Transporto priemonė: L 1518 ,LS 1518; VIN numerio dalis: 345306
Grupė: 31 FRAME
| # | Kodas | Pavadinimas |
|---|---|---|
| 008 | A 3453109205 | FRAME |
| Repalced by: A 3453107196 | ||
| 008 | A 3453107196 | FRAME |
| 008 | A 3453104902 | FRAME |
| Repalced by: A 3453105302 | ||
| 008 | A 3453105302 | FRAME |
| 008 | A 3453109305 | FRAME |
| 008 | A 3453105002 | FRAME |
| 008 | A 3453109005 | FRAME |
| 008 | A 3453105102 | FRAME |
| 008 | A 3453105202 | FRAME |
| 008 | A 3453107196 | FRAME |
| 008 | A 3453105302 | FRAME |
| 008 | A 3453107296 | FRAME |
| 008 | A 3453105402 | FRAME |
| 008 | A 3453109505 | FRAME |
| 008 | A 3453106002 | FRAME |
| 008 | A 3453108096 | FRAME |
| Repalced by: A 3453107696 | ||
| 008 | A 3453107696 | FRAME |
| 008 | A 3453107396 | FRAME |
| Repalced by: A 3453107196 | ||
| 008 | A 3453107196 | FRAME |
| 008 | A 3453106102 | FRAME |
| 016 | A 3453100226 | ENGINE CROSS MEMBER |
| NO.1 | ||
| 016 | A 3453107626 | ENGINE CROSS MEMBER |
| NO.1 | ||
| 024 | A 3453100309 | BRACKET |
| WITH COUPLING MOUTH | ||
| 024 | A 3453100209 | BRACKET |
| WITH COUPLING MOUTH | ||
| 032 | N 000933010294 | SCREW |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| M 10X20 | ||
| 040 | N 000933010174 | SCREW |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| M 10X25 | ||
| 040 | N 000933010174 | SCREW |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| M 10X25 | ||
| 040 | N 000961012020 | SCREW |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| M 12X30 | ||
| 048 | A 3609900040 | WASHER |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| 056 | N 913004010004 | NUT |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| 056 | N 913004010004 | NUT |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| 056 | N 913004012003 | NUT |
| BRACKET WITH COUPLING MOUTH TO CROSS MEMBER | ||
| 064 | N 000933010174 | SCREW |
| CROSS MEMBER TO SIDE MEMBERS | ||
| M 10X25 | ||
| 064 | N 000933010129 | SCREW |
| CROSS MEMBER TO SIDE MEMBERS | ||
| M 10X30 | ||
| 072 | N 913004010004 | NUT |
| CROSS MEMBER TO SIDE MEMBERS | ||
| 080 | N 000961012154 | SCREW |
| CROSS MEMBER TO SIDE MEMBERS | ||
| M 12X28 | ||
| 088 | N 913004012003 | NUT |
| CROSS MEMBER TO SIDE MEMBERS | ||
| 096 | A 3603100028 | ENGINE CROSS MEMBER |
| NO.2 | ||
| 100 | A 3453127007 | ENGINE CROSS MEMBER |
| REAR | ||
| 104 | A 3603130008 | STAY |
| (ENGINE CROSS MEMBER),REAR | ||
| 105 | A 3763111051 | TRUSS |
| LEFT SIDE MEMBER | ||
| 105 | A 3763111151 | TRUSS |
