Transporto priemonė: LS 1934; VIN numerio dalis: 350048
Grupė: 32 SPRINGS AND SUSPENSION
| # | Kodas | Pavadinimas |
|---|---|---|
| 010 | A 3503207102 | FRONT SPRING |
| 8-LEAF | ||
| 015 | A 3953200002 | FRONT SPRING |
| 10-LEAF | ||
| 020 | A 3503200394 | SPRING LEAF |
| NO.1 | ||
| 025 | A 3953200394 | SPRING LEAF |
| NO.1 | ||
| 040 | A 3043210150 | BUSHING |
| 040 | A 6203210050 | BUSHING |
| 044 | A 3503217012 | SPRING LEAF |
| NO.2 | ||
| 048 | A 3953210312 | SPRING LEAF |
| NO.2 | ||
| 050 | A 3503217013 | SPRING LEAF |
| NO.3 | ||
| 056 | A 3953210013 | SPRING LEAF |
| NO.3 | ||
| 056 | A 3503200494 | SPRING LEAF |
| NO.3 | ||
| 057 | N 000963012011 | SCREW |
| 058 | A 3039902440 | WASHER |
| 060 | A 3463215514 | SPRING LEAF |
| NO.4 | ||
| 066 | A 3953210014 | SPRING LEAF |
| NO.4 | ||
| 070 | A 3463215515 | SPRING LEAF |
| NO.5 | ||
| 076 | A 3953210015 | SPRING LEAF |
| NO.5 | ||
| 080 | A 3463215516 | SPRING LEAF |
| NO.6 | ||
| 086 | A 3953210016 | SPRING LEAF |
| NO.6 | ||
| 090 | A 3463215517 | SPRING LEAF |
| NO.7 | ||
| 096 | A 3953210017 | SPRING LEAF |
| NO.7 | ||
| 100 | A 3463215518 | SPRING LEAF |
| NO.8 | ||
| 102 | A 3953210018 | SPRING LEAF |
| NO.8 | ||
| 104 | A 3953210019 | SPRING LEAF |
| NO.9 | ||
| 106 | A 3953210020 | SPRING LEAF |
| NO.10 | ||
| 110 | A 3353210071 | SCREW |
| 110 | A 3463215071 | SCREW |
| 120 | N 913004014005 | NUT |
| 130 | A 0003249633 | SPRING CLAMP |
| 140 | N 000960012354 | SCREW |
| 140 | N 000960012351 | SCREW |
| 150 | A 3039902440 | WASHER |
| 160 | N 000934012004 | NUT |
| 170 | A 3703200062 | SHACKLE |
| IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: | ||
| 387 320 01 62 | ||
| 180 | A 3043210150 | BUSHING |
| 180 | A 6203210050 | BUSHING |
| 190 | A 3503227130 | SHACKLE PIN |
| 200 | N 071412010300 | GREASE NIPPLE |
| 210 | A 3523230376 | WASHER |
| 4.00 MM | ||
| 210 | A 3453230376 | WASHER |
| 4.00 MM | ||
| 210 | A 3523230476 | WASHER |
| 4.20 MM | ||
| 210 | A 3453230276 | WASHER |
| 4.20 MM | ||
| 210 | A 3523230576 | WASHER |
| 4.30 MM | ||
| 210 | A 3453230176 | WASHER |
| 4.30 MM | ||
| 220 | A 0029973140 | SEAL RING |
| SPRING SUSPENSION | ||
| 230 | A 3529900337 | BOLT |
| FRONT SPRING TO FRONT SPRING FRONT BRACKET | ||
| 240 | N 000125010517 | WASHER |
| FRONT SPRING TO FRONT SPRING FRONT BRACKET | ||
| 250 | N 913004010004 | NUT |
| FRONT SPRING TO FRONT SPRING FRONT BRACKET | ||
| 260 | A 3353310328 | SHIM |
| FRONT SPRINGS TO FRONT AXLE | ||
| 270 | A 3263310044 | RUBBER BUFFER |
| FRONT SPRINGS TO FRONT AXLE | ||
| 280 | A 3043310027 | SPACER |
| FRONT SPRINGS TO FRONT AXLE | ||
