Transporto priemonė: 1626 LS; VIN numerio dalis: 387212
Grupė: 26 TRANSMISSION
| # | Kodas | Pavadinimas |
|---|---|---|
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 719.0 | ||
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 719.5 | ||
| T YYYYYYYYYYYY | PART NAME MISSING | |
| FOR TRANSMISSION,SEE UNIT STANDARD VERSION,MODEL: | ||
| 719.2 | ||
| A 3872605539 | SHIFT LEVER | |
| Repalced by: A 3892606039 | ||
| A 3892606039 | SHIFT LEVER | |
| A 3852607439 | SHIFT LEVER | |
| Repalced by: A 3852607039 | ||
| 010 | A 3852607139 | SHIFT LEVER |
| Repalced by: A 3852607039 | ||
| 010 | A 3852607039 | SHIFT LEVER |
| 015 | A 3892606039 | SHIFT LEVER |
| A 3892606139 | SHIFT LEVER | |
| 020 | A 3359920203 | BUSHING |
| 025 | A 0009815531 | JOINT BEARING |
| Repalced by: A 0019813931 | ||
| 025 | A 0019813931 | JOINT BEARING |
| SHIFT LEVER | ||
| 025 | A 0009814531 | JOINT BEARING |
| SHIFT LEVER | ||
| 030 | N 000472042001 | LOCK RING |
| SHIFT LEVER | ||
| A 3852681074 | PIN | |
| Repalced by: A 3852681474 | ||
| 035 | A 3852681474 | PIN |
| SHIFT LEVER | ||
| 040 | A 3852680696 | BOOT |
| Repalced by: A 6202680196 | ||
| 040 | A 6202680196 | BOOT |
| SHIFT LEVER | ||
| A 3892605162 | BRACKET | |
| Repalced by: A 3892605262 | ||
| 045 | A 3892605262 | BRACKET |
| BRACKET TO CAB | ||
| A 3892685240 | BRACKET | |
| Repalced by: A 3892680240 | ||
| 050 | A 3892680240 | BRACKET |
| Repalced by: A 3892680440 | ||
| 050 | A 3892680440 | BRACKET |
| BRACKET TO CAB | ||
| 055 | N 913004008004 | NUT |
| Repalced by: N 913004008001 | ||
| 055 | N 913004008001 | NUT |
| BRACKET TO BRACKET | ||
| 060 | A 3852600057 | VALVE |
| (SHIFT LEVER VALVE) | ||
| A 0049974848 | SEAL RING | |
| 070 | A 3859970082 | HOSE |
| Repalced by: A 3019970682 | ||
| 070 | A 3019970682 | HOSE |
| Repalced by: A 3019971182 | ||
| 070 | A 3019971182 | HOSE |
| (PARTS KIT) | ||
| A 0012609957 | REPAIR KIT | |
| SHIFT LEVER VALVE | ||
| 075 | A 3602600040 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 075 | A 3602600140 | HANDLE |
| Repalced by: A 3432600040 | ||
| 075 | A 3432600040 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 085 | A 3852600140 | HANDLE |
| (GEARSHIFT LEVER KNOB) | ||
| 087 | A 3852670001 | SHIFT LEVER |
| Repalced by: A 6202680042 | ||
| 087 | A 6202680042 | KNOB |
| (SHIFT LEVER HANDLE) | ||
| 088 | A 0002670114 | CAP |
| Repalced by: A 6202680157 | ||
| 088 | A 6202680157 | COVER |
| LESS GEAR INDICATOR | ||
| 090 | N 000936010010 | NUT |
| GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER | ||
| 095 | A 3852680357 | COVER |
| SHIFT LEVER KNOB | ||
| 100 | A 3855840040 | DECALCOMANIA |
| NINE-SPEED,SHIFT LEVER KNOB | ||
| 100 | A 3855840140 | DECALCOMANIA |
| NINE-SPEED,SHIFT LEVER KNOB | ||
| A 3855840138 | GUMMED LABEL | |
| NINE-SPEED,ASHTRAY | ||
| A 3855840238 | GUMMED LABEL | |
| NINE-SPEED,ASHTRAY | ||
| 110 | A 3852603133 | SHIFTING ROD |
| FRONT | ||
| A 3852609333 | SHIFTING ROD | |
| FRONT | ||
| A 3852609333 | SHIFTING ROD | |
| FRONT | ||
| A 3892603733 | SHIFTING ROD | |
