Transporto priemonė: 1935 S; VIN numerio dalis: 646123
Grupė: 41 PROPELLER SHAFT
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 3954104702 | PROPELLER SHAFT |
| FROM TRANSMISSION TO TRANSFER CASE | ||
| 650 MM | ||
| 009 | A 3954110911 | DRIVE FLANGE |
| Repalced by: A 3954111011 | ||
| 009 | A 3954111011 | DRIVE FLANGE |
| FROM TRANSMISSION TO TRANSFER CASE | ||
| 013 | A 6204100031 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9404100031 | ||
| 013 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 017 | N 071412008302 | GREASE NIPPLE |
| 021 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2,00 MM | ||
| 021 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2,10 MM | ||
| 021 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2,20 MM | ||
| 025 | N 000960014237 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 029 | N 912004014100 | LOCK WASHER |
| PROPELLER SHAFT TO TRANSMISSION AND TO TRANSFER CASE | ||
| 033 | N 000934014020 | NUT |
| PROPELLER SHAFT TO TRANSMISSION AND TO TRANSFER CASE | ||
| 037 | A 3854105407 | PROPELLER SHAFT |
| FROM TRANSFER CASE TO FRONT AXLE | ||
| 1400 MM | ||
| 041 | A 3854111711 | DRIVE FLANGE |
| 045 | A 3814100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9734100031 | ||
| 045 | A 9734100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 049 | N 071412008302 | GREASE NIPPLE |
| 053 | A 0069940841 | LOCK |
| AS REQUIRED | ||
| 1.70 MM | ||
| 053 | A 0069941241 | LOCK |
| AS REQUIRED | ||
| 1,80 MM | ||
| 053 | A 0069941441 | LOCK |
| AS REQUIRED | ||
| 1,85 MM | ||
| A 3954110059 | SEAL RING | |
| PROTECTIVE TUBE | ||
| 105X17 MM | ||
| A 0004110159 | SEAL RING | |
| PROTECTIVE TUBE | ||
| 102.5X22 MM | ||
| 057 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 057 | N 071412008102 | GREASE NIPPLE |
| 061 | A 3609901901 | SCREW |
| Repalced by: A 3609903001 | ||
| 061 | A 3609903001 | SCREW |
| PROPELLER SHAFT TO TRANSFER CASE AND TO FRONT AXLE | ||
| 065 | N 912004012100 | LOCK WASHER |
| PROPELLER SHAFT TO TRANSFER CASE AND TO FRONT AXLE | ||
| 069 | N 000934012034 | NUT |
| PROPELLER SHAFT TO TRANSFER CASE AND TO FRONT AXLE | ||
| 072 | A 3954101304 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1616 MM | ||
| 072 | A 3954101104 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1503 MM | ||
| 072 | A 3954101504 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1564 MM | ||
| 072 | A 3954101604 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1446 MM | ||
| 075 | A 3954101404 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE SHAFT BEARING I | ||
| 1312 MM | ||
| 078 | A 3954102004 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING I TO INTERMEDIATE BEARING II | ||
| 872 MM | ||
| 081 | A 3954110811 | DRIVE FLANGE |
| 084 | A 6204100031 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9404100031 | ||
| 084 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 087 | N 071412008302 | GREASE NIPPLE |
| 090 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 090 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 090 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 093 | A 3894130061 | PROTECTIVE CAP |
| 093 | A 3954130061 | PROTECTIVE CAP |
| 096 | N 912004016101 | LOCK WASHER |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 099 | N 000934016013 | NUT |
| Repalced by: N 308673016001 | ||
| 099 | N 308673016001 | NUT |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 102 | A 3954100022 | INTERMEDIATE BEARING |
| Repalced by: A 3954100622 | ||
| 102 | A 3954100622 | INTERMEDIATE BEARING |
| Repalced by: A 6554100022 | ||
| 102 | A 6554100022 | INTERMEDIATE BEARING |
| PROPELLER SHAFT | ||
| 105 | A 0029819225 | BALL BEARING |
| 105 | A 0029819325 | BALL BEARING |
| 108 | N 912009110200 | SNAP RING |
| 111 | A 3874130261 | PROTECTIVE CAP |
| A 6554110052 | SPACER WASHER | |
| PROPELLER SHAFT BEARING | ||
| 114 | A 3954100130 | CENTERING FLANGE |
| Repalced by: A 3874110446 | ||
| 114 | A 3874110446 | FLANGE |
| PROPELLER SHAFT BEARING | ||
| 117 | A 3894130061 | PROTECTIVE CAP |
| 117 | A 3954130061 | PROTECTIVE CAP |