| RIGHT SIDE MEMBER | ||
| 106 | A 3762427002 | SUPPORT |
| ENGINE REAR CROSS MEMBER TO SIDE MEMBERS | ||
| 107 | N 000961012171 | SCREW |
| CONSOLE TO SIDE MEMBER | ||
| 108 | N 000125013012 | WASHER |
| CONSOLE TO SIDE MEMBER | ||
| 109 | N 913004012003 | NUT |
| CONSOLE TO SIDE MEMBER | ||
| 110 | A 3453127084 | SHIM |
| CROSS MEMBER TO CONSOLE | ||
| 111 | N 000961012106 | SCREW |
| CROSS MEMBER TO CONSOLE | ||
| 111E | N 000125013012 | WASHER |
| CROSS MEMBER TO CONSOLE | ||
| 111K | N 913004012003 | NUT |
| CROSS MEMBER TO CONSOLE | ||
| 112 | A 3453127215 | CROSS MEMBER |
| NO.3 | ||
| 112 | A 3453127115 | CROSS MEMBER |
| NO.3 | ||
| 116 | A 3453120115 | CROSS MEMBER |
| 120 | A 3523120552 | ANGLE |
| 120 | A 3453128752 | ANGLE |
| 120 | A 3453128852 | ANGLE |
| 128 | A 3453120052 | ANGLE |
| LEFT | ||
| 128 | A 3453128452 | ANGLE |
| LEFT | ||
| 128 | A 3453120152 | ANGLE |
| RIGHT | ||
| 128 | A 3453128552 | ANGLE |
| RIGHT | ||
| 136 | A 3453127115 | CROSS MEMBER |
| NO.4 | ||
| 136 | A 3453127115 | CROSS MEMBER |
| NO.4,5 | ||
| 144 | A 3523120052 | ANGLE |
| TOP | ||
| 152 | A 3523120552 | ANGLE |
| BOTTOM | ||
| 152 | A 3453127552 | ANGLE |
| BOTTOM | ||
| 160 | A 3453127317 | CROSS MEMBER |
| NO.4 | ||
| 160 | A 3453127317 | CROSS MEMBER |
| NO.5 | ||
| 160 | A 3453127317 | CROSS MEMBER |
| NO.5,6 | ||
| 160 | A 3453127317 | CROSS MEMBER |
| NO.6,7 | ||
| 168 | A 3453127360 | REINFORCEMENT |
| IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: | ||
| 383 312 03 60 | ||
| 176 | N 000933010129 | SCREW |
| STAY TO CROSS MEMBER | ||
| M 10X30 | ||
| 184 | N 913004010006 | NUT |
| STAY TO CROSS MEMBER | ||
| 192 | A 3453127235 | CROSS MEMBER |
| (REAR CROSS MEMBER) | ||
| 200 | N 000963010025 | SCREW |
| ANGLE TO FRAME | ||
| 208 | N 913004010004 | NUT |
| ANGLE TO FRAME | ||
| 216 | A 3443120087 | GUSSET PLATE |
| RIGHT | ||
| 216 | A 3453127887 | GUSSET PLATE |
| RIGHT | ||
| 216 | A 3453127987 | GUSSET PLATE |
| LEFT | ||
| 216 | A 3443120187 | GUSSET PLATE |
| LEFT | ||
| 224 | A 3453127687 | GUSSET PLATE |
| BOTTOM LEFT | ||
| 224 | A 3453127487 | GUSSET PLATE |
| BOTTOM LEFT | ||
| 224 | A 3453127787 | GUSSET PLATE |
| BOTTOM RIGHT | ||
| 224 | A 3453127587 | GUSSET PLATE |
| 232 | N 000960012041 | SCREW |
| REINFORCEMENTS AND CROSS MEMBER TO SIDE MEMBERS | ||
| 232 | N 000961012106 | SCREW |
| REINFORCEMENTS AND CROSS MEMBER TO SIDE MEMBERS | ||
| 240 | N 000127012201 | LOCK WASHER |
| REINFORCEMENTS AND CROSS MEMBER TO SIDE MEMBERS | ||
