Transporto priemonė: 2420; VIN numerio dalis: 653011
Grupė: 41 PROPELLER SHAFT
| # | Kodas | Pavadinimas |
|---|---|---|
| 300 | A 6504101504 | PROPELLER SHAFT |
| Repalced by: A 9734103304 | ||
| 300 | A 9734103304 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 908 MM | ||
| 300 | A 6504100104 | PROPELLER SHAFT |
| Repalced by: A 9734102804 | ||
| 300 | A 9734102804 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1672 MM | ||
| 300 | A 6504100304 | PROPELLER SHAFT |
| Repalced by: A 9734100804 | ||
| 300 | A 9734100804 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING I | ||
| 983 MM | ||
| 300 | A 6504100204 | PROPELLER SHAFT |
| Repalced by: A 9734101304 | ||
| 300 | A 9734101304 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1018 MM | ||
| 300 | A 6544100504 | PROPELLER SHAFT |
| Repalced by: A 6544103104 | ||
| 300 | A 6544103104 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1794 MM | ||
| 300 | A 3954103604 | PROPELLER SHAFT |
| Repalced by: A 6554101304 | ||
| 300 | A 6554101304 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 769 MM | ||
| 300 | A 3954104304 | PROPELLER SHAFT |
| Repalced by: A 6554100704 | ||
| 300 | A 6554100704 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1455 MM | ||
| 300 | A 3954105104 | PROPELLER SHAFT |
| Repalced by: A 6554101804 | ||
| 300 | A 6554101804 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1735 MM | ||
| 300 | A 6544100804 | PROPELLER SHAFT |
| Repalced by: A 6544103904 | ||
| 300 | A 6544103904 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 934 MM | ||
| 304 | A 6504100804 | PROPELLER SHAFT |
| Repalced by: A 9734103004 | ||
| 304 | A 9734103004 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING I TO INTERMEDIATE BEARING II | ||
| 1180 MM | ||
| 315 | A 6504110111 | DRIVE FLANGE |
| Repalced by: A 6504110411 | ||
| 315 | A 6504110411 | DRIVE FLANGE |
| 315 | A 6544110011 | DRIVE FLANGE |
| Repalced by: A 6544110311 | ||
| 315 | A 6544110311 | DRIVE FLANGE |
| 315 | A 3954110911 | DRIVE FLANGE |
| Repalced by: A 3954111011 | ||
| 315 | A 3954111011 | DRIVE FLANGE |
| Repalced by: A 3954111211 | ||
| 315 | A 3954111211 | DRIVE FLANGE |
| 318 | A 3814100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9734100031 | ||
| 318 | A 9734100031 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 318 | A 0004100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 0004101628 | ||
| 318 | A 0004101628 | UNIVERSAL JOINT |
| Repalced by: A 9424100131 | ||
| 318 | A 9424100131 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 318 | A 6204100031 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9404100031 | ||
| 318 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 321 | N 071412008302 | GREASE NIPPLE |
| 324 | A 0069940641 | LOCK |
| AS REQUIRED | ||
| 1.65 MM | ||
| 324 | A 0069940841 | LOCK |
| AS REQUIRED | ||
| 1.70 MM | ||
| 324 | A 0069941241 | LOCK |
| AS REQUIRED | ||
| 1.80 MM | ||
| 324 | A 0069941441 | LOCK |
| AS REQUIRED | ||
| 1.85 MM | ||
| 324 | A 0069941941 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 324 | A 0069942341 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 324 | A 0069942741 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 324 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 324 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 324 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 336 | A 3854130161 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 336 | A 3854130461 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 336 | A 3894130161 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 336 | A 3894130361 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 336 | A 3894130061 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 336 | A 3954130061 | PROTECTIVE CAP |
| PROPELLER SHAFT BEARING | ||
| 339 | A 3609902901 | SCREW |
| Repalced by: A 3609903101 | ||
| 339 | A 3609903101 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 339 | A 3609903101 | SCREW |
