Transporto priemonė: 809 K; VIN numerio dalis: 673042
Grupė: 41 PROPELLER SHAFT
| # | Kodas | Pavadinimas |
|---|---|---|
| 300 | A 6734105304 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 664 MM | ||
| 300 | A 6734104104 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1212 MM | ||
| 300 | A 6734102804 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1422 MM | ||
| 300 | A 6734105604 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1134 MM | ||
| 300 | A 6734101204 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 1867 MM | ||
| 300 | A 6734105404 | PROPELLER SHAFT |
| FROM TRANSMISSION TO INTERMEDIATE BEARING | ||
| 634 MM | ||
| 321 | A 0009974188 | GREASE NIPPLE |
| Repalced by: A 0009974588 | ||
| 321 | A 0009974588 | GREASE NIPPLE |
| Repalced by: N 900216008100 | ||
| 321 | N 900216008100 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 321 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 321 | N 071412008102 | GREASE NIPPLE |
| UNIVERSAL JOINT CROSS | ||
| 336 | A 4604130061 | PROTECTIVE CAP |
| 336 | A 4604110096 | PROTECTIVE CAP |
| 339 | A 3129901601 | SCREW |
| Repalced by: A 3099901501 | ||
| 339 | A 3099901501 | SCREW |
| Repalced by: A 3539900001 | ||
| 339 | A 3539900001 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 339 | A 3539900001 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION | ||
| 342 | N 912004010102 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 342 | N 912004010102 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 345 | N 000934010010 | NUT |
| PROPELLER SHAFT | ||
| 345 | N 000934010010 | NUT |
| PROPELLER SHAFT | ||
| 400 | A 4604100022 | INTERMEDIATE BEARING |
| Repalced by: A 4604100222 | ||
| 400 | A 4604100222 | INTERMEDIATE BEARING |
| PROPELLER SHAFT | ||
| 412 | A 6734100030 | CENTERING FLANGE |
| PROPELLER SHAFT BEARING | ||
| 412 | A 6734100045 | FLANGE |
| PROPELLER SHAFT BEARING | ||
| 415 | A 4604130061 | PROTECTIVE CAP |
| 415 | A 4604110096 | PROTECTIVE CAP |
| 418 | A 3609901304 | SCREW |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 421 | A 3182740276 | WASHER |
| Repalced by: A 6734110062 | ||
| 421 | A 6734110062 | THRUST WASHER |
| FOLLOWER FLANGE TO PROPELLER SHAFT | ||
| 424 | A 3854139142 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854136342 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3854130442 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 424 | A 3804130442 | BRACKET |
| PROPELLER SHAFT BEARING,LEFT | ||
| 427 | A 3854139042 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854136242 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3854130642 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 427 | A 3804130342 | BRACKET |
| PROPELLER SHAFT BEARING,RIGHT | ||
| 430 | N 000933010219 | SCREW |
| Repalced by: N 304017010043 | ||
| 430 | N 304017010043 | SCREW |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 433 | N 912004010102 | LOCK WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 436 | N 007349010003 | WASHER |
| Repalced by: N 007349010007 | ||
| 436 | N 007349010007 | WASHER |
| BRACKET TO PROPELLER SHAFT BEARING HOUSING | ||
| 438 | A 6734130011 | REINFORCEMENT |
| PROPELLER SHAFT BEARING | ||
| 448 | N 000960010026 | SCREW |
| Repalced by: N 000961010031 | ||
| 448 | N 000961010031 | SCREW |
| Repalced by: N 308676010023 | ||
| 448 | N 308676010023 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 449 | A 3854130111 | REINFORCEMENT |
| BRACKET TO CROSS MEMBER | ||
| 451 | N 007349010003 | WASHER |
| Repalced by: N 007349010007 | ||
| 451 | N 007349010007 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| 454 | N 913002010010 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 500 | A 6734103804 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1230 MM | ||
| 500 | A 6734103804 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1230 MM | ||
| 500 | A 6734104404 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1560 MM | ||
| 500 | A 6734105904 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1035 MM | ||
| 500 | A 6734103704 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1290 MM | ||
| 500 | A 6734103704 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1290 MM | ||
| 500 | A 6734103404 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1630 MM | ||
| 500 | A 6734101304 | PROPELLER SHAFT |
| FROM INTERMEDIATE BEARING TO REAR AXLE | ||
| 1840 MM | ||
| 502 | A 6734101504 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1900 MM | ||
| 502 | A 3814103404 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1970 MM | ||
| 502 | A 6734104804 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1865 MM | ||
| 502 | A 6734104904 | PROPELLER SHAFT |
| FROM TRANSMISSION TO REAR AXLE | ||
| 1935 MM | ||
| 521 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 521 | N 071412008102 | GREASE NIPPLE |
| UNIVERSAL JOINT CROSS | ||
| 530 | N 071412008101 | GREASE NIPPLE |
| Repalced by: N 071412008102 | ||
| 530 | N 071412008102 | GREASE NIPPLE |
| 539 | A 3129901601 | SCREW |
| Repalced by: A 3099901501 | ||
| 539 | A 3099901501 | SCREW |
| Repalced by: A 3539900001 | ||
| 539 | A 3539900001 | SCREW |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 539 | A 3539900001 | SCREW |
| PROPELLER SHAFT TO PROPELLER SHAFT BEARING AND TO REAR AXLE | ||
| 539 | A 3539900001 | SCREW |
| PROPELLER SHAFT TO TRANSMISSION AND TO REAR AXLE | ||
| 542 | N 912004010102 | LOCK WASHER |
| PROPELLER SHAFT | ||
| 545 | N 000934010010 | NUT |
| PROPELLER SHAFT | ||
