Transporto priemonė: 2220 L; VIN numerio dalis: 619402
Grupė: 25 CLUTCH
| # | Kodas | Pavadinimas |
|---|---|---|
| 009 | A 0022507504 | CLUTCH PRESSURE PLATE |
| Repalced by: A 0042502404 | ||
| 009 | A 0042502404 | CLUTCH PRESSURE PLATE |
| 015 | A 0032502504 | CLUTCH PRESSURE PLATE |
| 015 | A 0032503304 | CLUTCH PRESSURE PLATE |
| 021 | A 0002520727 | SPRING |
| SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING | ||
| 021 | A 0002523927 | SPRING |
| SUSPENDED BELOW LEAF SPRING | ||
| 027 | A 0002523227 | SPRING |
| SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING | ||
| 027 | A 0002524027 | SPRING |
| SUSPENDED BELOW LEAF SPRING | ||
| 033 | A 0002520412 | PRESSURE PLATE |
| 033 | A 0002524912 | PRESSURE PLATE |
| 039 | A 0002524613 | RELEASE LEVER |
| 045 | A 0002520616 | SPINDLE |
| FOR RELEASE LEVERS | ||
| 045 | A 0002522216 | SPINDLE |
| FOR RELEASE LEVERS | ||
| 051 | A 0002522816 | SPINDLE |
| FOR BRACKETS | ||
| 057 | A 0002520118 | ROLLER |
| FOR BEDDING THE LEVERS IN BRACKETS | ||
| 063 | A 0002520614 | BRACKET |
| FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE | ||
| 069 | N 006799007007 | LOCK PLATE |
| 075 | A 0002520535 | SLEEVE |
| 081 | A 0002522145 | FLANGE |
| 081 | A 0002521745 | FLANGE |
| Repalced by: A 0002521245 | ||
| 081 | A 0002521245 | FLANGE |
| 087 | A 0002524420 | PRESSURE SPRING |
| SPRING STEEL WIRE DIA., | ||
| 4.00 MM | ||
| 093 | A 0002524320 | PRESSURE SPRING |
| SPRING STEEL WIRE DIA., | ||
| 3.75 MM | ||
| 093 | A 0002524320 | PRESSURE SPRING |
| SPRING STEEL WIRE DIA., | ||
| 3.75 MM | ||
| 093 | A 0002524820 | PRESSURE SPRING |
| SPRING STEEL WIRE DIA., | ||
| 3.50 MM | ||
| 099 | A 0002520519 | LEAF SPRING |
| THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING | ||
| 099 | A 0002523719 | LEAF SPRING |
| THIGH SPRING SUSPENDED BELOW LEAF SPRING | ||
| 105 | A 0002523072 | NUT |
| 111 | A 0002521073 | LOCK |
| 117 | A 0002522971 | SCREW |
| 123 | N 000931008248 | SCREW |
| Repalced by: N 304017008053 | ||
| 123 | N 304017008053 | SCREW |
| CLUTCH TO FLYWHEEL | ||
| 129 | N 000931010268 | SCREW |
| Repalced by: N 304017010050 | ||
| 129 | N 304017010050 | SCREW |
| CLUTCH TO FLYWHEEL | ||
| M 10X70 | ||
| 129 | N 000931010239 | SCREW |
| CLUTCH TO FLYWHEEL | ||
| M 10X80 | ||
| 135 | N 912004008102 | LOCK WASHER |
| CLUTCH TO FLYWHEEL | ||
| 141 | N 912004010102 | LOCK WASHER |
| CLUTCH TO FLYWHEEL | ||
| 147 | A 0072507403 | CLUTCH DISC |
| ASBESTOS-FREE LINING | ||
| 147 | A 0052503903 | CLUTCH DISC |
| 147 | A 0052504003 | CLUTCH DISC |
