Transporto priemonė: 1620 L/LL; VIN numerio dalis: 617447
Grupė: 40 WHEELS
| # | Kodas | Pavadinimas |
|---|---|---|
| 012 | A 6174000002 | DISC WHEEL |
| Repalced by: A 3854001302 | ||
| 012 | A 3854001302 | DISC WHEEL |
| Repalced by: A 0004017405 | ||
| 012 | A 0004017405 | RIM |
| RED-BROWN | ||
| 7.50 - 22.5 | ||
| 012 | A 0004018705 | RIM |
| Repalced by: A 0004012302 | ||
| 012 | A 0004012302 | DISC WHEEL |
| Repalced by: A 0004002902 | ||
| 012 | A 0004002902 | DISC WHEEL |
| 7.50-22.5 | ||
| 012 | A 0004019805 | RIM |
| RED-BROWN | ||
| 7.50-22.5 | ||
| 012 | A 6174000102 | DISC WHEEL |
| Repalced by: A 3874000102 | ||
| 012 | A 3874000102 | DISC WHEEL |
| Repalced by: A 0004017605 | ||
| 012 | A 0004017605 | RIM |
| Repalced by: A 0004017905 | ||
| 012 | A 0004017905 | RIM |
| Repalced by: A 0004016702 | ||
| 012 | A 0004016702 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 012 | A 0004016602 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 012 | A 0004011702 | DISC WHEEL |
| Repalced by: A 0004018905 | ||
| 012 | A 0004018905 | RIM |
| Repalced by: A 0004016502 | ||
| 012 | A 0004016502 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 012 | A 0004001002 | DISC WHEEL |
| 8.25-22.5 | ||
| 012 | A 0004000602 | DISC WHEEL |
| 8.25-22.5 | ||
| 012 | A 0004001902 | DISC WHEEL |
| 8.25-22.5 | ||
| 024 | A 0004012913 | VALVE |
| Repalced by: A 0004017113 | ||
| 024 | A 0004017113 | VALVE |
| Repalced by: A 0004013213 | ||
| 024 | A 0004013213 | VALVE |
| 27 DEGREES | ||
| 036 | A 0004010272 | NUT |
| VALVE TO DISC WHEEL | ||
| 048 | A 3854010013 | VALVE |
| EXTENSION | ||
| 048 | A 3854010113 | VALVE |
| EXTENSION | ||
| 072 | N 007757008600 | VALVE CAP |
| 084 | A 3854000124 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 084 | A 6174000024 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 084 | A 0004010672 | NUT |
| DISC WHEELS TO FRONT AND REAR AXLES | ||
| 089 | A 3354030130 | CRANK |
| 096 | A 3854000039 | BRACKET |
| Repalced by: A 3854000539 | ||
| 096 | A 3854000539 | SPARE WHEEL CARRIER |
| 108 | A 3854030003 | BEARING BRACKET |
| CRANK | ||
| 120 | N 000933006121 | SCREW |
| Repalced by: N 304017006020 | ||
| 120 | N 304017006020 | SCREW |
| BEARING BRACKET TO BRACKET | ||
| 132 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 132 | N 913004006001 | NUT |
| BEARING BRACKET TO BRACKET | ||
| 144 | A 3854030085 | WORM |
| Repalced by: A 6204030085 | ||
| 144 | A 6204030085 | WORM |
| 156 | A 3854030083 | STOP GEAR |
| Repalced by: A 6204030583 | ||
| 156 | A 6204030583 | STOP GEAR |
| 168 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 168 | N 083334008000 | WIRE CABLE |
| 172 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO WORM | ||
| 180 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 192 | N 002093031201 | DISC SPRING |
| WORM AND SHAFT TO BRACKET | ||
| 204 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 216 | N 001481008038 | CLAMPING SLEEVE |
| Repalced by: N 308752008000 | ||
| 216 | N 308752008000 | CLAMPING PIN |
| WORM AND SHAFT TO BRACKET | ||
| 228 | A 3854000020 | COVERING |
| PROTECTION PLATE TO BRACKET | ||
| 240 | N 000933006121 | SCREW |
| Repalced by: N 304017006020 | ||
| 240 | N 304017006020 | SCREW |
| PROTECTION PLATE TO BRACKET | ||
| 252 | N 009021006205 | WASHER |
| Repalced by: N 009021006208 | ||
| 252 | N 009021006208 | WASHER |
| PROTECTION PLATE TO BRACKET | ||
| 264 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 264 | N 913004006001 | NUT |