| 248 | N 000934012004 | NUT |
| REINFORCEMENTS AND CROSS MEMBER TO SIDE MEMBERS | ||
| 248 | N 913004012003 | NUT |
| REINFORCEMENTS AND CROSS MEMBER TO SIDE MEMBERS | ||
| 256 | A 3453110053 | ANGLE |
| LEFT FRONT SPRING REAR BRACKET | ||
| 256 | A 3453110153 | ANGLE |
| RIGHT FRONT SPRING REAR BRACKET | ||
| 264 | A 3523220201 | FRONT SPRING BRACKET |
| FRONT AND REAR | ||
| 272 | A 3219901601 | SCREW |
| FRONT BRACKET TO SIDE MEMBER | ||
| 272 | A 3409900201 | SCREW |
| FRONT BRACKET TO SIDE MEMBER | ||
| 280 | N 000934014008 | NUT |
| FRONT BRACKET TO SIDE MEMBER | ||
| 288 | A 3603230663 | BEARING BRACKET |
| TORSION BAR TO SHACKLE | ||
| 296 | A 3523250101 | REAR SPRING BRACKET |
| FRONT AND REAR | ||
| A 3559900501 | SCREW | |
| REAR SPRING BRACKET TO SIDE MEMBER | ||
| N 000934014008 | NUT | |
| REAR SPRING BRACKET TO SIDE MEMBER | ||
| 304 | A 3523250041 | STIFFENING |
| 312 | A 3523250417 | HELPER SPRING BRACKET |
| HELPER SPRING | ||
| 320 | A 3453157206 | COUPLING PIN |
| COUPLING MOUTH | ||
| 328 | A 0008500095 | FASTENER |
| COUPLING PIN | ||
| 336 | A 3453100167 | BODY SUPPORT |
| CAB,LEFT | ||
| 336 | A 3453107163 | CONSOLE |
| CAB, RIGHT | ||
| 352 | A 3523170628 | REINFORCEMENT |
| CAB,LEFT | ||
| 352 | A 3523170728 | REINFORCEMENT |
| CAB, RIGHT | ||
| 360 | A 3453230095 | REINFORCEMENT |
| TOP BEARING BRACKET TO FRAME | ||
| 368 | N 910005010001 | RIVET |
| 10 X 24 MM | ||
| 368 | N 910005010002 | RIVET |
| 10 X 26 MM | ||
| 368 | N 910005010003 | RIVET |
| 10X 28 MM | ||
| 368 | N 910005010004 | RIVET |
| 10 X 30 MM | ||
| 368 | N 910005010005 | RIVET |
| 10X34 MM | ||
| 368 | N 910005010006 | RIVET |
| 10 X 36 MM | ||
| 368 | N 910005010004 | RIVET |
| 10X38 MM | ||
| 368 | N 910005012001 | RIVET |
| 12 X 28 MM | ||
| 368 | N 910005012002 | RIVET |
| 12 X 30 MM | ||
| 368 | N 910005012029 | RIVET |
| 12X32 MM | ||
| 368 | N 910005012003 | RIVET |
| 12 X 34 MM | ||
| 368 | N 910005012004 | RIVET |
| 12X36 MM | ||
| 368 | N 910005012021 | RIVET |
| 12 X 45 MM | ||
| 368 | N 910005014041 | RIVET |
| 14X32 MM | ||
| 368 | N 910005014059 | RIVET |
| 14 X 48 MM | ||
| 368 | N 910005014022 | RIVET |
| 14 X 50 MM | ||
| 376 | A 3443100367 | BODY SUPPORT |
| CAB,REAR LEFT AND RIGHT | ||
| 376 | A 3443107067 | BODY SUPPORT |
| CAB,REAR LEFT AND RIGHT | ||
| 384 | N 000933010129 | SCREW |
| CONSOLE TO SIDE MEMBER | ||
| M 10X28 | ||
| 384 | N 000933010269 | SCREW |
| CONSOLE TO SIDE MEMBER | ||
| M 10X35 | ||
| 392 | N 000125010517 | WASHER |
