | NUT | |
| SPARE WHEEL TO CROSS MEMBER | ||
| 050 | A 3834000039 | BRACKET |
| Repalced by: A 3834000639 | ||
| A 3834000639 | SPARE WHEEL HOIST | |
| 060 | A 3814030185 | WORM |
| Repalced by: A 6204030085 | ||
| 060 | A 6204030085 | WORM |
| 066 | A 3814030250 | BUSHING |
| 072 | N 001481006027 | CLAMPING SLEEVE |
| 080 | A 3834030183 | STOP GEAR |
| Repalced by: A 6204030383 | ||
| 080 | A 6204030383 | STOP GEAR |
| 085 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 085 | N 083334008000 | WIRE CABLE |
| 2700 MM | ||
| 092 | A 3149900440 | WASHER |
| A 3819900340 | WASHER | |
| 100 | A 3819900140 | WASHER |
| 105 | N 001481008038 | CLAMPING SLEEVE |
| Repalced by: N 308752008000 | ||
| 105 | N 308752008000 | CLAMPING PIN |
| 110 | N 000933010105 | SCREW |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 115 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 115 | N 910113010000 | NUT |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 130 | A 3834030050 | BUSHING |
| 134 | A 3814030045 | CRANK |
| 137 | N 001481006027 | CLAMPING SLEEVE |
| 140 | A 3814002239 | BRACKET |
| Repalced by: A 3814002639 | ||
| 140 | A 3814002639 | BRACKET |
| SPARE WHEEL CARRIER | ||
| 144 | A 3874030319 | BASE BLOCK |
| SPARE WHEEL CARRIER TO FRAME | ||
| 146 | A 3874030074 | PIN |
| SPARE WHEEL CARRIER TO FRAME | ||
| 148 | N 000444016104 | EYEBOLT |
| SPARE WHEEL CARRIER TO FRAME | ||
| 153 | N 912004016101 | LOCK WASHER |
| SPARE WHEEL CARRIER TO FRAME | ||
| 157 | N 000934016012 | NUT |
| SPARE WHEEL CARRIER TO FRAME | ||
| N 000094004023 | COTTER PIN | |
| SPARE WHEEL CARRIER TO FRAME | ||
| 162 | N 007349021001 | WASHER |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 162 | N 007349019002 | WASHER |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 166 | N 912004020100 | LOCK WASHER |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 166 | N 912004018101 | LOCK WASHER |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 170 | N 000934020008 | NUT |
| Repalced by: N 308673020002 | ||
| 170 | N 308673020002 | NUT |
| Repalced by: N 308674020000 | ||
| 170 | N 308674020000 | NUT |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 170 | N 000934018006 | NUT |
| SUPPORT TO SPARE WHEEL CARRIER | ||
| 180 | A 3874030701 | SUPPORT |
| EXTENSION | ||
| 185 | N 910113012002 | NUT |
| SPARE WHEEL CARRIER | ||
| N 910005012080 | RIVET | |
| SPARE WHEEL CARRIER | ||