| 290 | A 3873310925 | U-BOLT |
| FRONT SPRINGS TO FRONT AXLE | ||
| 300 | N 000934020002 | NUT |
| FRONT SPRINGS TO FRONT AXLE | ||
| 310 | A 0023235300 | SHOCK ABSORBER |
| BOGE | ||
| 310 | A 3503237100 | SHOCK ABSORBER |
| COFOP | ||
| 310 | A 3503237000 | SHOCK ABSORBER |
| AMORTEX | ||
| 320 | A 0003232444 | RUBBER BUFFER |
| TO 002 323 53 00 | ||
| 330 | A 0003232550 | BUSHING |
| TO 002 323 53 00 | ||
| 340 | A 3503237263 | BEARING BRACKET |
| SHOCK ABSORBER | ||
| 350 | N 000933010129 | SCREW |
| BEARING BRACKET TO FRAME | ||
| M 10X70 | ||
| 350 | N 000933010258 | SCREW |
| BEARING BRACKET TO FRAME | ||
| M 10X40 | ||
| 360 | N 913004010004 | NUT |
| BEARING BRACKET TO FRAME | ||
| 370 | N 000960016238 | SCREW |
| SHOCK ABSORBER MOUNTING | ||
| 380 | N 913004016004 | NUT |
| SHOCK ABSORBER MOUNTING | ||
| 390 | A 3523230340 | BRACKET |
| Repalced by: A 3953230140 | ||
| 390 | A 3953230140 | BRACKET |
| SHOCK ABSORBER | ||
| 393 | A 3349900001 | SCREW |
| SHOCK ABSORBER BRACKET | ||
| 396 | N 913004020000 | NUT |
| SHOCK ABSORBER BRACKET | ||
| 400 | A 3529903201 | SCREW |
| SHOCK ABSORBER TO BEARING BRACKET | ||
| 410 | N 913004020004 | NUT |
| SHOCK ABSORBER TO BEARING BRACKET | ||
| 420 | N 000960016238 | SCREW |
| SHOCK ABSORBER MOUNTING | ||
| 430 | N 913004016004 | NUT |
| SHOCK ABSORBER MOUNTING | ||
| 440 | A 3893200308 | REAR SPRING |
| 8-LEAF | ||
| 444 | A 3633200508 | REAR SPRING |
| 6-LEAF | ||
| 450 | A 3893200393 | SPRING LEAF |
| NO.1 | ||
| 454 | A 3463205493 | SPRING LEAF |
| NO.1 | ||
| 460 | A 3353240350 | BUSHING |
| 460 | A 6203240050 | BUSHING |
| 470 | A 3893240312 | SPRING LEAF |
| NO.2 | ||
| 474 | A 3353241412 | SPRING LEAF |
| NO.2 | ||
| 480 | A 3893240313 | SPRING LEAF |
| NO.3 | ||
| 484 | A 3503200293 | SPRING LEAF |
| NO. 3 | ||
| 484 | A 3353241413 | SPRING LEAF |
| NO.3 | ||
| 490 | A 3893240314 | SPRING LEAF |
| NO.4 | ||
| 494 | A 3353241414 | SPRING LEAF |
| NO.4 | ||
| 500 | A 3893240315 | SPRING LEAF |
| NO.5 | ||
| 504 | A 3353241415 | SPRING LEAF |
| NO.5 | ||
| 510 | A 3893240316 | SPRING LEAF |
| NO.6 | ||
| 514 | A 3353241416 | SPRING LEAF |
| NO.6 | ||
| 520 | A 3893240317 | SPRING LEAF |
| NO.7 | ||
| 530 | A 3893240318 | SPRING LEAF |
| NO.8 | ||
| 540 | A 3893240340 | SPRING LEAF |
| HELPER SPRING | ||
| NO.1 | ||
| 540 | A 3363240940 | SPRING LEAF |
| HELPER SPRING | ||
| NO.1 | ||
| 550 | A 3893240341 | SPRING LEAF |
| HELPER SPRING | ||
| NO.2 | ||
| 550 | A 3353241440 | SPRING LEAF |
| HELPER SPRING | ||
| NO.2 | ||
| 560 | A 3893240342 | SPRING LEAF |
| HELPER SPRING | ||
| NO.3 | ||
| 560 | A 3353241414 | SPRING LEAF |
