Transporto priemonė: LS 1924; VIN numerio dalis: 350013

Grupė: 52 CHASSIS SHEET METAL - 001 SHEET METAL,AIR INTAKE

#	Kodas	Pavadinimas
	X XXXXXXXXXXXX	PART NAME MISSING
		AIR CLEANER
010	A 0070944202	AIR CLEANER
	Repalced by: A 3450947102
010	A 3450947102	AIR CLEANER
	Repalced by: A 3450948002
010	A 3450948002	AIR CLEANER
		"MANN DO BRASIL"
010	A 3450947702	AIR CLEANER
	Repalced by: A 3450947802
010	A 3450947802	AIR CLEANER
		"FRAM DO BRASIL"
015	A 3500947002	AIR CLEANER
		"MANN DO BRASIL"
015	A 3500947002	AIR CLEANER
		"MANN DO BRASIL"
017	A 3500947102	AIR CLEANER
		"MANN DO BRASIL"
020	A 3450947204	FILTER ELEMENT
	Repalced by: A 3440947104
020	A 3440947104	FILTER ELEMENT
		TO 345 094 77 02,345 094 78 02
020	A 0010945204	FILTER ELEMENT
		TO 345 094 71 02,345 094 80 02
020	A 3500947004	FILTER ELEMENT
		TO 350 094 70 02,350 094 71 02
022	A 0000940158	ADAPTER FITTING
		TO 345 094 78 02,345 094 77 02
023	A 0000940167	THREADED NIPPLE
		TO 345 094 78 02,345 094 77 02
025	A 3089907051	NUT
	Repalced by: N 913002008001
025	N 913002008001	NUT
		TO 345 094 71 02,345 094 80 02
025	A 3500947072	NUT
		TO 350 094 70 02,350 094 71 02
027	A 0000940472	NUT
		TO 345 094 78 02,345 094 77 02
030	A 3440947003	FILTER BOWL
		CYCLONE
		TO 345 094 71 02,345 094 80 02
030	A 3500947103	FILTER BOWL
		CYCLONE
		TO 350 094 70 02,350 094 71 02
033	A 0000948203	FILTER BOWL
		TO 345 094 78 02
036	A 0000940173	LOCK
		TO 345 094 78 02
038	N 000084008172	SCREW
		TO 350 094 70 02
040	A 0000941360	SEAL RING
		TO 345 094 78 02
042	A 0010948080	GASKET
		TO 345 094 78 02
044	A 0000940375	NUT
		TO 345 094 78 02
046	A 0000940572	NUT
		TO 345 094 78 02,345 094 77 02
048	A 0000942171	SCREW
		TO 345 094 78 02,344 094 77 02
050	H 983440940010	BOTTOM PARTITION
		TO 345 094 71 02
055	A 0010947980	GASKET
	Repalced by: A 0000941027
055	A 0000941027	BRACKET
		TO 345 094 78 02,345 094 77 02
060	A 3440947006	COVER
		TO 345 094 71 02
065	A 0000948703	FILTER BOWL
		TO 345 094 80 02
070	A 0010940055	FASTENER
		TO 345 094 80 02
072	A 3760947165	VALVE
		TO 345 094 80 02
072	A 0000941405	SEPARATOR
		TO 345 094 78 02
074	A 0000941905	CYCLONE PRE-FILTER BOWL
		TO 345 094 77 02,345 094 78 02
076	A 3500947003	FILTER BOWL
		TO 350 094 70 02,350 094 71 02
078	A 3500907072	NUT
		PARTS KIT
		TO 350 094 70 02,350 094 71 02
080	A 1109900052	NUT
		TO 345 094 80 02,350 094 70 02
082	N 000084008172	SCREW
		TO 345 094 80 02,350 094 70 02
084	A 3760947165	VALVE
		TO 350 094 70 02,350 094 71 02
086	A 0000942668	VACUUM BOX
		TO 345 094 78 02,345 094 77 02
	A 3450947068	VACUUM BOX
	Repalced by: A 3500947068
086	A 3500947068	VACUUM BOX
		TO 345 094 71 02,350 094 80 02
088	A 0000940368	VACUUM BOX
090	A 0009908654	NUT
		TO 345 094 80 02
092	A 0010944480	GASKET
		TO 350 094 70 02,345 094 80 02