| PROPELLER SHAFT TO INTERMEDIATE BEARING | ||
| 339 | N 000960014237 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 342 | N 912004012100 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 342 | N 912004014100 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 345 | N 000934012034 | NUT |
| PROPELLER SHAFT | ||
| 345 | N 000934014020 | NUT |
| PROPELLER SHAFT | ||
| 400 | A 3854100922 | INTERMEDIATE BEARING |
| Repalced by: A 3854101722 | ||
| 400 | A 3854101722 | INTERMEDIATE BEARING |
| Repalced by: A 9734100022 | ||
| 400 | A 9734100022 | INTERMEDIATE BEARING |
| PROPELLER SHAFT | ||
| 400 | A 3894100122 | INTERMEDIATE BEARING |
| Repalced by: A 3894100222 | ||
| 400 | A 3894100222 | INTERMEDIATE BEARING |
| Repalced by: A 6544100022 | ||
| 400 | A 6544100022 | INTERMEDIATE BEARING |
| PROPELLER SHAFT | ||
| 400 | A 3954100022 | INTERMEDIATE BEARING |
| Repalced by: A 3954100622 | ||
| 400 | A 3954100622 | INTERMEDIATE BEARING |
| Repalced by: A 6554100022 | ||
| 400 | A 6554100022 | INTERMEDIATE BEARING |
| PROPELLER SHAFT | ||
| 403 | A 0019818125 | BALL BEARING |
| Repalced by: A 0079818525 | ||
| 403 | A 0079818525 | BALL BEARING |
| 403 | A 0029819625 | BALL BEARING |
| 403 | A 0029819725 | BALL BEARING |
| 403 | A 0029819225 | BALL BEARING |
| 403 | A 0029819325 | BALL BEARING |
| 406 | N 912009100200 | SNAP RING |
| 406 | N 912009110200 | SNAP RING |
| 406 | N 912009110200 | SNAP RING |
| 409 | A 3854130061 | PROTECTIVE CAP |
| 409 | A 3894130261 | PROTECTIVE CAP |
| 409 | A 3894130061 | PROTECTIVE CAP |
| 410 | A 6554110052 | SPACER WASHER |
| PROPELLER SHAFT BEARING | ||
| 410 | A 6544110052 | SPACER WASHER |
| PROPELLER SHAFT BEARING | ||
| 410 | A 9734110052 | SPACER WASHER |
| PROPELLER SHAFT BEARING | ||
| 412 | A 6504100030 | CENTERING FLANGE |
| Repalced by: A 6504110046 | ||
| 412 | A 6504110046 | FLANGE |
| PROPELLER SHAFT BEARING | ||
| 412 | A 6544100030 | CENTERING FLANGE |
| Repalced by: A 6544110045 | ||
| 412 | A 6544110045 | FLANGE |
| PROPELLER SHAFT BEARING | ||
| 412 | A 6454100030 | CENTERING FLANGE |
| Repalced by: A 6454110046 | ||
| 412 | A 6454110046 | FLANGE |
| PROPELLER SHAFT BEARING | ||
| 415 | A 3854130161 | PROTECTIVE CAP |
| 415 | A 3854130461 | PROTECTIVE CAP |
| 415 | A 3894130161 | PROTECTIVE CAP |
| 415 | A 3894130361 | PROTECTIVE CAP |
| 415 | A 3894130061 | PROTECTIVE CAP |
| 415 | A 3954130061 | PROTECTIVE CAP |
| 418 | A 3839900019 | SCREW |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 418 | A 3899900019 | SCREW |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 421 | A 3894110162 | THRUST WASHER |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 421 | A 3894110062 | THRUST WASHER |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 424 | A 3854139442 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854135742 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854139842 | BRACKET |
| PROPELLER SHAFT BEARING I,LEFT | ||
| 424 | A 3854134942 | BRACKET |
| PROPELLER SHAFT BEARING II,LEFT | ||
| 424 | A 3974130142 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854138242 | BRACKET |
| PROPELLER SHAFT BEARING I,LEFT | ||
| 424 | A 3854137342 | BRACKET |
| PROPELLER SHAFT BEARING II,LEFT | ||
| 424 | A 3804130342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854135342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 6174132142 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 6524130142 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 6174131642 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 6174133942 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 6524130442 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 427 | A 3854139542 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854135642 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854139942 | BRACKET |
| PROPELLER SHAFT BEARING I,RIGHT | ||
| 427 | A 3854134842 | BRACKET |
