Transporto priemonė: LP 911 B; VIN numerio dalis: 353056
Grupė: 46 STEERING
| # | Kodas | Pavadinimas |
|---|---|---|
| A 3374601301 | STEERING BOX ASSEMBLY | |
| Repalced by: A 3374601601 | ||
| 002 | A 3374601601 | STEERING BOX ASSEMBLY |
| Repalced by: A 3444601101 | ||
| 002 | A 3444601101 | STEERING BOX ASSEMBLY |
| A 3374601201 | STEERING BOX ASSEMBLY | |
| Repalced by: A 3374601501 | ||
| 002 | A 3374601501 | STEERING BOX ASSEMBLY |
| Repalced by: A 3374601701 | ||
| 002 | A 3374601701 | STEERING BOX ASSEMBLY |
| T YYYYYYYYYYYY | PART NAME MISSING | |
| FOR STEERING, SEE PARTS LIST: | ||
| 760.6 | ||
| 005 | A 3214601302 | STEERING BOX |
| 005 | A 3274600202 | STEERING BOX |
| 007 | A 3214610350 | BUSHING |
| STANDARD | ||
| 47.1 MM | ||
| 007 | A 3214610550 | BUSHING |
| REPAIR SIZE I | ||
| 47.6 MM | ||
| 010 | A 0019970645 | SEAL RING |
| 010 | A 0049976845 | SEAL RING |
| A 3029970035 | PLUG | |
| Repalced by: N 000906016002 | ||
| 015 | N 000906016002 | SCREW PLUG |
| BOX COVER | ||
| A 3274602308 | STEERING WORM | |
| Repalced by: A 3094600708 | ||
| 018 | A 3094600708 | STEERING WORM |
| Repalced by: A 3094601018 | ||
| 018 | A 3094601018 | STEERING NUT |
| Repalced by: A 3094600708 | ||
| 018 | A 3094600708 | STEERING WORM |
| WITH STEERING NUT | ||
| A 3274602208 | STEERING WORM | |
| Repalced by: A 4064600118 | ||
| A 4064600118 | STEERING NUT | |
| Repalced by: A 4064600218 | ||
| A 4064600218 | STEERING NUT | |
| WITH STEERING WORM | ||
| 020 | A 3219970740 | SEAL RING |
| 022 | A 0009811306 | BARREL-TYPE BEARING |
| 022 | A 3459817006 | BARREL-TYPE BEARING |
| 022 | A 0009810806 | BARREL-TYPE BEARING |
| A 3214600911 | STEERG. WORM SECTOR SHAFT | |
| Repalced by: A 3214601111 | ||
| 025 | A 3214601111 | STEERG. WORM SECTOR SHAFT |
| 026 | A 3214620437 | BALL CUP |
| A 3214620537 | BALL CUP | |
| 030 | N 009045038000 | SNAP RING |
| 032 | A 3219970640 | SEAL RING |
| 034 | A 3214600315 | OIL LEVEL CHECK PIPE |
| 036 | N 007603030400 | SEAL RING |
| OIL DRAIN | ||
| 038 | N 007604030201 | SCREW PLUG |
| Repalced by: N 007604030206 | ||
| 038 | N 007604030206 | SCREW PLUG |
| OIL DRAIN | ||
| A 3274600214 | STEERING BOX COVER | |
| Repalced by: A 3214600414 | ||
| 040 | A 3214600414 | STEERING BOX COVER |
| A 3274600314 | STEERING BOX COVER | |
| Repalced by: A 3214600514 | ||
| 040 | A 3214600514 | STEERING BOX COVER |
| 042 | A 3214620250 | BUSHING |
| STEERING SHAFT BEARING IN COVER | ||
| 043 | A 3214610880 | GASKET |
| Repalced by: A 3524610180 | ||
| 043 | A 3524610180 | GASKET |
| COVER TO BOX | ||
| 045 | N 912004008102 | LOCK WASHER |
| COVER TO BOX | ||
| 048 | A 0019909101 | SCREW |
| COVER TO BOX | ||
| 050 | A 3214620171 | SCREW |
| COVER TO BOX | ||
| 052 | A 3219932201 | SPRING |
| STEERING WORM SECTOR SHAFT | ||
| 055 | A 3214620185 | THRUST PIECE |
| STEERING WORM SECTOR SHAFT | ||
| 057 | A 3214610162 | THRUST WASHER |
| STEERING WORM SECTOR SHAFT | ||
| 060 | A 0009946041 | LOCK |
| STEERING WORM SECTOR SHAFT | ||
| A 0019976140 | SEAL RING | |
| STEERING WORM SECTOR SHAFT TO COVER | ||
| A 3219900050 | NUT | |
| STEERING WORM SECTOR SHAFT TO COVER | ||
| 065 | A 0029900251 | NUT |
| STEERING WORM SECTOR SHAFT TO COVER | ||
| A 3224620051 | RING | |
| Repalced by: A 3224620151 | ||
| 070 | A 3224620151 | RING |
| 072 | A 0029979845 | SEAL RING |