| FRONT | ||
| A 3852606033 | SHIFTING ROD | |
| FRONT | ||
| 112 | A 3852609433 | SHIFTING ROD |
| FRONT | ||
| 113 | A 3852607033 | SHIFTING ROD |
| (TELESCOPIC TUBE) | ||
| 113 | A 3852607033 | SHIFTING ROD |
| (TELESCOPIC TUBE) | ||
| 113 | A 3892600833 | SHIFTING ROD |
| (TELESCOPIC TUBE) | ||
| 113 | A 3852603882 | SHIFTING TUBE |
| (TELESCOPIC TUBE) | ||
| 113 | A 3852603882 | SHIFTING TUBE |
| (TELESCOPIC TUBE) | ||
| 113 | A 3852603882 | SHIFTING TUBE |
| (TELESCOPIC TUBE) | ||
| 114 | A 3852600689 | PULL ROD |
| 114 | A 3852600689 | PULL ROD |
| 114 | A 3892600089 | PULL ROD |
| A 3852600187 | PAWL | |
| MECHANICAL RELAESE | ||
| 115 | A 3852600387 | PAWL |
| Repalced by: A 6202600087 | ||
| 115 | A 6202600087 | PAWL |
| HYDRAULIC RELEASE | ||
| 116 | A 3359920203 | BUSHING |
| PAWL TO ROD END | ||
| A 6209920003 | BUSHING | |
| PAWL TO ROD END | ||
| A 6202680150 | BUSHING | |
| PAWL TO ROD END | ||
| A 3852680423 | YOKE | |
| MECHANICAL RELAESE | ||
| 118 | A 3852600534 | ROD END |
| HYDRAULIC RELEASE | ||
| 125 | A 3859930901 | SPRING |
| 127 | A 3859930020 | SPRING |
| PAWL TO ROD END | ||
| 128 | A 3859930120 | SPRING |
| PAWL TO ROD END | ||
| 130 | A 0009978648 | SEAL RING |
| 17.20 MM | ||
| 135 | A 0009978748 | SEAL RING |
| PULL ROD | ||
| 30.20 MM | ||
| 137 | A 0039970448 | SEAL RING |
| PULL ROD | ||
| 8.30 MM | ||
| 140 | A 3852680153 | SPACER TUBE |
| LONG | ||
| T YYYYYYYYYYYY | PART NAME MISSING | |
| SEE FIG. NO.: | ||
| 130 | ||
| 150 | N 000931010357 | SCREW |
| Repalced by: N 000933010192 | ||
| 150 | A 0019909404 | SCREW |
| PAWL TO ROD END | ||
| M10X75 | ||
| 155 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 155 | N 910113010000 | NUT |
| PAWL TO ROD END | ||
| 156 | A 3852600063 | SHIFTING CYLINDER |
| HYDRAULIC RELEASE | ||
| WABCO | ||
| 156 | A 3852600563 | SHIFTING CYLINDER |
| HYDRAULIC RELEASE | ||
| TECHNOMATIK | ||
| A 0069976748 | SEAL RING | |
| PISTON RINGS | ||
| TO 385 260 00 63 | ||
| A 0069976848 | SEAL RING | |
| SCREW FITTING | ||
| TO 385 260 00 63 | ||
| A 0019970641 | SEAL RING | |
| OUTSIDE | ||
| TO 385 260 00 63 | ||
| 157 | N 001444008234 | PIN |
| SHIFTING CYLINDER | ||
| 158 | N 001443008203 | PIN |
| Repalced by: N 001444008235 | ||
| 158 | N 001444008235 | PIN |
| SHIFTING CYLINDER | ||
| N 000094002059 | COTTER PIN | |
| SHIFTING CYLINDER | ||
| 160 | N 900055008002 | SPRING WASHER |
| SHIFTING CYLINDER | ||
| 162 | A 3852680776 | WASHER |
| FRONT SHIFTING ROD TO REAR SHIFTING ROD | ||
| 170 | A 3892608833 | SHIFTING ROD |
| REAR | ||
| A 3872601533 | SHIFTING ROD | |
| REAR | ||
| A 3892603533 | SHIFTING ROD | |
| REAR | ||
| A 3872607533 | SHIFTING ROD | |
| REAR | ||
| A 3872603033 | SHIFTING ROD | |
| REAR | ||
| A 3892609033 | SHIFTING ROD | |
| REAR | ||
| A 3892609933 | SHIFTING ROD | |
| Repalced by: A 3892601182 | ||
| A 3892601182 | SHIFTING TUBE | |
| REAR | ||
| 180 | A 3852680188 | CLAMPING PIECE |
| SHIFTING ROD TO UNIVERSAL JOINT | ||
| 185 | N 000933010202 | SCREW |
| Repalced by: N 304017010047 | ||
| 185 | N 304017010047 | SCREW |
