Transporto priemonė: LPKF 808,809; VIN numerio dalis: 316083
Grupė: 40 WHEELS
| # | Kodas | Pavadinimas |
|---|---|---|
| 007 | A 3164000002 | DISC WHEEL |
| Repalced by: A 0024010401 | ||
| 007 | A 0024010401 | DISC WHEEL |
| 6.00 G-16 | ||
| 007 | A 3134000002 | DISC WHEEL |
| Repalced by: A 3184001402 | ||
| 007 | A 3184001402 | DISC WHEEL |
| 5.25-17.5 | ||
| 012 | A 0004012506 | SIDE RING |
| Repalced by: A 0004015906 | ||
| 012 | A 0004015906 | SIDE RING |
| Repalced by: A 6674010006 | ||
| 012 | A 6674010006 | SIDE RING |
| Repalced by: A 0004015906 | ||
| 012 | A 0004015906 | SIDE RING |
| 014 | A 0004013213 | VALVE |
| 015 | A 0004010272 | NUT |
| 016 | A 3184000225 | HUB CAP |
| Repalced by: A 3184000125 | ||
| 016 | A 3184000125 | HUB CAP |
| 022 | A 3249970026 | WASHER |
| DISC WHEEL TO REAR AXLE | ||
| 026 | N 074361018352 | LOCK WASHER |
| DISC WHEELS TO FRONT AND REAR AXLES | ||
| 031 | N 074361018205 | NUT |
| DISC WHEELS TO FRONT AND REAR AXLES | ||
| 036 | A 0004010013 | VALVE |
| Repalced by: A 3104010113 | ||
| 036 | A 3104010113 | VALVE |
| EXTENSION | ||
| 036 | A 3104010413 | VALVE |
| EXTENSION | ||
| 040 | N 007757008600 | VALVE CAP |
| A 0004017194 | BALANCING WEIGHT | |
| 50 G. | ||
| A 0004017294 | BALANCING WEIGHT | |
| 100 G. | ||
| A 0004017394 | BALANCING WEIGHT | |
| 150 G. | ||
| 046 | A 3524030529 | HOOK BOLT |
| 048 | N 074361014351 | LOCK WASHER |
| 051 | A 3144000069 | CLAMPING PIECE |
| Repalced by: A 3529900262 | ||
| 051 | A 3529900262 | NUT |
| HOOK BOLT | ||
| 057 | A 3144000239 | BRACKET |
| SPARE WHEEL | ||
| 063 | A 3144000141 | MOUNTING BOW |
| SPARE WHEEL CARRIER TO FRAME | ||
| 064 | N 000933010128 | SCREW |
| SPARE WHEEL CARRIER TO FRAME | ||
| 065 | N 912004010102 | LOCK WASHER |
| SPARE WHEEL CARRIER TO FRAME | ||
| 066 | N 000934010014 | NUT |
| SPARE WHEEL CARRIER TO FRAME | ||
| 068 | N 001434010082 | PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 075 | N 000125010518 | WASHER |
| Repalced by: N 000125010532 | ||
| 075 | N 000125010532 | WASHER |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 076 | N 000094003219 | COTTER PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 079 | A 3144000439 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 083 | A 3144030340 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 084 | N 000933010105 | SCREW |
| SPARE WHEEL MOUNTING | ||
| 085 | N 912004010102 | LOCK WASHER |
| SPARE WHEEL MOUNTING | ||
| 086 | N 000934010014 | NUT |
| SPARE WHEEL MOUNTING | ||
| A 3144000470 | CLAMPING SCREW | |
| Repalced by: A 3144000570 | ||
| 088 | A 3144000570 | CLAMPING SCREW |
| SPARE WHEEL MOUNTING | ||
| H 403198980265 | NUT | |
| Repalced by: A 3198980265 | ||
| 093 | A 3198980265 | SCREW |
| 097 | N 001434014042 | PIN |
| SPARE WHEEL MOUNTING | ||
| 103 | N 000125015013 | WASHER |
| Repalced by: N 000125015019 | ||
| 103 | N 000125015019 | WASHER |
| SPARE WHEEL MOUNTING | ||
| 104 | N 000094004065 | COTTER PIN |
| SPARE WHEEL MOUNTING | ||
| A 3184000239 | BRACKET | |
| Repalced by: A 3184000939 | ||
| 108 | A 3184000939 | BRACKET |
| SPARE WHEEL CARRIER | ||
| 109 | N 000933010105 | SCREW |
| BRACKET TO FRAME | ||
| 110 | N 913002010001 | NUT |
| BRACKET TO FRAME | ||
| 121 | N 001434016027 | PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 121 | N 001434016016 | PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 127 | N 000125017010 | WASHER |
| Repalced by: N 000125017016 | ||
| 127 | N 000125017016 | WASHER |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 131 | N 000094004065 | COTTER PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 133 | A 3144000839 | BRACKET |
| SPARE WHEEL | ||
| 137 | A 3144001239 | BRACKET |
| SPARE WHEEL | ||
| 139 | N 000933010105 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 142 | N 913002010001 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 144 | N 006331016001 | NUT |
| BRACKET TO CONSOLE | ||
| 148 | A 3144030073 | LOCK |
| SPARE WHEEL MOUNTING | ||
