Transporto priemonė: LK 1514; VIN numerio dalis: 351027
Grupė: 25 CLUTCH
16845
16846
16847
16848
# Kodas Pavadinimas
005 A 0012500304 CLUTCH PRESSURE PLATE
Repalced by: A 0022509504
005 A 0022509404 CLUTCH PRESSURE PLATE
Repalced by: A 0022509504
005 A 0022509504 CLUTCH PRESSURE PLATE
005 A 0022509604 CLUTCH PRESSURE PLATE
005 A 3512507104 CLUTCH PRESSURE PLATE
010 A 0032502004 CLUTCH PRESSURE PLATE
015 A 0002522512 PRESSURE PLATE
TO 001 250 03 04
A 0002524312 PRESSURE PLATE
Repalced by: A 0002527112
015 A 0002527112 PRESSURE PLATE
TO 002 250 94 04,002 250 95 04
015 A 0002527112 PRESSURE PLATE
TO 002 250 96 04
015 A 0002528112 PRESSURE PLATE
TO 351 250 71 04,72 04
A 0002525012 PRESSURE PLATE
Repalced by: A 0002520412
020 A 0002520412 PRESSURE PLATE
TO 003 250 20 04
025 A 0002522045 FLANGE
TO 003 250 20 04
030 A 0002523713 RELEASE LEVER
TO 000 252 43 12
030 A 0002527113 RELEASE LEVER
TO 000 252 71 12
030 A 0002527313 RELEASE LEVER
TO 351 250 71 04
035 A 0002524613 RELEASE LEVER
TO 003 250 20 04
040 A 0002522314 BRACKET
TO 000 252 43 12
040 A 0002523214 BRACKET
TO 000 252 71 12
040 A 0002523614 BRACKET
TO 351 250 71 04
045 A 0002520614 BRACKET
TO 003 250 20 04
050 A 0002521616 SPINDLE
TO 000 252 43 12
050 A 0002524016 SPINDLE
TO 000 252 71 12
050 A 0002524316 SPINDLE
TO 351 250 71 04
A 0002522916 SPINDLE
Repalced by: A 0002520616
055 A 0002520616 SPINDLE
TO 003 250 20 04
060 A 0002521716 SPINDLE
TO 000 252 43 12
060 A 0002524116 SPINDLE
TO 000 252 71 12
060 A 0002524416 SPINDLE
TO 351 250 71 04
065 A 0002522816 SPINDLE
TO 003 250 20 04
070 A 0002520318 ROLLER
TO 001 250 03 04
070 A 0002520318 ROLLER
TO 002 250 94 04; 002 250 95 04
070 A 0002520318 ROLLER
TO 002 250 96 04
070 A 0002520818 ROLLER
TO 351 250 71 04
075 A 0002520118 ROLLER
TO 003 250 20 04
080 A 0002520827 SPRING
TO 000 252 43 12
080 A 0002524427 SPRING
TO 000 252 71 12
080 A 0002524627 SPRING
TO 351 250 71 04
085 A 0002520727 SPRING
TO 003 250 20 04
090 N 006799007007 LOCK PLATE
TO 001 250 03 04
090 N 006799007007 LOCK PLATE
TO 002 250 94 04; 002 250 95 04
090 N 006799007007 LOCK PLATE
TO 002 250 96 04
090 A 0079940241 LOCK
TO 351 250 71 04
A 0002522472 NUT
Repalced by: A 0002523372
095 A 0002523372 NUT
TO 002 250 94 04,95 04,96 04
095 A 0002524072 NUT
TO 351 250 71 04
095 A 0002522772 NUT
TO 001 250 03 04
095 A 0002523372 NUT
TO 002 250 96 04
100 A 0002521372 NUT
TO 003 250 20 04
A 0455860025 REPAIR KIT
Repalced by: A 3515867025
105 A 3515867025 REPAIR KIT
A 0002520473 LOCK
Repalced by: A 0002521173
110 A 0002521173 LOCK