| HELPER SPRING | ||
| NO.3 | ||
| 570 | A 3893240343 | SPRING LEAF |
| HELPER SPRING | ||
| NO.4 | ||
| 570 | A 3353241415 | SPRING LEAF |
| HELPER SPRING | ||
| NO.4 | ||
| 580 | A 3893240344 | SPRING LEAF |
| HELPER SPRING | ||
| NO.5 | ||
| 580 | A 3353241416 | SPRING LEAF |
| HELPER SPRING | ||
| NO.5 | ||
| 590 | A 3893240345 | SPRING LEAF |
| HELPER SPRING | ||
| NO.6 | ||
| 600 | A 3873240035 | SPACER |
| 610 | A 3463245071 | SPRING BOLT |
| 610 | A 3473240271 | SPRING BOLT |
| 620 | N 007349019001 | WASHER |
| 630 | N 913004018000 | NUT |
| 640 | A 0003246733 | SPRING CLAMP |
| 640 | A 0003246333 | SPRING CLAMP |
| 650 | N 000960012351 | SCREW |
| 660 | A 3039902440 | WASHER |
| 670 | N 000934012041 | NUT |
| 680 | A 3463255062 | THRUST WASHER |
| 690 | A 0029973640 | SEAL RING |
| 700 | A 3463205063 | SHACKLE |
| REAR SPRING | ||
| 710 | A 3353240050 | BUSHING |
| REAR SPRING | ||
| 720 | N 071412008200 | GREASE NIPPLE |
| REAR SPRING | ||
| 720 | A 3459977188 | GREASE NIPPLE |
| REAR SPRING | ||
| 730 | A 3463255162 | THRUST WASHER |
| Repalced by: A 3503257062 | ||
| 730 | A 3503257062 | THRUST WASHER |
| 740 | N 000439024202 | NUT |
| 750 | A 3503257130 | SHACKLE PIN |
| 760 | N 071412010100 | GREASE NIPPLE |
| REAR SPRING PIN | ||
| 770 | A 3523230976 | WASHER |
| 4.00 MM | ||
| 770 | A 3453230776 | WASHER |
| 4.00 MM | ||
| 770 | A 3523231076 | WASHER |
| 4.20 MM | ||
| 770 | A 3453230676 | WASHER |
| 4.20 MM | ||
| 770 | A 3523231176 | WASHER |
| 4.30 MM | ||
| 770 | A 3453230576 | WASHER |
| 4.30 MM | ||
| 780 | A 0029973040 | SEAL RING |
| 790 | A 3529900337 | BOLT |
| REAR SPRING TO REAR SPRING FRONT BRACKET | ||
| 800 | N 000125010517 | WASHER |
| REAR SPRING TO REAR SPRING FRONT BRACKET | ||
| 810 | N 913004010004 | NUT |
| REAR SPRING TO REAR SPRING FRONT BRACKET | ||
| 820 | A 3873510128 | PAD |
| REAR SPRING TO REAR AXLE HOUSING WITH DIFFERENTIAL | ||
| 830 | A 3873510026 | SPRING CLAMPING PLATE |
| Repalced by: A 6203510026 | ||
| 830 | A 6203510026 | SPRING CLAMPING PLATE |
| REAR SPRING TO REAR AXLE HOUSING WITH DIFFERENTIAL | ||
| 840 | A 3353510725 | U-BOLT |
| REAR SPRING TO REAR AXLE HOUSING WITH DIFFERENTIAL | ||
| 850 | A 3879975026 | WASHER |
| Repalced by: A 3509977026 | ||
| 850 | A 3509977026 | WASHER |
| REAR SPRING TO REAR AXLE HOUSING WITH DIFFERENTIAL | ||
| 860 | N 000934024006 | NUT |
| REAR SPRING TO REAR AXLE HOUSING WITH DIFFERENTIAL | ||
| 870 | A 3443207029 | STOP |
| 880 | N 000963010025 | SCREW |
| STOP TO FRAME | ||
| 890 | N 000125010517 | WASHER |
| STOP TO FRAME | ||
| 900 | N 000934010005 | NUT |
| STOP TO FRAME | ||
