Transporto priemonė: LP 913; VIN numerio dalis: 318059
Grupė: 40 WHEELS
| # | Kodas | Pavadinimas |
|---|---|---|
| 007 | A 3164000002 | DISC WHEEL |
| Repalced by: A 0024010401 | ||
| 007 | A 0024010401 | DISC WHEEL |
| 6.00 G - 16 SDC | ||
| 007 | A 3134000002 | DISC WHEEL |
| Repalced by: A 3184001402 | ||
| 007 | A 3184001402 | DISC WHEEL |
| 5.25-17.5 | ||
| 007 | A 3184000002 | DISC WHEEL |
| Repalced by: A 0024015301 | ||
| 007 | A 0024015301 | DISC WHEEL |
| 6.50 H - 16 SDC | ||
| 007 | A 3184001202 | DISC WHEEL |
| 6.75 X 17.5 | ||
| 012 | A 0004015906 | SIDE RING |
| Repalced by: A 6674010006 | ||
| 012 | A 6674010006 | SIDE RING |
| Repalced by: A 0004015906 | ||
| 012 | A 0004015906 | SIDE RING |
| 012 | A 0004016006 | SIDE RING |
| 014 | A 0004012913 | VALVE |
| Repalced by: A 0004017113 | ||
| 014 | A 0004017113 | VALVE |
| 014 | A 0004013213 | VALVE |
| 015 | A 0004010272 | NUT |
| A 3184000225 | HUB CAP | |
| Repalced by: A 3184000125 | ||
| 016 | A 3184000125 | HUB CAP |
| 022 | A 3249970026 | WASHER |
| 026 | N 074361018352 | LOCK WASHER |
| 031 | N 074361018205 | NUT |
| 036 | A 0004010013 | VALVE |
| Repalced by: A 3104010113 | ||
| 036 | A 3104010113 | VALVE |
| EXTENSION | ||
| 036 | A 3104010413 | VALVE |
| EXTENSION | ||
| 036 | A 3854010013 | VALVE |
| 036 | A 3854010113 | VALVE |
| 040 | N 007757008006 | VALVE CAP |
| A 0004017194 | BALANCING WEIGHT | |
| 50 G | ||
| A 0004017294 | BALANCING WEIGHT | |
| 100 G | ||
| A 0004017394 | BALANCING WEIGHT | |
| 150 G | ||
| A 3184000239 | BRACKET | |
| Repalced by: A 3184000939 | ||
| 045 | A 3184000939 | BRACKET |
| SPARE WHEEL CARRIER | ||
| 047 | A 3184000839 | BRACKET |
| SPARE WHEEL CARRIER | ||
| 049 | N 000933010105 | SCREW |
| BRACKET TO FRAME | ||
| 051 | N 913002010001 | NUT |
| BRACKET TO FRAME | ||
| 053 | A 3184030103 | BEARING BRACKET |
| 055 | N 000933010129 | SCREW |
| Repalced by: N 304017010002 | ||
| 055 | N 304017010002 | SCREW |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 057 | N 000125010518 | WASHER |
| Repalced by: N 000125010532 | ||
| 057 | N 000125010532 | WASHER |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 061 | N 913002010001 | NUT |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 063 | N 001434016027 | PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 063 | N 001434016016 | PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 069 | N 000125017010 | WASHER |
| Repalced by: N 000125017016 | ||
| 069 | N 000125017016 | WASHER |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 071 | N 000094004065 | COTTER PIN |
| SPARE WHEEL CARRIER TO SUBSTRUCTURE | ||
| 075 | A 3144000839 | BRACKET |
| SPARE WHEEL | ||
| 079 | A 3144001239 | BRACKET |
| SPARE WHEEL | ||
| 081 | N 000933010105 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| 085 | N 913002010001 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 087 | N 006331016001 | NUT |
| BRACKET TO CROSS MEMBER | ||
| 091 | A 3144030073 | LOCK |
| SPARE WHEEL MOUNTING | ||
| 093 | N 005296020204 | RING |
| SPARE WHEEL MOUNTING | ||
| 095 | N 005686001003 | CHAIN |
| SPARE WHEEL MOUNTING | ||
| 099 | N 074361018352 | LOCK WASHER |
| DISC WHEEL TO SUPPORT | ||
| 103 | N 000961016006 | SCREW |
| DISC WHEEL TO SUPPORT | ||
