Transporto priemonė: 2228; VIN numerio dalis: 623008
Grupė: 40 WHEELS
| # | Kodas | Pavadinimas |
|---|---|---|
| 004 | A 6174000102 | DISC WHEEL |
| Repalced by: A 3874000102 | ||
| 004 | A 3874000102 | DISC WHEEL |
| Repalced by: A 0004017605 | ||
| 004 | A 0004017605 | RIM |
| Repalced by: A 0004017905 | ||
| 004 | A 0004017905 | RIM |
| Repalced by: A 0004016702 | ||
| 004 | A 0004016702 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 004 | A 0004016602 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 004 | A 0004018905 | RIM |
| Repalced by: A 0004016502 | ||
| 004 | A 0004016502 | DISC WHEEL |
| Repalced by: A 0004001002 | ||
| 004 | A 0004001002 | DISC WHEEL |
| 8.25-22.5 | ||
| 004 | A 0004000602 | DISC WHEEL |
| 8.25-22.5 | ||
| 004 | A 0004001902 | DISC WHEEL |
| 8.25-22.5 | ||
| 004 | A 3874000502 | DISC WHEEL |
| Repalced by: A 0004018305 | ||
| 004 | A 0004018305 | RIM |
| Repalced by: A 0004018205 | ||
| 004 | A 0004018205 | RIM |
| Repalced by: A 0004016902 | ||
| 004 | A 0004016902 | DISC WHEEL |
| 9.00-22.5 | ||
| 004 | A 0004016902 | DISC WHEEL |
| 9.00-22.5 | ||
| 004 | A 0004019305 | RIM |
| Repalced by: A 0004019205 | ||
| 004 | A 0004019205 | RIM |
| Repalced by: A 0004012002 | ||
| 004 | A 0004012002 | DISC WHEEL |
| Repalced by: A 0004016402 | ||
| 004 | A 0004016402 | DISC WHEEL |
| 9.00-22.5 | ||
| 004 | A 0004016402 | DISC WHEEL |
| 9.00-22.5 | ||
| 004 | A 0004016802 | DISC WHEEL |
| 9.00-22.5 | ||
| 004 | A 0004016802 | DISC WHEEL |
| 9.00-22.5 | ||
| 008 | A 0004012913 | VALVE |
| Repalced by: A 0004017113 | ||
| 008 | A 0004017113 | VALVE |
| Repalced by: A 0004013213 | ||
| 008 | A 0004013213 | VALVE |
| 27 DEGREES | ||
| A 0004010272 | NUT | |
| VALVE TO DISC WHEEL | ||
| 012 | A 3894010113 | VALVE |
| Repalced by: A 3854010113 | ||
| 012 | A 3854010113 | VALVE |
| EXTENSION | ||
| 012 | A 3894010013 | VALVE |
| Repalced by: A 3854010013 | ||
| 012 | A 3854010013 | VALVE |
| EXTENSION | ||
| N 007757008600 | VALVE CAP | |
| 024 | A 3854000124 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 024 | A 6174000024 | WHEEL NUT |
| Repalced by: A 0004010672 | ||
| 024 | A 0004010672 | NUT |
| DISC WHEELS TO FRONT AND REAR AXLES | ||
| 028 | A 3874002539 | BRACKET |
| SPARE WHEEL MOUNTING,LEFT | ||
| 032 | A 3874030003 | BEARING BRACKET |
| SPARE WHEEL LIFTER TO FRAME | ||
| 036 | N 000933010129 | SCREW |
| Repalced by: N 304017010002 | ||
| 036 | N 304017010002 | SCREW |
| BRACKET TO BEARING BRACKET | ||
| 040 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 040 | N 910113010000 | NUT |
| BRACKET TO BEARING BRACKET | ||
| 044 | A 3874002639 | BRACKET |
| SPARE WHEEL MOUNTING,RIGHT | ||
| 048 | A 3874030040 | BRACKET |
| CRANK | ||
| 052 | N 000961012151 | SCREW |
| CONSOLE TO CONSOLE | ||
| 052 | N 000961012151 | SCREW |
| BRACKET TO CONSOLE | ||
| 056 | N 910113012002 | NUT |
| CONSOLE TO CONSOLE | ||
| 056 | N 910113012002 | NUT |
| BRACKET TO CONSOLE | ||
| 060 | A 3814030185 | WORM |
| Repalced by: A 6204030085 | ||
| 060 | A 6204030085 | WORM |
| SPARE WHEEL HOIST | ||
| 064 | N 001481006027 | CLAMPING SLEEVE |
| 068 | A 3874030083 | STOP GEAR |
| Repalced by: A 6204030683 | ||
| 068 | A 6204030683 | STOP GEAR |
| 072 | N 002093031201 | DISC SPRING |
| WORM AND SHAFT TO BRACKET | ||