| 153 | A 0072500903 | CLUTCH DISC |
| ASBESTOS-FREE LINING | ||
| 153 | A 0072501003 | CLUTCH DISC |
| ASBESTOS-FREE LINING | ||
| 153 | A 0062504503 | CLUTCH DISC |
| Repalced by: A 0072500803 | ||
| 153 | A 0072500803 | CLUTCH DISC |
| 153 | A 0062504603 | CLUTCH DISC |
| 153 | A 0072506803 | CLUTCH DISC |
| ASBESTOS-FREE LINING | ||
| 153 | A 0072506903 | CLUTCH DISC |
| ASBESTOS-FREE LINING | ||
| 153 | A 0072506703 | CLUTCH DISC |
| 157 | A 0002523419 | LEAF SPRING |
| Repalced by: A 0002524419 | ||
| 157 | A 0002524419 | LEAF SPRING |
| 161 | A 0002520419 | LEAF SPRING |
| Repalced by: A 0002523819 | ||
| 161 | A 0002523819 | LEAF SPRING |
| 161 | A 0002523319 | LEAF SPRING |
| Repalced by: A 0002523919 | ||
| 161 | A 0002523919 | LEAF SPRING |
| 165 | A 0002522075 | RIVET |
| LEAF SPRING TO CLUTCH DISC | ||
| 5X6 MM | ||
| 165 | A 0002523975 | RIVET |
| LEAF SPRING TO CLUTCH DISC | ||
| 6X6 MM | ||
| 169 | A 0012524810 | CLUTCH LINING |
| ASBESTOS-FREE | ||
| 169 | A 0002528810 | CLUTCH LINING |
| Repalced by: A 0012524310 | ||
| 169 | A 0012524310 | CLUTCH LINING |
| 173 | A 0012523210 | CLUTCH LINING |
| ASBESTOS-FREE | ||
| 173 | A 0012522910 | CLUTCH LINING |
| 173 | A 0012523310 | CLUTCH LINING |
| Repalced by: A 0012528310 | ||
| 173 | A 0012528310 | CLUTCH LINING |
| Repalced by: A 0022520010 | ||
| 173 | A 0022520010 | CLUTCH LINING |
| ASBESTOS-FREE | ||
| 173 | A 0012522010 | CLUTCH LINING |
| 177 | A 0002521275 | RIVET |
| Repalced by: A 0002524375 | ||
| 177 | A 0002524375 | RIVET |
| LINING WITH INTERMEDIATE SPRING | ||
| 177 | A 0002524375 | RIVET |
| LINING WITH INTERMEDIATE SPRING | ||
| A 0002521475 | RIVET | |
| Repalced by: A 0002523875 | ||
| A 0002523875 | RIVET | |
| LINING WITH CLUTCH DISC | ||
| A 0002523875 | RIVET | |
| LINING WITH CLUTCH DISC | ||
| 177 | A 0002523375 | RIVET |
| Repalced by: A 0002523775 | ||
| 177 | A 0002523775 | RIVET |
| Repalced by: A 0002524675 | ||
| 177 | A 0002524675 | RIVET |
| Repalced by: A 0002524875 | ||
| 177 | A 0002524875 | RIVET |
| LINING WITH CLUTCH DISC AND INTERMEDIATE SPRING | ||
| 183 | A 6152510001 | BELL HOUSING |
| Repalced by: A 6152512301 | ||
| 183 | A 6152512301 | BELL HOUSING |
| Repalced by: A 6152511301 | ||
| 183 | A 6152511301 | BELL HOUSING |
| 189 | A 6202510601 | BELL HOUSING |
| Repalced by: A 6202510701 | ||
| 189 | A 6202510701 | BELL HOUSING |
| Repalced by: A 6202511601 | ||
| 189 | A 6202511601 | BELL HOUSING |
| N 000961018038 | SCREW | |
| BELL HOUSING | ||
| N 007603018104 | SEAL RING | |
| BELL HOUSING | ||