| PROPELLER SHAFT BEARING II,RIGHT | ||
| 427 | A 3974130042 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854138342 | BRACKET |
| PROPELLER SHAFT BEARING I,RIGHT | ||
| 427 | A 3854137242 | BRACKET |
| PROPELLER SHAFT BEARING II,RIGHT | ||
| 427 | A 3804130442 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854135242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 6174132242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 6524130042 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 6174131542 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 6174134042 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 6524130542 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 430 | N 000931010282 | SCREW |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| M 10X40 | ||
| 430 | N 000933010105 | SCREW |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| M 10X25 | ||
| 430 | N 000961012094 | SCREW |
| Repalced by: N 308676012013 | ||
| 430 | N 308676012013 | HEXAGON HEAD BOLT |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 433 | N 912004010102 | LOCK WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 433 | N 912004012100 | LOCK WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 436 | N 007349010003 | WASHER |
| Repalced by: N 007349010007 | ||
| 436 | N 007349010007 | WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 436 | A 3299900040 | WASHER |
| Repalced by: A 1232420366 | ||
| 436 | A 1232420366 | WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 438 | A 3854130011 | REINFORCEMENT |
| PROPELLER SHAFT BEARING | ||
| 439 | A 3874130111 | REINFORCEMENT |
| PROPELLER SHAFT BEARING II | ||
| 439 | A 3954130011 | REINFORCEMENT |
| PROPELLER SHAFT BEARING | ||
| 442 | N 000961010018 | SCREW |
| Repalced by: A 0079901001 | ||
| 442 | A 0079901001 | SCREW |
| REINFORCEMENT TO BRACKET | ||
| 442 | N 000961012094 | SCREW |
| Repalced by: N 308676012013 | ||
| 442 | N 308676012013 | HEXAGON HEAD BOLT |
| REINFORCEMENT TO BRACKET | ||
| 445 | N 913004010014 | NUT |
| Repalced by: N 910113010003 | ||
| 445 | N 910113010003 | NUT |
| REINFORCEMENT TO BRACKET | ||
| 445 | N 913004012009 | NUT |
| Repalced by: N 910113012003 | ||
| 445 | N 910113012003 | HEXAGON NUT |
| REINFORCEMENT TO BRACKET | ||
| 448 | N 000960010026 | SCREW |
| Repalced by: N 000961010031 | ||
| 448 | N 000961010031 | SCREW |
| Repalced by: N 308676010023 | ||
| 448 | N 308676010023 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 448 | N 000961012106 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 449 | A 3854130111 | REINFORCEMENT |
| BRACKET TO CROSS MEMBER | ||
| 451 | N 007349010003 | WASHER |
| Repalced by: N 007349010007 | ||
| 451 | N 007349010007 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| 451 | A 6739900640 | WASHER |
| Repalced by: A 3879900040 | ||
| 451 | A 3879900040 | WASHER |
| Repalced by: N 007349013003 | ||
| 451 | N 007349013005 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| 454 | N 913002010010 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 454 | N 913004012009 | NUT |
| Repalced by: N 910113012003 | ||
| 454 | N 910113012003 | HEXAGON NUT |
| BRACKET TO CROSS MEMBER | ||
| 500 | A 6504104802 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1390 MM | ||
| 500 | A 6504104502 | PROPELLER SHAFT |
| Repalced by: A 9734109002 | ||
| 500 | A 9734109002 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1230 MM | ||
| 500 | A 6504105002 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING II TO REAR AXLE | ||
| 1700 MM | ||
| 500 | A 6504101302 | PROPELLER SHAFT |
| Repalced by: A 9734106802 | ||
| 500 | A 9734106802 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1190 MM | ||
| 500 | A 6504101402 | PROPELLER SHAFT |
| Repalced by: A 9734101702 | ||
| 500 | A 9734101702 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1130 MM | ||
| 500 | A 6504102302 | PROPELLER SHAFT |
| Repalced by: A 9734107002 | ||
