Transporto priemonė: U 1850; VIN numerio dalis: 437114
Grupė: 49 EXHAUST SYSTEM
| # | Kodas | Pavadinimas |
|---|---|---|
| 005 | A 4374900319 | EXHAUST PIPE |
| FRONT | ||
| 008 | A 4364900019 | EXHAUST PIPE |
| FRONT | ||
| 008 | A 4364900119 | EXHAUST PIPE |
| FRONT | ||
| 011 | A 4374921301 | FRONT EXHAUST PIPE |
| CENTRAL | ||
| 011 | A 4374922001 | FRONT EXHAUST PIPE |
| CENTRAL | ||
| 014 | A 4374922301 | FRONT EXHAUST PIPE |
| CENTRAL | ||
| 017 | A 4374900301 | EXHAUST MUFFLER |
| 020 | A 4354900901 | EXHAUST MUFFLER |
| 023 | A 4374900840 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 026 | A 4254900140 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 032 | A 4374900530 | PROTECTIVE PLATE |
| SCREENING PLATE | ||
| 080 | A 4374921004 | REAR EXHAUST PIPE |
| 086 | A 4374921401 | FRONT EXHAUST PIPE |
| 092 | A 4374921314 | END PIECE |
| (TAIL PIPE) | ||
| 092 | A 4374920214 | END PIECE |
| Repalced by: A 4364920401 | ||
| 092 | A 4364920401 | REAR EXHAUST PIPE |
| (TAIL PIPE) | ||
| 095 | A 4374921741 | BRACKET |
| TAIL PIPE TO TANK CONSOLE | ||
| 098 | A 4374924341 | BRACKET |
| EXHAUST PIPE TO FRAME | ||
| 101 | N 000961016142 | SCREW |
| BRACKET TO FRAME | ||
| M16X1,5X30 | ||
| 104 | N 071555090502 | CLAMP |
| TAIL PIPE | ||
| 107 | A 4374930143 | CLAMP |
| Repalced by: A 3034930643 | ||
| 107 | A 3034930643 | CLAMP |
| EXHAUST PIPE TO BRACKET | ||
| 107 | A 3034930643 | CLAMP |
| MUFFLER TO BRACKET | ||
| 110 | N 910105010006 | SCREW |
| MUFFLER TO BRACKET | ||
| M 10X20 | ||
| 113 | N 910105010009 | SCREW |
| 113 | A 0019908204 | SCREW |
| Repalced by: N 910105010009 | ||
| 113 | N 910105010009 | SCREW |
| MUFFLER TO BRACKET | ||
| 116 | N 910105010001 | HEXAGON HEAD BOLT |
| EXHAUST PIPE TO BRACKET | ||
| M10X30 | ||
| 116 | N 910105010001 | HEXAGON HEAD BOLT |
| MUFFLER TO BRACKET | ||
| 119 | N 913023010003 | NUT |
| TAIL PIPE TO EXHAUST MUFFLER AND TO BRACKET | ||
| 119 | N 913023010003 | NUT |
| MUFFLER TO BRACKET | ||
| 119 | N 913023010003 | NUT |
| EXHAUST PIPE TO BRACKET | ||
| 122 | N 000125010532 | WASHER |
| MUFFLER TO BRACKET | ||
| 122 | N 000125010532 | WASHER |
| EXHAUST PIPE TO BRACKET | ||
| 125 | A 4374900542 | STRAP |
| EXHAUST MUFFLER TO BRACKET | ||
| 128 | N 308673012001 | NUT |
| EXHAUST MUFFLER TO BRACKET | ||
| 137 | N 910105010009 | SCREW |
| 140 | N 913023010003 | NUT |
| CENTRAL EXHAUST PIPE TO EXHAUST MUFFLER | ||
| 142 | A 4374920121 | STRAP |
| EXHAUST MUFFLER TO FRAME | ||
| A 4374901540 | BRACKET | |
| Repalced by: A 4374902140 | ||
| A 4374902140 | BRACKET | |
| EXHAUST MUFFLER TO FRAME | ||
| 146 | A 4374902140 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 146 | A 4374902140 | BRACKET |
| FRONT | ||
| 149 | A 4374923441 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 152 | A 4374902040 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 152 | A 4374902040 | BRACKET |
| REAR | ||
| 155 | A 4374901640 | BRACKET |
| Repalced by: A 4374902740 | ||
| 155 | A 4374902740 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| A 4374900040 | BRACKET | |
| CENTRAL EXHAUST PIPE AND MUFFLER TO FRAME | ||
| 170 | A 4274900540 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 173 | A 4374924241 | BRACKET |
| EXHAUST MUFFLER TO FRAME | ||
| 176 | N 000000000428 | HEXAGON HEAD BOLT |
| BRACKET TO FRAME | ||