| N 000908020001 | SCREW PLUG | |
| BELL HOUSING | ||
| TO 620 251 07 01,620 251 16 01 | ||
| 195 | A 6202500214 | SHAFT |
| (PARTS KIT),RELEASE SHAFT | ||
| A 6202540207 | SHAFT | |
| (CLUTCH RELEASE SHAFT) | ||
| 201 | N 914112010025 | SCREW |
| CLUTCH RELEASE SHAFT TO BELL HOUSING | ||
| 207 | A 6152500213 | RELEASE LEVER |
| Repalced by: A 6152540208 | ||
| 207 | A 6152540208 | RELEASE LEVER |
| Repalced by: A 6152540708 | ||
| 207 | A 6152540708 | RELEASE LEVER |
| 213 | A 6202500413 | RELEASE LEVER |
| Repalced by: A 6202540308 | ||
| 213 | A 6202540308 | RELEASE LEVER |
| Repalced by: A 6202540508 | ||
| 213 | A 6202540508 | RELEASE LEVER |
| Repalced by: A 6202540708 | ||
| 213 | A 6202540708 | RELEASE LEVER |
| A 0012540235 | BEARING | |
| RELEASE LEVER | ||
| A 0002540335 | BEARING | |
| RELEASE LEVER | ||
| 219 | A 0099810410 | NEEDLE BEARING |
| RELEASE LEVER | ||
| 225 | A 0079978847 | SEAL RING |
| RELEASE LEVER | ||
| 231 | N 001481005044 | CLAMPING SLEEVE |
| RELEASE LEVER TO SHAFT | ||
| 237 | N 000933010145 | SCREW |
| BELL HOUSING TO FLYWHEEL HOUSING | ||
| 243 | N 000931010264 | SCREW |
| BELL HOUSING TO TIMING GEAR CASE | ||
| 249 | N 000125010518 | WASHER |
| Repalced by: N 000125010532 | ||
| 249 | N 000125010532 | WASHER |
| BELL HOUSING TO TIMING GEAR CASE | ||
| 255 | A 0002507015 | RELEASE BEARING |
| 261 | A 0002507615 | RELEASE BEARING |
| 267 | A 6169930025 | SPRING |
| Repalced by: A 6799930025 | ||
| 267 | A 6799930025 | SPRING |
| RELEASE LEVER TO RELEASE BEARING | ||
| 273 | A 6209930125 | SPRING |
| RELEASE LEVER TO RELEASE BEARING | ||
| 285 | A 3649970082 | HOSE |
| RELEASE BEARING LUBRICATION | ||
| 285 | A 3205730036 | HOSE |
| Repalced by: A 0005732636 | ||
| 285 | A 0005732636 | HOSE |
| RELEASE BEARING LUBRICATION | ||
| 287 | A 6209970288 | GREASE NIPPLE |
| (PARTS KIT) RELEASE BEARING LUBRICATION | ||
| 289 | N 071428004102 | SCREW-IN FITTING |
| RELEASE BEARING LUBRICATION | ||
| 291 | N 003871004102 | UNION SCREW |
| RELEASE BEARING LUBRICATION | ||
| 297 | N 003862004001 | DOUBLE TAPER RING |
| RELEASE BEARING LUBRICATION | ||
| 315 | A 3872510108 | INTERMEDIATE PIECE |
| Repalced by: A 6209970088 | ||
| 315 | A 6209970088 | GREASE NIPPLE |
| RELEASE BEARING LUBRICATION | ||
| 321 | N 003411002001 | GREASE CUP |
| Repalced by: A 6209880135 | ||
| 321 | A 6209880135 | CAP |
| RELEASE BEARING LUBRICATION | ||
| 323 | N 912004014100 | LOCK WASHER |
| RELEASE BEARING LUBRICATION | ||
| 325 | N 000936014010 | NUT |
| Repalced by: N 308675014000 | ||
| 325 | N 308675014000 | NUT |