| 500 | A 9734107002 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1715 MM | ||
| 500 | A 6544100902 | PROPELLER SHAFT |
| Repalced by: A 6544105802 | ||
| 500 | A 6544105802 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1843 MM | ||
| 500 | A 3954100507 | PROPELLER SHAFT |
| Repalced by: A 6554102902 | ||
| 500 | A 6554102902 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1498 MM | ||
| 500 | A 3954107702 | PROPELLER SHAFT |
| Repalced by: A 6554102802 | ||
| 500 | A 6554102802 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1183 MM | ||
| 500 | A 3954108502 | PROPELLER SHAFT |
| Repalced by: A 6554101202 | ||
| 500 | A 6554101202 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1741 MM | ||
| 500 | A 3954107902 | PROPELLER SHAFT |
| Repalced by: A 6554100302 | ||
| 500 | A 6554100302 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1872 MM | ||
| 500 | A 6544100402 | PROPELLER SHAFT |
| Repalced by: A 6544103702 | ||
| 500 | A 6544103702 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1443 MM | ||
| 502 | A 6544100202 | PROPELLER SHAFT |
| Repalced by: A 6544107702 | ||
| 502 | A 6544107702 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 1723 MM | ||
| 502 | A 6544101002 | PROPELLER SHAFT |
| Repalced by: A 6544106802 | ||
| 502 | A 6544106802 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 1545 MM | ||
| 502 | A 6544100802 | PROPELLER SHAFT |
| Repalced by: A 6544107202 | ||
| 502 | A 6544107202 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 2200 MM | ||
| 502 | A 6544101602 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 2150 MM | ||
| 502 | A 3954106302 | PROPELLER SHAFT |
| Repalced by: A 6554100402 | ||
| 502 | A 6554100402 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 1940 MM | ||
| 502 | A 6564101702 | PROPELLER SHAFT |
| Repalced by: A 6564107102 | ||
| 502 | A 6564107102 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE I | ||
| 1945 MM | ||
| 515 | A 6504110011 | DRIVE FLANGE |
| 515 | A 6504110111 | DRIVE FLANGE |
| Repalced by: A 6504110411 | ||
| 515 | A 6504110411 | DRIVE FLANGE |
| 515 | A 6544110011 | DRIVE FLANGE |
| Repalced by: A 6544110311 | ||
| 515 | A 6544110311 | DRIVE FLANGE |
| 515 | A 3954110911 | DRIVE FLANGE |
| Repalced by: A 3954111011 | ||
| 515 | A 3954111011 | DRIVE FLANGE |
| Repalced by: A 3954111211 | ||
| 515 | A 3954111211 | DRIVE FLANGE |
| 515 | A 3954111211 | DRIVE FLANGE |
| 515 | A 6564110011 | DRIVE FLANGE |
| Repalced by: A 6564110311 | ||
| 515 | A 6564110311 | DRIVE FLANGE |
| 518 | A 3814100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9734100031 | ||
| 518 | A 9734100031 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 518 | A 0004100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 0004101628 | ||
| 518 | A 0004101628 | UNIVERSAL JOINT |
| Repalced by: A 9424100131 | ||
| 518 | A 9424100131 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 518 | A 6204100031 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9404100031 | ||
| 518 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 518 | A 9404100031 | UNIVERSAL JOINT CROSS |
| WITH BUSHINGS | ||
| 518 | A 6564100131 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9424100031 | ||
| 518 | A 9424100031 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 521 | N 071412008302 | GREASE NIPPLE |
| 524 | A 0069940641 | LOCK |
| AS REQUIRED | ||
| 1.65 MM | ||
| 524 | A 0069940841 | LOCK |
| AS REQUIRED | ||
| 1.70 MM | ||
| 524 | A 0069941241 | LOCK |
| AS REQUIRED | ||
| 1.80 MM | ||
| 524 | A 0069941441 | LOCK |
| AS REQUIRED | ||
| 1.85 MM | ||
| 524 | A 0069941941 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 524 | A 0069942341 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 524 | A 0069942741 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 524 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 524 | A 0069943141 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 524 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 524 | A 0069943541 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 524 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 524 | A 0069943941 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 524 | A 6564111073 | LOCK |
