Transporto priemonė: 1017 LS; VIN numerio dalis: 380252
Grupė: 30 CONTROL
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3813000104 | ACCELERATOR PEDAL |
| Repalced by: A 6243000304 | ||
| 005 | A 6243000104 | ACCELERATOR PEDAL |
| Repalced by: A 6243000304 | ||
| 006 | A 6243000304 | ACCELERATOR PEDAL |
| (PARTS KIT) | ||
| A 6153000104 | PAD | |
| ACCELERATOR PEDAL | ||
| 012 | N 007991005007 | SCREW |
| ACCELERATOR PEDAL | ||
| 015 | N 071803010301 | BALL PIVOT |
| ACCELERATOR PEDAL | ||
| 015 | A 0009911015 | BALL PIVOT |
| ACCELERATOR PEDAL | ||
| 017 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 017 | N 913004006001 | NUT |
| ACCELERATOR PEDAL | ||
| 020 | A 3813010184 | SHIM |
| Repalced by: A 3813010284 | ||
| 020 | A 3813010284 | SHIM |
| Repalced by: A 6153010084 | ||
| 020 | A 6153010084 | SHIM |
| ACCELERATOR PEDAL | ||
| 022 | A 3813010197 | BOOT |
| Repalced by: A 3813010297 | ||
| 022 | A 3813010297 | BOOT |
| ACCELERATOR PEDAL | ||
| 022 | A 6153010097 | BOOT |
| ACCELERATOR PEDAL | ||
| 025 | N 000965006003 | SCREW |
| PEDAL TO CAB FLOOR | ||
| M 6X25 | ||
| 027 | N 000965006006 | SCREW |
| PEDAL TO CAB FLOOR | ||
| M 6X20 | ||
| A 6553010093 | GUIDE RAIL | |
| ACCELERATOR PEDAL TO FLOOR PLATE | ||
| N 000965006077 | SCREW | |
| GUIDE RAIL RETROFIT | ||
| 030 | N 000931008254 | SCREW |
| Repalced by: N 304014008002 | ||
| 030 | N 304014008002 | SCREW |
| PEDAL TO CAB FLOOR | ||
| M 8X65 | ||
| 032 | N 304032008006 | NUT |
| PEDAL TO CAB FLOOR | ||
| 034 | A 3813010041 | STOP |
| PEDAL TO CAB FLOOR | ||
| 040 | A 3819910123 | BALL SOCKET |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 042 | N 071805010403 | SECURING CLIP |
| FROM ACCELERATOR PEDAL TO SHAFT | ||
| 050 | A 3813000021 | BEARING TUBE |
| Repalced by: A 6153000021 | ||
| 050 | A 6153000021 | BEARING TUBE |
| CONTROL SHAFT | ||
| 052 | A 3813020050 | BUSHING |
| BEARING TUBE | ||
| 055 | A 3813000020 | SHAFT |
| Repalced by: A 6153000020 | ||
| 055 | A 6153000020 | SHAFT |
| CONTROL | ||
| 060 | A 3813000625 | LEVER |
| CONTROL | ||
| 062 | N 071803010204 | BALL PIVOT |
| 064 | N 001481004017 | CLAMPING SLEEVE |
| Repalced by: N 308752004001 | ||
| 064 | N 308752004001 | CLAMPING PIN |
| 066 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 066 | N 304017008016 | SCREW |
| INTERMEDIATE BEARING TO CAB FLOOR | ||
| 068 | N 913004008004 | NUT |
| Repalced by: N 913004008001 | ||
| 068 | N 913004008001 | NUT |
| INTERMEDIATE BEARING TO CAB FLOOR | ||
| 075 | A 3604302992 | ROD |
| FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING | ||
| 077 | A 3604301992 | ROD |
| FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING | ||
| 079 | A 0009912422 | BALL SOCKET |
| 081 | N 000934006007 | NUT |
| 083 | N 071805010403 | SECURING CLIP |
| 090 | A 3813000436 | BEARING BRACKET |
| Repalced by: A 6203000536 | ||
| 090 | A 6203000536 | BEARING BRACKET |
| INTERMEDIATE BEARING | ||
| A 3813000636 | BEARING BRACKET | |
| Repalced by: A 6203000436 | ||
| A 6203000436 | BEARING BRACKET | |
| INTERMEDIATE BEARING | ||
| 095 | A 3813000328 | LEVER |
| Repalced by: A 6153000028 | ||
| 095 | A 6153000028 | LEVER |
| Repalced by: A 6203000628 | ||
| 095 | A 6203000628 | LEVER |
| INTERMEDIATE BEARING | ||
| 097 | A 3813000628 | LEVER |
| INTERMEDIATE BEARING | ||
| 097 | A 3813001028 | LEVER |
| Repalced by: A 6153001028 | ||
| 097 | A 6153001028 | LEVER |
| INTERMEDIATE BEARING | ||
| 099 | N 071803010209 | BALL PIVOT |
| Repalced by: A 3129910120 | ||
