Transporto priemonė: 1419 MBSA-RSA; VIN numerio dalis: 397013
Grupė: 35 REAR AXLE
| # | Kodas | Pavadinimas |
|---|---|---|
| 006 | A 0089976082 | HOSE |
| FROM 3/2-WAY VALVE TO FOUR-CIRCUIT PROTECTIVE VALVE | ||
| 006 | A 0089976082 | HOSE |
| FROM 3/2-WAY VALVE TO PNEUMATIC CYLINDER | ||
| 008 | A 0039979172 | FITTING |
| (PARTS KIT),LINE RUPTURE | ||
| 009 | N 915052004015 | BANJO UNION |
| 012 | N 915052004016 | BANJO UNION |
| 014 | A 3874297240 | BRACKET |
| COMPRESSED AIR LINES | ||
| 015 | A 0019978490 | LOOM TIE |
| LINE MOUNTING | ||
| 018 | A 0019975036 | VALVE |
| 3/2-WAY | ||
| BOSCH | ||
| 018 | A 0019976136 | VALVE |
| 3/2-WAY | ||
| WESTINGHOUSE | ||
| 021 | A 0049937501 | SPRING |
| TO 001 997 61 36 | ||
| 024 | A 0069972648 | SEAL RING |
| TO 001 997 61 36 | ||
| 027 | A 0039979640 | SEAL RING |
| TO 001 997 61 36 | ||
| 030 | A 3855840824 | UNIT IDENTIFICATION PLATE |
| AT VALVE | ||
| 033 | A 3839900051 | NUT |
| 3/2-WAY VALVE TO CAB | ||
| 036 | A 6239900040 | WASHER |
| 3/2-WAY VALVE TO CAB | ||
| 040 | N 915036006202 | HOLLOW SCREW |
| THREE-WAY VALVE,CONNECTION: | ||
| "1/2" | ||
| 043 | N 007603010103 | SEAL RING |
| THREE-WAY VALVE,CONNECTION: | ||
| "1/2" | ||
| 058 | A 0009904578 | CONNECTOR |
| COMPRESSED AIR LINE TO VALVE | ||
| "1" | ||
| 064 | N 915036008202 | HOLLOW SCREW |
| 067 | N 007603012405 | SEAL RING |