| 105 | A 3144001139 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 108 | N 000933010105 | SCREW |
| BRACKET TO SIDE MEMBER | ||
| 111 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 111 | N 910113010000 | NUT |
| BRACKET TO SIDE MEMBER | ||
| 113 | A 3184000739 | BRACKET |
| SPARE WHEEL MOUNTING | ||
| 116 | N 000934016011 | NUT |
| Repalced by: N 308673016001 | ||
| 116 | N 308673016001 | NUT |
| SPARE WHEEL MOUNTING | ||
| 119 | N 912004016101 | LOCK WASHER |
| SPARE WHEEL MOUNTING | ||
| 121 | N 000961012122 | SCREW |
| SPARE WHEEL TO CROSS MEMBER | ||
| 123 | N 007349013001 | WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 125 | N 074361018352 | LOCK WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 127 | N 000934012022 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 131 | A 3184003839 | BRACKET |
| 131 | A 3184003839 | BRACKET |
| A 3814001739 | BRACKET | |
| Repalced by: A 3184004339 | ||
| 131 | A 3184004339 | BRACKET |
| CRANK TO WORM | ||
| 131 | A 3184004339 | BRACKET |
| CRANK TO WORM | ||
| A 3184004539 | BRACKET | |
| Repalced by: A 3184005739 | ||
| 135 | A 3184005739 | BRACKET |
| CRANK TO WORM | ||
| 135 | A 3184006339 | BRACKET |
| CRANK TO WORM | ||
| A 3814030085 | WORM | |
| Repalced by: A 3814030185 | ||
| A 3814030185 | WORM | |
| Repalced by: A 6204030085 | ||
| 137 | A 6204030085 | WORM |
| 137 | A 6204030085 | WORM |
| 141 | A 3814030250 | BUSHING |
| WORM AND SHAFT TO BRACKET | ||
| 141 | A 3814030250 | BUSHING |
| WORM AND SHAFT TO BRACKET | ||
| 143 | A 3149900440 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 147 | N 001481008038 | CLAMPING SLEEVE |
| Repalced by: N 308752008000 | ||
| 147 | N 308752008000 | CLAMPING PIN |
| WORM AND SHAFT TO BRACKET | ||
| A 3814030083 | STOP GEAR | |
| Repalced by: A 3814030183 | ||
| A 3814030183 | STOP GEAR | |
| Repalced by: A 6204030483 | ||
| 151 | A 6204030483 | STOP GEAR |
| 151 | A 6204030483 | STOP GEAR |
| 154 | N 083331008500 | WIRE CABLE |
| Repalced by: N 083334008000 | ||
| 154 | N 083334008000 | WIRE CABLE |
| 154 | N 083334008000 | WIRE CABLE |
| 157 | A 3149900440 | WASHER |
| Repalced by: A 3819900340 | ||
| 157 | A 3819900340 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 157 | A 6179900540 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 157 | A 6179900540 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 158 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 158 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 161 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 161 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 163 | A 3819900140 | WASHER |
| WORM AND SHAFT TO BRACKET | ||
| 167 | A 3184000017 | SHAFT |
| 169 | N 001481006027 | CLAMPING SLEEVE |
| 173 | A 3184004739 | BRACKET |
| 173 | A 3184006139 | BRACKET |
| 178 | N 000933010105 | SCREW |
| SPARE WHEEL CARRIER | ||
| 178 | N 000933010105 | SCREW |
| SPARE WHEEL CARRIER | ||
| 178 | N 000961012097 | SCREW |
| Repalced by: N 308676012026 | ||
| 178 | N 308676012026 | SCREW |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 178 | N 308676012026 | SCREW |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 178 | N 308676012026 | SCREW |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 181 | N 913002010001 | NUT |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 181 | N 913002010001 | NUT |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 181 | N 910113012002 | NUT |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 183 | N 007349013003 | WASHER |