| 076 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BEARING BRACKET | ||
| 080 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 080 | N 083334008000 | WIRE CABLE |
| 2700 MM | ||
| 090 | A 3354030130 | CRANK |
| 094 | A 6234030094 | PLATE |
| BRACKET TO FRAME | ||
| 098 | N 000961014028 | SCREW |
| BRACKET TO FRAME | ||
| 102 | N 913004014002 | NUT |
| Repalced by: N 910113014001 | ||
| 102 | N 910113014001 | NUT |
| BRACKET TO FRAME | ||
| 106 | A 3894000839 | BRACKET |
| DISC WHEEL | ||
| 110 | N 000125015013 | WASHER |
| Repalced by: N 000125015019 | ||
| 110 | N 000125015019 | WASHER |
| DISC WHEEL TO BRACKET | ||
| 114 | N 912004014100 | LOCK WASHER |
| DISC WHEEL TO BRACKET | ||
| 118 | N 000934014019 | NUT |
| Repalced by: N 308673014001 | ||
| 118 | N 308673014001 | NUT |
| DISC WHEEL TO BRACKET | ||
| 122 | A 3874004039 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 126 | A 3874030074 | PIN |
| 130 | N 000094004065 | COTTER PIN |
| 134 | A 3859900023 | SCREW |
| Repalced by: A 6519900023 | ||
| 134 | A 6519900023 | SCREW |
| 138 | A 3874030319 | BASE BLOCK |
| 142 | N 912004016101 | LOCK WASHER |
| 146 | N 000934016011 | NUT |
| Repalced by: N 308673016001 | ||
| 146 | N 308673016001 | NUT |
| 150 | N 007346004016 | CLAMPING SLEEVE |
| 154 | A 3834000039 | BRACKET |
| Repalced by: A 3834000639 | ||
| 154 | A 3834000739 | BRACKET |
| Repalced by: A 3834000639 | ||
| 156 | A 3834000639 | SPARE WHEEL HOIST |
| 158 | A 3814030185 | WORM |
| Repalced by: A 6204030085 | ||
| 158 | A 6204030085 | WORM |
| 159 | A 3814030250 | BUSHING |
| 160 | N 001481006027 | CLAMPING SLEEVE |
| 162 | A 3834030183 | STOP GEAR |
| Repalced by: A 6204030383 | ||
| 162 | A 6204030383 | STOP GEAR |
| 164 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 164 | N 083334008000 | WIRE CABLE |
| 2700 MM | ||
| 168 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 172 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 176 | N 001481008038 | CLAMPING SLEEVE |
| Repalced by: N 308752008000 | ||
| 176 | N 308752008000 | CLAMPING PIN |
| WORM AND SHAFT TO BRACKET | ||
| 180 | N 002093031201 | DISC SPRING |
| WORM AND SHAFT TO BRACKET | ||
| 184 | A 3854000020 | COVERING |
| SPARE WHEEL HOIST | ||
| 188 | N 000933006130 | SCREW |
| PROTECTION PLATE TO BRACKET | ||
| M 6X18 | ||
| 192 | N 009021006205 | WASHER |
| Repalced by: N 009021006208 | ||
| 192 | N 009021006208 | WASHER |
| PROTECTION PLATE TO BRACKET | ||
| 196 | N 913004006002 | NUT |
| Repalced by: N 913004006001 | ||
| 196 | N 913004006001 | NUT |
| PROTECTION PLATE TO BRACKET | ||
| 200 | N 000933010128 | SCREW |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 204 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 204 | N 910113010000 | NUT |
| SPARE WHEEL HOIST TO CROSS MEMBER | ||
| 208 | A 3814030150 | BUSHING |
| 212 | A 3814030045 | CRANK |
| SPARE WHEEL HOIST | ||
| 216 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO JOINT SLEEVE | ||
| 220 | N 007349021001 | WASHER |
| SPARE WHEEL TO BRACKET | ||
| 224 | N 912004020100 | LOCK WASHER |
| SPARE WHEEL TO BRACKET | ||
| 228 | N 000934020008 | NUT |
| Repalced by: N 308673020002 | ||
| 228 | N 308673020002 | NUT |
| Repalced by: N 308674020000 | ||
| 228 | N 308674020000 | NUT |
| SPARE WHEEL TO BRACKET | ||