| CLAMPING PIECE TO SHIFTING ROD | ||
| M10X35 | ||
| A 3312600138 | SHAFT | |
| SHIFTING ROD TO TRANSMISSION | ||
| 186 | A 3892609233 | SHIFTING ROD |
| SHIFTING ROD TO TRANSMISSION | ||
| 186 | A 3892609233 | SHIFTING ROD |
| SHIFTING ROD TO TRANSMISSION | ||
| 187 | N 000933008152 | SCREW |
| Repalced by: N 304017008027 | ||
| 187 | N 304017008027 | SCREW |
| SHIFTING TUBE TO TRANSMISSION | ||
| M 8X30 | ||
| 188 | N 913004008004 | NUT |
| Repalced by: N 913004008001 | ||
| 188 | N 913004008001 | NUT |
| SHIFTING TUBE TO TRANSMISSION | ||
| 197 | A 3852680153 | SPACER TUBE |
| SHIFTING TUBE TO SHIFT LEVER | ||
| A 0029971745 | SEAL RING | |
| Repalced by: A 0009978648 | ||
| 197B | A 0009978648 | SEAL RING |
| SHIFTING TUBE TO SHIFT LEVER | ||
| 198 | N 000931010357 | SCREW |
| Repalced by: N 000933010192 | ||
| 198 | A 0019909404 | SCREW |
| SHIFTING TUBE TO SHIFT LEVER | ||
| M10X75 | ||
| 199 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 199 | N 910113010000 | NUT |
| SHIFTING TUBE TO SHIFT LEVER | ||
| N 900055018001 | SPRING WASHER | |
| SHIFTING TUBE TO SHIFT LEVER | ||
| 200 | N 000933010105 | SCREW |
| FRONT SHIFTING ROD TO REAR SHIFTING ROD | ||
| M10X25 | ||
| 210 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 210 | N 910113010000 | NUT |
| FRONT SHIFTING ROD TO REAR SHIFTING ROD | ||
| A 3852680292 | RUBBER PAD | |
| Repalced by: A 3852680392 | ||
| A 3892687125 | TUBE | |
| BRACKET TO BRACKET | ||
| 220 | A 3852680392 | RUBBER PAD |
| BRACKET TO BRACKET | ||
| 225 | A 3892680525 | TUBE |
| BRACKET TO BRACKET | ||
| 230 | A 3852600562 | BRACKET |
| SHIFT LEVER | ||
| 228 | A 3852601962 | BRACKET |
| SHIFT LEVER | ||
| 235 | A 3852600962 | BRACKET |
| SHIFT LEVER | ||
| 238 | A 3852681640 | BRACKET |
| SHIFT LEVER | ||
| A 3852680192 | RUBBER PAD | |
| Repalced by: A 3852680492 | ||
| 240 | A 3852680492 | RUBBER PAD |
| BRACKET TO BRACKET | ||
| 242 | N 000931008047 | SCREW |
| Repalced by: N 304017008018 | ||
| 242 | N 304017008018 | SCREW |
| SHIFT LEVER | ||
| M8X35 | ||
| 244 | A 3852681950 | BUSHING |
| (SHIFT LEVER VALVE) | ||
| 250 | N 913004008004 | NUT |
| Repalced by: N 913004008001 | ||
| 250 | N 913004008001 | NUT |
| BRACKET TO BRACKET | ||
| N 007981003214 | SHEET METAL SCREW | |
| CAB | ||
| 255 | A 3859970086 | PLUG |
| 260 | A 3892685086 | RUBBER RING |
| SHIFT LEVER | ||
| 270 | A 3852680497 | BOOT |
| Repalced by: A 3892680097 | ||
| 270 | A 3892685197 | BOOT |
| Repalced by: A 3892680097 | ||
| 270 | A 3892680097 | BOOT |
| SHIFT LEVER | ||
| 300 | A 3892600062 | BRACKET |
| PNEUMATIC SHIFT MECHANISM | ||
| A 3892600262 | BRACKET | |
| PNEUMATIC SHIFT MECHANISM | ||
| A 3892600162 | BRACKET | |
| Repalced by: A 3892600262 | ||
| 305 | N 006798006103 | SERRATED WASHER |
| CAB FLOOR | ||
| 310 | N 000934006007 | NUT |
| CAB FLOOR | ||
| 315 | N 915017004101 | UNION NUT |
| LINE TO BRACKET | ||
| 317 | N 003861004001 | GLAND |
| LINE TO BRACKET | ||
| 325 | A 0009920605 | BUSHING |
| Repalced by: N 915062002000 | ||
| 325 | N 915062002000 | SLEEVE |