| Repalced by: N 308675014002 | ||
| 325 | N 308675014002 | NUT |
| RELEASE BEARING LUBRICATION | ||
| 327 | A 0009968740 | ROD END |
| CLUTCH ACTUATION | ||
| A 6202950274 | PIN | |
| CLUTCH ACTUATION | ||
| 333 | A 6202560074 | PIN |
| ROD END TO RELEASE LEVER | ||
| 339 | A 0019970041 | SEAL RING |
| Repalced by: A 0019972141 | ||
| 339 | A 0019972141 | SEAL RING |
| ROD END TO RELEASE LEVER | ||
| 345 | N 000471012001 | LOCK RING |
| ROD END TO RELEASE LEVER | ||
| 351 | A 0012954507 | SLAVE CYLINDER |
| Repalced by: A 0012955407 | ||
| 351 | A 0012955407 | SLAVE CYLINDER |
| Repalced by: A 0012959607 | ||
| 351 | A 0012959607 | SLAVE CYLINDER |
| CLUTCH ACTUATION | ||
| 351 | A 0012954407 | SLAVE CYLINDER |
| CLUTCH ACTUATION | ||
| A 0002950460 | SEAL RING | |
| Repalced by: A 0002902467 | ||
| 357 | A 0004310265 | VALVE |
| Repalced by: A 3075530107 | ||
| 357 | A 3075530107 | VALVE |
| BREATHER | ||
| 363 | A 3164210187 | PROTECTIVE CAP |
| Repalced by: A 0004210887 | ||
| 363 | A 0004210887 | PROTECTIVE CAP |
| Repalced by: A 0004217187 | ||
| 363 | A 0004217187 | PROTECTIVE CAP |
| 369 | A 0002954783 | BOOT |
| Repalced by: A 0002955983 | ||
| 369 | A 0002955383 | BOOT |
| Repalced by: A 0002955983 | ||
| 369 | A 0002955983 | BOOT |
| 369 | A 0002954883 | BOOT |
| Repalced by: A 0002956083 | ||
| 369 | A 0002956083 | BOOT |
| 375 | A 0002901167 | REPAIR KIT |
| CLUTCH SLAVE CYLINDER | ||
| TO 001 295 45 07;FAG,KN 28022 A 1 F | ||
| 375 | A 0002902467 | REPAIR KIT |
| Repalced by: A 0002904567 | ||
| 375 | A 0002904567 | REPAIR KIT |
| CLUTCH SLAVE CYLINDER | ||
| TO 001 295 54 07;FAG,KN 28022 C 1 F, | ||
| T YYYYYYYYYYYY | PART NAME MISSING | |
| 0012959607;FAG,KN28022 D1F | ||
| 375 | A 0002901267 | REPAIR KIT |
| Repalced by: A 0002904067 | ||
| 375 | A 0002904067 | REPAIR KIT |
| CLUTCH SLAVE CYLINDER | ||
| 381 | A 6152950045 | FLANGE |
| CLUTCH SLAVE CYLINDER TO BELL HOUSING | ||
| 387 | N 000931010264 | SCREW |
| CLUTCH SLAVE CYLINDER TO BELL HOUSING | ||
| M 10X45 | ||
| 387 | N 000931010439 | SCREW |
| CLUTCH SLAVE CYLINDER TO BELL HOUSING | ||
| M 10X170 | ||
| 387 | N 000933010105 | SCREW |
| CLUTCH SLAVE CYLINDER TO BELL HOUSING | ||
| 393 | N 000960018111 | SCREW |
| BELL HOUSING TO TRANSMISSION | ||
| 399 | N 912004018101 | LOCK WASHER |
| BELL HOUSING TO TRANSMISSION | ||
| 405 | A 0065420717 | SENDER UNIT |
| Repalced by: A 0065427117 | ||
| 405 | A 0065427117 | SENDER UNIT |
| OVERREVVING | ||
| 405 | A 0065427117 | SENDER UNIT |
| OVERREVVING | ||
| 411 | A 6162510071 | SCREW |
| BELL HOUSING | ||