| 099 | A 3129910120 | BALL PIVOT |
| 101 | N 071803013208 | BALL PIVOT |
| N 009021006205 | WASHER | |
| Repalced by: N 009021006208 | ||
| N 009021006208 | WASHER | |
| 103 | A 3813020050 | BUSHING |
| INTERMEDIATE BEARING | ||
| 103 | A 3813020050 | BUSHING |
| INTERMEDIATE BEARING | ||
| 105 | A 3813010388 | COVERING |
| Repalced by: A 6153010088 | ||
| 105 | A 6153010088 | COVERING |
| INTERMEDIATE BEARING | ||
| 107 | N 006799010001 | LOCK PLATE |
| INTERMEDIATE BEARING | ||
| 110 | N 000933010105 | SCREW |
| CONTROL SHAFT BEARING TO FIRE WALL | ||
| 112 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 112 | N 910113010000 | NUT |
| CONTROL SHAFT BEARING TO FIRE WALL | ||
| 120 | A 3813001615 | ROD |
| Repalced by: A 3813001715 | ||
| 120 | A 3813001715 | ROD |
| FROM INTERMEDIATE BEARING TO SHAFT | ||
| 122 | A 3813001315 | ROD |
| FROM INTERMEDIATE BEARING TO SHAFT | ||
| 122 | A 3813002415 | ROD |
| FROM INTERMEDIATE BEARING TO SHAFT | ||
| 124 | N 071805013203 | BALL SOCKET |
| 126 | A 4069910022 | BALL SOCKET |
| N 304032008006 | NUT | |
| 130 | N 071805013402 | SECURING CLIP |
| 132 | N 001434008005 | PIN |
| ROD TO LEVER | ||
| 134 | N 000433008406 | WASHER |
| ROD TO LEVER | ||
| 136 | N 000137008204 | SPRING WASHER |
| ROD TO LEVER | ||
| N 000094001617 | COTTER PIN | |
| ROD TO LEVER | ||
| 140 | A 3813000326 | MANUAL CONTROL |
| IDLING ADJUSTMENT | ||
| A 3813020108 | GUIDE | |
| IDLING ADJUSTMENT | ||
| 144 | A 3813020201 | KNOB |
| Repalced by: A 6153020001 | ||
| 144 | A 6153020001 | KNOB |
| 148 | A 3819940016 | LOCK |
| Repalced by: N 000988030003 | ||
| 148 | N 000988030003 | FITTED WASHER |
| IDLING ADJUSTMENT | ||
| 152 | A 3819900051 | NUT |
| IDLING ADJUSTMENT | ||
| 160 | A 3813001130 | WIRE CABLE |
| IDLING ADJUSTMENT | ||
| A 3813001230 | WIRE CABLE | |
| IDLING ADJUSTMENT | ||
| 170 | A 3813020340 | BRACKET |
| Repalced by: A 3813020240 | ||
| 170 | A 3813020240 | BRACKET |
| IDLING ADJUSTER AND STARTER PILOT | ||
| N 000933006103 | SCREW | |
| Repalced by: N 304017006018 | ||
| N 304017006018 | SCREW | |
| BRACKET TO WINDOW SILL | ||
| N 007976005207 | SHEET METAL SCREW | |
| Repalced by: N 914031005208 | ||
| N 914031005208 | COMBINATION BOLT | |
| BRACKET TO WINDOW SILL | ||
| N 000933006102 | SCREW | |
| FRESH AIR DUCT | ||
| N 913004006002 | NUT | |
| Repalced by: N 913004006001 | ||
| N 913004006001 | NUT | |
| FRESH AIR DUCT | ||
| 175 | A 3833020091 | GROMMET |
| CABLE | ||
| 180 | A 3833020840 | BRACKET |
| WIRE CABLE | ||
| 185 | A 3873020140 | BRACKET |
| FRAME SIDE MEMBER | ||
| A 3609950201 | CLAMP | |
| Repalced by: A 3604300143 | ||
| A 3604300143 | CLAMP | |
| Repalced by: N 916016008200 | ||
| N 916016008200 | CLAMP | |
| BRACKET TO SIDE MEMBER | ||
| A 3609950501 | CLAMP | |
| Repalced by: A 3609952001 | ||
| 195 | A 3609952001 | CLAMP |
| Repalced by: A 6739950001 | ||
| 195 | A 6739950001 | CLAMP |
| CABLE TO BRACKET ON CROSS MEMBER NO. 1 | ||
| N 000000001147 | SCREW | |
| CABLE TO BRACKET ON CROSS MEMBER NO. 1 | ||
| M 6X20 | ||
| N 912004006102 | LOCK WASHER | |
| CABLE TO BRACKET ON CROSS MEMBER NO. 1 | ||
| N 913004006002 | NUT | |
| Repalced by: N 913004006001 | ||
| N 913004006001 | NUT | |
| CABLE TO BRACKET ON CROSS MEMBER NO. 1 | ||
| 200 | A 3839950101 | CLAMP |
| WIRE CABLE TO BEARING BRACKET | ||
| N 000933010105 | SCREW | |
| WIRE CABLE TO BEARING BRACKET | ||
| N 913004010008 | NUT | |
| Repalced by: N 910113010000 | ||
| N 910113010000 | NUT | |
| WIRE CABLE TO BEARING BRACKET | ||