094	A 0009972075	THREADED UNION
		TO 345 094 80 02
096	A 0000940927	BRACKET
		TO 345 094 80 02
096	A 0000940627	BRACKET
		TO 350 094 70 02
096	A 0000940627	BRACKET
		TO 350 094 70 02
096	A 0000940727	BRACKET
		TO 350 094 71 02
	A 0000944741	BRACKET
	Repalced by: A 3450947041
096	A 3450947041	BRACKET
		TO 345 094 71 02,
098	A 0000946011	SCOOP
		TO 345 094 77 02
100	A 3505207041	BRACKET
		AIR CLEANER
100	A 3505207341	BRACKET
		AIR CLEANER
100	A 3505207341	BRACKET
		AIR CLEANER
102	A 3505207741	BRACKET
		AIR CLEANER
104	A 3505287340	BRACKET
104	A 3505287540	BRACKET
104	A 3505287540	BRACKET
106	A 3505207841	BRACKET
108	A 3505287039	SUPPORT
108	A 3505287139	SUPPORT
108	A 3505287139	SUPPORT
110	A 3505287439	SUPPORT
112	N 000933010294	SCREW
		BRACKET TO CAB
		M 10X20 MM
112	N 000933010294	SCREW
		BRACKET TO FIRE WALL
		M 10X20 MM
112	N 000933010294	SCREW
		BRACKET TO SUPPORT
		M 10X20 MM
114	N 000127010202	LOCK WASHER
		BRACKET TO CAB
114	N 000127010202	LOCK WASHER
		BRACKET TO FIRE WALL
114	N 000127010202	LOCK WASHER
		BRACKET TO SUPPORT
114	N 000127010202	LOCK WASHER
		SUPPORT TO CAB
116	N 000933010174	SCREW
		BRACKET TO SUPPORT
		M 10X22 MM
116	N 000933010174	SCREW
		SUPPORT TO CAB
		M 10X22 MM
118	N 000125010517	WASHER
		BRACKET TO WHEELHOUSE
118	N 000125010517	WASHER
		BRACKET TO SUPPORT
118	N 000125010517	WASHER
		SUPPORT TO CAB
120	N 000934010000	NUT
		BRACKET TO SUPPORT
120	N 000934010000	NUT
		SUPPORT TO CAB
150	A 0000941809	INTAKE PIPE
		FROM AIR CLEANER TO AIR INTAKE PIPE
155	A 3505207001	AIR INTAKE PIPE
155	A 3505207001	AIR INTAKE PIPE
157	A 3505287091	BOOT
		AIR CLEANER
160	A 3505287082	HOSE
		AIR INTAKE PIPE
160	A 3505287182	HOSE
		AIR INTAKE PIPE
160	A 3505288182	HOSE
		AIR INTAKE PIPE
		A 350 528 71 82
161	A 0009977552	HOSE
	Repalced by: A 3529973382
161	A 3529973382	HOSE
		FROM AIR CLEANER TO AIR COMPRESSOR
161	A 3529973382	HOSE
		FROM AIR CLEANER TO AIR COMPRESSOR
163	A 4429970282	HOSE
		FROM AIR CLEANER TO AIR COMPRESSOR
165	A 3509970490	LOOM TIE
		AS REQUIRED
165	A 3509970390	LOOM TIE
		AS REQUIRED
167	A 3505287282	HOSE
167	A 3505287282	HOSE
169	A 3509971890	LOOM TIE
169	A 3509971890	LOOM TIE
171	A 3505287482	HOSE
		FROM AIR CLEANER TO TURBOCHARGER
171	A 3505287482	HOSE
		FROM AIR CLEANER TO TURBOCHARGER
173	A 3505288082	HOSE
		FROM AIR CLEANER TO TURBOCHARGER
175	A 3509971490	LOOM TIE
		FROM AIR CLEANER TO TURBOCHARGER
175	A 3509971690	LOOM TIE
		FROM AIR CLEANER TO TURBOCHARGER
175	A 3509971690	LOOM TIE
		FROM AIR CLEANER TO TURBOCHARGER
175	A 3509971890	LOOM TIE
		FROM AIR CLEANER TO TURBOCHARGER
180	A 3509971690	LOOM TIE
		AS REQUIRED
180	A 3509971790	LOOM TIE
		AS REQUIRED
180	A 3449979990	CLAMP
		AS REQUIRED
180	A 3459979990	CLAMP
		AS REQUIRED
180	A 3509971790	LOOM TIE
		AS REQUIRED