| 153 | N 005296020204 | RING |
| SPARE WHEEL MOUNTING | ||
| 157 | N 005686001003 | CHAIN |
| SPARE WHEEL MOUNTING | ||
| 162 | N 074361018352 | LOCK WASHER |
| DISC WHEEL TO SUPPORT | ||
| 166 | N 000961016006 | SCREW |
| DISC WHEEL TO SUPPORT | ||
| 172 | A 3184000839 | BRACKET |
| SPARE WHEEL CARRIER | ||
| 176 | N 001434016016 | PIN |
| SPARE WHEEL CARRIER | ||
| 181 | N 000125017010 | WASHER |
| Repalced by: N 000125017016 | ||
| 181 | N 000125017016 | WASHER |
| SPARE WHEEL CARRIER | ||
| 184 | N 000094004065 | COTTER PIN |
| SPARE WHEEL CARRIER | ||
| 186 | A 3184030103 | BEARING BRACKET |
| 187 | N 000933010129 | SCREW |
| Repalced by: N 304017010002 | ||
| 187 | N 304017010002 | SCREW |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 188 | N 000125010518 | WASHER |
| Repalced by: N 000125010532 | ||
| 188 | N 000125010532 | WASHER |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 190 | N 913002010001 | NUT |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 192 | A 3144001139 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 192 | A 3144001139 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 193 | N 000933010105 | SCREW |
| BRACKET TO FRAME | ||
| 193 | N 000933010105 | SCREW |
| BRACKET TO FRAME | ||
| 194 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 194 | N 910113010000 | NUT |
| BRACKET TO FRAME | ||
| 194 | N 910113010000 | NUT |
| BRACKET TO FRAME | ||
| 196 | A 3184000739 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 196 | A 3184000739 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 198 | N 912004016101 | LOCK WASHER |
| SPARE WHEEL MOUNTING | ||
| 198 | N 912004016101 | LOCK WASHER |
| SPARE WHEEL MOUNTING | ||
| 200 | N 000934016011 | NUT |
| Repalced by: N 308673016001 | ||
| 200 | N 308673016001 | NUT |
| SPARE WHEEL MOUNTING | ||
| 200 | N 308673016001 | NUT |
| SPARE WHEEL MOUNTING | ||
| 211 | A 3184003839 | BRACKET |
| 216 | A 3814030185 | WORM |
| Repalced by: A 6204030085 | ||
| 216 | A 6204030085 | WORM |
| 221 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 226 | A 3814030250 | BUSHING |
| WORM AND SHAFT TO BRACKET | ||
| 231 | N 001481006005 | CLAMPING SLEEVE |
| WORM AND SHAFT TO BRACKET | ||
| A 3814030083 | STOP GEAR | |
| Repalced by: A 3814030183 | ||
| A 3814030183 | STOP GEAR | |
| Repalced by: A 6204030483 | ||
| 237 | A 6204030483 | STOP GEAR |
| 243 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 248 | N 001481008027 | CLAMPING SLEEVE |
| WORM AND SHAFT TO BRACKET | ||
| 254 | A 3814030036 | CABLE |
| Repalced by: N 083331008500 | ||
| 254 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 254 | N 083334008000 | WIRE CABLE |
| 2700 MM | ||
| 259 | A 3814030044 | COVER PLATE |
| COVER PLATE TO BRACKET | ||
| 261 | N 000933010105 | SCREW |
| COVER PLATE TO BRACKET | ||
| 264 | N 913002010001 | NUT |
| COVER PLATE TO BRACKET | ||
| 266 | A 3814030150 | BUSHING |
| CRANK | ||
| 271 | A 3184030045 | CRANK |
| Repalced by: A 3814030045 | ||
| 271 | A 3814030045 | CRANK |
| 276 | N 001481006005 | CLAMPING SLEEVE |
| CRANK TO JOINT SLEEVE | ||
| 277 | N 000933010200 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 277 | N 000961014050 | SCREW |
| Repalced by: N 308676014020 | ||
| 277 | N 308676014020 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 279 | N 913002010001 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 279 | N 913002014002 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 280 | N 074361018103 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 281 | A 3184004139 | BRACKET |
| Repalced by: A 3184005439 | ||
| 281 | A 3184005439 | BRACKET |
| 286 | A 3184004239 | BRACKET |
| LEFT | ||
| 286 | A 3184004039 | BRACKET |
| RIGHT | ||
| 290 | N 000961016142 | SCREW |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 295 | N 000125017010 | WASHER |
| Repalced by: N 000125017016 | ||
| 295 | N 000125017016 | WASHER |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 300 | A 3184000191 | STAY |
| SPARE WHEEL HOIST | ||