| Repalced by: N 007349013005 | ||
| 183 | N 007349013005 | WASHER |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 183 | N 007349013005 | WASHER |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 183 | N 007349013005 | WASHER |
| SPARE WHEEL CARRIER TO CROSS MEMBER | ||
| 187 | A 3814030150 | BUSHING |
| AT SIDE MEMBER | ||
| 187 | A 3814030150 | BUSHING |
| AT SIDE MEMBER | ||
| A 3184030045 | CRANK | |
| Repalced by: A 3814030045 | ||
| 190 | A 3814030045 | CRANK |
| 190 | A 3814030045 | CRANK |
| 190 | A 3814030045 | CRANK |
| 193 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO JOINT SLEEVE | ||
| 193 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO JOINT SLEEVE | ||
| 193 | N 001481006027 | CLAMPING SLEEVE |
| CRANK TO JOINT SLEEVE | ||
| A 3184004139 | BRACKET | |
| Repalced by: A 3184005439 | ||
| 197 | A 3184005439 | BRACKET |
| 197 | A 3184005439 | BRACKET |
| 197 | A 3184005439 | BRACKET |
| 199 | A 3184000191 | STAY |
| SPARE WHEEL TO BRACKET | ||
| 201 | N 000125019010 | WASHER |
| SPARE WHEEL TO BRACKET | ||
| 205 | N 074361018205 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 205 | N 074361018205 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 205 | N 074361018205 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 205 | N 074361018205 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 207 | N 000433017004 | WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 209 | N 000934016011 | NUT |
| Repalced by: N 308673016001 | ||
| 209 | N 308673016001 | NUT |
| SPARE WHEEL TO CROSS MEMBER | ||
| 211 | N 074361018352 | LOCK WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 211 | N 074361018352 | LOCK WASHER |
| SPARE WHEEL TO CROSS MEMBER | ||
| 213 | N 000961016142 | SCREW |
| SUPPORT TO FRAME | ||
| 213 | N 000961016142 | SCREW |
| SUPPORT TO FRAME | ||
| 217 | N 000125017010 | WASHER |
| Repalced by: N 000125017016 | ||
| 217 | N 000125017016 | WASHER |
| SUPPORT TO FRAME | ||
| 217 | N 000125017016 | WASHER |
| SUPPORT TO FRAME | ||
| 220 | A 3184004239 | BRACKET |
| LEFT | ||
| 220 | A 3184004239 | BRACKET |
| LEFT | ||
| 220 | A 3184004039 | BRACKET |
| RIGHT | ||
| 220 | A 3184004039 | BRACKET |
| RIGHT | ||
| 225 | N 000933010200 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 225 | N 000933010200 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 225 | N 000961014088 | SCREW |
| Repalced by: N 308676014008 | ||
| 225 | N 308676014008 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 225 | N 308676014008 | SCREW |
| SPARE WHEEL HOIST TO BRACKET | ||
| 227 | N 913004014002 | NUT |
| Repalced by: N 910113014001 | ||
| 227 | N 910113014001 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 227 | N 910113014001 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 227 | N 913004010008 | NUT |
| Repalced by: N 910113010000 | ||
| 227 | N 910113010000 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 227 | N 910113010000 | NUT |
| SPARE WHEEL HOIST TO BRACKET | ||
| 231 | A 3814030044 | COVER PLATE |
| 231 | A 3814030044 | COVER PLATE |