| 120 | A 3899900019 | SCREW |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 123 | A 3894110062 | THRUST WASHER |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 126 | A 6204132942 | BRACKET |
| PROPELLER SHAFT BEARING I,LEFT | ||
| 126 | A 6204136342 | BRACKET |
| PROPELLER SHAFT BEARING II,LEFT | ||
| 126 | A 6204136342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 126 | A 6204138342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 126 | A 6204134342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 126 | A 6204136142 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 129 | A 6204132842 | BRACKET |
| PROPELLER SHAFT BEARING I,RIGHT | ||
| 129 | A 6204136242 | BRACKET |
| PROPELLER SHAFT BEARING II,RIGHT | ||
| 129 | A 6204136242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 129 | A 6204138242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 129 | A 6204134242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 129 | A 6204136042 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 132 | N 000961012106 | SCREW |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 135 | N 912004012100 | LOCK WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 138 | A 3299900040 | WASHER |
| Repalced by: A 1232420366 | ||
| 138 | A 1232420366 | WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 141 | A 3954130011 | REINFORCEMENT |
| PROPELLER SHAFT BEARING | ||
| 144 | N 000961012106 | SCREW |
| REINFORCEMENT TO BRACKET | ||
| 147 | N 913004012009 | NUT |
| Repalced by: N 910113012003 | ||
| 147 | N 910113012003 | NUT |
| REINFORCEMENT TO BRACKET | ||
| 150 | N 000961012108 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 156 | A 3299900040 | WASHER |
| Repalced by: A 1232420366 | ||
| 156 | A 1232420366 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| 162 | N 913004012009 | NUT |
| Repalced by: N 910113012003 | ||
| 162 | N 910113012003 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 168 | A 3954100202 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1183 MM | ||
| 168 | A 6204100302 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1537 MM | ||
| 168 | A 6234100002 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1098 MM | ||
| 170 | A 3954100102 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING II TO REAR AXLE | ||
| 1618 MM | ||
| 174 | A 6204100302 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1537 MM | ||
| 174 | A 6204100402 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1798 MM | ||
| 174 | A 3954103102 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 2105 MM | ||
| 174 | A 6204100102 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1688 MM | ||
| 174 | A 3954101802 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1998 MM | ||
| 177 | A 3954102302 | PROPELLER SHAFT |
| FROM TRANSFER CASE TO REAR AXLE | ||
| 899 MM | ||
| 177 | A 3954100202 | PROPELLER SHAFT |
| FROM TRANSFER CASE TO REAR AXLE | ||
| 1183 MM | ||
| 180 | A 3954110811 | DRIVE FLANGE |
| 186 | A 6204100031 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9404100031 | ||
| 186 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 192 | N 071412008302 | GREASE NIPPLE |
| 198 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 198 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 198 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| A 3954110059 | SEAL RING | |
| PROTECTIVE TUBE | ||
| 105X17 MM | ||
| A 0004110159 | SEAL RING | |
| PROTECTIVE TUBE | ||
| 102.5X22 MM | ||
| 204 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 204 | N 071412008102 | GREASE NIPPLE |
| 210 | A 0029909901 | SCREW |
| Repalced by: A 3959900501 | ||
| 210 | A 3959900501 | SCREW |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 210 | A 3959900501 | SCREW |
| PROPELLER SHAFT TO REAR AXLE | ||
| 216 | N 912004016101 | LOCK WASHER |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 216 | N 912004016101 | LOCK WASHER |
| PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE | ||
| 222 | N 000934016013 | NUT |
| Repalced by: N 308673016001 | ||
| 222 | N 308673016001 | NUT |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 222 | N 308673016001 | NUT |
| PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE | ||