| AS REQUIRED | ||
| 2.90 MM | ||
| 524 | A 6564110173 | LOCK |
| Repalced by: A 6564110673 | ||
| 524 | A 6564110673 | LOCK |
| AS REQUIRED | ||
| 3.00 MM | ||
| 524 | A 6564110573 | LOCK |
| Repalced by: A 6564110673 | ||
| 524 | A 6564110673 | LOCK |
| AS REQUIRED | ||
| 3.10 MM | ||
| 524 | A 6564110973 | LOCK |
| AS REQUIRED | ||
| 3.20 MM | ||
| 524 | A 6564111473 | LOCK |
| AS REQUIRED | ||
| 3.25 MM | ||
| 524 | A 6564111773 | LOCK |
| AS REQUIRED | ||
| 3.30 MM | ||
| 527 | A 3854110059 | SEAL RING |
| PROTECTIVE TUBE | ||
| 527 | A 3894110080 | GASKET |
| PROTECTIVE TUBE | ||
| 527 | A 3954110059 | SEAL RING |
| PROTECTIVE TUBE | ||
| 105X17 MM | ||
| 527 | A 0004110159 | SEAL RING |
| PROTECTIVE TUBE | ||
| 102.5X22 MM | ||
| 527 | A 0004110259 | SEAL RING |
| PROTECTIVE TUBE | ||
| 105.6X12 MM | ||
| 530 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 530 | N 071412008102 | GREASE NIPPLE |
| 539 | A 3609902901 | SCREW |
| Repalced by: A 3609903101 | ||
| 539 | A 3609903101 | SCREW |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 539 | A 3609903101 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE | ||
| 539 | N 000960014237 | SCREW |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 539 | N 000960014237 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE | ||
| 542 | N 912004012100 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 542 | N 912004014100 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 545 | N 000934012034 | NUT |
| PROPELLER SHAFT | ||
| 545 | N 000934014020 | NUT |
| PROPELLER SHAFT | ||
| 600 | A 6504101702 | PROPELLER SHAFT |
| Repalced by: A 9734102002 | ||
| 600 | A 9734102002 | PROPELLER SHAFT |
| FROM REAR AXLE I TO REAR AXLE II | ||
| 740 MM | ||
| 600 | A 3894102502 | PROPELLER SHAFT |
| Repalced by: A 6544104102 | ||
| 600 | A 6544104102 | PROPELLER SHAFT |
| Repalced by: A 3894102502 | ||
| 600 | A 3894102502 | PROPELLER SHAFT |
| FROM REAR AXLE I TO REAR AXLE II | ||
| 780 MM | ||
| 615 | A 6504110011 | DRIVE FLANGE |
| 615 | A 3894110411 | DRIVE FLANGE |
| Repalced by: A 6544110511 | ||
| 615 | A 6544110511 | DRIVE FLANGE |
| 618 | A 3814100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 9734100031 | ||
| 618 | A 9734100031 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 618 | A 0004100231 | UNIVERSAL JOINT CROSS |
| Repalced by: A 0004101628 | ||
| 618 | A 0004101628 | UNIVERSAL JOINT |
| Repalced by: A 9424100131 | ||
| 618 | A 9424100131 | UNIVERSAL JOINT CROSS |
| MAINTENANCE-FREE | ||
| 621 | N 071412008302 | GREASE NIPPLE |
| 624 | A 0069940641 | LOCK |
| AS REQUIRED | ||
| 1.65 MM | ||
| 624 | A 0069940841 | LOCK |
| AS REQUIRED | ||
| 1.70 MM | ||
| 624 | A 0069941241 | LOCK |
| AS REQUIRED | ||
| 1.80 MM | ||
| 624 | A 0069941441 | LOCK |
| AS REQUIRED | ||
| 1.85 MM | ||
| 624 | A 0069941941 | LOCK |
| AS REQUIRED | ||
| 2.00 MM | ||
| 624 | A 0069942341 | LOCK |
| AS REQUIRED | ||
| 2.10 MM | ||
| 624 | A 0069942741 | LOCK |
| AS REQUIRED | ||
| 2.20 MM | ||
| 627 | A 3854110059 | SEAL RING |
| PROTECTIVE TUBE | ||
| 627 | A 3894110080 | GASKET |
| PROTECTIVE TUBE | ||
| 630 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 630 | N 071412008102 | GREASE NIPPLE |
| 633 | N 000906008001 | SCREW PLUG |
| 639 | A 3609902901 | SCREW |
| Repalced by: A 3609903101 | ||
| 639 | A 3609903101 | SCREW |
| PROPELLER SHAFT TO REAR AXLES I AND II | ||
| 642 | N 912004012100 | LOCK WASHER |
| PROPELLER SHAFT TO REAR AXLES I AND II | ||
| 645 | N 000934012034 | NUT |
| PROPELLER SHAFT TO REAR AXLES I AND II | ||
© 2010-2013 UAB "RPV" Paslaugų teikimo sąlygos - Privatumo politika - Kopijuoti ir naudoti komerciniais tikslais draudžiama