| LINE TO BRACKET | ||
| A 0009903563 | HOLLOW SCREW | |
| Repalced by: N 915047008100 | ||
| N 915047008202 | HOLLOW SCREW | |
| CONNECTION 23 | ||
| 330 | A 0019900170 | T-FITTING |
| N 915039008202 | HOLLOW SCREW FITTING | |
| 3/2-WAY | ||
| N 007603012405 | SEAL RING | |
| 3/2-WAY | ||
| A 0039979172 | FITTING | |
| (PARTS KIT),LINE RUPTURE | ||
| 335 | A 0089976082 | HOSE |
| Repalced by: A 0009872627 | ||
| 335 | A 0009872627 | PLASTIC PIPE |
| AIR RESERVOIR,SHIFT VALVE,CHECK VALVE, 3/2-WAY VALVE | ||
| 4X6 MM | ||
| A 0089979082 | HOSE | |
| FROM 3/2-WAY VALVE AT BRAKE BOOSTER TO CONTROL COCK | ||
| 8 MM | ||
| A 0039978972 | FITTING | |
| Repalced by: A 0029905971 | ||
| A 0029905971 | FITTING | |
| (PARTS KIT),LINE RUPTURE | ||
| 340 | N 040621006203 | INSULATING HOSE |
| RED | ||
| N 040621006235 | INSULATING HOSE | |
| BLUE | ||
| N 040621006204 | INSULATING HOSE | |
| YELLOW | ||
| N 915036006202 | HOLLOW SCREW | |
| LINE CONNECTIONS | ||
| N 007603010103 | SEAL RING | |
| Repalced by: N 007603010110 | ||
| N 007603010110 | SEAL RING | |
| LINE CONNECTIONS | ||
| 350 | N 915017006100 | UNION NUT |
| LINE CONNECTIONS | ||
| N 003870006108 | UNION NUT | |
| LINE CONNECTIONS | ||
| 360 | N 003861006007 | GLAND |
| Repalced by: A 0019901667 | ||
| 360 | A 0019901667 | SEAL CONE |
| LINE CONNECTIONS | ||
| N 003861006008 | GLAND | |
| LINE CONNECTIONS | ||
| 370 | A 0009920205 | BUSHING |
| Repalced by: N 915062004000 | ||
| 370 | A 0009920105 | BUSHING |
| Repalced by: N 915062004000 | ||
| 370 | N 915062004000 | SLEEVE |
| LINE CONNECTIONS | ||
| 375 | A 0009903888 | BANJO UNION |
| Repalced by: N 915052004006 | ||
| 375 | N 915052004015 | BANJO UNION |
| HOSE WIDTH, / I.D., | ||
| 4/12 MM | ||
| 375 | A 0009906688 | BANJO UNION |
| Repalced by: N 915052006013 | ||
| 375 | N 915052006013 | BANJO UNION |
| HOSE WIDTH, / I.D., | ||
| 6/12 | ||
| 380 | N 915052004016 | BANJO UNION |
| HOSE WIDTH, / I.D., | ||
| 4/10 MM | ||
| 385 | N 915039008202 | HOLLOW SCREW FITTING |
| LINE CONNECTIONS | ||
| 390 | N 915036006202 | HOLLOW SCREW |
| LINE CONNECTIONS | ||
| 395 | N 007603012405 | SEAL RING |
| LINE CONNECTIONS | ||
| 400 | N 007603010103 | SEAL RING |
| Repalced by: N 007603010110 | ||
| 400 | N 007603010110 | SEAL RING |
| LINE CONNECTIONS | ||
| 410 | A 0019977290 | LOOM TIE |
| Repalced by: A 0019978390 | ||
| 410 | A 0019978390 | LOOM TIE |
| LINE MOUNTING | ||
| 280 MM | ||
| 410 | A 0019978490 | LOOM TIE |
| LINE MOUNTING | ||
| 376 MM | ||
| 415 | A 0019972872 | FITTING |
| Repalced by: A 0039979072 | ||
| 415 | A 0039979072 | FITTING |
| Repalced by: A 0029906071 | ||
| 415 | A 0029906071 | FITTING |
| AT VALVE | ||
| 420 | N 007603012405 | SEAL RING |
| AT VALVE | ||
| 425 | A 0002602457 | VALVE |
| Repalced by: A 0002608157 | ||
| 425 | A 0002608157 | VALVE |
| (SOLENOID VALVE BATTERY) 24 V | ||
| 427 | A 0015869643 | REPAIR KIT |
| HERION,94 172032/0711/24V | ||
| 427 | A 0015861626 | REPAIR KIT |
| HERION,94 172037/0734/24V | ||
| 430 | A 3872640041 | BRACKET |
| AT VALVE | ||
| 430 | A 3872640641 | BRACKET |
