Transporto priemonė: 1928 S MBSA; VIN numerio dalis: 621111
Grupė: 47 FUEL SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3874702301 | FUEL TANK |
| 300 L | ||
| 010 | A 0004717930 | FILLER CAP |
| Repalced by: A 0004700305 | ||
| 010 | A 0004718030 | FILLER CAP |
| Repalced by: A 0004700305 | ||
| 010 | A 0004700305 | FILLER CAP |
| 010 | A 0004700105 | FILLER CAP |
| Repalced by: A 0004700305 | ||
| 015 | A 3049970340 | SEAL RING |
| 020 | A 3034700031 | CHAIN |
| 025 | A 0055424117 | SENDER UNIT |
| Repalced by: A 0085428317 | ||
| 025 | A 0085428317 | SENDER UNIT |
| FUEL GAUGE | ||
| 030 | A 0004710235 | FUEL STRAINER |
| AT TANK | ||
| 035 | A 0119970745 | SEAL RING |
| FUEL GAUGE SENDER UNIT TO FUEL TANK | ||
| 040 | N 007603014405 | SEAL RING |
| AT TANK | ||
| 045 | N 007604014106 | SCREW PLUG |
| AT TANK | ||
| 050 | A 3874702142 | SUPPORT |
| FRONT TANK | ||
| 050 | A 3874701442 | SUPPORT |
| REAR TANK | ||
| 055 | A 3874750519 | BASE |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| 060 | N 007349015003 | WASHER |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| 065 | N 000961014054 | SCREW |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| M 14X1.5X45 | ||
| 070 | N 000960014167 | SCREW |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| M 14X1.5X50 | ||
| 075 | N 912004014100 | LOCK WASHER |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| 080 | N 913004014002 | NUT |
| CONSOLE TO RIGHT SIDE MEMBER | ||
| 085 | A 3874700240 | STRAP |
| FUEL TANK TO CONSOLE | ||
| 090 | N 001443016203 | PIN |
| STRAP TO SUPPORT | ||
| 095 | N 000094004051 | COTTER PIN |
| STRAP TO SUPPORT | ||
| 100 | N 000934012022 | NUT |
| STRAP TO SUPPORT | ||
| 105 | A 3634750220 | PAD |
| FUEL TANK TO CONSOLE | ||
| 110 | A 3634750320 | PAD |
| STRAP | ||
| 115 | A 0089975482 | HOSE |
| FEED & RETURN | ||
| 8X11 MM | ||
| 120 | A 0089979082 | HOSE |
| AERATION | ||
| 6X8 MM | ||
| 125 | A 0039978972 | FITTING |
| Repalced by: A 0029905971 | ||
| 125 | A 0029905971 | FITTING |
| (PARTS KIT),LINE RUPTURE | ||
| 130 | A 3054760126 | HOSE |
| FEED LINE AND RETURN LINE | ||
| 135 | A 0029978790 | CLIP |
| FEED LINE AND RETURN LINE | ||
| 140 | N 916026010000 | CLAMP |
| FUEL LINE TO SENDER UNIT | ||
| 145 | N 040621011200 | INSULATING HOSE |
| FEED LINE | ||
| 150 | N 915052008016 | BANJO UNION |
| FEED LINE | ||
| 155 | A 3879900078 | CONNECTOR |
| Repalced by: N 915062008000 | ||
| 155 | N 915062008000 | SLEEVE |
| FUEL LINE | ||
| 160 | N 915017010201 | UNION NUT |
| RETURN LINE | ||
| 165 | A 0019974972 | FITTING |
| RETURN LINE | ||
| 170 | A 3854760836 | BRACKET |
| LINE MOUNTING | ||
| 175 | A 3854760036 | BRACKET |
| Repalced by: A 6205240340 | ||
| 175 | A 6205240340 | BRACKET |
| LINE MOUNTING | ||
| 180 | A 0019978490 | LOOM TIE |
| FUEL LINE | ||
| 376 MM | ||
| 180 | A 0019978390 | LOOM TIE |
| FUEL LINE | ||
| 280 MM | ||
| 185 | N 915036010204 | HOLLOW SCREW |
| FUEL LINE TO FEED PUMP | ||
| 190 | N 007603014405 | SEAL RING |
| FUEL LINE TO FEED PUMP | ||
| 195 | A 3229971581 | GROMMET |
| FUEL LINE TO SIDE MEMBER | ||
| A 3549970081 | GROMMET | |
| FUEL LINE TO SIDE MEMBER | ||
| 32/27 MM | ||
| A 6209971081 | GROMMET | |
| FUEL LINE TO SIDE MEMBER | ||