| CONSOLE TO SIDE MEMBER | ||
| 400 | N 000127010202 | LOCK WASHER |
| CONSOLE TO SIDE MEMBER | ||
| 408 | N 000934010000 | NUT |
| CONSOLE TO SIDE MEMBER | ||
| 416 | N 000961012154 | SCREW |
| CONSOLE TO SIDE MEMBER | ||
| M 12X30 | ||
| 416 | N 000961012106 | SCREW |
| CONSOLE TO SIDE MEMBER | ||
| M 12X35 | ||
| 424 | N 000125013012 | WASHER |
| CONSOLE TO SIDE MEMBER | ||
| 432 | N 000127012201 | LOCK WASHER |
| CONSOLE TO SIDE MEMBER | ||
| 440 | N 000934012013 | NUT |
| CONSOLE TO SIDE MEMBER | ||
| M12 X 1,5 MM | ||
| 448 | A 3523170240 | BRACKET |
| CAB SUSPENSION | ||
| 456 | A 3529900030 | SCREW |
| Repalced by: N 000000000011 | ||
| 456 | N 000000000011 | SCREW |
| SPRING BRACKET TO CAB CONSOLE | ||
| M10X25 | ||
| 464 | N 000125010517 | WASHER |
| SPRING BRACKET TO CAB CONSOLE | ||
| 472 | N 000127010202 | LOCK WASHER |
| SPRING BRACKET TO CAB CONSOLE | ||
| 480 | N 000934010000 | NUT |
| SPRING BRACKET TO CAB CONSOLE | ||
| 488 | A 3523130826 | BRACKET |
| LEFT | ||
| 488 | A 3523130926 | BRACKET |
| RIGHT | ||
| 496 | N 000933010174 | SCREW |
| BRACKET TO ENGINE FRONT CROSS MEMBER | ||
| 504 | N 913004010004 | NUT |
| BRACKET TO ENGINE FRONT CROSS MEMBER | ||
| 512 | A 3455200032 | STAY |
| LEFT | ||
| 512 | A 3455200132 | STAY |
| RIGHT | ||
| 520 | N 000933010129 | SCREW |
| 528 | N 913004010004 | NUT |
| STAY TO FRAME | ||
| 536 | A 3223100179 | SPRING |
| CAB | ||
| 544 | A 3223100279 | SPRING |
| NO.1 | ||
| 552 | A 0453100079 | SPRING |
| NO.4 | ||
| 560 | N 004626008103 | SPRING BOLT |
| 568 | N 000934008000 | NUT |
| 576 | A 0009883610 | RUBBER MOUNTING |
| 576 | A 3443177012 | RUBBER BUFFER |
| 584 | N 000960012385 | SCREW |
| SPRING TO CONSOLE | ||
| 592 | N 913004012003 | NUT |
| SPRING TO CONSOLE | ||
| 600 | A 3229910640 | SPACER TUBE |
| SPRING TO CONSOLE | ||
| 608 | A 3358910411 | PLATE |
| SPRING TO CAB | ||
| 616 | N 000127010202 | LOCK WASHER |
| SPRING TO CAB | ||
| 624 | N 000931010002 | SCREW |
| SPRING TO CAB | ||
| 632 | A 3448907019 | SHOCK ABSORBER |
| 632 | A 0008910805 | SHOCK ABSORBER |
| 632 | A 3448907119 | SHOCK ABSORBER |
| 640 | A 0003231450 | BUSHING |
| 648 | A 0083230144 | RUBBER BUFFER |
| 656 | N 000961012192 | SCREW |
| SHOCK ABSORBER TO CONSOLE | ||
| 664 | N 913004012003 | NUT |
| SHOCK ABSORBER TO CONSOLE | ||
| 672 | N 000961012192 | SCREW |
| SHOCK ABSORBER TO CAB | ||
| 680 | N 000127012201 | LOCK WASHER |
| SHOCK ABSORBER TO CAB | ||
| 688 | N 000934012004 | NUT |
| SHOCK ABSORBER TO CAB | ||