| AT VALVE | ||
| 440 | N 000931006114 | SCREW |
| Repalced by: N 304017006012 | ||
| 440 | N 304017006012 | SCREW |
| SOLENOID VALVE TO RETAINING PLATE | ||
| M 6X30 | ||
| 445 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 445 | N 913004006001 | NUT |
| SOLENOID VALVE TO RETAINING PLATE | ||
| 450 | A 3384310051 | SPACER RING |
| RETAINING PLATE TO SHIFTER COVER | ||
| 460 | N 912004010102 | LOCK WASHER |
| RETAINING PLATE TO SHIFTER COVER | ||
| 465 | N 000931010348 | SCREW |
| RETAINING PLATE TO SHIFTER COVER | ||
| M 10X100 | ||
| 465 | N 304017010027 | SCREW |
| RETAINING PLATE TO SHIFTER COVER | ||
| M 10X80 | ||
| 471 | A 0002680759 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.80 MM | ||
| 471 | A 0002680759 | SEAL RING |
| IDLE POSITION INDICATOR SWITCH TO TRANSMISSION CASE OVER | ||
| 1.80 MM | ||
| 471 | A 0002680459 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.60 MM | ||
| 471 | A 0002680359 | SEAL RING |
| Repalced by: N 007603018100 | ||
| 471 | N 007603018100 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.50 MM | ||
| 471 | N 007603018100 | SEAL RING |
| GROUP SHIFT INDICATOR SWITCH TO TRANSMISSION CASE | ||
| 1.50 MM | ||
| 471 | A 0002680259 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.40 MM | ||
| 471 | A 0002680159 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.20 MM | ||
| 471 | A 0002680559 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 1.00 MM | ||
| 471 | A 0002680559 | SEAL RING |
| IDLE-INDICATOR-SWITCH THREADED BUSHING | ||
| 1.00 MM | ||
| 471 | A 0002680659 | SEAL RING |
| IDLE POSITION SWITCH TO TRANSMISSION CASE COVER; AS REQUIRED | ||
| 0.80 MM | ||
| 478 | A 0005454214 | SWITCH |
| Repalced by: A 0015458214 | ||
| 478 | A 0015458214 | SWITCH |
| NEUTRAL POSITION | ||
| 478 | A 0015454714 | SWITCH |
| NEUTRAL POSITION | ||
| 478 | A 0005454214 | SWITCH |
| Repalced by: A 0005455209 | ||
| 486 | A 0005455209 | SWITCH |
| Repalced by: A 0005457909 | ||
| 486 | A 0005457909 | SWITCH |
| Repalced by: A 0005459009 | ||
| 486 | A 0005459009 | SWITCH |
| Repalced by: A 0015451109 | ||
| 486 | A 0015451109 | SWITCH |
| Repalced by: A 0015452709 | ||
| 486 | A 0015452709 | SWITCH |
| NEUTRAL POSITION | ||
| 492 | A 0002684674 | PIN |
| IDLE POSITION INDICATOR SWITCH CONTROL | ||
| 500 | A 0002610131 | THREADED BUSHING |
| IDLE POSITION INDICATOR SWITCH TO TRANSMISSION CASE OVER | ||
| 507 | A 0002681759 | SEAL RING |
| IDLE POSITION SWITCH TO THREADED BUSHING; AS REQUIRED | ||
| 2.40 MM | ||
| 507 | A 0002681659 | SEAL RING |
| IDLE POSITION SWITCH TO THREADED BUSHING; AS REQUIRED | ||
| 2.20 MM | ||
| 507 | A 0002681559 | SEAL RING |
| IDLE POSITION SWITCH TO THREADED BUSHING; AS REQUIRED | ||
| 2.00 MM | ||
| 514 | A 0015453414 | SWITCH |
| Repalced by: A 0025458114 | ||
| 514 | A 0025458114 | SWITCH |
| Repalced by: A 0035451614 | ||
| 514 | A 0035451614 | SWITCH |
| GEAR CLUSTER INDICATION | ||
© 2010-2013 UAB "RPV" Paslaugų teikimo sąlygos - Privatumo politika - Kopijuoti ir naudoti komerciniais tikslais draudžiama