| PROTECTION PLATE TO BRACKET | ||
| 276 | A 3854000439 | BRACKET |
| SPARE WHEEL | ||
| 288 | N 007349019002 | WASHER |
| BRACKET TO SPARE WHEEL CARRIER | ||
| 300 | N 912004018101 | LOCK WASHER |
| BRACKET TO SPARE WHEEL CARRIER | ||
| 312 | N 000934018006 | NUT |
| BRACKET TO SPARE WHEEL CARRIER | ||
| 324 | N 000961012122 | SCREW |
| SPARE WHEEL CARRIER TO FRAME | ||
| 336 | N 910113012002 | NUT |
| SPARE WHEEL CARRIER TO FRAME | ||
| 348 | A 3814002639 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 360 | A 3874030074 | PIN |
| 372 | N 000094004065 | COTTER PIN |
| 384 | A 3859900023 | SCREW |
| Repalced by: A 6519900023 | ||
| 384 | A 6519900023 | SCREW |
| 396 | A 3874030319 | BASE BLOCK |
| 408 | N 912004016101 | LOCK WASHER |
| 420 | N 000934016011 | NUT |
| Repalced by: N 308673016001 | ||
| 420 | N 308673016001 | NUT |
| 432 | N 007346004016 | CLAMPING SLEEVE |
| 444 | A 3834000639 | SPARE WHEEL HOIST |
| 456 | A 3814030185 | WORM |
| Repalced by: A 6204030085 | ||
| 456 | A 6204030085 | WORM |
| 468 | A 3814030250 | BUSHING |
| 480 | N 001481006027 | CLAMPING SLEEVE |
| 492 | A 3834030183 | STOP GEAR |
| Repalced by: A 6204030383 | ||
| 492 | A 6204030383 | STOP GEAR |
| 504 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 504 | N 083334008000 | WIRE CABLE |
| 516 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 528 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 540 | N 001481008038 | CLAMPING SLEEVE |
| Repalced by: N 308752008000 | ||
| 540 | N 308752008000 | CLAMPING PIN |
| WORM AND SHAFT TO BRACKET | ||
| 8X50 MM | ||
| 552 | N 002093031201 | DISC SPRING |
| WORM AND SHAFT TO BRACKET | ||
| 564 | A 3854000020 | COVERING |
| PROTECTION PLATE TO BRACKET | ||
| 576 | N 000933006130 | SCREW |
| PROTECTION PLATE TO BRACKET | ||
| 588 | N 009021006205 | WASHER |
| Repalced by: N 009021006208 | ||
| 588 | N 009021006208 | WASHER |
| PROTECTION PLATE TO BRACKET | ||
| 600 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 600 | N 913004006001 | NUT |
| PROTECTION PLATE TO BRACKET | ||
| 612 | N 000933010128 | SCREW |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 624 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 624 | N 910113010000 | NUT |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 636 | A 3834030050 | BUSHING |
| AT SIDE MEMBER | ||
| 648 | A 3814030045 | CRANK |
| SPARE WHEEL HOIST | ||
| 660 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO BUSHING | ||
| 672 | N 007349021001 | WASHER |
| SPARE WHEEL TO BRACKET | ||
| 684 | N 912004020100 | LOCK WASHER |
| SPARE WHEEL TO BRACKET | ||
| 696 | N 000934020008 | NUT |
| Repalced by: N 308673020002 | ||
| 696 | N 308673020002 | NUT |
| Repalced by: N 308674020000 | ||
| 696 | N 308674020000 | NUT |
| SPARE WHEEL TO BRACKET | ||
| 708 | A 3529900802 | SCREW |
| SPARE WHEEL TO CROSS MEMBER | ||
| 708 | A 3609902201 | SCREW |
| Repalced by: A 3529900802 | ||
| 708 | A 3529900802 | SCREW |
| SPARE WHEEL TO CROSS MEMBER | ||
| 708 | N 000960012264 | SCREW |
| Repalced by: N 308765012003 | ||
| 708 | N 308765012003 | SCREW |
| SPARE WHEEL TO CROSS MEMBER | ||
| 720 | N 000440014100 | WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 720 | N 000440014100 | WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 732 | N 910113012002 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 732 | N 910113012002 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 744 | A 3814000044 | INTERMEDIATE PIECE |
| SPARE WHEEL TO CROSS MEMBER | ||