| STEERING NUT BEARING | ||
| 074 | A 0029974346 | SEAL RING |
| STEERING NUT BEARING | ||
| 076 | N 070852060000 | NUT |
| Repalced by: A 6743560226 | ||
| 076 | A 6743560226 | GROOVED NUT |
| STEERING NUT BEARING | ||
| 078 | A 3229940115 | LOCK |
| STEERING NUT BEARING | ||
| 080 | A 0009902555 | NUT |
| PITMAN ARM TO STEERING BOX ASSEMBLY | ||
| N 000094006006 | COTTER PIN | |
| PITMAN ARM TO STEERING BOX ASSEMBLY | ||
| 082 | A 3524630801 | PITMAN ARM |
| 082 | A 3524630901 | PITMAN ARM |
| A 3529900114 | SCREW | |
| Repalced by: A 3279900114 | ||
| 085 | A 3279900114 | SCREW |
| STEERING TO STEERING BRACKET | ||
| 087 | A 3529900214 | SCREW |
| STEERING TO STEERING BRACKET | ||
| 089 | A 3279900050 | NUT |
| STEERING TO STEERING BRACKET | ||
| N 000094003222 | COTTER PIN | |
| STEERING TO STEERING BRACKET | ||
| 092 | A 0004640601 | STEERING WHEEL |
| Repalced by: A 0004641101 | ||
| 092 | A 0004641101 | STEERING WHEEL |
| A 0004641201 | STEERING WHEEL | |
| A 0004640131 | CAP | |
| Repalced by: A 0004641231 | ||
| 094 | A 0004641231 | CAP |
| Repalced by: A 0004642631 | ||
| 094 | A 0004642631 | CAP |
| STEERING WHEEL TO STEERING COLUMN | ||
| 096 | A 0004640177 | PROTECTIVE RING |
| STEERING WHEEL TO STEERING COLUMN | ||
| A 3524600435 | BRACKET | |
| Repalced by: A 3554600429 | ||
| A 3604600429 | STEERING BRACKET | |
| Repalced by: A 3554600429 | ||
| 098 | A 3554600429 | STEERING BRACKET |
| AT FRAME | ||
| A 3524600535 | BRACKET | |
| Repalced by: A 3554600529 | ||
| A 3604600529 | STEERING BRACKET | |
| Repalced by: A 3554600529 | ||
| A 3554600529 | STEERING BRACKET | |
| AT FRAME | ||
| A 0029908201 | SCREW | |
| STEERING BRACKET TO FRAME | ||
| A 3229901901 | SCREW | |
| STEERING BRACKET TO FRAME | ||
| N 912004012100 | LOCK WASHER | |
| STEERING BRACKET TO FRAME | ||
| N 000934012013 | NUT | |
| STEERING BRACKET TO FRAME | ||
| A 3534620096 | BOOT | |
| UNIVERSAL JOINT COVERING | ||
| A 3534620075 | WASHER | |
| UNIVERSAL JOINT COVERING | ||
| 105 | A 3354600337 | BEARING |
| Repalced by: A 3354600437 | ||
| 105 | A 3354600437 | BEARING |
| PLEASE REFER TO ADDITIONAL PARTS | ||
| 105 | A 3354600137 | BEARING |
| Repalced by: A 3354600337 | ||
| 105 | A 3354600337 | BEARING |
| Repalced by: A 3354600437 | ||
| 105 | A 3354600437 | BEARING |
| STEERING SHAFT | ||
| 107 | A 3124621150 | BUSHING |
| Repalced by: A 0119815110 | ||
| 107 | A 0119815110 | NEEDLE BEARING |
| 109 | A 3214620165 | RING |
| 112 | A 3224620023 | COVER |
| N 000931010282 | SCREW | |
| STEERING COLUMN BRACKET TO CAB | ||
| N 000137010200 | SPRING WASHER | |
| STEERING COLUMN BRACKET TO CAB | ||
| 115 | A 3524620296 | BOOT |
| Repalced by: A 3604620596 | ||
| 115 | A 3604620596 | BOOT |
| UNIVERSAL JOINT,TOP | ||
| 117 | A 3214620060 | SEAL RING |
| THRU CAB | ||
| A 3604620096 | BOOT | |
| Repalced by: A 3604620496 | ||
| 120 | A 3604620296 | BOOT |
| Repalced by: A 3604620496 | ||
| 120 | A 3604620496 | BOOT |
| STEERING COLUMN TUBE THRU CAB FLOOR | ||
| N 900288140000 | CLAMP | |
| STEERING COLUMN TUBE THRU CAB FLOOR | ||
| A 3274600157 | UNIVERSAL JOINT | |
| Repalced by: A 3524600057 | ||
| A 3524600057 | UNIVERSAL JOINT | |
| 124 | A 3164600057 | UNIVERSAL JOINT |
| Repalced by: A 0004600057 | ||
| 124 | A 0004600057 | UNIVERSAL JOINT |
| A 3164600157 | UNIVERSAL JOINT | |
| Repalced by: A 0004600157 | ||