TO 001 250 03 04
110 A 0002521173 LOCK
TO 002 250 95 04,002 250 96 04
110 A 3512527073 LOCK
TO 002 250 95 04
110 A 0002521673 LOCK
TO 351 250 71 04
115 A 0002521073 LOCK
TO 003 250 20 04
120 N 912004005100 LOCK WASHER
TO 001 250 03 04; 002 250 95 04
120 N 000127005206 LOCK WASHER
TO 002 250 95 04
120 A 0009906047 LOCK WASHER
TO 351 250 71 04
125 A 0009901647 LOCK WASHER
TO 003 250 20 04
130 N 000085005106 SCREW
TO 001 250 03 04
130 N 000085005106 SCREW
TO 002 250 95 04
130 A 0002522971 SCREW
TO 002 250 96 04
130 A 0002520015 SCREW
TO 351 250 71 04
135 A 0002520535 SLEEVE
TO 003 250 20 04
140 A 0002525020 PRESSURE SPRING
TO 001 250 03 04,002 250 94 04
140 A 0002525020 PRESSURE SPRING
TO 002 250 96 04
140 A 0002525120 PRESSURE SPRING
TO 002 250 95 04
140 A 0002529120 PRESSURE SPRING
TO 351 260 71 04
145 A 0002524320 PRESSURE SPRING
TO 003 250 20 04
150 A 0002520619 LEAF SPRING
TO 000 252 43 12
150 A 0002524319 LEAF SPRING
TO 000 252 71 12
150 A 0002525619 LEAF SPRING
TO 351 250 71 04,72 04
155 A 0002520519 LEAF SPRING
TO 003 250 20 04
160 A 0002521927 SPRING
TO 003 250 20 04
165 A 0002520929 CLAMP
TO 003 250 20 04
170 A 0002520253 SPACER TUBE
TO 001 250 03 04
170 A 0002520253 SPACER TUBE
TO 002 250 94 04; 002 250 95 04
170 A 0002520253 SPACER TUBE
TO 002 250 96 04
170 A 0002520350 BUSHING
TO 351 250 71 04
175 A 0002524332 HOUSING
TO 002 250 94 04; 002 250 95 04
175 A 0002524432 HOUSING
TO 002 250 96 04
180 A 0002520932 HOUSING
TO 003 250 20 04
185 A 3452507403 CLUTCH DISC
Repalced by: A 0072507103
185 A 0072507103 CLUTCH DISC
"F & S"
185 A 0022500403 CLUTCH DISC
Repalced by: A 0072502503
185 A 3452507503 CLUTCH DISC
Repalced by: A 0072502503
070 A 0072502503 CLUTCH DISC
"F & S"
A 0012506003 CLUTCH DISC
Repalced by: A 0032508303
185 A 0032508303 CLUTCH DISC
"F & S"
185 A 3512507003 CLUTCH DISC
WOBRON
A 0012505503 CLUTCH DISC
Repalced by: A 0032505103
190 A 0032505103 CLUTCH DISC
190 A 3452507103 CLUTCH DISC
Repalced by: A 0072503603
190 A 0072503603 CLUTCH DISC
190 A 0072503703 CLUTCH DISC
195 A 0002522019 LEAF SPRING
TO 002 250 04 03,001 250 60 03
200 A 0002520419 LEAF SPRING
TO 001 250 55 03,003 250 51 03
205 A 0002522075 RIVET
TO 001 250 60 03
205 A 0002522175 RIVET
TO 002 250 04 03,003 250 83 03
205 A 0002522575 RIVET
TO 003 250 83 03
A 0002520675 RIVET
Repalced by: A 0002522075
210 A 0002522075 RIVET
TO 001 250 55 03,003 250 51 03
A 0002525210 CLUTCH LINING
Repalced by: A 3452527010
A 3452527010 CLUTCH LINING
Repalced by: A 0002529010
215 A 0002529010 CLUTCH LINING