| M10X35 | ||
| 179 | N 910105010009 | SCREW |
| 182 | N 000125010532 | WASHER |
| BRACKET TO FRAME | ||
| 185 | N 913023010003 | NUT |
| BRACKET TO FRAME | ||
| 204 | N 910105012023 | SCREW |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| M 12X45 | ||
| 204 | N 304017012015 | SCREW |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| M 12X80 | ||
| 204 | N 304017012015 | SCREW |
| 207 | N 999901012000 | NUT |
| EXHAUST PIPE TO EXHAUST MANIFOLD | ||
| 210 | A 4374920050 | BUSHING |
| BRACKET TO REINFORCEMENT | ||
| 213 | N 910105010016 | SCREW |
| BRACKET TO REINFORCEMENT | ||
| M 10X80 | ||
| N 910105010006 | SCREW | |
| EXHAUST MUFFLER TO BRACKET | ||
| M10X20 | ||
| 218 | N 000933010200 | SCREW |
| BRACKET TO REINFORCEMENT | ||
| M 10X30 | ||
| 218 | N 910105010001 | HEXAGON HEAD BOLT |
| BRACKET TO REINFORCEMENT | ||
| M10X30 | ||
| 218 | N 910105010001 | HEXAGON HEAD BOLT |
| BRACKET TO BRACKET | ||
| 221 | N 913023010003 | NUT |
| BRACKET TO BRACKET | ||
| 221 | N 913023010003 | NUT |
| BRACKET TO REINFORCEMENT | ||
| 221 | N 913023010003 | NUT |
| BRACKET TO BRACKET | ||
| 223 | N 000125010532 | WASHER |
| BRACKET TO BRACKET | ||
| N 000000000428 | HEXAGON HEAD BOLT | |
| BRACKET TO BRACKET | ||
| M10X35 | ||
| A 4374900730 | PROTECTIVE PLATE | |
| 226 | A 4374900930 | PROTECTIVE PLATE |
| 229 | N 910105008008 | SCREW |
| PROTECTIVE PLATE TO BRACKET | ||
| M 8X16 | ||
| 229 | N 910105008004 | SCREW |
| PROTECTIVE PLATE TO BRACKET | ||
| M 8X20 | ||
| 243 | N 913023008002 | NUT |
| PROTECTIVE PLATE TO BRACKET | ||
| 246 | N 000125008443 | WASHER |
| PROTECTIVE PLATE TO BRACKET | ||
| 249 | A 4374900430 | PROTECTIVE PLATE |
| PLASTIC PIPING | ||
| 249 | A 4355200237 | PROTECTIVE PLATE |
| Repalced by: A 4355200375 | ||
| 249 | A 4355200375 | PANELLING |
| PLASTIC PIPING | ||
| 252 | N 304017008016 | SCREW |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| M 8X16 | ||
| 252 | N 910105008004 | SCREW |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| M 8X20 | ||
| 253 | N 914007008084 | SCREW-AND-WASHER ASSEMBLY |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| M8X16 | ||
| 255 | N 000125008443 | WASHER |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| 258 | N 007349008007 | WASHER |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| 261 | N 913023008002 | NUT |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| 267 | N 910105006023 | SCREW |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| M 6X16 | ||
| 270 | N 000125006421 | WASHER |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| Repalced by: N 000125006449 | ||
| 270 | N 000125006449 | WASHER |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| 273 | A 0009902150 | NUT |
| PROTECTIVE PLATE TO SIDE MEMBER | ||
| 275 | A 4374920830 | PROTECTIVE PLATE |
| 277 | N 304017006018 | SCREW |
| HEAT SHIELD | ||
| M 6X12 | ||
| 278 | N 000125006421 | WASHER |
| HEAT SHIELD | ||
| Repalced by: N 000125006449 | ||
| 278 | N 000125006449 | WASHER |
| HEAT SHIELD | ||
| 279 | N 304017008021 | SCREW |
| M 8X20 | ||
| 280 | N 000125008443 | WASHER |
| 281 | N 913023008002 | NUT |
| 282 | A 4374900330 | PROTECTIVE PLATE |
| 283 | N 910105010006 | SCREW |
| HEAT SHIELD TO MUFFLER | ||
| M 10X20 | ||
| 284 | N 000125010532 | WASHER |
| HEAT SHIELD TO MUFFLER | ||