| A 0004600157 | UNIVERSAL JOINT | |
| A 4214600457 | UNIVERSAL JOINT | |
| Repalced by: A 3164600057 | ||
| 126 | A 1884100231 | UNIVERSAL JOINT CROSS |
| 128 | A 1884110258 | SEAL HOLDER |
| 129 | A 1884110460 | RUBBER RING |
| 130 | A 1104110242 | BEARING BUSHING |
| A 1104110342 | BEARING BUSHING | |
| A 0009811487 | NEEDLE | |
| Repalced by: A 3229810087 | ||
| 132 | A 3229810087 | NEEDLE |
| SET = 192 PIECES | ||
| 135 | A 1889940534 | SNAP RING |
| AS REQUIRED | ||
| 1.45 MM | ||
| A 1889940034 | SNAP RING | |
| AS REQUIRED | ||
| 1.50 MM | ||
| A 1889940134 | SNAP RING | |
| AS REQUIRED | ||
| 1.55 MM | ||
| A 1889940234 | SNAP RING | |
| AS REQUIRED | ||
| 1.60 MM | ||
| A 1889940334 | SNAP RING | |
| AS REQUIRED | ||
| 1.65 MM | ||
| A 1889940434 | SNAP RING | |
| AS REQUIRED | ||
| 1.70 MM | ||
| A 3524620201 | STEERING SHAFT | |
| BOTTOM | ||
| 140 | A 3604621101 | STEERING SHAFT |
| BOTTOM | ||
| 140 | A 3604622001 | STEERING SHAFT |
| BOTTOM | ||
| 142 | A 3524620001 | STEERING SHAFT |
| Repalced by: A 3524623901 | ||
| 142 | A 3524623901 | STEERING SHAFT |
| PLEASE REFER TO ADDITIONAL PARTS | ||
| 142 | A 3524621801 | STEERING SHAFT |
| Repalced by: A 3524624101 | ||
| 142 | A 3524624101 | STEERING SHAFT |
| PLEASE REFER TO ADDITIONAL PARTS | ||
| 142 | A 3524622601 | STEERING SHAFT |
| Repalced by: A 3524623101 | ||
| 142 | A 3524623101 | STEERING SHAFT |
| TOP | ||
| 142 | A 3524622801 | STEERING SHAFT |
| Repalced by: A 3524623601 | ||
| 142 | A 3524623601 | STEERING SHAFT |
| TOP | ||
| A 3219900401 | SCREW | |
| UNIVERSAL JOINT TO STEERING COLUMN | ||
| M 10X35 | ||
| 144 | A 3169900114 | SCREW |
| UNIVERSAL JOINT TO STEERING COLUMN | ||
| M 8X38 | ||
| 144 | A 3819900114 | SCREW |
| UNIVERSAL JOINT TO STEERING COLUMN | ||
| M8X42 | ||
| N 000463010500 | LOCK PLATE | |
| UNIVERSAL JOINT TO STEERING COLUMN | ||
| 146 | N 910113008001 | NUT |
| UNIVERSAL JOINT TO STEERING COLUMN | ||
| 148 | N 006888005002 | WOODRUFF KEY |
| STEERING WHEEL TO STEERING COLUMN | ||
| 150 | N 000936022002 | NUT |
| STEERING WHEEL TO STEERING COLUMN | ||
| A 3524601005 | DRAG LINK | |
| Repalced by: A 3524602705 | ||
| A 3524601905 | DRAG LINK | |
| Repalced by: A 3524602705 | ||
| 155 | A 3524602705 | DRAG LINK |
| Repalced by: A 3524605405 | ||
| 155 | A 3524605405 | DRAG LINK |
| LEMFOERDER | ||
| 155 | A 3524604405 | DRAG LINK |
| EHRENREICH | ||
| A 3524601105 | DRAG LINK | |
| Repalced by: A 3524602805 | ||
| A 3524602005 | DRAG LINK | |
| Repalced by: A 3524602805 | ||
| 155 | A 3524602805 | DRAG LINK |
| Repalced by: A 3524605705 | ||
| 155 | A 3524605705 | DRAG LINK |
| LEMFOERDER | ||
| 155 | A 3524604505 | DRAG LINK |
| EHRENREICH | ||
| N 071412008101 | GREASE NIPPLE | |
| Repalced by: N 071412008102 | ||
| N 071412008102 | GREASE NIPPLE | |
| 158 | A 0003380027 | BALL SOCKET |
| Repalced by: A 0005860033 | ||
| 160 | A 3349910615 | BALL PIVOT |
| Repalced by: A 0005860033 | ||
| 160 | A 0005860033 | REPAIR KIT |
| 162 | A 0004630061 | SPRING RETAINER |
| 164 | A 0009930105 | SPRING |
| 166 | A 0004631656 | DUST CAP |
| 168 | A 0009940037 | SNAP RING |
| 170 | A 0003381656 | DUST CAP |
| A 0003300285 | BOOT | |
| Repalced by: A 0003300885 | ||
| A 0003300885 | BOOT | |
| 172 | N 000937018003 | NUT |
| N 000094004065 | COTTER PIN | |
| 174 | A 0005860033 | REPAIR KIT |