215 A 0012522910 CLUTCH LINING
220 A 0002521275 RIVET
TO 001 250 60 03
220 A 0002521275 RIVET
TO 001 250 55 03,003 250 51 03
220 A 0002521275 RIVET
TO 345 250 74 03
220 A 0002521475 RIVET
TO 002 250 04 03
220 A 0002521475 RIVET
TO 001 250 55 03,003 250 51 03
220 A 0002521475 RIVET
TO 003 250 83 03
225 A 3455867025 REPAIR KIT
TO 345 250 74 03,345 250 75 03
225 A 3455867125 REPAIR KIT
TO 345 250 71 03
230 A 3522520071 SCREW
CLUTCH TO FLYWHEEL
230 A 3412527071 SCREW
CLUTCH TO FLYWHEEL
230 N 000931008045 SCREW
CLUTCH TO FLYWHEEL
235 N 912004008104 LOCK WASHER
CLUTCH TO FLYWHEEL
240 N 000931010115 SCREW
CLUTCH TO FLYWHEEL
245 N 000127010205 LOCK WASHER
CLUTCH TO FLYWHEEL
A 3522500305 HOUSING
Repalced by: A 3522510201
250 A 3522510201 BELL HOUSING
250 A 3452510301 BELL HOUSING
Repalced by: A 3412510501
250 A 3412510501 BELL HOUSING
250 A 3512517501 BELL HOUSING
255 A 3452500105 HOUSING
260 A 3432510050 BUSHING
265 A 3439920003 BUSHING
270 N 005419035101 FELT RING
275 N 000939010027 STUD BOLT
275 N 000939010079 STUD BOLT
275 A 0009902605 STUD
Repalced by: A 6709900005
275 A 6709900005 STUD
280 A 3432930027 COVER PLATE
285 A 3432510150 BUSHING
285 A 3439920103 BUSHING
290 N 000931012277 SCREW
BELL HOUSING TO CYLINDER CRANKCASE
295 N 900170012049 SCREW
BELL HOUSING TO CYLINDER CRANKCASE
300 N 900170012005 SCREW
BELL HOUSING TO CYLINDER CRANKCASE
305 N 000127012203 LOCK WASHER
BELL HOUSING TO CYLINDER CRANKCASE
310 A 3602510004 END COVER
315 N 000933006015 SCREW
320 N 000127006206 LOCK WASHER
A 3122511006 PROTECTIVE PLATE
Repalced by: A 3522510106
325 A 3522510106 PROTECTIVE PLATE
330 N 000933006010 SCREW
PROTECTIVE PLATE TO BELL HOUSING
335 N 000137006102 SPRING WASHER
PROTECTIVE PLATE TO BELL HOUSING
340 A 3522510002 BELL HOUSING
LOWER PART
340 A 3522510102 BELL HOUSING
LOWER PART
340 A 3812510102 BELL HOUSING
LOWER PART
345 N 000933006010 SCREW
LOWER PART TO HOUSING
350 N 000137006102 SPRING WASHER
LOWER PART TO HOUSING
355 A 3522510004 END COVER
BELL HOUSING
360 N 000933008014 SCREW
COVER TO BELL HOUSING
365 N 912004008104 LOCK WASHER
COVER TO BELL HOUSING
370 A 3522540040 BRACKET
375 A 3522540135 BEARING
A 3272501213 RELEASE LEVER
Repalced by: A 3412500313
380 A 3412500313 RELEASE LEVER
380 A 3412500313 RELEASE LEVER
385 A 3029910015 BALL PIVOT
390 A 3402540013 SPRING LOCK
A 3222500215 RELEASE BEARING
Repalced by: A 3522500515
395 A 3522500515 RELEASE BEARING
400 A 3522540110 RELEASE COLLAR
TO 352 250 05 15
400 A 3122541110 RELEASE COLLAR
TO A 322 250 02 15
405 A 0002540020 RELEASE BEARING
405 A 0002540120 RELEASE BEARING
405 A 3452547020 RELEASE BEARING
410 A 3129870110 STRIP
415 A 3522500243 BRACKET
Repalced by: A 3412500043
415 A 3412500043 BRACKET
420 N 000933008036 SCREW
425 N 912004008104 LOCK WASHER
A 3522540097 BOOT
Repalced by: A 3142540197
430 A 3142540197 BOOT
435 A 6152540097 BOOT
A 3372540208 RELEASE LEVER
Repalced by: A 3452937011
A 3452937011 RELEASE YOKE
Repalced by: A 3452930111
440 A 3452930111 RELEASE YOKE
445 A 3172930377 WASHER
450 N 005419025101 FELT RING
455 A 3432930001 RELEASE SHAFT
460 N 000931012042 SCREW
RELEASE LEVER TO SHAFT
460 N 000931012251 SCREW
RELEASE LEVER TO SHAFT
465 N 000127012203 LOCK WASHER
RELEASE LEVER TO SHAFT
465 N 000127012201 LOCK WASHER
RELEASE LEVER TO SHAFT
470 A 3432930052 SPACER WASHER
RELEASE LEVER TO SHAFT
475 N 000471024000 LOCK RING
RELEASE LEVER TO SHAFT
475 N 000471024001 LOCK RING
RELEASE LEVER TO SHAFT
480 A 3432540010 RELEASE COLLAR
485 N 071428004102 SCREW-IN FITTING
490 N 007603008112 SEAL RING
495 A 3202500015 RELEASE BEARING
500 A 3355730036 HOSE
Repalced by: A 3059971982
500 A 3059971982 HOSE
RELEASE COLLAR LUBRICATION
500 A 3089977182 HOSE
RELEASE COLLAR LUBRICATION
500 A 3949977182 HOSE
RELEASE COLLAR LUBRICATION
505 N 003871004100 UNION SCREW
RELEASE COLLAR LUBRICATION
510 N 003862004001 DOUBLE TAPER RING
RELEASE COLLAR LUBRICATION
515 A 0009973683 SLEEVE
RELEASE COLLAR LUBRICATION
520 N 000137014203 SPRING WASHER
RELEASE COLLAR LUBRICATION
525 N 080705014003 NUT
RELEASE COLLAR LUBRICATION
525 N 000936014010 NUT
RELEASE COLLAR LUBRICATION
530 N 071412008200 GREASE NIPPLE
RELEASE COLLAR LUBRICATION
A 3122541013 SPRING LOCK
Repalced by: A 3402540013
535 A 3402540013 SPRING LOCK
540 A 3439900040 WASHER
545 A 3452547025 LEVER
CLUTCH ACTUATION
550 A 3029910115 BALL PIVOT
555 N 000931010093 SCREW
LEVER TO RELEASE SHAFT
560 N 000127010205 LOCK WASHER
LEVER TO RELEASE SHAFT
565 N 000934010000 NUT
LEVER TO RELEASE SHAFT
570 A 3439900040 WASHER
LEVER TO RELEASE SHAFT
575 A 3352500055 COVER
580 N 000127016202 LOCK WASHER
BELL HOUSING TO CYLINDER CRANKCASE
585 N 000934016002 NUT
BELL HOUSING TO CYLINDER CRANKCASE
590 N 000931012025 SCREW
BELL HOUSING TO CYLINDER CRANKCASE
600 N 000127012203 LOCK WASHER
BELL HOUSING TO CYLINDER CRANKCASE
605 N 000961018024 SCREW
BELL HOUSING TO TRANSMISSION CASE
610 N 000127018203 LOCK WASHER
BELL HOUSING TO TRANSMISSION CASE
615 A 3462540016 GUIDE
615 A 3462545016 GUIDE
620 N 000127010202 LOCK WASHER
GUIDE TO BELL HOUSING
625 N 000933010016 SCREW
GUIDE TO BELL HOUSING
